インバースキネマティクス基礎（2）

/**
 * Copyright _wonder ( http://wonderfl.net/user/_wonder )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/tBzH
 */

// forked from _wonder's インバースキネマティクス基礎
// forked from _wonder's フォワードキネマティクス基礎
package {
    import flash.display.Sprite;
    import flash.events.Event;

    public class SingleSegment extends Sprite {
    		private var segments:Array;
    		private var numSegments:uint = 6;

        public function SingleSegment() {
            init();
        }

        private function init():void {
        		segments = new Array();
        		for( var i:uint = 0; i < numSegments; i++ ){
        			var segment:Segment = new Segment(50, 10);
        			addChild( segment );
        			segments.push( segment );
        		}

        		addEventListener(Event.ENTER_FRAME, onEnterFrame);
        }

        private function onEnterFrame(e:Event):void {
        		drag(segments[0], mouseX, mouseY);
        		for( var i:uint = 1; i < numSegments; i++ ){
        			var segmentA:Segment = segments[i];
        			var segmentB:Segment = segments[i - 1];
        			drag(segmentA, segmentB.x, segmentB.y);
        		}
        }

        private function drag(segment:Segment, xpos:Number, ypos:Number):void {
        		var dx:Number = xpos - segment.x;
        		var dy:Number = ypos - segment.y;
        		var angle:Number = Math.atan2( dy, dx );
        		segment.rotation = angle * 180 / Math.PI;

        		var w:Number = segment.getPin().x - segment.x;
        		var h:Number = segment.getPin().y - segment.y;
        		segment.x = xpos - w;
        		segment.y = ypos - h;
        }
    }
}

import flash.display.Sprite;
import flash.geom.Point;

class Segment extends Sprite {
	private var color:uint;
	private var segmentWidth:Number;
	private var segmentHeight:Number;

	public var vx:Number = 0;
	public var vy:Number = 0;

	public function Segment(segmentWidth:Number,segmentHeight:Number,color:uint=0xffffff){
		this.segmentWidth = segmentWidth;
		this.segmentHeight = segmentHeight;
		this.color = color;
		init();
	}

	public function init():void {
		//セグメントの描画
		graphics.lineStyle( 0 );
		graphics.beginFill( color );
		graphics.drawRoundRect( -segmentHeight / 2, -segmentHeight / 2, segmentWidth+segmentHeight, segmentHeight, segmentHeight, segmentHeight );
		graphics.endFill();

		//ピン
		graphics.drawCircle( 0, 0, 2 );
		graphics.drawCircle( segmentWidth, 0, 2 );
	}

	public function getPin():Point {
		var angle:Number = rotation * Math.PI / 180;
		var xPos:Number = x + Math.cos( angle ) * segmentWidth;
		var yPos:Number = y + Math.sin( angle ) * segmentWidth;
		return new Point( xPos, yPos );
	}
}

import flash.display.Sprite;
import flash.events.MouseEvent;
import flash.geom.Rectangle;
import flash.events.Event;

class SimpleSlider extends Sprite
	{
		private var _width:Number = 16;
		private var _height:Number = 100;
		private var _value:Number;
		private var _max:Number = 100;
		private var _min:Number = 0;
		private var _handle:Sprite;
		private var _back:Sprite;
		private var _backWidth:Number = 4;
		private var _handleHeight:Number = 6;
		private var _backColor:uint = 0xcccccc;
		private var _backBorderColor:uint = 0x999999;
		private var _handleColor:uint = 0xeeeeee;
		private var _handleBorderColor:uint = 0xcccccc;
		private var _handleRadius:Number = 2;
		private var _backRadius:Number = 2;

		public function SimpleSlider(min:Number=0, max:Number=100, value:Number=100)
		{
			_min = min;
			_max = max;
			_value = Math.min(Math.max(value, min), max)
			init();
		}

		private function init():void
		{
			_back = new Sprite();
			addChild(_back);

			_handle = new Sprite();
			addChild(_handle);
			_handle.addEventListener(MouseEvent.MOUSE_DOWN, onMouseDown);

			draw();
			updatePosition();
		}

		private function draw():void
		{
			drawBack();
			drawHandle();
		}

		private function drawBack():void
		{
			_back.graphics.clear();
			_back.graphics.beginFill(_backColor);
			_back.graphics.lineStyle(0, _backBorderColor);
			_back.graphics.drawRoundRect(0, 0, _backWidth, _height, _backRadius, _backRadius);
			_back.graphics.endFill();
			_back.x = _width / 2 - _backWidth / 2;
		}

		private function drawHandle():void
		{
			_handle.graphics.clear();
			_handle.graphics.beginFill(_handleColor);
			_handle.graphics.lineStyle(0, _handleBorderColor);
			_handle.graphics.drawRoundRect(0, 0, _width, _handleHeight, _handleRadius, _handleRadius);
			_handle.graphics.endFill();
		}

		private function updatePosition():void
		{
			var handleRange:Number = _height - _handleHeight;
			var valueRange:Number = _max - _min;
			_handle.y = handleRange - (_value - _min) / valueRange * handleRange;
		}

		private function updateValue():void
		{
			var handleRange:Number = _height - _handleHeight;
			var valueRange:Number = _max - _min;
			_value = (handleRange - _handle.y) / handleRange * valueRange + _min;
			dispatchEvent(new Event(Event.CHANGE));
		}

		private function onMouseUp(event:MouseEvent):void
		{
			stage.removeEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
			stage.removeEventListener(MouseEvent.MOUSE_UP, onMouseUp);
			_handle.stopDrag();
		}

		private function onMouseDown(event:MouseEvent):void
		{
			stage.addEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
			stage.addEventListener(MouseEvent.MOUSE_UP, onMouseUp);
			_handle.startDrag(false, new Rectangle(0, 0, 0, _height - _handleHeight));
		}

		private function onMouseMove(event:MouseEvent):void
		{
			updateValue();
		}



		public function invalidate():void
		{
			draw();
		}

		public function move(x:Number, y:Number):void
		{
			this.x = x;
			this.y = y;
		}

		public function setSize(w:Number, h:Number):void
		{
			_width = w;
			_height = h;
			draw();
		}






		public function set backBorderColor(n:uint):void
		{
			_backBorderColor = n;
			draw();
		}
		public function get backBorderColor():uint
		{
			return _backBorderColor;
		}

		public function set backColor(n:uint):void
		{
			_backColor = n;
			draw();
		}
		public function get backColor():uint
		{
			return _backColor;
		}

		public function set backRadius(n:Number):void
		{
			_backRadius = n;
		}
		public function get backRadius():Number
		{
			return _backRadius;
		}

		public function set backWidth(n:Number):void
		{
			_backWidth = n;
			draw();
		}
		public function get backWidth():Number
		{
			return _backWidth;
		}

		public function set handleBorderColor(n:uint):void
		{
			_handleBorderColor = n;
			draw();
		}
		public function get handleBorderColor():uint
		{
			return _handleBorderColor;
		}

		public function set handleColor(n:uint):void
		{
			_handleColor = n;
			draw();
		}
		public function get handleColor():uint
		{
			return _handleColor;
		}

		public function set handleRadius(n:Number):void
		{
			_handleRadius = n;
			draw();
		}
		public function get handleRadius():Number
		{
			return _handleRadius;
		}

		public function set handleHeight(n:Number):void
		{
			_handleHeight = n;
			draw();
			updatePosition();
		}
		public function get handleHeight():Number
		{
			return _handleHeight;
		}

		override public function set height(n:Number):void
		{
			_height = n;
			draw();
		}
		override public function get height():Number
		{
			return _height;
		}

		public function set max(n:Number):void
		{
			_max = n;
			updatePosition();
		}
		public function get max():Number
		{
			return _max;
		}

		public function set min(n:Number):void
		{
			_min = n;
			updatePosition();
		}
		public function get min():Number
		{
			return _min;
		}

		public function set value(n:Number):void
		{
			_value = n;
			_value = Math.min(_max, Math.max(_value, _min));
			updatePosition();
		}
		public function get value():Number
		{
			return _value;
		}

		override public function set width(n:Number):void
		{
			_width = n;
			draw();
		}
		override public function get width():Number
		{
			return _width;
		}
	}
