インバースキネマティクス基礎

/**
 * Copyright _wonder ( http://wonderfl.net/user/_wonder )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/6RjF
 */

// forked from _wonder's フォワードキネマティクス基礎
package {
    import flash.display.Sprite;
    import flash.events.Event;

    public class SingleSegment extends Sprite {
            private var segment0:Segment;

        public function SingleSegment() {
            init();
        }

        private function init():void {
                segment0 = new Segment(100, 20);
                addChild( segment0 );
                segment0.x = stage.stageWidth / 2;
                segment0.y = stage.stageHeight / 2;

                addEventListener(Event.ENTER_FRAME, onEnterFrame);
        }

        private function onEnterFrame(e:Event):void {
                var dx:Number = mouseX - segment0.x;
                var dy:Number = mouseY - segment0.y;
                var angle:Number = Math.atan2( dy, dx );
                segment0.rotation = angle * 180 / Math.PI;

                var w:Number = segment0.getPin().x - segment0.x;
                var h:Number = segment0.getPin().y - segment0.y;
                segment0.x = mouseX - w;
                segment0.y = mouseY - h;
        }
    }
}

import flash.display.Sprite;
import flash.geom.Point;

class Segment extends Sprite {
    private var color:uint;
    private var segmentWidth:Number;
    private var segmentHeight:Number;

    public var vx:Number = 0;
    public var vy:Number = 0;

    public function Segment(segmentWidth:Number,segmentHeight:Number,color:uint=0xffffff){
        this.segmentWidth = segmentWidth;
        this.segmentHeight = segmentHeight;
        this.color = color;
        init();
    }

    public function init():void {
        //セグメントの描画
        graphics.lineStyle( 0 );
        graphics.beginFill( color );
        graphics.drawRoundRect( -segmentHeight / 2, -segmentHeight / 2, segmentWidth+segmentHeight, segmentHeight, segmentHeight, segmentHeight );
        graphics.endFill();

        //ピン
        graphics.drawCircle( 0, 0, 2 );
        graphics.drawCircle( segmentWidth, 0, 2 );
    }

    public function getPin():Point {
        var angle:Number = rotation * Math.PI / 180;
        var xPos:Number = x + Math.cos( angle ) * segmentWidth;
        var yPos:Number = y + Math.sin( angle ) * segmentWidth;
        return new Point( xPos, yPos );
    }
}

import flash.display.Sprite;
import flash.events.MouseEvent;
import flash.geom.Rectangle;
import flash.events.Event;

class SimpleSlider extends Sprite
    {
        private var _width:Number = 16;
        private var _height:Number = 100;
        private var _value:Number;
        private var _max:Number = 100;
        private var _min:Number = 0;
        private var _handle:Sprite;
        private var _back:Sprite;
        private var _backWidth:Number = 4;
        private var _handleHeight:Number = 6;
        private var _backColor:uint = 0xcccccc;
        private var _backBorderColor:uint = 0x999999;
        private var _handleColor:uint = 0xeeeeee;
        private var _handleBorderColor:uint = 0xcccccc;
        private var _handleRadius:Number = 2;
        private var _backRadius:Number = 2;

        public function SimpleSlider(min:Number=0, max:Number=100, value:Number=100)
        {
            _min = min;
            _max = max;
            _value = Math.min(Math.max(value, min), max)
            init();
        }

        private function init():void
        {
            _back = new Sprite();
            addChild(_back);

            _handle = new Sprite();
            addChild(_handle);
            _handle.addEventListener(MouseEvent.MOUSE_DOWN, onMouseDown);

            draw();
            updatePosition();
        }

        private function draw():void
        {
            drawBack();
            drawHandle();
        }

        private function drawBack():void
        {
            _back.graphics.clear();
            _back.graphics.beginFill(_backColor);
            _back.graphics.lineStyle(0, _backBorderColor);
            _back.graphics.drawRoundRect(0, 0, _backWidth, _height, _backRadius, _backRadius);
            _back.graphics.endFill();
            _back.x = _width / 2 - _backWidth / 2;
        }

        private function drawHandle():void
        {
            _handle.graphics.clear();
            _handle.graphics.beginFill(_handleColor);
            _handle.graphics.lineStyle(0, _handleBorderColor);
            _handle.graphics.drawRoundRect(0, 0, _width, _handleHeight, _handleRadius, _handleRadius);
            _handle.graphics.endFill();
        }

        private function updatePosition():void
        {
            var handleRange:Number = _height - _handleHeight;
            var valueRange:Number = _max - _min;
            _handle.y = handleRange - (_value - _min) / valueRange * handleRange;
        }

        private function updateValue():void
        {
            var handleRange:Number = _height - _handleHeight;
            var valueRange:Number = _max - _min;
            _value = (handleRange - _handle.y) / handleRange * valueRange + _min;
            dispatchEvent(new Event(Event.CHANGE));
        }

        private function onMouseUp(event:MouseEvent):void
        {
            stage.removeEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
            stage.removeEventListener(MouseEvent.MOUSE_UP, onMouseUp);
            _handle.stopDrag();
        }

        private function onMouseDown(event:MouseEvent):void
        {
            stage.addEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
            stage.addEventListener(MouseEvent.MOUSE_UP, onMouseUp);
            _handle.startDrag(false, new Rectangle(0, 0, 0, _height - _handleHeight));
        }

        private function onMouseMove(event:MouseEvent):void
        {
            updateValue();
        }



        public function invalidate():void
        {
            draw();
        }

        public function move(x:Number, y:Number):void
        {
            this.x = x;
            this.y = y;
        }

        public function setSize(w:Number, h:Number):void
        {
            _width = w;
            _height = h;
            draw();
        }






        public function set backBorderColor(n:uint):void
        {
            _backBorderColor = n;
            draw();
        }
        public function get backBorderColor():uint
        {
            return _backBorderColor;
        }

        public function set backColor(n:uint):void
        {
            _backColor = n;
            draw();
        }
        public function get backColor():uint
        {
            return _backColor;
        }

        public function set backRadius(n:Number):void
        {
            _backRadius = n;
        }
        public function get backRadius():Number
        {
            return _backRadius;
        }

        public function set backWidth(n:Number):void
        {
            _backWidth = n;
            draw();
        }
        public function get backWidth():Number
        {
            return _backWidth;
        }

        public function set handleBorderColor(n:uint):void
        {
            _handleBorderColor = n;
            draw();
        }
        public function get handleBorderColor():uint
        {
            return _handleBorderColor;
        }

        public function set handleColor(n:uint):void
        {
            _handleColor = n;
            draw();
        }
        public function get handleColor():uint
        {
            return _handleColor;
        }

        public function set handleRadius(n:Number):void
        {
            _handleRadius = n;
            draw();
        }
        public function get handleRadius():Number
        {
            return _handleRadius;
        }

        public function set handleHeight(n:Number):void
        {
            _handleHeight = n;
            draw();
            updatePosition();
        }
        public function get handleHeight():Number
        {
            return _handleHeight;
        }

        override public function set height(n:Number):void
        {
            _height = n;
            draw();
        }
        override public function get height():Number
        {
            return _height;
        }

        public function set max(n:Number):void
        {
            _max = n;
            updatePosition();
        }
        public function get max():Number
        {
            return _max;
        }

        public function set min(n:Number):void
        {
            _min = n;
            updatePosition();
        }
        public function get min():Number
        {
            return _min;
        }

        public function set value(n:Number):void
        {
            _value = n;
            _value = Math.min(_max, Math.max(_value, _min));
            updatePosition();
        }
        public function get value():Number
        {
            return _value;
        }

        override public function set width(n:Number):void
        {
            _width = n;
            draw();
        }
        override public function get width():Number
        {
            return _width;
        }
    }
