forked from: Iosmetric projection

/**
 * Copyright hacker_mx_95scj ( http://wonderfl.net/user/hacker_mx_95scj )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/yz4j
 */

// forked from mtok's Iosmetric projection
package
{
    import flash.display.Sprite;
    import flash.events.Event;
    import flash.display.StageAlign;
    import flash.display.StageScaleMode;
    import flash.geom.Point;
    import flash.display.Graphics;
    /**
     * ...
     * @author Motoki Matsumoto
     */
    public class TileTest extends Sprite
    {

        public function TileTest()
        {
            addEventListener(Event.ADDED_TO_STAGE, addedToStageHandler);
        }

        private function addedToStageHandler(e:Event):void
        {
            removeEventListener(Event.ADDED_TO_STAGE, addedToStageHandler);

            init();
        }

        private function init():void
        {
            stage.align = StageAlign.TOP_LEFT;
            stage.scaleMode = StageScaleMode.NO_SCALE;

            var world:Sprite = new Sprite();
            addChild(world);
            world.x = stage.stageWidth * 0.5;
            world.y = 100;

            for ( var i:int = 0; i < 10; i++) {
                for ( var j:int = 0; j < 10; j++) {
                    var tile:DrawnIsoTile = new DrawnIsoTile(20, 0xcccccc);
                    tile.position = new Point3D(i * 20, 0, j * 20);
                    world.addChild(tile);
                }
            }
        }

    }
}

import flash.display.GradientType;
import flash.display.Sprite;
import flash.geom.Point;
import flash.geom.Rectangle;
import flash.display.Graphics;

class IsoUtils {
    public static const Y_CORRECT:Number = Math.cos( -Math.PI / 6) * Math.SQRT2;
    public static function isoToScreen(pos:Point3D):Point {
        var screenX:Number = pos.x - pos.z;
        var screenY:Number = pos.y * Y_CORRECT + (pos.x + pos.z) * 0.5;

        return new Point(screenX, screenY);
    }
    public static function screenToIso(point:Point):Point3D {
        var xpos:Number = point.y + point.x * 0.5;
        var ypos:Number = 0;
        var zpos:Number = point.y - point.x * 0.5;
        return new Point3D(xpos, ypos, zpos);
    }
}
class Point3D {
    public var x:Number;
    public var y:Number;
    public var z:Number;
    public function Point3D(x:Number = 0, y:Number = 0, z:Number = 0) {
        this.x = x;
        this.y = y;
        this.z = z;
    }
}

class IsoObject extends Sprite {
    protected var _position:Point3D;
    protected var _size:Number;
    protected var _walkable:Boolean = false;

    public static const Y_CORRECT:Number = Math.cos( -Math.PI / 6) * Math.SQRT2;

    public function IsoObject(size:Number) {
        _size = size;
        _position = new Point3D();
        updateScreenPosition();
    }

    protected function updateScreenPosition():void
    {
        var screenPos:Point = IsoUtils.isoToScreen(_position);
        super.x = screenPos.x;
        super.y = screenPos.y;
    }

    override public function get x():Number { return _position.x; }
    override public function set x(value:Number):void
    {
        _position.x = value;
        updateScreenPosition();
    }

    override public function get y():Number { return _position.y; }
    override public function set y(value:Number):void
    {
        _position.y = value;
        updateScreenPosition();
    }
    override public function set z(value:Number):void {
        _position.z = value;
        updateScreenPosition();
    }
    override public function get z():Number {
        return _position.z;
    }
    public function get position():Point3D {
        return _position;
    }
    public function set position(value:Point3D):void {
        _position = value;
        updateScreenPosition();
    }
    public function get depth():Number {
        return (_position.x + _position.z) * 0.866 - _position.y * 0.707;
    }

    public function get walkable():Boolean { return _walkable; }

    public function set walkable(value:Boolean):void
    {
        _walkable = value;
    }

    public function get size():Number { return _size; }

    public function get rect():Rectangle {
        return new Rectangle(x - size / 2, z - size / 2, size, size);
    }

}

class DrawnIsoTile extends IsoObject {
    protected var _height:Number;
    protected var _color:uint;

    public function DrawnIsoTile(size:Number, color:uint, height:Number = 0) {
        super(size);
        _color = color;
        _height = height;
        draw();
    }

    private function draw():void
    {
        var g:Graphics = graphics;

        g.clear();
        g.lineStyle(0, 0, 0.5);
        g.beginFill(_color);
        g.moveTo( -size, 0);
        g.lineTo(0, -size * 0.5);
        g.lineTo(size, 0);
        g.lineTo(0, size * 0.5);
        g.lineTo( -size, 0);
        g.endFill();
    }

    override public function get height():Number { return _height; }
    override public function set height(value:Number):void
    {
        _height = value;
        draw();
    }

    public function get color():uint { return _color; }
    public function set color(value:uint):void
    {
        _color = value;
    }
}
