* Copyright Glidias ( http://wonderfl.net/user/Glidias )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/x3eo
*/
package {
//import alternterrainxtras.msa.MathUtils;
//import alternterrainxtras.msa.Perlin;
//import alternterrainxtras.msa.Smoothing;
import com.bit101.components.NumericStepper;
import com.bit101.components.VBox;
//import de.polygonal.math.PM_PRNG;
import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.display.DisplayObject;
import flash.display.Graphics;
import flash.display.GraphicsPath;
import flash.display.GraphicsPathWinding;
import flash.display.IGraphicsData;
import flash.display.Loader;
import flash.display.Sprite;
import flash.events.Event;
import flash.events.IEventDispatcher;
import flash.events.KeyboardEvent;
import flash.events.MouseEvent;
import flash.geom.Rectangle;
import flash.net.URLRequest;
import flash.system.LoaderContext;
import flash.text.TextField;
import flash.ui.Keyboard;
import flash.utils.Dictionary;
//import terraingen.island.mapgen2;
[SWF(width = "465", height = "465", frameRate = "30", backgroundColor = "#ffffff")]
public class WonderFLIsles extends Sprite
{
public static var LATE_LEAF:Boolean = false;
public var THRESHOLD:Number = LATE_LEAF ? .35 : .15;
public var COLOR_THRESHOLD:uint = 168;
private var fillRectangleArray:Array;
private var image:Bitmap;
private var imageData:BitmapData;
private var _canvas:Sprite;
public var seed:uint;
private var locField:TextField;
private var stepperX:NumericStepper;
private var stepperY:NumericStepper;
private var rootNode:KDNode;
private var prng:PM_PRNG;
private var seededNodeDict:Dictionary = new Dictionary();
private const OFFSETS:Vector.<int> = createOffsetTable();
private static function createOffsetTable():Vector.<int> {
var vec:Vector.<int> = new Vector.<int>(8, true);
var len:int = vec.length;
var count:int = 0;
for (var i:int = 1; i < len; i++) {
var totalPerLevel:int = (1 << (i-1));
totalPerLevel *= totalPerLevel;
vec[i] = count += totalPerLevel;
}
return vec;
}
public function WonderFLIsles():void
{
prng = new PM_PRNG();
loadComplete();
init();
if (stage) {
initStage();
}
else addEventListener(Event.ADDED_TO_STAGE, initStage);
}
private function initStage(e:Event=null):void
{
if (e != null) (e.currentTarget as IEventDispatcher).removeEventListener(e.type, initStage);
stage.addEventListener(KeyboardEvent.KEY_DOWN, onKeyDown, false, 0, true);
locField = new TextField();
locField.autoSize = "left";
locField.y = 64;
locField.multiline = true;
locField.height = 32;
addChild(locField);
var length:int = Math.sqrt(PM_PRNG.MAX);
vBox = new VBox(this, 0, 100);
stepperX = new NumericStepper(vBox, 0, 0, onStepperChange);
stepperY = new NumericStepper(vBox, 0, 0, onStepperChange);
stepperX.minimum = -length * .5;
stepperY.minimum = -length * .5;
stepperX.maximum = length * .5;
stepperY.maximum = length * .5;
updateLocField();
hitAreas = new Sprite();
hitAreas.addEventListener(MouseEvent.CLICK, onHitAreaClick);
hitAreas.x = _canvas.x;
hitAreas.y = _canvas.y;
cont.addChild(hitAreas);
renderTree();
}
private var foundLevel:int;
private function findNode(x:Number, y:Number):KDNode {
si = 1;
var curLevel:int;
searchStack[0] = rootNode;
searchStackLevels[0] = 0;
var node:KDNode = null;
while (si > 0) {
node = searchStack[--si];
curLevel = searchStackLevels[si];
if ( (node.flags & 1) && !(x < node.boundMinX || x > node.boundMaxX || y < node.boundMinY || y > node.boundMaxY) ) {
foundLevel = curLevel;
return node;
}
if (node.positive && (node.flags & KDNode.FLAG_SLAVE) == 0) {
searchStack[si] = node.positive;
searchStackLevels[si] = curLevel + (node.splitDownLevel() ? 1 : 0);
si++;
}
if (node.negative) {
searchStack[si] = node.negative;
searchStackLevels[si] = curLevel + (node.splitDownLevel() ? 1 : 0);
si++;
}
}
return null;
}
private function onHitAreaClick(e:MouseEvent):void
{
var node:KDNode = findNode(e.localX, e.localY);
if (node == null) return;
_canvas.graphics.beginFill(0x0000CC, 1);
_canvas.graphics.drawRect(node.boundMinX, node.boundMinY, (node.boundMaxX - node.boundMinX), (node.boundMaxY - node.boundMinY));
if (node.isSeeded()) {
if (_mapGen && _mapGen.parent) {
removeChild(_mapGen);
}
vBox.mouseChildren = false;
vBox.alpha = .5;
hitAreas.mouseChildren = false;
hitAreas.mouseEnabled = false;
mapgen2.PREVIEW_SIZE = getShortSide(foundLevel);
mapgen2.SIZE = 1024;
mapgen2.islandSeedInitial = node.seed+"-1";
_mapGen = new mapgen2();
//_mapGen.visible = false;
_mapGen.mouseChildren = false;
_mapGen.mouseEnabled = false;
_mapGen.addEventListener(mapgen2.COMPLETED, onMapGenCompleted);
addChild(_mapGen);
_mapGen.x = node.boundMinX + (node.isRectangle() === 1 ? node.offset : 0);
_mapGen.y = node.boundMinY + (node.isRectangle() === 2 ? node.offset : 0);
_mapGen.scaleX = .25;
_mapGen.scaleY = .25;
}
}
private function onMapGenCompleted(e:Event):void
{
_mapGen.removeEventListener(e.type, onMapGenCompleted);
var scaler:Number = 4;
var child:Bitmap = hitAreas.addChild( _mapGen.getPreviewBmp(mapgen2.PREVIEW_SIZE * scaler) ) as Bitmap;
previewBmps.push( child.bitmapData);
child.x = _mapGen.x;
child.y = _mapGen.y;
child.scaleX = 1/scaler;
child.scaleY = 1/scaler;
removeChild(_mapGen);
vBox.alpha = 1;
vBox.mouseChildren = true;
hitAreas.mouseChildren = true;
hitAreas.mouseEnabled = true;
_mapGen = null;
}
private var _mapGen:mapgen2;
private function onStepperChange(e:Event):void
{
if (e.currentTarget === stepperX) {
init(stepperX.value, ty);
}
else {
init(tx, stepperY.value);
}
updateLocField();
}
private function onKeyDown(e:KeyboardEvent):void
{
if (!vBox.mouseChildren) return;
var kc:uint = e.keyCode;
if (kc === Keyboard.UP ) {
init(tx, ty - 1);
updateLocField();
}
else if (kc === Keyboard.DOWN) {
init(tx, ty + 1);
updateLocField();
}
else if (kc === Keyboard.LEFT) {
init(tx - 1, ty);
updateLocField();
}
else if (kc === Keyboard.RIGHT) {
init(tx + 1, ty);
updateLocField();
}
}
private function updateLocField():void
{
locField.text = "(" + tx + ", " + ty + ")\n"+seed;
stepperX.value = tx;
stepperY.value = ty;
}
public function init(setX:Number = 0, setY:Number=0 ):void
{
seededNodeDict = new Dictionary();
var p:RectanglePiece = new RectanglePiece();
p.x0 = 0;
p.y0 = 0;
p.x1 = imageData.width;
p.y1 = imageData.height;
p.c = 0;
rootNode = setupNode(p);
fillRectangleArray = new Array(p);
tx = setX;
ty = setY;
var max:int = PM_PRNG.MAX;
var sqDim:int = Math.sqrt(max);
var radius:int = sqDim * .5;
seed = ( (ty +radius)*sqDim + tx+radius);
if (seed == 0) seed = 1;
prng.setSeed( seed);
updateLores();
_canvas.graphics.clear();
while (onEnterFrame()) { };
cleanupTree();
if (locField) renderTree();
}
private function cleanupTree():void
{
var nodeIndex:int;
var mult:Number;
var curLevel:int;
var node:KDNode;
si = 1;
searchStack[0] = rootNode;
searchStackLevels[0] = 0;
while (si > 0) {
node = searchStack[--si];
curLevel = searchStackLevels[si];
var shortSide:Number = getShortSide(curLevel);
if (node.flags & 1) {
node.positive = null;
node.negative = null;
mult = (1 /shortSide );
nodeIndex = OFFSETS[curLevel] + (node.boundMinY * mult) * (1 << curLevel) + (node.boundMinX * mult);
seededNodeDict[ nodeIndex ] = node;
seededNodeDict[node] = curLevel +"|"+nodeIndex+"|"+node.boundMinY+"|"+node.boundMinX + "| "+getShortSide(curLevel);
continue;
}
if (node.positive ) {
searchStack[si] = node.positive;
searchStackLevels[si] = curLevel + (node.splitDownLevel() ? 1 : 0);
si++;
}
if (node.negative) {
searchStack[si] = node.negative;
searchStackLevels[si] = curLevel + (node.splitDownLevel() ? 1 : 0);
si++;
}
}
si = 1;
searchStack[0] = rootNode;
searchStackLevels[0] = 0;
var masterOff:int;
var slaveCount:int;
while (si > 0) {
node = searchStack[--si];
curLevel = searchStackLevels[si];
shortSide = getShortSide(curLevel);
if (node.flags & 1) {
mult = (1 / shortSide);
nodeIndex = OFFSETS[curLevel] + (node.boundMinY * mult) * (1 << curLevel) + (node.boundMinX * mult);
var off:int;
var master:KDNode;
var masterNodeIndex:int;
var reachEnd:Boolean;
var slave:KDNode;
off = 0;
slaveCount = 0;
master = null;
reachEnd = false;
while (true) {
++off;
reachEnd = node.boundMinX * mult - off < 0;
nodeIndex = !reachEnd ? OFFSETS[curLevel] + (node.boundMinY * mult) * (1 << curLevel) + (node.boundMinX * mult) - off : -1;
if (nodeIndex != -1 && seededNodeDict[nodeIndex]) {
master = seededNodeDict[nodeIndex];
masterNodeIndex = nodeIndex;
masterOff = off;
}
else break;
}
if (master == null) off = 0;
else off = masterOff;
if (reachEnd) off--;
while (--off > -1) {
nodeIndex = OFFSETS[curLevel] + (node.boundMinY * mult) * (1 << curLevel) + (node.boundMinX * mult) - off;
slave = seededNodeDict[nodeIndex];
if (master === slave) {
continue;
}
slave.flags |= KDNode.FLAG_SLAVE;
slave.flags &= ~1;
slave.positive = master;
master.boundMaxX += shortSide;
slaveCount++;
delete seededNodeDict[nodeIndex];
}
if (slaveCount > 0) {
master.offset = prng.nextDoubleRange(0, slaveCount * shortSide);
}
if (master!=null) continue;
off = 0;
master = null;
slaveCount = 0;
reachEnd = false;
while (true) {
++off;
reachEnd = node.boundMinY * mult - off < 0;
nodeIndex = !reachEnd ? OFFSETS[curLevel] + (node.boundMinY * mult - off) * (1 << curLevel) + (node.boundMinX * mult) : -1;
if (nodeIndex != -1 && seededNodeDict[nodeIndex]) {
master = seededNodeDict[nodeIndex];
masterNodeIndex = nodeIndex;
masterOff = off;
}
else break;
}
if (master == null) off = 0;
else off = masterOff;
if (reachEnd) off--;
while (--off > -1) {
nodeIndex = OFFSETS[curLevel] + (node.boundMinY*mult- off) * (1 << curLevel) + (node.boundMinX * mult);
slave = seededNodeDict[nodeIndex];
if (master === slave) {
continue;
}
slave.flags |= KDNode.FLAG_SLAVE;
slave.flags &= ~1;
slave.positive = master;
master.boundMaxY += shortSide;
slaveCount++;
delete seededNodeDict[nodeIndex];
}
if (slaveCount > 0) {
master.offset = prng.nextDoubleRange(0, slaveCount * shortSide);
}
continue;
}
if (node.positive && ((node.flags & KDNode.FLAG_SLAVE)==0) ) {
searchStack[si] = node.positive;
searchStackLevels[si] = curLevel + (node.splitDownLevel() ? 1 : 0);
si++;
}
if (node.negative) {
searchStack[si] = node.negative;
searchStackLevels[si] = curLevel + (node.splitDownLevel() ? 1 : 0);
si++;
}
}
}
private static const BM_SIZE_SMALL:Number = 64;
private var bitmapData:BitmapData = new BitmapData(BM_SIZE_SMALL, BM_SIZE_SMALL, false, 0);
public var tx:Number = 0;
public var ty:Number = 0;
private var postFunction:Function = Smoothing.linear;
private var noiseFunction:Function = Perlin.fractalNoise;
private var phase:Number = 0;
private var brightness:Number = 0;
private var contrast:Number = 3.29;
private var scaler:Number = 128;
private var _noiseBmp:Bitmap;
public function updateLores():void {
var x:Number;
var y:Number;
bitmapData.lock();
for (y = 0; y < BM_SIZE_SMALL; y++)
for (x = 0; x < BM_SIZE_SMALL; x++) drawNoise(x, y, 4);
bitmapData.unlock();
}
public function drawNoise(x:Number, y:Number, r:Number):void {
var i:Number = (x * r - BM_SIZE_SMALL * 0.5) / scaler + tx*r;
var j:Number = (y * r - BM_SIZE_SMALL * 0.5) / scaler + ty*r;
var n:Number = int( 255 * MathUtils.clamp(postFunction (MathUtils.contrast (MathUtils.brightness( noiseFunction(i, j, phase), brightness), contrast) ) ));
bitmapData.setPixel(x, y, n + (n << 8) + (n << 16));
}
public function loadComplete():void
{
Perlin.setParams( {octaves:4, H:0.64, lacunarity:2 } );
imageData = bitmapData;
_canvas = new Sprite;
_noiseBmp = new Bitmap(bitmapData);
cont = new Sprite();
addChild(cont);
cont.scaleX = 4;
cont.scaleY = 4;
addChild(_noiseBmp);
cont.addChild(_canvas);
_canvas.x +=(BM_SIZE_SMALL+32) / 4;
}
private var searchStack:Vector.<KDNode> = new Vector.<KDNode>();
private var searchStackLevels:Vector.<int> = new Vector.<int>();
private var si:int = 0;
private var hitAreas:Sprite;
private var cont:Sprite;
private var vBox:VBox;
private var previewBmps:Vector.<BitmapData> = new Vector.<BitmapData>();
private function disposePreviewBmps():void {
var i:int = previewBmps.length;
while (--i > -1) {
previewBmps[i].dispose();
}
previewBmps.length = 0;
}
private function renderTree():void {
si = 1;
searchStack[0] = rootNode;
var graphics:Graphics =_canvas.graphics;
graphics.clear();
hitAreas.removeChildren();
disposePreviewBmps();
while (si > 0) {
var node:KDNode = searchStack[--si];
if (node.positive && !(node.flags & KDNode.FLAG_SLAVE)) searchStack[si++] = node.positive;
if (node.negative) searchStack[si++] = node.negative;
graphics.beginFill( node.flags & 1 ? 0x00CCFF : 0x0000CC );
graphics.drawRect(node.boundMinX, node.boundMinY, (node.boundMaxX - node.boundMinX), (node.boundMaxY - node.boundMinY));
hitAreas.addChild( new HitArea(node, node.boundMinX, node.boundMinY, (node.boundMaxX - node.boundMinX), (node.boundMaxY - node.boundMinY), node.flags & 1) );
}
}
private function getShortSide(level:int):int {
return BM_SIZE_SMALL / (1 << level);
}
private function onEnterFrame(e:Event=null):Boolean
{
if (fillRectangleArray.length < 1) {
removeEventListener(Event.ENTER_FRAME, onEnterFrame);
return false;
}else {
var rect:RectanglePiece = fillRectangleArray.shift();
var cArray:Array = deviationLogic(rect.x0, rect.y0, rect.x1, rect.y1);
rect.c = cArray[0];
var halfWidth:Number = (rect.x1 - rect.x0) *.5;
var halfHeight:Number = (rect.y1 - rect.y0) *.5;
if (rect.c > THRESHOLD && (halfWidth > 1 || halfHeight > 1)) {
var seeded:Boolean = (cArray[1] & 0xFF) > COLOR_THRESHOLD;
if (seeded) {
var mult:Number = (1 / getShortSide(rect.level));
var nodeIndex:int = OFFSETS[rect.level] + rect.y0*mult*(1<<rect.level) + rect.x0 *mult;
var isRect:int = rect.node.isRectangle();
if (isRect == 1) seededNodeDict[nodeIndex + 1] = rect.node;
var seededParent:RectanglePiece = LATE_LEAF ? rect.findSeededParent() : null;
if (seededParent) seededParent.node.transferSeedTo( rect.node );
else rect.node.setSeed( prng.nextInt() );
rect.node.offset = isRect === 0 ? 0 : isRect === 1 ? prng.nextDoubleRange(0, (rect.node.boundMaxX - rect.node.boundMinX)*.5 ): prng.nextDoubleRange(0,(rect.node.boundMaxY - rect.node.boundMinY)*.5);
}
else {
rect.node.flags &= ~1;
}
rect.node.flags |= 4;
var rect0:RectanglePiece = new RectanglePiece();
var rect1:RectanglePiece = new RectanglePiece();
if (halfWidth > halfHeight) {
rect.node.vertical = false;
rect0.x0 = rect.x0;
rect0.y0 = rect.y0;
rect0.x1 = rect.x0+halfWidth;
rect0.y1 = rect.y1;
fillRectangleArray.push(rect0);
rect1.x0 = rect.x0+halfWidth;
rect1.y0 = rect.y0;
rect1.x1 = rect.x1;
rect1.y1 = rect.y1;
fillRectangleArray.push(rect1);
}else {
rect.node.vertical = true;
rect0.x0 = rect.x0;
rect0.y0 = rect.y0;
rect0.x1 = rect.x1;
rect0.y1 = rect.y0+halfHeight;
fillRectangleArray.push(rect0);
rect1.x0 = rect.x0;
rect1.y0 = rect.y0+halfHeight;
rect1.x1 = rect.x1;
rect1.y1 = rect.y1;
fillRectangleArray.push(rect1);
}
var node0:KDNode = setupNode(rect0);
var node1:KDNode = setupNode(rect1);
rect0.level = rect.node.splitDownLevel() ? rect.level + 1 : rect.level;
rect1.level = rect0.level;
if (LATE_LEAF || !rect.node.isSeeded() ) {
rect0.parent = rect;
rect1.parent = rect;
rect.node.positive = node0;
rect.node.negative = node1;
}
}
return true;
}
return false;
}
private function setupNode(p:RectanglePiece):KDNode {
var node:KDNode;
node = new KDNode();
p.node = node;
node.boundMinX = p.x0;
node.boundMinY = p.y0;
node.boundMaxX = p.x1;
node.boundMaxY = p.y1;
return node;
}
private function deviationLogic(x0:Number,y0:Number,x1:Number,y1:Number):Array {
var rgb:uint = 0;
var r:uint = 0;
var g:uint = 0;
var b:uint = 0;
var hsb:Array = new Array();
var bArray:Array = new Array();
var br:Number = 0;
var av:Number = 0;
for (var i:int = x0; i < x1;i++ ) {
for (var j:int = y0; j < y1; j++ ) {
rgb = imageData.getPixel(i, j);
r += (rgb >> 16) & 255;
g += (rgb >> 8) & 255;
b += rgb & 255;
hsb = uintRGBtoHSB(rgb);
br += hsb[2];
bArray.push(hsb[2]);
}
}
av = br / bArray.length;
r = r / bArray.length;
g = g / bArray.length;
b = b / bArray.length;
rgb = (r << 16) | (g << 8) | (b << 0);
br = 0;
for (i = 0; i < bArray.length; i++ ) {
br += (bArray[i] - av) *(bArray[i] - av);
}
return [Math.sqrt(br / bArray.length),rgb];
}
private function uintRGBtoHSB(rgb:uint):Array {
var r:uint = (rgb >> 16) & 255;
var g:uint = (rgb >> 8) & 255;
var b:uint = rgb & 255;
return RGBtoHSB(r, g, b);
}
private function RGBtoHSB(r:int, g:int, b:int):Array {
var cmax:Number = Math.max(r, g, b);
var cmin:Number = Math.min(r, g, b);
var brightness:Number = cmax / 255.0;
var hue:Number = 0;
var saturation:Number = (cmax != 0) ? (cmax - cmin) / cmax : 0;
if (saturation != 0) {
var redc:Number = (cmax - r) / (cmax - cmin);
var greenc:Number = (cmax - g) / (cmax - cmin);
var bluec:Number = (cmax - b) / (cmax - cmin);
if (r == cmax) {
hue = bluec - greenc;
} else if (g == cmax) {
hue = 2.0 + redc - bluec;
} else {
hue = 4.0 + greenc - redc;
}
hue = hue / 6.0;
if (hue < 0) {
hue = hue + 1.0;
}
}
return [hue, saturation, brightness];
}
}
}
import flash.display.Sprite;
class RectanglePiece
{
public var x0:Number;
public var y0:Number;
public var x1:Number;
public var y1:Number;
public var c:Number;
public var node:KDNode;
public var parent:RectanglePiece;
public var level:int;
public function RectanglePiece()
{
this.x0 = 0;
this.y0 = 0;
this.x1 = 0;
this.x1 = 0;
this.c = 0;
this.level = 0;
}
public function findSeededParent():RectanglePiece {
var p:RectanglePiece = parent;
while (p != null) {
if (p.node.flags & 1) return p;
p = p.parent;
}
return null;
}
}
class KDNode
{
public var positive:KDNode;
public var negative:KDNode;
public var boundMinX:Number;
public var boundMaxX:Number;
public var boundMinY:Number;
public var boundMaxY:Number;
public var seed:uint;
public var flags:int;
public static const FLAG_SEEDED:int = 1;
public static const FLAG_VERTICAL:int = 2;
public static const FLAG_CONSIDERSEED:int = 4;
public static const FLAG_SLAVE:int = 8;
public var offset:int;
public function setSeed(val:uint):void {
flags |= FLAG_SEEDED;
seed = val;
}
public function isSeeded():Boolean {
return flags & FLAG_SEEDED;
}
public function get vertical():Boolean {
return flags & FLAG_VERTICAL;
}
public function set vertical(val:Boolean):void {
if (val) flags |= FLAG_VERTICAL
else flags &= ~FLAG_VERTICAL;
}
public function getMeasuredShortSide():Number {
return isRectangle() === 1 ? boundMaxY - boundMinY : boundMaxX - boundMinX;
}
public function splitDownLevel():Boolean {
return flags & FLAG_VERTICAL;
}
public function isRectangle():int {
return boundMaxY - boundMinY == boundMaxX - boundMinX ? 0 : boundMaxY - boundMinY < boundMaxX - boundMinX ? 1 : 2;
}
public function KDNode() {
flags = 0;
offset = 0;
}
public function transferSeedTo(node:KDNode):uint
{
node.setSeed(seed);
flags &= ~FLAG_SEEDED;
flags &= ~FLAG_CONSIDERSEED;
return seed;
}
}
class HitArea extends Sprite {
public var node:KDNode;
public function HitArea(node:KDNode, x:Number, y:Number, width:Number, height:Number, buttonMode:Boolean=true) {
this.node = node;
graphics.beginFill(0, 0);
graphics.drawRect(x, y, width, height);
this.buttonMode = buttonMode;
}
}//package {
import __AS3__.vec.Vector;
//import com.nodename.geom.LineSegment;
import flash.geom.Point;
internal function visibleLineSegments(edges:Vector.<DEdge>):Vector.<LineSegment>
{
var segments:Vector.<LineSegment> = new Vector.<LineSegment>();
for each (var edge:DEdge in edges)
{
if (edge.visible)
{
var p1:Point = edge.clippedEnds[LR.LEFT];
var p2:Point = edge.clippedEnds[LR.RIGHT];
segments.push(new LineSegment(p1, p2));
}
}
return segments;
}
//}
//package com.nodename.Delaunay
//{
import flash.geom.Point;
//internal
final class Vertex extends Object implements ICoord
{
internal static const VERTEX_AT_INFINITY:Vertex = new Vertex(PrivateConstructorEnforcer, NaN, NaN);
private static var _pool:Vector.<Vertex> = new Vector.<Vertex>();
private static function create(x:Number, y:Number):Vertex
{
if (isNaN(x) || isNaN(y))
{
return VERTEX_AT_INFINITY;
}
if (_pool.length > 0)
{
return _pool.pop().init(x, y);
}
else
{
return new Vertex(PrivateConstructorEnforcer, x, y);
}
}
private static var _nvertices:int = 0;
private var _coord:Point;
public function get coord():Point
{
return _coord;
}
private var _vertexIndex:int;
public function get vertexIndex():int
{
return _vertexIndex;
}
public function Vertex(lock:Class, x:Number, y:Number)
{
if (lock != PrivateConstructorEnforcer)
{
throw new Error("Vertex constructor is private");
}
init(x, y);
}
private function init(x:Number, y:Number):Vertex
{
_coord = new Point(x, y);
return this;
}
public function dispose():void
{
_coord = null;
_pool.push(this);
}
public function setIndex():void
{
_vertexIndex = _nvertices++;
}
public function toString():String
{
return "Vertex (" + _vertexIndex + ")";
}
/**
* This is the only way to make a Vertex
*
* @param halfedge0
* @param halfedge1
* @return
*
*/
public static function intersect(halfedge0:Halfedge, halfedge1:Halfedge):Vertex
{
var edge0:DEdge, edge1:DEdge, edge:DEdge;
var halfedge:Halfedge;
var determinant:Number, intersectionX:Number, intersectionY:Number;
var rightOfSite:Boolean;
edge0 = halfedge0.edge;
edge1 = halfedge1.edge;
if (edge0 == null || edge1 == null)
{
return null;
}
if (edge0.rightSite == edge1.rightSite)
{
return null;
}
determinant = edge0.a * edge1.b - edge0.b * edge1.a;
if (-1.0e-10 < determinant && determinant < 1.0e-10)
{
// the edges are parallel
return null;
}
intersectionX = (edge0.c * edge1.b - edge1.c * edge0.b)/determinant;
intersectionY = (edge1.c * edge0.a - edge0.c * edge1.a)/determinant;
if (Voronoi.compareByYThenX(edge0.rightSite, edge1.rightSite) < 0)
{
halfedge = halfedge0; edge = edge0;
}
else
{
halfedge = halfedge1; edge = edge1;
}
rightOfSite = intersectionX >= edge.rightSite.x;
if ((rightOfSite && halfedge.leftRight == LR.LEFT)
|| (!rightOfSite && halfedge.leftRight == LR.RIGHT))
{
return null;
}
return Vertex.create(intersectionX, intersectionY);
}
public function get x():Number
{
return _coord.x;
}
public function get y():Number
{
return _coord.y;
}
}
//}
// package com.nodename.Delaunay
//{
import flash.geom.Point;
import flash.geom.Rectangle;
//public
final class Site implements ICoord
{
private static var _pool:Vector.<Site> = new Vector.<Site>();
public static function create(p:Point, index:int, weight:Number, color:uint):Site
{
if (_pool.length > 0)
{
return _pool.pop().init(p, index, weight, color);
}
else
{
return new Site(PrivateConstructorEnforcer, p, index, weight, color);
}
}
internal static function sortSites(sites:Vector.<Site>):void
{
sites.sort(Site.compare);
}
/**
* sort sites on y, then x, coord
* also change each site's _siteIndex to match its new position in the list
* so the _siteIndex can be used to identify the site for nearest-neighbor queries
*
* haha "also" - means more than one responsibility...
*
*/
private static function compare(s1:Site, s2:Site):Number
{
var returnValue:int = Voronoi.compareByYThenX(s1, s2);
// swap _siteIndex values if necessary to match new ordering:
var tempIndex:int;
if (returnValue == -1)
{
if (s1._siteIndex > s2._siteIndex)
{
tempIndex = s1._siteIndex;
s1._siteIndex = s2._siteIndex;
s2._siteIndex = tempIndex;
}
}
else if (returnValue == 1)
{
if (s2._siteIndex > s1._siteIndex)
{
tempIndex = s2._siteIndex;
s2._siteIndex = s1._siteIndex;
s1._siteIndex = tempIndex;
}
}
return returnValue;
}
private static const EPSILON:Number = .005;
private static function closeEnough(p0:Point, p1:Point):Boolean
{
return Point.distance(p0, p1) < EPSILON;
}
private var _coord:Point;
public function get coord():Point
{
return _coord;
}
internal var color:uint;
internal var weight:Number;
private var _siteIndex:uint;
// the edges that define this Site's Voronoi region:
private var _edges:Vector.<DEdge>;
internal function get edges():Vector.<DEdge>
{
return _edges;
}
// which end of each edge hooks up with the previous edge in _edges:
private var _edgeOrientations:Vector.<LR>;
// ordered list of points that define the region clipped to bounds:
private var _region:Vector.<Point>;
public function Site(lock:Class, p:Point, index:int, weight:Number, color:uint)
{
if (lock != PrivateConstructorEnforcer)
{
throw new Error("Site constructor is private");
}
init(p, index, weight, color);
}
private function init(p:Point, index:int, weight:Number, color:uint):Site
{
_coord = p;
_siteIndex = index;
this.weight = weight;
this.color = color;
_edges = new Vector.<DEdge>();
_region = null;
return this;
}
public function toString():String
{
return "Site " + _siteIndex + ": " + coord;
}
private function move(p:Point):void
{
clear();
_coord = p;
}
public function dispose():void
{
_coord = null;
clear();
_pool.push(this);
}
private function clear():void
{
if (_edges)
{
_edges.length = 0;
_edges = null;
}
if (_edgeOrientations)
{
_edgeOrientations.length = 0;
_edgeOrientations = null;
}
if (_region)
{
_region.length = 0;
_region = null;
}
}
internal function addEdge(edge:DEdge):void
{
_edges.push(edge);
}
internal function nearestEdge():DEdge
{
_edges.sort(DEdge.compareSitesDistances);
return _edges[0];
}
internal function neighborSites():Vector.<Site>
{
if (_edges == null || _edges.length == 0)
{
return new Vector.<Site>();
}
if (_edgeOrientations == null)
{
reorderEdges();
}
var list:Vector.<Site> = new Vector.<Site>();
var edge:DEdge;
for each (edge in _edges)
{
list.push(neighborSite(edge));
}
return list;
}
private function neighborSite(edge:DEdge):Site
{
if (this == edge.leftSite)
{
return edge.rightSite;
}
if (this == edge.rightSite)
{
return edge.leftSite;
}
return null;
}
internal function region(clippingBounds:Rectangle):Vector.<Point>
{
if (_edges == null || _edges.length == 0)
{
return new Vector.<Point>();
}
if (_edgeOrientations == null)
{
reorderEdges();
_region = clipToBounds(clippingBounds);
if ((new Polygon(_region)).winding() == Winding.CLOCKWISE)
{
_region = _region.reverse();
}
}
return _region;
}
private function reorderEdges():void
{
//trace("_edges:", _edges);
var reorderer:EdgeReorderer = new EdgeReorderer(_edges, Vertex);
_edges = reorderer.edges;
//trace("reordered:", _edges);
_edgeOrientations = reorderer.edgeOrientations;
reorderer.dispose();
}
private function clipToBounds(bounds:Rectangle):Vector.<Point>
{
var points:Vector.<Point> = new Vector.<Point>;
var n:int = _edges.length;
var i:int = 0;
var edge:DEdge;
while (i < n && ((_edges[i] as DEdge).visible == false))
{
++i;
}
if (i == n)
{
// no edges visible
return new Vector.<Point>();
}
edge = _edges[i];
var orientation:LR = _edgeOrientations[i];
points.push(edge.clippedEnds[orientation]);
points.push(edge.clippedEnds[LR.other(orientation)]);
for (var j:int = i + 1; j < n; ++j)
{
edge = _edges[j];
if (edge.visible == false)
{
continue;
}
connect(points, j, bounds);
}
// close up the polygon by adding another corner point of the bounds if needed:
connect(points, i, bounds, true);
return points;
}
private function connect(points:Vector.<Point>, j:int, bounds:Rectangle, closingUp:Boolean = false):void
{
var rightPoint:Point = points[points.length - 1];
var newEdge:DEdge = _edges[j] as DEdge;
var newOrientation:LR = _edgeOrientations[j];
// the point that must be connected to rightPoint:
var newPoint:Point = newEdge.clippedEnds[newOrientation];
if (!closeEnough(rightPoint, newPoint))
{
// The points do not coincide, so they must have been clipped at the bounds;
// see if they are on the same border of the bounds:
if (rightPoint.x != newPoint.x
&& rightPoint.y != newPoint.y)
{
// They are on different borders of the bounds;
// insert one or two corners of bounds as needed to hook them up:
// (NOTE this will not be correct if the region should take up more than
// half of the bounds rect, for then we will have gone the wrong way
// around the bounds and included the smaller part rather than the larger)
var rightCheck:int = BoundsCheck.check(rightPoint, bounds);
var newCheck:int = BoundsCheck.check(newPoint, bounds);
var px:Number, py:Number;
if (rightCheck & BoundsCheck.RIGHT)
{
px = bounds.right;
if (newCheck & BoundsCheck.BOTTOM)
{
py = bounds.bottom;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.TOP)
{
py = bounds.top;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.LEFT)
{
if (rightPoint.y - bounds.y + newPoint.y - bounds.y < bounds.height)
{
py = bounds.top;
}
else
{
py = bounds.bottom;
}
points.push(new Point(px, py));
points.push(new Point(bounds.left, py));
}
}
else if (rightCheck & BoundsCheck.LEFT)
{
px = bounds.left;
if (newCheck & BoundsCheck.BOTTOM)
{
py = bounds.bottom;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.TOP)
{
py = bounds.top;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.RIGHT)
{
if (rightPoint.y - bounds.y + newPoint.y - bounds.y < bounds.height)
{
py = bounds.top;
}
else
{
py = bounds.bottom;
}
points.push(new Point(px, py));
points.push(new Point(bounds.right, py));
}
}
else if (rightCheck & BoundsCheck.TOP)
{
py = bounds.top;
if (newCheck & BoundsCheck.RIGHT)
{
px = bounds.right;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.LEFT)
{
px = bounds.left;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.BOTTOM)
{
if (rightPoint.x - bounds.x + newPoint.x - bounds.x < bounds.width)
{
px = bounds.left;
}
else
{
px = bounds.right;
}
points.push(new Point(px, py));
points.push(new Point(px, bounds.bottom));
}
}
else if (rightCheck & BoundsCheck.BOTTOM)
{
py = bounds.bottom;
if (newCheck & BoundsCheck.RIGHT)
{
px = bounds.right;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.LEFT)
{
px = bounds.left;
points.push(new Point(px, py));
}
else if (newCheck & BoundsCheck.TOP)
{
if (rightPoint.x - bounds.x + newPoint.x - bounds.x < bounds.width)
{
px = bounds.left;
}
else
{
px = bounds.right;
}
points.push(new Point(px, py));
points.push(new Point(px, bounds.top));
}
}
}
if (closingUp)
{
// newEdge's ends have already been added
return;
}
points.push(newPoint);
}
var newRightPoint:Point = newEdge.clippedEnds[LR.other(newOrientation)];
if (!closeEnough(points[0], newRightPoint))
{
points.push(newRightPoint);
}
}
internal function get x():Number
{
return _coord.x;
}
internal function get y():Number
{
return _coord.y;
}
internal function dist(p:ICoord):Number
{
return Point.distance(p.coord, this._coord);
}
}
//}
/*public*/ class PrivateConstructorEnforcer {}//package {
//import com.nodename.geom.Circle;
//import com.nodename.utils.IDisposable;
import flash.display.BitmapData;
import flash.geom.Point;
import flash.geom.Rectangle;
internal final class SiteList implements IDisposable
{
private var _sites:Vector.<Site>;
private var _currentIndex:uint;
private var _sorted:Boolean;
public function SiteList()
{
_sites = new Vector.<Site>();
_sorted = false;
}
public function dispose():void
{
if (_sites)
{
for each (var site:Site in _sites)
{
site.dispose();
}
_sites.length = 0;
_sites = null;
}
}
public function push(site:Site):uint
{
_sorted = false;
return _sites.push(site);
}
public function get length():uint
{
return _sites.length;
}
public function next():Site
{
if (_sorted == false)
{
throw new Error("SiteList::next(): sites have not been sorted");
}
if (_currentIndex < _sites.length)
{
return _sites[_currentIndex++];
}
else
{
return null;
}
}
internal function getSitesBounds():Rectangle
{
if (_sorted == false)
{
Site.sortSites(_sites);
_currentIndex = 0;
_sorted = true;
}
var xmin:Number, xmax:Number, ymin:Number, ymax:Number;
if (_sites.length == 0)
{
return new Rectangle(0, 0, 0, 0);
}
xmin = Number.MAX_VALUE;
xmax = Number.MIN_VALUE;
for each (var site:Site in _sites)
{
if (site.x < xmin)
{
xmin = site.x;
}
if (site.x > xmax)
{
xmax = site.x;
}
}
ymin = _sites[0].y;
ymax = _sites[_sites.length - 1].y;
return new Rectangle(xmin, ymin, xmax - xmin, ymax - ymin);
}
public function siteColors(referenceImage:BitmapData = null):Vector.<uint>
{
var colors:Vector.<uint> = new Vector.<uint>();
for each (var site:Site in _sites)
{
colors.push(referenceImage ? referenceImage.getPixel(site.x, site.y) : site.color);
}
return colors;
}
public function siteCoords():Vector.<Point>
{
var coords:Vector.<Point> = new Vector.<Point>();
for each (var site:Site in _sites)
{
coords.push(site.coord);
}
return coords;
}
public function circles():Vector.<Circle>
{
var circles:Vector.<Circle> = new Vector.<Circle>();
for each (var site:Site in _sites)
{
var radius:Number = 0;
var nearestEdge:DEdge = site.nearestEdge();
!nearestEdge.isPartOfConvexHull() && (radius = nearestEdge.sitesDistance() * 0.5);
circles.push(new Circle(site.x, site.y, radius));
}
return circles;
}
public function regions(plotBounds:Rectangle):Vector.<Vector.<Point>>
{
var regions:Vector.<Vector.<Point>> = new Vector.<Vector.<Point>>();
for each (var site:Site in _sites)
{
regions.push(site.region(plotBounds));
}
return regions;
}
public function nearestSitePoint(proximityMap:BitmapData, x:Number, y:Number):Point
{
var index:uint = proximityMap.getPixel(x, y);
if (index > _sites.length - 1)
{
return null;
}
return _sites[index].coord;
}
}
//}//package {
//import com.nodename.geom.Polygon;
//import com.nodename.geom.Winding;
import flash.geom.Point;
import flash.geom.Rectangle;
/*public*/ class BoundsCheck
{
public static const TOP:int = 1;
public static const BOTTOM:int = 2;
public static const LEFT:int = 4;
public static const RIGHT:int = 8;
public static function check(point:Point, bounds:Rectangle):int
{
var value:int = 0;
if (point.x == bounds.left)
{
value |= LEFT;
}
if (point.x == bounds.right)
{
value |= RIGHT;
}
if (point.y == bounds.top)
{
value |= TOP;
}
if (point.y == bounds.bottom)
{
value |= BOTTOM;
}
return value;
}
public function BoundsCheck()
{
throw new Error("BoundsCheck constructor unused");
}
}//package {
import flash.geom.Point;
import flash.display.BitmapData;
internal function selectNonIntersectingEdges(keepOutMask:BitmapData, edgesToTest:Vector.<DEdge>):Vector.<DEdge>
{
if (keepOutMask == null)
{
return edgesToTest;
}
var zeroPoint:Point = new Point();
return edgesToTest.filter(myTest);
function myTest(edge:DEdge, index:int, vector:Vector.<DEdge>):Boolean
{
var delaunayLineBmp:BitmapData = edge.makeDelaunayLineBmp();
var notIntersecting:Boolean = !(keepOutMask.hitTest(zeroPoint, 1, delaunayLineBmp, zeroPoint, 1));
delaunayLineBmp.dispose();
return notIntersecting;
}
}
//}
//package {
import __AS3__.vec.Vector;
import flash.geom.Point;
internal function selectEdgesForSitePoint(coord:Point, edgesToTest:Vector.<DEdge>):Vector.<DEdge>
{
return edgesToTest.filter(myTest);
function myTest(edge:DEdge, index:int, vector:Vector.<DEdge>):Boolean
{
return ((edge.leftSite && edge.leftSite.coord == coord)
|| (edge.rightSite && edge.rightSite.coord == coord));
}
}
//}//package {
import __AS3__.vec.Vector;
import flash.utils.Dictionary;
//import com.nodename.geom.LineSegment;
/*public*/ class Node
{
public static var pool:Vector.<Node> = new Vector.<Node>();
public var parent:Node;
public var treeSize:int;
public function Node() {}
}
//package {
import flash.geom.Point;
internal interface ICoord
{
function get coord():Point;
}
//}//package {
import flash.geom.Point;
internal final class HalfedgePriorityQueue
{
private var _hash:Vector.<Halfedge>;
private var _count:int;
private var _minBucket:int;
private var _hashsize:int;
private var _ymin:Number;
private var _deltay:Number;
public function HalfedgePriorityQueue(ymin:Number, deltay:Number, sqrt_nsites:int)
{
_ymin = ymin;
_deltay = deltay;
_hashsize = 4 * sqrt_nsites;
initialize();
}
public function dispose():void
{
for (var i:int = 0; i < _hashsize; ++i)
{
_hash[i].dispose();
_hash[i] = null;
}
_hash = null;
}
private function initialize():void
{
var i:int;
_count = 0;
_minBucket = 0;
_hash = new Vector.<Halfedge>(_hashsize);
for (i = 0; i < _hashsize; ++i)
{
_hash[i] = Halfedge.createDummy();
_hash[i].nextInPriorityQueue = null;
}
}
public function insert(halfEdge:Halfedge):void
{
var previous:Halfedge, next:Halfedge;
var insertionBucket:int = bucket(halfEdge);
if (insertionBucket < _minBucket)
{
_minBucket = insertionBucket;
}
previous = _hash[insertionBucket];
while ((next = previous.nextInPriorityQueue) != null
&& (halfEdge.ystar > next.ystar || (halfEdge.ystar == next.ystar && halfEdge.vertex.x > next.vertex.x)))
{
previous = next;
}
halfEdge.nextInPriorityQueue = previous.nextInPriorityQueue;
previous.nextInPriorityQueue = halfEdge;
++_count;
}
public function remove(halfEdge:Halfedge):void
{
var previous:Halfedge;
var removalBucket:int = bucket(halfEdge);
if (halfEdge.vertex != null)
{
previous = _hash[removalBucket];
while (previous.nextInPriorityQueue != halfEdge)
{
previous = previous.nextInPriorityQueue;
}
previous.nextInPriorityQueue = halfEdge.nextInPriorityQueue;
_count--;
halfEdge.vertex = null;
halfEdge.nextInPriorityQueue = null;
halfEdge.dispose();
}
}
private function bucket(halfEdge:Halfedge):int
{
var theBucket:int = (halfEdge.ystar - _ymin)/_deltay * _hashsize;
if (theBucket < 0) theBucket = 0;
if (theBucket >= _hashsize) theBucket = _hashsize - 1;
return theBucket;
}
private function isEmpty(bucket:int):Boolean
{
return (_hash[bucket].nextInPriorityQueue == null);
}
private function adjustMinBucket():void
{
while (_minBucket < _hashsize - 1 && isEmpty(_minBucket))
{
++_minBucket;
}
}
public function empty():Boolean
{
return _count == 0;
}
public function min():Point
{
adjustMinBucket();
var answer:Halfedge = _hash[_minBucket].nextInPriorityQueue;
return new Point(answer.vertex.x, answer.ystar);
}
public function extractMin():Halfedge
{
var answer:Halfedge;
answer = _hash[_minBucket].nextInPriorityQueue;
_hash[_minBucket].nextInPriorityQueue = answer.nextInPriorityQueue;
_count--;
answer.nextInPriorityQueue = null;
return answer;
}
}
//}//package {
import flash.geom.Point;
//package com.nodename.Delaunay
//{
import flash.geom.Point;
//internal
final class Halfedge
{
private static var _pool:Vector.<Halfedge> = new Vector.<Halfedge>();
public static function create(edge:DEdge, lr:LR):Halfedge
{
if (_pool.length > 0)
{
return _pool.pop().init(edge, lr);
}
else
{
return new Halfedge(PrivateConstructorEnforcer, edge, lr);
}
}
public static function createDummy():Halfedge
{
return create(null, null);
}
public var edgeListLeftNeighbor:Halfedge, edgeListRightNeighbor:Halfedge;
public var nextInPriorityQueue:Halfedge;
public var edge:DEdge;
public var leftRight:LR;
public var vertex:Vertex;
// the vertex's y-coordinate in the transformed Voronoi space V*
public var ystar:Number;
public function Halfedge(lock:Class, edge:DEdge = null, lr:LR = null)
{
if (lock != PrivateConstructorEnforcer)
{
throw new Error("Halfedge constructor is private");
}
init(edge, lr);
}
private function init(edge:DEdge, lr:LR):Halfedge
{
this.edge = edge;
leftRight = lr;
nextInPriorityQueue = null;
vertex = null;
return this;
}
public function toString():String
{
return "Halfedge (leftRight: " + leftRight + "; vertex: " + vertex + ")";
}
public function dispose():void
{
if (edgeListLeftNeighbor || edgeListRightNeighbor)
{
// still in EdgeList
return;
}
if (nextInPriorityQueue)
{
// still in PriorityQueue
return;
}
edge = null;
leftRight = null;
vertex = null;
_pool.push(this);
}
public function reallyDispose():void
{
edgeListLeftNeighbor = null;
edgeListRightNeighbor = null;
nextInPriorityQueue = null;
edge = null;
leftRight = null;
vertex = null;
_pool.push(this);
}
internal function isLeftOf(p:Point):Boolean
{
var topSite:Site;
var rightOfSite:Boolean, above:Boolean, fast:Boolean;
var dxp:Number, dyp:Number, dxs:Number, t1:Number, t2:Number, t3:Number, yl:Number;
topSite = edge.rightSite;
rightOfSite = p.x > topSite.x;
if (rightOfSite && this.leftRight == LR.LEFT)
{
return true;
}
if (!rightOfSite && this.leftRight == LR.RIGHT)
{
return false;
}
if (edge.a == 1.0)
{
dyp = p.y - topSite.y;
dxp = p.x - topSite.x;
fast = false;
if ((!rightOfSite && edge.b < 0.0) || (rightOfSite && edge.b >= 0.0) )
{
above = dyp >= edge.b * dxp;
fast = above;
}
else
{
above = p.x + p.y * edge.b > edge.c;
if (edge.b < 0.0)
{
above = !above;
}
if (!above)
{
fast = true;
}
}
if (!fast)
{
dxs = topSite.x - edge.leftSite.x;
above = edge.b * (dxp * dxp - dyp * dyp) <
dxs * dyp * (1.0 + 2.0 * dxp/dxs + edge.b * edge.b);
if (edge.b < 0.0)
{
above = !above;
}
}
}
else /* edge.b == 1.0 */
{
yl = edge.c - edge.a * p.x;
t1 = p.y - yl;
t2 = p.x - topSite.x;
t3 = yl - topSite.y;
above = t1 * t1 > t2 * t2 + t3 * t3;
}
return this.leftRight == LR.LEFT ? above : !above;
}
}
//}
internal final class EdgeReorderer
{
private var _edges:Vector.<DEdge>;
private var _edgeOrientations:Vector.<LR>;
public function get edges():Vector.<DEdge>
{
return _edges;
}
public function get edgeOrientations():Vector.<LR>
{
return _edgeOrientations;
}
public function EdgeReorderer(origEdges:Vector.<DEdge>, criterion:Class)
{
if (criterion != Vertex && criterion != Site)
{
throw new ArgumentError("Edges: criterion must be Vertex or Site");
}
_edges = new Vector.<DEdge>();
_edgeOrientations = new Vector.<LR>();
if (origEdges.length > 0)
{
_edges = reorderEdges(origEdges, criterion);
}
}
public function dispose():void
{
_edges = null;
_edgeOrientations = null;
}
private function reorderEdges(origEdges:Vector.<DEdge>, criterion:Class):Vector.<DEdge>
{
var i:int;
var j:int;
var n:int = origEdges.length;
var edge:DEdge;
var done:Vector.<Boolean> = new Vector.<Boolean>(n, true);
var nDone:int = 0;
for each (var b:Boolean in done)
{
b = false;
}
var newEdges:Vector.<DEdge> = new Vector.<DEdge>();
i = 0;
edge = origEdges[i];
newEdges.push(edge);
_edgeOrientations.push(LR.LEFT);
var firstPoint:ICoord = (criterion == Vertex) ? edge.leftVertex : edge.leftSite;
var lastPoint:ICoord = (criterion == Vertex) ? edge.rightVertex : edge.rightSite;
if (firstPoint == Vertex.VERTEX_AT_INFINITY || lastPoint == Vertex.VERTEX_AT_INFINITY)
{
return new Vector.<DEdge>();
}
done[i] = true;
++nDone;
while (nDone < n)
{
for (i = 1; i < n; ++i)
{
if (done[i])
{
continue;
}
edge = origEdges[i];
var leftPoint:ICoord = (criterion == Vertex) ? edge.leftVertex : edge.leftSite;
var rightPoint:ICoord = (criterion == Vertex) ? edge.rightVertex : edge.rightSite;
if (leftPoint == Vertex.VERTEX_AT_INFINITY || rightPoint == Vertex.VERTEX_AT_INFINITY)
{
return new Vector.<DEdge>();
}
if (leftPoint == lastPoint)
{
lastPoint = rightPoint;
_edgeOrientations.push(LR.LEFT);
newEdges.push(edge);
done[i] = true;
}
else if (rightPoint == firstPoint)
{
firstPoint = leftPoint;
_edgeOrientations.unshift(LR.LEFT);
newEdges.unshift(edge);
done[i] = true;
}
else if (leftPoint == firstPoint)
{
firstPoint = rightPoint;
_edgeOrientations.unshift(LR.RIGHT);
newEdges.unshift(edge);
done[i] = true;
}
else if (rightPoint == lastPoint)
{
lastPoint = leftPoint;
_edgeOrientations.push(LR.RIGHT);
newEdges.push(edge);
done[i] = true;
}
if (done[i])
{
++nDone;
}
}
}
return newEdges;
}
}
//}//package {
//import com.nodename.utils.IDisposable;
import flash.geom.Point;
internal final class EdgeList implements IDisposable
{
private var _deltax:Number;
private var _xmin:Number;
private var _hashsize:int;
private var _hash:Vector.<Halfedge>;
private var _leftEnd:Halfedge;
public function get leftEnd():Halfedge
{
return _leftEnd;
}
private var _rightEnd:Halfedge;
public function get rightEnd():Halfedge
{
return _rightEnd;
}
public function dispose():void
{
var halfEdge:Halfedge = _leftEnd;
var prevHe:Halfedge;
while (halfEdge != _rightEnd)
{
prevHe = halfEdge;
halfEdge = halfEdge.edgeListRightNeighbor;
prevHe.dispose();
}
_leftEnd = null;
_rightEnd.dispose();
_rightEnd = null;
var i:int;
for (i = 0; i < _hashsize; ++i)
{
_hash[i] = null;
}
_hash = null;
}
public function EdgeList(xmin:Number, deltax:Number, sqrt_nsites:int)
{
_xmin = xmin;
_deltax = deltax;
_hashsize = 2 * sqrt_nsites;
var i:int;
_hash = new Vector.<Halfedge>(_hashsize, true);
_leftEnd = Halfedge.createDummy();
_rightEnd = Halfedge.createDummy();
_leftEnd.edgeListLeftNeighbor = null;
_leftEnd.edgeListRightNeighbor = _rightEnd;
_rightEnd.edgeListLeftNeighbor = _leftEnd;
_rightEnd.edgeListRightNeighbor = null;
_hash[0] = _leftEnd;
_hash[_hashsize - 1] = _rightEnd;
}
public function insert(lb:Halfedge, newHalfedge:Halfedge):void
{
newHalfedge.edgeListLeftNeighbor = lb;
newHalfedge.edgeListRightNeighbor = lb.edgeListRightNeighbor;
lb.edgeListRightNeighbor.edgeListLeftNeighbor = newHalfedge;
lb.edgeListRightNeighbor = newHalfedge;
}
public function remove(halfEdge:Halfedge):void
{
halfEdge.edgeListLeftNeighbor.edgeListRightNeighbor = halfEdge.edgeListRightNeighbor;
halfEdge.edgeListRightNeighbor.edgeListLeftNeighbor = halfEdge.edgeListLeftNeighbor;
halfEdge.edge = DEdge.DELETED;
halfEdge.edgeListLeftNeighbor = halfEdge.edgeListRightNeighbor = null;
}
public function edgeListLeftNeighbor(p:Point):Halfedge
{
var i:int, bucket:int;
var halfEdge:Halfedge;
bucket = (p.x - _xmin)/_deltax * _hashsize;
if (bucket < 0)
{
bucket = 0;
}
if (bucket >= _hashsize)
{
bucket = _hashsize - 1;
}
halfEdge = getHash(bucket);
if (halfEdge == null)
{
for (i = 1; true ; ++i)
{
if ((halfEdge = getHash(bucket - i)) != null) break;
if ((halfEdge = getHash(bucket + i)) != null) break;
}
}
if (halfEdge == leftEnd || (halfEdge != rightEnd && halfEdge.isLeftOf(p)))
{
do
{
halfEdge = halfEdge.edgeListRightNeighbor;
}
while (halfEdge != rightEnd && halfEdge.isLeftOf(p));
halfEdge = halfEdge.edgeListLeftNeighbor;
}
else
{
do
{
halfEdge = halfEdge.edgeListLeftNeighbor;
}
while (halfEdge != leftEnd && !halfEdge.isLeftOf(p));
}
if (bucket > 0 && bucket <_hashsize - 1)
{
_hash[bucket] = halfEdge;
}
return halfEdge;
}
private function getHash(b:int):Halfedge
{
var halfEdge:Halfedge;
if (b < 0 || b >= _hashsize)
{
return null;
}
halfEdge = _hash[b];
if (halfEdge != null && halfEdge.edge == DEdge.DELETED)
{
_hash[b] = null;
return null;
}
else
{
return halfEdge;
}
}
}
//}//package {
//import com.nodename.geom.LineSegment;
import flash.display.BitmapData;
import flash.display.CapsStyle;
import flash.display.Graphics;
import flash.display.LineScaleMode;
import flash.display.Sprite;
import flash.geom.Point;
import flash.geom.Rectangle;
import flash.utils.Dictionary;
import __AS3__.vec.Vector;
//import com.nodename.geom.LineSegment;
internal function delaunayLinesForEdges(edges:Vector.<DEdge>):Vector.<LineSegment>
{
var segments:Vector.<LineSegment> = new Vector.<LineSegment>();
for each (var edge:DEdge in edges)
{
segments.push(edge.delaunayLine());
}
return segments;
}
//}
//package {
/*public*/ interface IDisposable
{
function dispose():void;
}
//}
//package {
internal class NoiseSuper {
static public var hash:Array = [0xA2,0xA0,0x19,0x3B,0xF8,0xEB,0xAA,0xEE,0xF3,0x1C,0x67,0x28,0x1D,0xED,0x0,0xDE,0x95,0x2E,0xDC,0x3F,0x3A,0x82,0x35,0x4D,0x6C,0xBA,0x36,0xD0,0xF6,0xC,0x79,0x32,0xD1,0x59,0xF4,0x8,0x8B,0x63,0x89,0x2F,0xB8,0xB4,0x97,0x83,0xF2,0x8F,0x18,0xC7,0x51,0x14,0x65,0x87,0x48,0x20,0x42,0xA8,0x80,0xB5,0x40,0x13,0xB2,0x22,0x7E,0x57,
0xBC,0x7F,0x6B,0x9D,0x86,0x4C,0xC8,0xDB,0x7C,0xD5,0x25,0x4E,0x5A,0x55,0x74,0x50,0xCD,0xB3,0x7A,0xBB,0xC3,0xCB,0xB6,0xE2,0xE4,0xEC,0xFD,0x98,0xB,0x96,0xD3,0x9E,0x5C,0xA1,0x64,0xF1,0x81,0x61,0xE1,0xC4,0x24,0x72,0x49,0x8C,0x90,0x4B,0x84,0x34,0x38,0xAB,0x78,0xCA,0x1F,0x1,0xD7,0x93,0x11,0xC1,0x58,0xA9,0x31,0xF9,0x44,0x6D,
0xBF,0x33,0x9C,0x5F,0x9,0x94,0xA3,0x85,0x6,0xC6,0x9A,0x1E,0x7B,0x46,0x15,0x30,0x27,0x2B,0x1B,0x71,0x3C,0x5B,0xD6,0x6F,0x62,0xAC,0x4F,0xC2,0xC0,0xE,0xB1,0x23,0xA7,0xDF,0x47,0xB0,0x77,0x69,0x5,0xE9,0xE6,0xE7,0x76,0x73,0xF,0xFE,0x6E,0x9B,0x56,0xEF,0x12,0xA5,0x37,0xFC,0xAE,0xD9,0x3,0x8E,0xDD,0x10,0xB9,0xCE,0xC9,0x8D,
0xDA,0x2A,0xBD,0x68,0x17,0x9F,0xBE,0xD4,0xA,0xCC,0xD2,0xE8,0x43,0x3D,0x70,0xB7,0x2,0x7D,0x99,0xD8,0xD,0x60,0x8A,0x4,0x2C,0x3E,0x92,0xE5,0xAF,0x53,0x7,0xE0,0x29,0xA6,0xC5,0xE3,0xF5,0xF7,0x4A,0x41,0x26,0x6A,0x16,0x5E,0x52,0x2D,0x21,0xAD,0xF0,0x91,0xFF,0xEA,0x54,0xFA,0x66,0x1A,0x45,0x39,0xCF,0x75,0xA4,0x88,0xFB,0x5D,
0xA2,0xA0,0x19,0x3B,0xF8,0xEB,0xAA,0xEE,0xF3,0x1C,0x67,0x28,0x1D,0xED,0x0,0xDE,0x95,0x2E,0xDC,0x3F,0x3A,0x82,0x35,0x4D,0x6C,0xBA,0x36,0xD0,0xF6,0xC,0x79,0x32,0xD1,0x59,0xF4,0x8,0x8B,0x63,0x89,0x2F,0xB8,0xB4,0x97,0x83,0xF2,0x8F,0x18,0xC7,0x51,0x14,0x65,0x87,0x48,0x20,0x42,0xA8,0x80,0xB5,0x40,0x13,0xB2,0x22,0x7E,0x57,
0xBC,0x7F,0x6B,0x9D,0x86,0x4C,0xC8,0xDB,0x7C,0xD5,0x25,0x4E,0x5A,0x55,0x74,0x50,0xCD,0xB3,0x7A,0xBB,0xC3,0xCB,0xB6,0xE2,0xE4,0xEC,0xFD,0x98,0xB,0x96,0xD3,0x9E,0x5C,0xA1,0x64,0xF1,0x81,0x61,0xE1,0xC4,0x24,0x72,0x49,0x8C,0x90,0x4B,0x84,0x34,0x38,0xAB,0x78,0xCA,0x1F,0x1,0xD7,0x93,0x11,0xC1,0x58,0xA9,0x31,0xF9,0x44,0x6D,
0xBF,0x33,0x9C,0x5F,0x9,0x94,0xA3,0x85,0x6,0xC6,0x9A,0x1E,0x7B,0x46,0x15,0x30,0x27,0x2B,0x1B,0x71,0x3C,0x5B,0xD6,0x6F,0x62,0xAC,0x4F,0xC2,0xC0,0xE,0xB1,0x23,0xA7,0xDF,0x47,0xB0,0x77,0x69,0x5,0xE9,0xE6,0xE7,0x76,0x73,0xF,0xFE,0x6E,0x9B,0x56,0xEF,0x12,0xA5,0x37,0xFC,0xAE,0xD9,0x3,0x8E,0xDD,0x10,0xB9,0xCE,0xC9,0x8D,
0xDA,0x2A,0xBD,0x68,0x17,0x9F,0xBE,0xD4,0xA,0xCC,0xD2,0xE8,0x43,0x3D,0x70,0xB7,0x2,0x7D,0x99,0xD8,0xD,0x60,0x8A,0x4,0x2C,0x3E,0x92,0xE5,0xAF,0x53,0x7,0xE0,0x29,0xA6,0xC5,0xE3,0xF5,0xF7,0x4A,0x41,0x26,0x6A,0x16,0x5E,0x52,0x2D,0x21,0xAD,0xF0,0x91,0xFF,0xEA,0x54,0xFA,0x66,0x1A,0x45,0x39,0xCF,0x75,0xA4,0x88,0xFB,0x5D];
static public function lerp(t:Number, a:Number, b:Number):Number {
return a + t * (b - a);
}
static public function smoothClamp(n:Number):Number {
return Smoothing.smooth5(clamp(n));
}
static public function clamp(n:Number):Number {
return n < 0 ? 0 : n > 1 ? 1 : n;
}
static public function smooth5(t:Number):Number {
return t * t * t * (t * (t * 6 - 15) + 10);
}
static public function smooth3(t:Number):Number {
return t * t * (3 - 2 * t);
}
static protected function grad(hash:int, x:Number, y:Number, z:Number):Number {
var h:Number = hash & 15;
var u:Number = h<8 ? x : y;
var v:Number = h<4 ? y : (h == 12 || h==14) ? x : z;
return ((h&1) == 0 ? u : -u) + ((h&2) == 0 ? v : -v);
}
}
// package com.nodename.geom
//{
import flash.errors.IllegalOperationError;
//public
final class Winding
{
public static const CLOCKWISE:Winding = new Winding(PrivateConstructorEnforcer, "clockwise");
public static const COUNTERCLOCKWISE:Winding = new Winding(PrivateConstructorEnforcer, "counterclockwise");
public static const NONE:Winding = new Winding(PrivateConstructorEnforcer, "none");
private var _name:String;
public function Winding(lock:Class, name:String)
{
super();
if (lock != PrivateConstructorEnforcer)
{
throw new IllegalOperationError("Invalid constructor access");
}
_name = name;
}
public function toString():String
{
return _name;
}
}
//}
//}//package {
import flash.geom.Point;
/*public*/ class Polygon
{
private var _vertices:Vector.<Point>;
public function Polygon(vertices:Vector.<Point>)
{
_vertices = vertices;
}
public function area():Number
{
return Math.abs(signedDoubleArea() * 0.5);
}
public function winding():Winding
{
var signedDoubleArea:Number = signedDoubleArea();
if (signedDoubleArea < 0)
{
return Winding.CLOCKWISE;
}
if (signedDoubleArea > 0)
{
return Winding.COUNTERCLOCKWISE;
}
return Winding.NONE;
}
private function signedDoubleArea():Number
{
var index:uint, nextIndex:uint;
var n:uint = _vertices.length;
var point:Point, next:Point;
var signedDoubleArea:Number = 0;
for (index = 0; index < n; ++index)
{
nextIndex = (index + 1) % n;
point = _vertices[index] as Point;
next = _vertices[nextIndex] as Point;
signedDoubleArea += point.x * next.y - next.x * point.y;
}
return signedDoubleArea;
}
}
//}//package {
import flash.errors.IllegalOperationError;
//package {
import flash.geom.Point;
/*public*/ class Circle extends Object
{
public var center:Point;
public var radius:Number;
public function Circle(centerX:Number, centerY:Number, radius:Number)
{
super();
this.center = new Point(centerX, centerY);
this.radius = radius;
}
public function toString():String
{
return "Circle (center: " + center + "; radius: " + radius + ")";
}
}
//}//package {
import __AS3__.vec.Vector;
/*public*/ class Triangle
{
private var _sites:Vector.<Site>;
public function get sites():Vector.<Site>
{
return _sites;
}
public function Triangle(a:Site, b:Site, c:Site)
{
_sites = Vector.<Site>([ a, b, c ]);
}
public function dispose():void
{
_sites.length = 0;
_sites = null;
}
}
//}//package {
import flash.display.BitmapData;
import __AS3__.vec.Vector;
import flash.geom.Matrix;
import flash.geom.Point;
import flash.geom.Rectangle;
/*public*/ class BitmapDataUtil {
public static function getPointsMatchingColor(bmd:BitmapData,color:uint):Vector.<Point>{
var points:Vector.<Point>=new Vector.<Point>();
for(var i:uint=0;i<bmd.height;i++){
for(var j:uint=0;j<bmd.width;j++){
if(bmd.getPixel32(j,i)==color){
points.push(new Point(j,i));
}
}
}
return points;
}
public static function getPointNotMatchingColor(bmd:BitmapData,color:uint):Point {
for(var i:uint=0;i<bmd.height;i++){
for(var j:uint=0;j<bmd.width;j++){
if(bmd.getPixel32(j,i)!=color){
return new Point(j,i);
}
}
}
return null;
}
public static function getPointsMatchingColor32(bmd:BitmapData,color:uint):Vector.<Point>{
var points:Vector.<Point>=new Vector.<Point>();
for(var i:uint=0;i<bmd.height;i++){
for(var j:uint=0;j<bmd.width;j++){
if(bmd.getPixel32(j,i)==color){
points.push(new Point(j,i));
}
}
}
return points;
}
public static function getNonTransparentPoints(bmd:BitmapData,grab_every:uint=2,resize_percent:Number=1,offset:Point=null):Vector.<Point>{
if(offset==null)offset=new Point(0,0);
var points:Vector.<Point>=new Vector.<Point>();
for(var i:uint=0;i<bmd.height;i+=grab_every){
for(var j:uint=0;j<bmd.width;j+=grab_every){
if(bmd.getPixel32(j,i)>0x00000000){
points.push(new Point(j/resize_percent+offset.x,i/resize_percent+offset.y));
}
}
}
return points;
}
public static function toMonoChrome(source:BitmapData,mono_color:uint=0xFF000000):BitmapData{
var bmd:BitmapData=source.clone();
bmd.threshold(bmd,bmd.rect,new Point(),">",0x00000000,mono_color);
return bmd;
}
public static function containsTransparentPixels(bmd:BitmapData):Boolean{
if(!bmd.transparent)return false;
var test:BitmapData=bmd.clone();
return test.threshold(bmd,bmd.rect,new Point(),"<",0x01,0xFF000000) > 0 ? true : false ;
}
public static function containsSolidPixels(bmd:BitmapData):Boolean{
var rect:Rectangle=bmd.getColorBoundsRect(0xFF000000,0,false);
return !rect.equals(new Rectangle());
}
public static function stripTransparentEdges(bm:BitmapData):BitmapData{
bm=stripTransparentEdgeFromTop(bm);
bm=stripTransparentEdgeFromBottom(bm);
bm=stripTransparentEdgeFromRight(bm);
return stripTransparentEdgeFromLeft(bm);
}
public static function stripTransparentEdgeFromTop(bm:BitmapData):BitmapData{
var i:uint,j:uint,first_colored:uint=0;
outer:for(i=0;i<bm.height;i++){
for(j=0;j<bm.width;j++){
if(bm.getPixel32(j,i)!=0x00000000){
first_colored=i;
break outer;
}
}
}
if(first_colored==0)return bm;
var stripped:BitmapData=new BitmapData(bm.width,bm.height-first_colored,true,0x00000000);
stripped.draw(bm,new Matrix(1,0,0,1,0,-first_colored));
return stripped;
}
public static function stripTransparentEdgeFromBottom(bm:BitmapData):BitmapData{
var i:int,j:uint,first_colored:uint=bm.height;
outer:for(i=bm.height;i>-1;i--){
for(j=0;j<bm.width;j++){
if(bm.getPixel32(j,i)!=0x00000000){
first_colored=i+1;
break outer;
}
}
}
if(first_colored==bm.height)return bm;
var stripped:BitmapData=new BitmapData(bm.width,first_colored,true,0x00000000);
stripped.draw(bm);
return stripped;
}
public static function stripTransparentEdgeFromLeft(bm:BitmapData):BitmapData{
var i:uint,j:uint,first_colored:uint=0;
outer:for(i=0;i<bm.width;i++){
for(j=0;j<bm.height;j++){
if(bm.getPixel32(i,j)!=0x00000000){
first_colored=i;
break outer;
}
}
}
if(first_colored==0)return bm;
var stripped:BitmapData=new BitmapData(bm.width-first_colored,bm.height,true,0x00000000);
stripped.draw(bm,new Matrix(1,0,0,1,-first_colored,0));
return stripped;
}
public static function stripTransparentEdgeFromRight(bm:BitmapData):BitmapData{
var i:int,j:uint,first_colored:uint=bm.width;
outer:for(i=bm.width;i>-1;i--){
for(j=0;j<bm.height;j++){
if(bm.getPixel32(i,j)!=0x00000000){
first_colored=i+1;
break outer;
}
}
}
if(first_colored==bm.width)return bm;
var stripped:BitmapData=new BitmapData(first_colored,bm.height,true,0x00000000);
stripped.draw(bm);
return stripped;
}
public static function getFirstNonTransparentPixel( bmd:BitmapData, start_y:uint=0 ):Point{
var hit_rect:Rectangle=new Rectangle(0,0,bmd.width,1);
var p:Point = new Point();
for( hit_rect.y = start_y; hit_rect.y < bmd.height; hit_rect.y++ ){
if( bmd.hitTest(p, 0x01, hit_rect) ){
var hit_bmd:BitmapData=new BitmapData( bmd.width, 1, true, 0 );
hit_bmd.copyPixels( bmd, hit_rect, p );
return hit_rect.topLeft.add( hit_bmd.getColorBoundsRect(0xFF000000, 0, false).topLeft );
}
}
return null;
}
public static function getFirstNonTransparentPixel2( bmd:BitmapData ):Point{
var r1:Rectangle = bmd.getColorBoundsRect( 0xff000000, 0, false );
if ( r1.width > 0 ){
var temp:BitmapData = new BitmapData( r1.width, 1, true, 0 );
temp.copyPixels( bmd, r1, new Point());
var r2:Rectangle = temp.getColorBoundsRect( 0xff000000, 0, false );
return r1.topLeft.add( r2.topLeft );
}
return null;
}
public static function getFirstNonTransparentPixelLooping(bmd:BitmapData):Point{
var ix:uint,iy:uint,bmd_height:uint=bmd.height,bmd_width:uint=bmd.width;
for (iy=0;iy<bmd_height;iy++){
for(ix=0;ix<bmd_width;ix++){
if(bmd.getPixel32(ix,iy)>0x00000000){
return new Point(ix,iy);
}
}
}
return null;
}
public static function getFirstNonTransparentPixelFloodFill(bmd:BitmapData,test_fill_color:uint=0xFFFFFF00):Point{
var hit_bmd:BitmapData;
var m:Matrix=new Matrix();
for(var i:int=0;i<bmd.height;i++){
m.ty=-i;
hit_bmd=new BitmapData(bmd.width,1,true,0);
hit_bmd.draw(bmd,m);
hit_bmd.floodFill(0,0,test_fill_color);
var bounds:Rectangle=hit_bmd.getColorBoundsRect(0xFFFFFFFF,test_fill_color);
if(bounds.width!=bmd.width){
return new Point(i,bounds.width);
}
hit_bmd.dispose();
}
return null;
}
public static function getFirstNonTransparentPixelHitTest(bmd:BitmapData,test_fill_color:uint=0xFFFFFF00):Point{
var hit_rect:Rectangle=new Rectangle(0,0,bmd.width,1);
for(var i:uint=0;i<bmd.height;i++){
if(bmd.hitTest(new Point(),0x01,hit_rect)){
var hit_bmd:BitmapData=new BitmapData(bmd.width,1,true,0);
var m:Matrix=new Matrix(1,0,0,1,0,-i);
hit_bmd.draw(bmd,m);
hit_bmd.floodFill(0,0,test_fill_color);
var bounds:Rectangle=hit_bmd.getColorBoundsRect(0xFFFFFFFF,test_fill_color);
return new Point(bounds.width,i);
}
hit_rect.y++;
}
return null;
}
public static function changeEdgePixels(bmd:BitmapData,replace:uint):BitmapData{
var ix:uint,iy:uint,bmd_height:uint=bmd.height,bmd_width:uint=bmd.width;
var max_y:uint=bmd_height-1,max_x:uint=bmd_width-1;
var update:Vector.<Point>=new Vector.<Point>();
for (iy=0;iy<bmd_height;iy++){
for(ix=0;ix<bmd_width;ix++){
if(bmd.getPixel32(ix,iy)>0x00000000){
if(!iy || !ix || iy==max_y || ix==max_x){
update.push(new Point(ix,iy));
}else if(
!( bmd.getPixel32(ix-1,iy)>0x00000000 &&
bmd.getPixel32(ix+1,iy)>0x00000000 &&
bmd.getPixel32(ix,iy-1)>0x00000000 &&
bmd.getPixel32(ix,iy+1)>0x00000000 )
){
update.push(new Point(ix,iy));
}
}
}
}
var tot:uint=update.length;
var p:Point;
for (var i:uint=0;i<tot;i++){
p=update[i];
bmd.setPixel32(p.x,p.y,replace);
}
return bmd;
}
}
//}//package {
import __AS3__.vec.Vector;
import flash.display.Shape;
import flash.display.Bitmap;
import flash.display.BitmapData;
/*public*/ class ExtractedShapeCollection{
private var _shapes:Vector.<BitmapData>;
public function get shapes():Vector.<BitmapData>{return _shapes;}
public function set shapes(a:Vector.<BitmapData>):void{_shapes=a;}
private var _negative_shapes:Vector.<BitmapData>;
public function get negative_shapes():Vector.<BitmapData>{return _negative_shapes;}
public function set negative_shapes(a:Vector.<BitmapData>):void{_negative_shapes=a}
public function get all_shapes():Vector.<BitmapData>{return _shapes.concat(_negative_shapes);}
public function set all_shapes(a:Vector.<BitmapData>):void{}
public function ExtractedShapeCollection(){
_shapes=new Vector.<BitmapData>();
_negative_shapes=new Vector.<BitmapData>();
}
public function addShape(bmd:BitmapData):void{
_shapes.push(bmd);
}
public function addNegativeShape(bmd:BitmapData):void{
_negative_shapes.push(bmd);
}
public function dispose():void
{
var i:int;
i = _shapes ? _shapes.length : 0;
while (--i > -1) {
_shapes[i].dispose();
}
i = _negative_shapes ? _negative_shapes.length : 0;
while (--i > -1) {
_negative_shapes[i].dispose();
}
_shapes = null;
_negative_shapes = null;
}
}
//}//package {
import __AS3__.vec.Vector;
import flash.events.Event;
import flash.events.EventDispatcher;
import flash.events.TimerEvent;
import flash.geom.Rectangle;
import flash.utils.Timer;
import flash.display.BitmapData;
import flash.display.BitmapDataChannel;
import flash.geom.Matrix;
import flash.geom.Point;
/*public*/ class BitmapShapeExtractor extends EventDispatcher {
private static var TEMP_DATA:BitmapData;
public static function extractShapes2(source_bmd:BitmapData, extraction_color:uint = 0xFF000000):ExtractedShapeCollection {
if (TEMP_DATA == null || TEMP_DATA.width != source_bmd.width || TEMP_DATA.height != source_bmd.height) {
if (TEMP_DATA) TEMP_DATA.dispose();
TEMP_DATA = new BitmapData(source_bmd.width, source_bmd.height, true, 0);
}
TEMP_DATA.fillRect(TEMP_DATA.rect, 0);
TEMP_DATA.threshold(source_bmd, source_bmd.rect, new Point(), "!=", extraction_color, 0, 0xFF0000FF, true);
return extractShapes(TEMP_DATA, extraction_color);
}
public static function extractShapes2Async(source_bmd:BitmapData, extraction_color:uint = 0xFF000000):BitmapShapeExtractor {
if (TEMP_DATA == null || TEMP_DATA.width != source_bmd.width || TEMP_DATA.height != source_bmd.height) {
if (TEMP_DATA) TEMP_DATA.dispose();
TEMP_DATA = new BitmapData(source_bmd.width, source_bmd.height, true, 0);
}
TEMP_DATA.fillRect(TEMP_DATA.rect, 0);
TEMP_DATA.threshold(source_bmd, source_bmd.rect, new Point(), "!=", extraction_color, 0, 0xFF0000FF, true);
var me:BitmapShapeExtractor = new BitmapShapeExtractor();
me.extractShapesAsync(TEMP_DATA, extraction_color);
return me;
}
public static function extractShapes(source_bmd:BitmapData,extraction_color:uint=0xFF000000):ExtractedShapeCollection{
var extracted:ExtractedShapeCollection=new ExtractedShapeCollection();
var positive_two_color:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0x00);
positive_two_color.draw(source_bmd);
positive_two_color=BitmapDataUtil.toMonoChrome(positive_two_color,0xFFFF0000);
if(!BitmapDataUtil.containsTransparentPixels(source_bmd)){
extracted.addShape(positive_two_color);
return extracted;
}
var temp:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0xFF0000FF);
temp.draw(positive_two_color);
var negative_two_color:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0xFFFF0000);
negative_two_color.copyChannel(temp,positive_two_color.rect,new Point(),BitmapDataChannel.BLUE,BitmapDataChannel.ALPHA);
extracted.shapes=extractShapesFromMonochrome(positive_two_color);
extracted.negative_shapes=extractShapesFromMonochrome(negative_two_color);
return extracted;
}
public function extractShapesAsync(source_bmd:BitmapData,extraction_color:uint=0xFF000000):void {
var positive_two_color:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0x00);
positive_two_color.draw(source_bmd);
positive_two_color=BitmapDataUtil.toMonoChrome(positive_two_color,0xFFFF0000);
if(!BitmapDataUtil.containsTransparentPixels(source_bmd)){
extracted.addShape(positive_two_color);
return;
}
var temp:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0xFF0000FF);
temp.draw(positive_two_color);
var negative_two_color:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0xFFFF0000);
negative_two_color.copyChannel(temp,positive_two_color.rect,new Point(),BitmapDataChannel.BLUE,BitmapDataChannel.ALPHA);
extractShapesFromMonochromeAsync(positive_two_color, extracted.shapes);
extractShapesFromMonochromeAsync(negative_two_color, extracted.negative_shapes);
return;
}
public static function extractShapesDoubleSize(source_bmd:BitmapData,extraction_color:uint=0xFF000000):ExtractedShapeCollection{
var extracted:ExtractedShapeCollection=new ExtractedShapeCollection();
var mono_chrome:BitmapData=new BitmapData(source_bmd.width,source_bmd.height,true,0x00);
mono_chrome.draw(source_bmd);
mono_chrome=BitmapDataUtil.toMonoChrome(mono_chrome,0xFFFF0000);
var positive_two_color:BitmapData=new BitmapData(source_bmd.width*2,source_bmd.height*2,true,0x00);
var m:Matrix=new Matrix();
m.scale(2,2);
positive_two_color.draw(mono_chrome,m);
positive_two_color=BitmapDataUtil.toMonoChrome(positive_two_color,0xFFFF0000);
mono_chrome.dispose();
mono_chrome=null;
if(!BitmapDataUtil.containsTransparentPixels(source_bmd)){
extracted.addShape(positive_two_color);
return extracted;
}
var temp:BitmapData=new BitmapData(positive_two_color.width,positive_two_color.height,true,0xFF0000FF);
temp.draw(positive_two_color);
var negative_two_color:BitmapData=new BitmapData(positive_two_color.width,positive_two_color.height,true,0xFFFF0000);
negative_two_color.copyChannel(temp,positive_two_color.rect,new Point(),BitmapDataChannel.BLUE,BitmapDataChannel.ALPHA);
extracted.shapes=extractShapesFromMonochrome(positive_two_color);
extracted.negative_shapes=extractShapesFromMonochrome(negative_two_color);
return extracted;
}
private var scan_y:uint;
private var bmd:BitmapData;
public var extracted:ExtractedShapeCollection = new ExtractedShapeCollection();
private var found:Vector.<BitmapData>;
private var timer:Timer = new Timer(30, 0);
public function BitmapShapeExtractor() {
timer.addEventListener(TimerEvent.TIMER, extractShapeFromMonochromeAsync_iterate);
}
protected function extractShapesFromMonochromeAsync(bmd:BitmapData, found:Vector.<BitmapData>):void {
scan_y = 0;
this.bmd = bmd
this.found = found;
timer.start();
}
protected function extractShapeFromMonochromeAsync_iterate(e:Event):void {
var non_trans:Point;;
non_trans=BitmapDataUtil.getFirstNonTransparentPixel(bmd,scan_y);
if (non_trans == null) return;
bmd.floodFill(non_trans.x, non_trans.y, 0xFF0000FF);
var copy_bmd:BitmapData = new BitmapData(bmd.width, bmd.height, true, 0xFFFF0000);
copy_bmd.copyChannel(bmd,bmd.rect,new Point(),BitmapDataChannel.BLUE, BitmapDataChannel.ALPHA);
bmd.floodFill(non_trans.x,non_trans.y,0x00000000);
found.push(copy_bmd);
scan_y = non_trans.y;
if (scan_y >= bmd.height) {
timer.stop();
dispatchEvent( new Event(Event.COMPLETE) );
}
}
protected static function extractShapesFromMonochrome(bmd:BitmapData):Vector.<BitmapData>{
var scan_y:uint=0;
var non_trans:Point;
var found:Vector.<BitmapData>=new Vector.<BitmapData>();
var copy_bmd:BitmapData;
var iterations:uint=0;
while(scan_y<bmd.height){
non_trans=BitmapDataUtil.getFirstNonTransparentPixel(bmd,scan_y);
if(non_trans==null)return found;
bmd.floodFill(non_trans.x, non_trans.y, 0xFF0000FF);
copy_bmd=new BitmapData(bmd.width,bmd.height,true,0xFFFF0000);
copy_bmd.copyChannel(bmd,bmd.rect,new Point(),BitmapDataChannel.BLUE, BitmapDataChannel.ALPHA);
bmd.floodFill(non_trans.x,non_trans.y,0x00000000);
found.push(copy_bmd);
scan_y=non_trans.y;
iterations++;
}
return found;
}
}
//}//package {
import flash.display.BitmapData;
import flash.geom.Matrix;
import flash.geom.Point;
import flash.utils.ByteArray;
import flash.utils.Dictionary;
/*public*/ class BiomePainter32
{
private var atlasTilesAcrossH:int;
private var atlasTilesAcrossV:int;
public var errorCount:int = 0;
private static var ROTATIONS:Vector.<int> = getRotations();
private static var READING_ORDER4:Vector.<uint> = new <uint>[
0, 1, 2, 3,
2, 0, 3, 1,
3, 2, 1, 0,
1, 3, 0, 2
];
private static var READING_ORDER_RGB:Vector.<uint> = new <uint>[
0, 0, 0,
0, 1, 2,
0, 1, 1,
0, 0, 1,
];
private static function getRotations():Vector.<int>
{
var vec:Vector.<int> = new Vector.<int>();
var mat:Matrix = new Matrix();
vec.push(mat.a, mat.b, mat.c, mat.d);
mat.rotate(.5*Math.PI);
vec.push(mat.a, mat.b, mat.c, mat.d);
mat.rotate(.5*Math.PI);
vec.push(mat.a, mat.b, mat.c, mat.d);
mat.rotate(.5*Math.PI);
vec.push(mat.a, mat.b, mat.c, mat.d);
return vec;
}
public function BiomePainter32(atlasTilesAcrossH:int, atlasTilesAcrossV:int)
{
if (!isValidTileAtlas(atlasTilesAcrossH, atlasTilesAcrossV)) {
throw new Error("Too many tiles exceeded 16! " + (atlasTilesAcrossH * atlasTilesAcrossV));
}
this.atlasTilesAcrossH = atlasTilesAcrossH;
this.atlasTilesAcrossV = atlasTilesAcrossV;
}
public function writeBmpData(data:ByteArray, tileBitmap:Vector.<uint>, tilesAcross:int):void {
data.writeShort(tilesAcross);
var len:int = tilesAcross * tilesAcross;
var color:uint;
for (var i:int = 0; i < len; i++) {
color = tileBitmap[i];
data.writeByte( (color & 0xFF0000) >> 16 );
data.writeByte( (color & 0xFF00) >> 8 );
data.writeByte( (color & 0xFF) );
}
}
public function getBmpData(data:ByteArray):BitmapData {
var tilesAcross:int = data.readShort();
var bmpData:BitmapData = new BitmapData(tilesAcross, tilesAcross, true, 0);
var color:uint;
for (var y:int = 0; y < tilesAcross; y++) {
for (var x:int = 0; x < tilesAcross; x++) {
color = 0xFF000000;
color |= (data.readUnsignedByte() << 16);
color |= (data.readUnsignedByte() << 8);
color |= data.readUnsignedByte();
bmpData.setPixel32(x, y, color);
}
}
return bmpData;
}
public function isValidTileAtlas(acrossH:int, acrossV:int):Boolean {
return (acrossH * acrossV) <= 16;
}
public function getUintFromIndices(ri:uint, gi:uint, bi:uint, ki:uint, ma:int, mb:int, mc:int, md:int):uint {
return getUint( uint(ri % atlasTilesAcrossH) / atlasTilesAcrossH, uint(ri / atlasTilesAcrossH) / atlasTilesAcrossV,
uint(gi % atlasTilesAcrossH) / atlasTilesAcrossH, uint(gi / atlasTilesAcrossH) / atlasTilesAcrossV,
uint(bi % atlasTilesAcrossH) / atlasTilesAcrossH, uint(bi / atlasTilesAcrossH) / atlasTilesAcrossV,
uint(ki % atlasTilesAcrossH) / atlasTilesAcrossH, 0,
ma, mb, mc, md);
}
public function getUintFromIndices2(ri:uint, gi:uint, bi:uint, ki:uint, mi:uint):uint {
var ma:int = ROTATIONS[mi * 4];
var mb:int = ROTATIONS[mi * 4+1];
var mc:int = ROTATIONS[mi * 4+2];
var md:int = ROTATIONS[mi * 4+3];
return getUintFromIndices(ri, gi, bi, ki, ma,mb,mc,md );
}
public function getUint(ru:Number, rv:Number, gu:Number, gv:Number, bu:Number, bv:Number, ku:Number, kv:Number, ma:int, mb:int, mc:int, md:int):uint {
ma++; mb++; mc++; md++;
if (ku == 0) {
kv = 0;
}
else {
kv = Math.floor( Math.random() * 5 );
if (kv < 4) {
kv *= .25;
}
else {
kv = ku;
ku = 0;
}
}
return ( 0xFF000000 | (uint(ru * 4) << 22) | (uint(rv * 4) << 20) |
(uint(gu * 4) << 18) | (uint(gv * 4) << 16) |
(uint(bu * 4) << 14) | (uint(bv * 4) << 12) |
(uint(ku * 4) << 10) | (uint(kv * 4) << 8) |
(uint(ma) << 6) |
(uint(mb) << 4) |
(uint(mc) << 2) |
(uint(md)) );
}
public function getUint16bits(color:uint):uint {
var r:uint = (color & 0xFF0000) >> 16;
var g:uint = (color & 0xFF00) >> 8;
var b:uint = (color & 0xFF);
var ru:uint = (r & 192) >> 6;
var rv:uint = (r & 48) >> 4;
var gu:uint = (r & 12) >> 2;
var gv:uint = (r & 3);
var bu:uint = (g & 192) >> 6;
var bv:uint = (g & 48) >> 4;
var ku:int = (g & 12) >> 2;
var kv:int = (g & 3);
if (ku == 0 && kv > 0) {
ku = kv;
}
var ma:int = (b & 192) >> 6;
var mb:int = (b & 48) >> 4;
var mc:int = (b & 12) >> 2;
var md:int = (b & 3);
ma--; mb--; mc--; md--;
var tindex:int = ma === 1 ? 0 : mc === -1 ? 1 : ma === -1 ? 2 : 3;
var readRGB:Vector.<uint> = READING_ORDER_RGB;
var readSquares:Vector.<uint> = READING_ORDER4;
var u:uint;
var v:uint;
var rr:int;
var result:uint = 0xFF000000;
var i:uint;
i = (readSquares[tindex * 4]); if (i > 2) i = 2;
i = ku * 3 + i ;
rr = readRGB[i];
u = rr === 0 ? ru : rr === 1 ? gu : bu;
v = rr === 0 ? rv : rr === 1 ? gv : bv;
result |= uint(v * .25 * atlasTilesAcrossV * atlasTilesAcrossH + u * .25 * atlasTilesAcrossH) << 0;
i = (readSquares[tindex * 4 + 1]); if (i > 2) i = 2;
i = ku * 3 + i;
rr = readRGB[i];
u = rr === 0 ? ru : rr === 1 ? gu : bu;
v = rr === 0 ? rv : rr === 1 ? gv : bv;
result |= uint(v * .25 * atlasTilesAcrossV * atlasTilesAcrossH + u * .25 * atlasTilesAcrossH) << 4;
i = (readSquares[tindex * 4 + 2]); if (i > 2) i = 2;
i = ku * 3 + i;
rr = readRGB[i];
u = rr === 0 ? ru : rr === 1 ? gu : bu;
v = rr === 0 ? rv : rr === 1 ? gv : bv;
result |= uint(v * .25 * atlasTilesAcrossV * atlasTilesAcrossH + u * .25 * atlasTilesAcrossH) << 8;
i = (readSquares[tindex * 4 + 3]); if (i > 2) i = 2;
i = ku * 3 + i;
rr = readRGB[i];
u = rr === 0 ? ru : rr === 1 ? gu : bu;
v = rr === 0 ? rv : rr === 1 ? gv : bv;
result |= uint(v * .25 * atlasTilesAcrossV * atlasTilesAcrossH + u * .25 * atlasTilesAcrossH) << 12;
return result;
}
private function getIdentityValue(s1:uint, s2:uint, s3:uint):uint {
var result:uint = 0xFF000000;
result |= (s1 << 0);
result |= (s2 << 4);
result |= (s3 << 8);
result |= (s3 << 12);
return result;
}
private function identifyTransform(s1:uint, s2:uint, s3:uint, layout16:uint):uint {
var result:uint;
result = 0xFF000000;
result |= (s1 << 0);
result |= (s2 << 4);
result |= (s3 << 8);
result |= (s3 << 12);
if (result == layout16) return 0;
result = 0xFF000000;
result |= (s3 << 0);
result |= (s1 << 4);
result |= (s3 << 8);
result |= (s2 << 12);
if (result == layout16) return 1;
result = 0xFF000000;
result |= (s3 << 0);
result |= (s3 << 4);
result |= (s2 << 8);
result |= (s1 << 12);
if (result == layout16) return 2;
result = 0xFF000000;
result |= (s2 << 0);
result |= (s3 << 4);
result |= (s1 << 8);
result |= (s3 << 12);
if (result == layout16) return 3;
return 0xFFFFFFFF;
}
private function setUint16bits(result:uint):uint {
var dict:Dictionary = new Dictionary();
var val:uint;
var u:Number;
var v:Number;
var readOrderRGB:Vector.<uint> = READING_ORDER_RGB;
var readOrderSquares:Vector.<uint> = READING_ORDER4;
var mValues:Vector.<int> = ROTATIONS;
var m:int;
val = result & 0xF;
if ( dict[val] == null) dict[val] = 1
else dict[val]++;
val = (result & 0xF0) >> 4;
if ( dict[val] == null) dict[val] = 1
else dict[val]++;
val =(result & 0xF00) >> 8;
if ( dict[val] == null) dict[val] = 1
else dict[val]++;
val = (result & 0xF000) >> 12;
if ( dict[val] == null) dict[val] = 1
else dict[val]++;
var count:int = 0;
var multiplier:int = 1;
for (var p:* in dict) {
multiplier *= dict[p]
count++;
}
var unique:int;
var unique2:int;
var swapVal:uint;
var swapVal2:uint;
var swappables:uint;
var ti:uint;
if (count != 1) {
var blendIndex:int = multiplier - 1;
if (blendIndex === 0) {
throw new Error("This should never happen under count!=1 case!")
}
else if (blendIndex === 1) {
unique = -1;
count = 0;
swappables = 0xFF000000;
for (p in dict) {
if (dict[p] === 2) {
unique = p;
}
else {
swappables |= (uint(p) << ((count++) << 2));
}
}
if (unique < 0) throw new Error("Could not find unique under blend index 1");
ti = identifyTransform( swapVal=(swappables & 0xF), swapVal2=((swappables & 0xF0) >> 4), unique, result);
if (ti ===0xFFFFFFFF) ti = identifyTransform( swapVal=(((swappables & 0xF0) >> 4)), swapVal2=(swappables & 0xF), unique, result);
if (ti === 0xFFFFFFFF) {
errorCount++;
return 0xFFFFFFFF;
throw new Error("Could not find valid transform index for blendIndex 1"+":"+getIdentityValue(swapVal, swapVal2, unique) + ", "+result + ", s1:"+swapVal + " s2:"+swapVal2 + " u:"+unique);
}
ti *= 4;
return getUintFromIndices(swapVal, swapVal2, unique, blendIndex, mValues[ti], mValues[ti + 1], mValues[ti + 2], mValues[ti + 3]);
}
else if (blendIndex === 2) {
unique = -1;
unique2 = -1;
count = 0;
for (p in dict) {
if (dict[p] === 3) {
unique2 = p;
}
else if (dict[p] === 1) {
unique = p;
}
}
if (unique < 0 || unique2 < 0) throw new Error("Could not find uniques under blend index 2");
ti = identifyTransform(unique, unique2, unique2, result);
if (ti === 0xFFFFFFFF) {
errorCount++;
return 0xFFFFFFFF;
throw new Error("Could not find valid transform index for blendIndex 2");
}
ti *= 4;
return getUintFromIndices(unique, unique2, 0, blendIndex, mValues[ti], mValues[ti + 1], mValues[ti + 2], mValues[ti + 3]);
}
else {
count = 0;
swappables = 0xFF000000;
for (p in dict) {
swappables |= ( uint(p) << ((count++) << 2) );
}
ti = identifyTransform( swapVal = (swappables & 0xF), (swappables & 0xF), swapVal2=(((swappables & 0xF0) >> 4)), result);
if (ti ===0xFFFFFFFF) ti = identifyTransform( swapVal=(((swappables & 0xF0) >> 4)), (((swappables & 0xF0) >> 4)), swapVal2=(swappables & 0xF), result);
if (ti === 0xFFFFFFFF) {
errorCount++;
return 0xFFFFFFFF;
throw new Error("Could not find valid transform index for blendIndex "+blendIndex+":"+getIdentityValue(swapVal, swapVal, swapVal2) + ", "+result + ", s1:"+swapVal + " s2:"+swapVal2);
}
ti *= 4;
return getUintFromIndices(swapVal, swapVal2, 0, blendIndex, mValues[ti], mValues[ti + 1], mValues[ti + 2], mValues[ti + 3]);
}
}
else {
v = int(val / atlasTilesAcrossH) / atlasTilesAcrossV;
u = int(val % atlasTilesAcrossH) / atlasTilesAcrossH;
return getUint(u, v, u, v, u, v, 0, 0, mValues[0], mValues[1], mValues[2], mValues[3]);
}
throw new Error("Failed to get valid value case!");
return 0xFFFFFFFF;
}
public function paintToTileMap(tileMap:Vector.<uint>, tilesAcross:int, tileIndex:uint, x:int, y:int):void {
var xi:int;
var yi:int;
var val16:uint;
var testVal:uint;
tileMap[y * tilesAcross + x] = getUintFromIndices(tileIndex, tileIndex, tileIndex, 0, 1, 0, 0, 1);
var lastIndex:int = -1;
xi = x -1;
yi = y - 1;
if (xi >= 0 && xi < tilesAcross && yi >= 0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xF000);
val16 |= (tileIndex << 12);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x;
yi = y - 1;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xFF00);
val16 |= (tileIndex << 12);
val16 |= (tileIndex << 8);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x +1;
yi = y -1;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
testVal = setUint16bits(val16);
val16 &= ~(0xF00);
val16 |= (tileIndex << 8);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x - 1;
yi = y;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xF0F0);
val16 |= (tileIndex << 4);
val16 |= (tileIndex << 12);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x +1;
yi = y;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xF0F);
val16 |= tileIndex;
val16 |= (tileIndex << 8);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x -1;
yi = y + 1;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xF0);
val16 |= (tileIndex << 4);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x;
yi = y + 1;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xFF);
val16 |= (tileIndex << 4);
val16 |= (tileIndex);
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
xi = x + 1;
yi = y + 1;
if (xi >= 0 && xi < tilesAcross && yi >=0 && yi < tilesAcross) {
val16 = getUint16bits( tileMap[yi * tilesAcross + xi] );
val16 &= ~(0xF);
val16 |= tileIndex;
testVal = setUint16bits(val16);
if (testVal != 0xFFFFFFFF) tileMap[yi * tilesAcross + xi] = testVal;
}
}
}
//package com.nodename.Delaunay
//{
//public
final class LR
{
public static const LEFT:LR = new LR(PrivateConstructorEnforcer, "left");
public static const RIGHT:LR = new LR(PrivateConstructorEnforcer, "right");
private var _name:String;
public function LR(lock:Class, name:String)
{
if (lock != PrivateConstructorEnforcer)
{
throw new Error("Illegal constructor access");
}
_name = name;
}
public static function other(leftRight:LR):LR
{
return leftRight == LEFT ? RIGHT : LEFT;
}
public function toString():String
{
return _name;
}
}
//}
//}//package {
//import com.nodename.geom.LineSegment;
import flash.display.BitmapData;
import flash.display.CapsStyle;
import flash.display.Graphics;
import flash.display.LineScaleMode;
import flash.display.Sprite;
import flash.geom.Point;
import flash.geom.Rectangle;
import flash.utils.Dictionary;
import flash.geom.Point;
/*public*/ class LineSegment extends Object
{
public static function compareLengths_MAX(segment0:LineSegment, segment1:LineSegment):Number
{
var length0:Number = Point.distance(segment0.p0, segment0.p1);
var length1:Number = Point.distance(segment1.p0, segment1.p1);
if (length0 < length1)
{
return 1;
}
if (length0 > length1)
{
return -1;
}
return 0;
}
public static function compareLengths(edge0:LineSegment, edge1:LineSegment):Number
{
return - compareLengths_MAX(edge0, edge1);
}
public var p0:Point;
public var p1:Point;
public function LineSegment(p0:Point, p1:Point)
{
super();
this.p0 = p0;
this.p1 = p1;
}
}
//}
//package com.nodename.Delaunay
//{
import __AS3__.vec.Vector;
import flash.utils.Dictionary;
//package {
//import com.nodename.geom.Circle;
//import com.nodename.geom.LineSegment;
import flash.display.BitmapData;
import flash.geom.Point;
import flash.geom.Rectangle;
import flash.utils.Dictionary;
/*public*/ class Voronoi
{
private var _sites:SiteList;
private var _sitesIndexedByLocation:Dictionary;
private var _triangles:Vector.<Triangle>;
private var _edges:Vector.<DEdge>;
private var _plotBounds:Rectangle;
public function get plotBounds():Rectangle
{
return _plotBounds;
}
public function dispose():void
{
var i:int, n:int;
if (_sites)
{
_sites.dispose();
_sites = null;
}
if (_triangles)
{
n = _triangles.length;
for (i = 0; i < n; ++i)
{
_triangles[i].dispose();
}
_triangles.length = 0;
_triangles = null;
}
if (_edges)
{
n = _edges.length;
for (i = 0; i < n; ++i)
{
_edges[i].dispose();
}
_edges.length = 0;
_edges = null;
}
_plotBounds = null;
_sitesIndexedByLocation = null;
}
public function Voronoi(points:Vector.<Point>, colors:Vector.<uint>, plotBounds:Rectangle)
{
_sites = new SiteList();
_sitesIndexedByLocation = new Dictionary(true);
addSites(points, colors);
_plotBounds = plotBounds;
_triangles = new Vector.<Triangle>();
_edges = new Vector.<DEdge>();
fortunesAlgorithm();
}
private function addSites(points:Vector.<Point>, colors:Vector.<uint>):void
{
var length:uint = points.length;
for (var i:uint = 0; i < length; ++i)
{
addSite(points[i], colors ? colors[i] : 0, i);
}
}
private function addSite(p:Point, color:uint, index:int):void
{
var weight:Number = Math.random() * 100;
var site:Site = Site.create(p, index, weight, color);
_sites.push(site);
_sitesIndexedByLocation[p] = site;
}
public function edges():Vector.<DEdge>
{
return _edges;
}
public function region(p:Point):Vector.<Point>
{
var site:Site = _sitesIndexedByLocation[p];
if (!site)
{
return new Vector.<Point>();
}
return site.region(_plotBounds);
}
public function neighborSitesForSite(coord:Point):Vector.<Point>
{
var points:Vector.<Point> = new Vector.<Point>();
var site:Site = _sitesIndexedByLocation[coord];
if (!site)
{
return points;
}
var sites:Vector.<Site> = site.neighborSites();
var neighbor:Site;
for each (neighbor in sites)
{
points.push(neighbor.coord);
}
return points;
}
public function circles():Vector.<Circle>
{
return _sites.circles();
}
public function voronoiBoundaryForSite(coord:Point):Vector.<LineSegment>
{
return visibleLineSegments(selectEdgesForSitePoint(coord, _edges));
}
public function delaunayLinesForSite(coord:Point):Vector.<LineSegment>
{
return delaunayLinesForEdges(selectEdgesForSitePoint(coord, _edges));
}
public function voronoiDiagram():Vector.<LineSegment>
{
return visibleLineSegments(_edges);
}
public function delaunayTriangulation(keepOutMask:BitmapData = null):Vector.<LineSegment>
{
return delaunayLinesForEdges(selectNonIntersectingEdges(keepOutMask, _edges));
}
public function hull():Vector.<LineSegment>
{
return delaunayLinesForEdges(hullEdges());
}
private function hullEdges():Vector.<DEdge>
{
return _edges.filter(myTest);
function myTest(edge:DEdge, index:int, vector:Vector.<DEdge>):Boolean
{
return (edge.isPartOfConvexHull());
}
}
public function hullPointsInOrder():Vector.<Point>
{
var hullEdges:Vector.<DEdge> = hullEdges();
var points:Vector.<Point> = new Vector.<Point>();
if (hullEdges.length == 0)
{
return points;
}
var reorderer:EdgeReorderer = new EdgeReorderer(hullEdges, Site);
hullEdges = reorderer.edges;
var orientations:Vector.<LR> = reorderer.edgeOrientations;
reorderer.dispose();
var orientation:LR;
var n:int = hullEdges.length;
for (var i:int = 0; i < n; ++i)
{
var edge:DEdge = hullEdges[i];
orientation = orientations[i];
points.push(edge.site(orientation).coord);
}
return points;
}
function kruskal(lineSegments:Vector.<LineSegment>, type:String = "minimum"):Vector.<LineSegment>
{
var nodes:Dictionary = new Dictionary(true);
var mst:Vector.<LineSegment> = new Vector.<LineSegment>();
var nodePool:Vector.<Node> = Node.pool;
switch (type)
{
// note that the compare functions are the reverse of what you'd expect
// because (see below) we traverse the lineSegments in reverse order for speed
case "maximum":
lineSegments.sort(LineSegment.compareLengths);
break;
default:
lineSegments.sort(LineSegment.compareLengths_MAX);
break;
}
for (var i:int = lineSegments.length; --i > -1;)
{
var lineSegment:LineSegment = lineSegments[i];
var node0:Node = nodes[lineSegment.p0];
var rootOfSet0:Node;
if (node0 == null)
{
node0 = nodePool.length > 0 ? nodePool.pop() : new Node();
// intialize the node:
rootOfSet0 = node0.parent = node0;
node0.treeSize = 1;
nodes[lineSegment.p0] = node0;
}
else
{
rootOfSet0 = find(node0);
}
var node1:Node = nodes[lineSegment.p1];
var rootOfSet1:Node;
if (node1 == null)
{
node1 = nodePool.length > 0 ? nodePool.pop() : new Node();
// intialize the node:
rootOfSet1 = node1.parent = node1;
node1.treeSize = 1;
nodes[lineSegment.p1] = node1;
}
else
{
rootOfSet1 = find(node1);
}
if (rootOfSet0 != rootOfSet1) // nodes not in same set
{
mst.push(lineSegment);
// merge the two sets:
var treeSize0:int = rootOfSet0.treeSize;
var treeSize1:int = rootOfSet1.treeSize;
if (treeSize0 >= treeSize1)
{
// set0 absorbs set1:
rootOfSet1.parent = rootOfSet0;
rootOfSet0.treeSize += treeSize1;
}
else
{
// set1 absorbs set0:
rootOfSet0.parent = rootOfSet1;
rootOfSet1.treeSize += treeSize0;
}
}
}
for each (var node:Node in nodes)
{
nodePool.push(node);
}
return mst;
}
function find(node:Node):Node
{
if (node.parent == node)
{
return node;
}
else
{
var root:Node = find(node.parent);
// this line is just to speed up subsequent finds by keeping the tree depth low:
node.parent = root;
return root;
}
}
public function spanningTree(type:String = "minimum", keepOutMask:BitmapData = null):Vector.<LineSegment>
{
var edges:Vector.<DEdge> = selectNonIntersectingEdges(keepOutMask, _edges);
var segments:Vector.<LineSegment> = delaunayLinesForEdges(edges);
return kruskal(segments, type);
}
public function regions():Vector.<Vector.<Point>>
{
return _sites.regions(_plotBounds);
}
public function siteColors(referenceImage:BitmapData = null):Vector.<uint>
{
return _sites.siteColors(referenceImage);
}
public function nearestSitePoint(proximityMap:BitmapData, x:Number, y:Number):Point
{
return _sites.nearestSitePoint(proximityMap, x, y);
}
public function siteCoords():Vector.<Point>
{
return _sites.siteCoords();
}
private function fortunesAlgorithm():void
{
var newSite:Site, bottomSite:Site, topSite:Site, tempSite:Site;
var v:Vertex, vertex:Vertex;
var newintstar:Point;
var leftRight:LR;
var lbnd:Halfedge, rbnd:Halfedge, llbnd:Halfedge, rrbnd:Halfedge, bisector:Halfedge;
var edge:DEdge;
var dataBounds:Rectangle = _sites.getSitesBounds();
var sqrt_nsites:int = int(Math.sqrt(_sites.length + 4));
var heap:HalfedgePriorityQueue = new HalfedgePriorityQueue(dataBounds.y, dataBounds.height, sqrt_nsites);
var edgeList:EdgeList = new EdgeList(dataBounds.x, dataBounds.width, sqrt_nsites);
var halfEdges:Vector.<Halfedge> = new Vector.<Halfedge>();
var vertices:Vector.<Vertex> = new Vector.<Vertex>();
var bottomMostSite:Site = _sites.next();
newSite = _sites.next();
for (;;)
{
if (heap.empty() == false)
{
newintstar = heap.min();
}
if (newSite != null
&& (heap.empty() || compareByYThenX(newSite, newintstar) < 0))
{
lbnd = edgeList.edgeListLeftNeighbor(newSite.coord);
rbnd = lbnd.edgeListRightNeighbor;
bottomSite = rightRegion(lbnd);
edge = DEdge.createBisectingEdge(bottomSite, newSite);
_edges.push(edge);
bisector = Halfedge.create(edge, LR.LEFT);
halfEdges.push(bisector);
edgeList.insert(lbnd, bisector);
if ((vertex = Vertex.intersect(lbnd, bisector)) != null)
{
vertices.push(vertex);
heap.remove(lbnd);
lbnd.vertex = vertex;
lbnd.ystar = vertex.y + newSite.dist(vertex);
heap.insert(lbnd);
}
lbnd = bisector;
bisector = Halfedge.create(edge, LR.RIGHT);
halfEdges.push(bisector);
edgeList.insert(lbnd, bisector);
if ((vertex = Vertex.intersect(bisector, rbnd)) != null)
{
vertices.push(vertex);
bisector.vertex = vertex;
bisector.ystar = vertex.y + newSite.dist(vertex);
heap.insert(bisector);
}
newSite = _sites.next();
}
else if (heap.empty() == false)
{
lbnd = heap.extractMin();
llbnd = lbnd.edgeListLeftNeighbor;
rbnd = lbnd.edgeListRightNeighbor;
rrbnd = rbnd.edgeListRightNeighbor;
bottomSite = leftRegion(lbnd);
topSite = rightRegion(rbnd);
v = lbnd.vertex;
v.setIndex();
lbnd.edge.setVertex(lbnd.leftRight, v);
rbnd.edge.setVertex(rbnd.leftRight, v);
edgeList.remove(lbnd);
heap.remove(rbnd);
edgeList.remove(rbnd);
leftRight = LR.LEFT;
if (bottomSite.y > topSite.y)
{
tempSite = bottomSite; bottomSite = topSite; topSite = tempSite; leftRight = LR.RIGHT;
}
edge = DEdge.createBisectingEdge(bottomSite, topSite);
_edges.push(edge);
bisector = Halfedge.create(edge, leftRight);
halfEdges.push(bisector);
edgeList.insert(llbnd, bisector);
edge.setVertex(LR.other(leftRight), v);
if ((vertex = Vertex.intersect(llbnd, bisector)) != null)
{
vertices.push(vertex);
heap.remove(llbnd);
llbnd.vertex = vertex;
llbnd.ystar = vertex.y + bottomSite.dist(vertex);
heap.insert(llbnd);
}
if ((vertex = Vertex.intersect(bisector, rrbnd)) != null)
{
vertices.push(vertex);
bisector.vertex = vertex;
bisector.ystar = vertex.y + bottomSite.dist(vertex);
heap.insert(bisector);
}
}
else
{
break;
}
}
heap.dispose();
edgeList.dispose();
for each (var halfEdge:Halfedge in halfEdges)
{
halfEdge.reallyDispose();
}
halfEdges.length = 0;
for each (edge in _edges)
{
edge.clipVertices(_plotBounds);
}
for each (vertex in vertices)
{
vertex.dispose();
}
vertices.length = 0;
function leftRegion(he:Halfedge):Site
{
var edge:DEdge = he.edge;
if (edge == null)
{
return bottomMostSite;
}
return edge.site(he.leftRight);
}
function rightRegion(he:Halfedge):Site
{
var edge:DEdge = he.edge;
if (edge == null)
{
return bottomMostSite;
}
return edge.site(LR.other(he.leftRight));
}
}
internal static function compareByYThenX(s1:Site, s2:*):Number
{
if (s1.y < s2.y) return -1;
if (s1.y > s2.y) return 1;
if (s1.x < s2.x) return -1;
if (s1.x > s2.x) return 1;
return 0;
}
}
//}
//package {
/*public*/ class Watersheds {
public var lowestCorner:Array = [];
public var watersheds:Array = [];
public function createWatersheds(map:Map):void {
var p:Center, q:Corner, s:Corner;
for each (p in map.centers) {
s = null;
for each (q in p.corners) {
if (s == null || q.elevation < s.elevation) {
s = q;
}
}
lowestCorner[p.index] = (s == null)? -1 : s.index;
watersheds[p.index] = (s == null)? -1 : (s.watershed == null)? -1 : s.watershed.index;
}
}
}
//}
//package {
import flash.geom.Point;
/*public*/ class Edge {
public var index:int;
public var d0:Center, d1:Center;
public var v0:Corner, v1:Corner;
public var midpoint:Point;
public var river:int;
}
//}
//package {
import flash.geom.Point;
/*public*/ class Center {
public var index:int;
public var point:Point;
public var water:Boolean;
public var ocean:Boolean;
public var coast:Boolean;
public var border:Boolean;
public var biome:String;
public var elevation:Number;
public var moisture:Number;
public var neighbors:Vector.<Center>;
public var borders:Vector.<Edge>;
public var corners:Vector.<Corner>;
}
//}
//package {
import flash.geom.Point;
/*public*/ class Corner {
public var index:int;
public var point:Point;
public var ocean:Boolean;
public var water:Boolean;
public var coast:Boolean;
public var border:Boolean;
public var elevation:Number;
public var moisture:Number;
public var touches:Vector.<Center>;
public var protrudes:Vector.<Edge>;
public var adjacent:Vector.<Corner>;
public var river:int;
public var downslope:Corner;
public var watershed:Corner;
public var watershed_size:int;
}
//}
//package {
/*public*/ class Lava {
static public var FRACTION_LAVA_FISSURES:Number = 0.2;
public var lava:Array = [];
public function createLava(map:Map, randomDouble:Function):void {
var edge:Edge;
for each (edge in map.edges) {
if (!edge.river && !edge.d0.water && !edge.d1.water
&& edge.d0.elevation > 0.8 && edge.d1.elevation > 0.8
&& edge.d0.moisture < 0.3 && edge.d1.moisture < 0.3
&& randomDouble() < FRACTION_LAVA_FISSURES) {
lava[edge.index] = true;
}
}
}
}
//}
//package {
//import com.sakri.utils.BitmapDataUtil;
//import com.sakri.utils.BitmapShapeExtractor;
//import com.sakri.utils.ExtractedShapeCollection;
import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.display.Shape;
import flash.display.Sprite;
import flash.events.Event;
import flash.events.EventDispatcher;
import flash.geom.Point;
import flash.text.TextField;
import flash.utils.ByteArray;
import flash.utils.Dictionary;
import jp.progression.commands.Func;
import jp.progression.commands.lists.LoaderList;
import jp.progression.commands.lists.SerialList;
import jp.progression.commands.Wait;
/*public*/ class BiomeApplicator32 extends EventDispatcher
{
public var tileBitMap:Vector.<uint>;
public var tileMap:BitmapData;
public var extractedShapes:ExtractedShapeCollection;
public var painter:BiomePainter32;
public var tilesAcross:int;
public var textureList:Array = [
["d"], ["OCEAN"],
["d"],["RIVER","MARSH"],
["f"],["SUBTROPICAL_DESERT"],
["h"],["TEMPERATE_DESERT"],
["q"],["SHRUBLAND","GRASSLAND"],
["n"],["TEMPERATE_RAIN_FOREST","TEMPERATE_DECIDUOUS_FOREST"],
["s"],["COAST","LAKESHORE","LAKE"],
["r"], ["LAVA","BEACH"],
["c"], ["TROPICAL_SEASONAL_FOREST","TROPICAL_RAIN_FOREST"],
["k"], ["TAIGA","SCORCHED"],
["g"], ["BARE", "ROAD1", "ROAD2", "ROAD3", "BRIDGE"],
["i"], ["SNOW","TUNDRA","ICE"]
];
public var atlasReadString:String = "dfhqnsrckgi";
public var atlasTilesAcrossH:int = 4;
public var atlasTilesAcrossV:int = 4;
private var textureDict:Dictionary;
public static var LOOKUP_STRINGS:Vector.<String>;
private var _serialList:SerialList;
public function BiomeApplicator32()
{
displayField.autoSize = "left";
}
private var counter:int = 0;
private function getDummyColor(colorDebug:*):int {
throw new Error("Texture not supported !"+colorDebug);
var result:int = counter + 1;
counter++;
if (counter >= textureList.length) counter = 0;
return result;
}
public function processBiomes(b:ByteArray, tilesAcross:int, testSpr:Sprite=null):void {
}
private var _currentLayerIndex:int;
private function completedLayer():void
{
extractedShapes.dispose();
}
private function scanlineCheck(shape:BitmapData, y:int, colorDisc:uint = 0):Boolean {
for (var x:int = 0; x < shape.width; x++) {
if ( shape.getPixel(x, y) != colorDisc ) {
if (shape.getPixel(shape.width - 1, y) != colorDisc) {
throw new Error("FAILED2: Not empty at end of line!");
}
return true;
}
};
throw new Error("FAILED");
return false;
}
private function notifyComplete():void
{
tileMap.setVector( tileMap.rect, tileBitMap);
displayField.text = "Process complete:" +biomeCount + " biomes. "+painter.errorCount+" potential errors.";
dispatchEvent( new Event(Event.COMPLETE) );
}
public var displayField:TextField = new TextField();
public var biomeCount:int=0;
private var count:int = 0;
private var _serialColorIndex:int;
private var _serialAtlasIndex:int;
public var testbitMap:BitmapData;
private function initProcess(tilesAcross:int):void
{
painter = new BiomePainter32(atlasTilesAcrossH, atlasTilesAcrossV);
if (LOOKUP_STRINGS == null) LOOKUP_STRINGS = mapgen2.getExportIndexLookup();
if (textureDict == null) calculateTextureDictionary();
this.tilesAcross = tilesAcross;
}
public function getNewBitmapData():BitmapData {
var bmpData:BitmapData = new BitmapData(tilesAcross, tilesAcross, false, 0);
bmpData.setVector(bmpData.rect, tileBitMap);
return bmpData;
}
public function calculateTextureDictionary():void
{
textureDict = new Dictionary();
var len:int = textureList.length;
var count:int = 1;
for (var i:int = 0; i < len; i+=2) {
var keys:Array = textureList[i + 1];
for each(var k:String in keys) {
textureDict[k] =count;
}
if (textureList[i][0] is String) {
var atlasIndex:int = atlasReadString.indexOf( textureList[i][0] );
if (atlasIndex < 0) throw new Error("Could not find atlas index from string under texture dictionary!");
textureList[i][0] = atlasIndex;
}
count++;
}
}
public function dispose():void
{
tileMap.dispose();
extractedShapes.dispose();
}
public function get serialList():SerialList
{
return _serialList;
}
}
//}
//package {
import flash.geom.*;
import flash.utils.Dictionary;
import flash.utils.getTimer;
import flash.system.System;
//import com.nodename.geom.LineSegment;
//import com.nodename.Delaunay.Voronoi;
//import de.polygonal.math.PM_PRNG;
/*public*/ class IslandShape {
static public var ISLAND_FACTOR:Number = 1.07;
static public function makeRadial(seed:int):Function {
var islandRandom:PM_PRNG = new PM_PRNG();
islandRandom.seed = seed;
var bumps:int = islandRandom.nextIntRange(1, 6);
var startAngle:Number = islandRandom.nextDoubleRange(0, 2*Math.PI);
var dipAngle:Number = islandRandom.nextDoubleRange(0, 2*Math.PI);
var dipWidth:Number = islandRandom.nextDoubleRange(0.2, 0.7);
function inside(q:Point):Boolean {
var angle:Number = Math.atan2(q.y, q.x);
var length:Number = 0.5 * (Math.max(Math.abs(q.x), Math.abs(q.y)) + q.length);
var r1:Number = 0.5 + 0.40*Math.sin(startAngle + bumps*angle + Math.cos((bumps+3)*angle));
var r2:Number = 0.7 - 0.20*Math.sin(startAngle + bumps*angle - Math.sin((bumps+2)*angle));
if (Math.abs(angle - dipAngle) < dipWidth
|| Math.abs(angle - dipAngle + 2*Math.PI) < dipWidth
|| Math.abs(angle - dipAngle - 2*Math.PI) < dipWidth) {
r1 = r2 = 0.2;
}
return (length < r1 || (length > r1*ISLAND_FACTOR && length < r2));
}
return inside;
}
static public function makePerlin(seed:int):Function {
var perlin:BitmapData = new BitmapData(256, 256);
perlin.perlinNoise(64, 64, 8, seed, false, true);
return function (q:Point):Boolean {
var c:Number = (perlin.getPixel(int((q.x+1)*128), int((q.y+1)*128)) & 0xff) / 255.0;
return c > (0.3+0.3*q.length*q.length);
};
}
static public function makeSquare(seed:int):Function {
return function (q:Point):Boolean {
return true;
};
}
static public function makeBlob(seed:int):Function {
return function(q:Point):Boolean {
var eye1:Boolean = new Point(q.x-0.2, q.y/2+0.2).length < 0.05;
var eye2:Boolean = new Point(q.x+0.2, q.y/2+0.2).length < 0.05;
var body:Boolean = q.length < 0.8 - 0.18*Math.sin(5*Math.atan2(q.y, q.x));
return body && !eye1 && !eye2;
};
}
}
//package {
/*public*/ class Roads {
public var road:Array;
public var roadConnections:Array;
public function Roads() {
road = [];
roadConnections = [];
}
public function createRoads(map:Map):void {
var queue:Array = [];
var p:Center, q:Corner, r:Center, edge:Edge, newLevel:int;
var elevationThresholds:Array = [0, 0.05, 0.37, 0.64];
var cornerContour:Array = [];
var centerContour:Array = [];
for each (p in map.centers) {
if (p.coast || p.ocean) {
centerContour[p.index] = 1;
queue.push(p);
}
}
while (queue.length > 0) {
p = queue.shift();
for each (r in p.neighbors) {
newLevel = centerContour[p.index] || 0;
while (r.elevation > elevationThresholds[newLevel] && !r.water) {
newLevel += 1;
}
if (newLevel < (centerContour[r.index] || 999)) {
centerContour[r.index] = newLevel;
queue.push(r);
}
}
}
for each (p in map.centers) {
for each (q in p.corners) {
cornerContour[q.index] = Math.min(cornerContour[q.index] || 999,
centerContour[p.index] || 999);
}
}
for each (p in map.centers) {
for each (edge in p.borders) {
if (edge.v0 && edge.v1
&& cornerContour[edge.v0.index] != cornerContour[edge.v1.index]) {
road[edge.index] = Math.min(cornerContour[edge.v0.index],
cornerContour[edge.v1.index]);
if (!roadConnections[p.index]) {
roadConnections[p.index] = [];
}
roadConnections[p.index].push(edge);
}
}
}
}
}
//}
//package com.nodename.Delaunay
//{
import flash.display.BitmapData;
import flash.display.CapsStyle;
import flash.display.Graphics;
import flash.display.LineScaleMode;
import flash.display.Sprite;
import flash.geom.Point;
import flash.geom.Rectangle;
import flash.utils.Dictionary;
/**
* The line segment connecting the two Sites is part of the Delaunay triangulation;
* the line segment connecting the two Vertices is part of the Voronoi diagram
* @author ashaw
*
*/
//public
final class DEdge
{
private static var _pool:Vector.<DEdge> = new Vector.<DEdge>();
/**
* This is the only way to create a new DEdge
* @param site0
* @param site1
* @return
*
*/
internal static function createBisectingEdge(site0:Site, site1:Site):DEdge
{
var dx:Number, dy:Number, absdx:Number, absdy:Number;
var a:Number, b:Number, c:Number;
dx = site1.x - site0.x;
dy = site1.y - site0.y;
absdx = dx > 0 ? dx : -dx;
absdy = dy > 0 ? dy : -dy;
c = site0.x * dx + site0.y * dy + (dx * dx + dy * dy) * 0.5;
if (absdx > absdy)
{
a = 1.0; b = dy/dx; c /= dx;
}
else
{
b = 1.0; a = dx/dy; c /= dy;
}
var edge:DEdge = DEdge.create();
edge.leftSite = site0;
edge.rightSite = site1;
site0.addEdge(edge);
site1.addEdge(edge);
edge._leftVertex = null;
edge._rightVertex = null;
edge.a = a; edge.b = b; edge.c = c;
//trace("createBisectingEdge: a ", edge.a, "b", edge.b, "c", edge.c);
return edge;
}
private static function create():DEdge
{
var edge:DEdge;
if (_pool.length > 0)
{
edge = _pool.pop();
edge.init();
}
else
{
edge = new DEdge(PrivateConstructorEnforcer);
}
return edge;
}
private static const LINESPRITE:Sprite = new Sprite();
private static const GRAPHICS:Graphics = LINESPRITE.graphics;
private var _delaunayLineBmp:BitmapData;
internal function get delaunayLineBmp():BitmapData
{
if (!_delaunayLineBmp)
{
_delaunayLineBmp = makeDelaunayLineBmp();
}
return _delaunayLineBmp;
}
// making this available to Voronoi; running out of memory in AIR so I cannot cache the bmp
internal function makeDelaunayLineBmp():BitmapData
{
var p0:Point = leftSite.coord;
var p1:Point = rightSite.coord;
GRAPHICS.clear();
// clear() resets line style back to undefined!
GRAPHICS.lineStyle(0, 0, 1.0, false, LineScaleMode.NONE, CapsStyle.NONE);
GRAPHICS.moveTo(p0.x, p0.y);
GRAPHICS.lineTo(p1.x, p1.y);
var w:int = int(Math.ceil(Math.max(p0.x, p1.x)));
if (w < 1)
{
w = 1;
}
var h:int = int(Math.ceil(Math.max(p0.y, p1.y)));
if (h < 1)
{
h = 1;
}
var bmp:BitmapData = new BitmapData(w, h, true, 0);
bmp.draw(LINESPRITE);
return bmp;
}
public function delaunayLine():LineSegment
{
// draw a line connecting the input Sites for which the edge is a bisector:
return new LineSegment(leftSite.coord, rightSite.coord);
}
public function voronoiEdge():LineSegment
{
if (!visible) return new LineSegment(null, null);
return new LineSegment(_clippedVertices[LR.LEFT],
_clippedVertices[LR.RIGHT]);
}
private static var _nedges:int = 0;
internal static const DELETED:DEdge = new DEdge(PrivateConstructorEnforcer);
// the equation of the edge: ax + by = c
internal var a:Number, b:Number, c:Number;
// the two Voronoi vertices that the edge connects
// (if one of them is null, the edge extends to infinity)
private var _leftVertex:Vertex;
internal function get leftVertex():Vertex
{
return _leftVertex;
}
private var _rightVertex:Vertex;
internal function get rightVertex():Vertex
{
return _rightVertex;
}
internal function vertex(leftRight:LR):Vertex
{
return (leftRight == LR.LEFT) ? _leftVertex : _rightVertex;
}
internal function setVertex(leftRight:LR, v:Vertex):void
{
if (leftRight == LR.LEFT)
{
_leftVertex = v;
}
else
{
_rightVertex = v;
}
}
internal function isPartOfConvexHull():Boolean
{
return (_leftVertex == null || _rightVertex == null);
}
public function sitesDistance():Number
{
return Point.distance(leftSite.coord, rightSite.coord);
}
public static function compareSitesDistances_MAX(edge0:DEdge, edge1:DEdge):Number
{
var length0:Number = edge0.sitesDistance();
var length1:Number = edge1.sitesDistance();
if (length0 < length1)
{
return 1;
}
if (length0 > length1)
{
return -1;
}
return 0;
}
public static function compareSitesDistances(edge0:DEdge, edge1:DEdge):Number
{
return - compareSitesDistances_MAX(edge0, edge1);
}
// Once clipVertices() is called, this Dictionary will hold two Points
// representing the clipped coordinates of the left and right ends...
private var _clippedVertices:Dictionary;
internal function get clippedEnds():Dictionary
{
return _clippedVertices;
}
// unless the entire DEdge is outside the bounds.
// In that case visible will be false:
internal function get visible():Boolean
{
return _clippedVertices != null;
}
// the two input Sites for which this DEdge is a bisector:
private var _sites:Dictionary;
internal function set leftSite(s:Site):void
{
_sites[LR.LEFT] = s;
}
internal function get leftSite():Site
{
return _sites[LR.LEFT];
}
internal function set rightSite(s:Site):void
{
_sites[LR.RIGHT] = s;
}
internal function get rightSite():Site
{
return _sites[LR.RIGHT] as Site;
}
internal function site(leftRight:LR):Site
{
return _sites[leftRight] as Site;
}
private var _edgeIndex:int;
public function dispose():void
{
if (_delaunayLineBmp)
{
_delaunayLineBmp.dispose();
_delaunayLineBmp = null;
}
_leftVertex = null;
_rightVertex = null;
if (_clippedVertices)
{
_clippedVertices[LR.LEFT] = null;
_clippedVertices[LR.RIGHT] = null;
_clippedVertices = null;
}
_sites[LR.LEFT] = null;
_sites[LR.RIGHT] = null;
_sites = null;
_pool.push(this);
}
public function DEdge(lock:Class)
{
if (lock != PrivateConstructorEnforcer)
{
throw new Error("DEdge: constructor is private");
}
_edgeIndex = _nedges++;
init();
}
private function init():void
{
_sites = new Dictionary(true);
}
public function toString():String
{
return "DEdge " + _edgeIndex + "; sites " + _sites[LR.LEFT] + ", " + _sites[LR.RIGHT]
+ "; endVertices " + (_leftVertex ? _leftVertex.vertexIndex : "null") + ", "
+ (_rightVertex ? _rightVertex.vertexIndex : "null") + "::";
}
/**
* Set _clippedVertices to contain the two ends of the portion of the Voronoi edge that is visible
* within the bounds. If no part of the DEdge falls within the bounds, leave _clippedVertices null.
* @param bounds
*
*/
internal function clipVertices(bounds:Rectangle):void
{
var xmin:Number = bounds.x;
var ymin:Number = bounds.y;
var xmax:Number = bounds.right;
var ymax:Number = bounds.bottom;
var vertex0:Vertex, vertex1:Vertex;
var x0:Number, x1:Number, y0:Number, y1:Number;
if (a == 1.0 && b >= 0.0)
{
vertex0 = _rightVertex;
vertex1 = _leftVertex;
}
else
{
vertex0 = _leftVertex;
vertex1 = _rightVertex;
}
if (a == 1.0)
{
y0 = ymin;
if (vertex0 != null && vertex0.y > ymin)
{
y0 = vertex0.y;
}
if (y0 > ymax)
{
return;
}
x0 = c - b * y0;
y1 = ymax;
if (vertex1 != null && vertex1.y < ymax)
{
y1 = vertex1.y;
}
if (y1 < ymin)
{
return;
}
x1 = c - b * y1;
if ((x0 > xmax && x1 > xmax) || (x0 < xmin && x1 < xmin))
{
return;
}
if (x0 > xmax)
{
x0 = xmax; y0 = (c - x0)/b;
}
else if (x0 < xmin)
{
x0 = xmin; y0 = (c - x0)/b;
}
if (x1 > xmax)
{
x1 = xmax; y1 = (c - x1)/b;
}
else if (x1 < xmin)
{
x1 = xmin; y1 = (c - x1)/b;
}
}
else
{
x0 = xmin;
if (vertex0 != null && vertex0.x > xmin)
{
x0 = vertex0.x;
}
if (x0 > xmax)
{
return;
}
y0 = c - a * x0;
x1 = xmax;
if (vertex1 != null && vertex1.x < xmax)
{
x1 = vertex1.x;
}
if (x1 < xmin)
{
return;
}
y1 = c - a * x1;
if ((y0 > ymax && y1 > ymax) || (y0 < ymin && y1 < ymin))
{
return;
}
if (y0 > ymax)
{
y0 = ymax; x0 = (c - y0)/a;
}
else if (y0 < ymin)
{
y0 = ymin; x0 = (c - y0)/a;
}
if (y1 > ymax)
{
y1 = ymax; x1 = (c - y1)/a;
}
else if (y1 < ymin)
{
y1 = ymin; x1 = (c - y1)/a;
}
}
_clippedVertices = new Dictionary(true);
if (vertex0 == _leftVertex)
{
_clippedVertices[LR.LEFT] = new Point(x0, y0);
_clippedVertices[LR.RIGHT] = new Point(x1, y1);
}
else
{
_clippedVertices[LR.RIGHT] = new Point(x0, y0);
_clippedVertices[LR.LEFT] = new Point(x1, y1);
}
}
}
//}
//package {
import flash.geom.Point;
//import de.polygonal.math.PM_PRNG;
/*public*/ class NoisyEdges {
static public var NOISY_LINE_TRADEOFF:Number = 0.5;
public var path0:Array = [];
public var path1:Array = [];
public function NoisyEdges() {
}
public function buildNoisyEdges(map:Map, lava:Lava, random:PM_PRNG):void {
var p:Center, edge:Edge;
for each (p in map.centers) {
for each (edge in p.borders) {
if (edge.d0 && edge.d1 && edge.v0 && edge.v1 && !path0[edge.index]) {
var f:Number = NOISY_LINE_TRADEOFF;
var t:Point = Point.interpolate(edge.v0.point, edge.d0.point, f);
var q:Point = Point.interpolate(edge.v0.point, edge.d1.point, f);
var r:Point = Point.interpolate(edge.v1.point, edge.d0.point, f);
var s:Point = Point.interpolate(edge.v1.point, edge.d1.point, f);
var minLength:int = 10;
if (edge.d0.biome != edge.d1.biome) minLength = 3;
if (edge.d0.ocean && edge.d1.ocean) minLength = 100;
if (edge.d0.coast || edge.d1.coast) minLength = 1;
if (edge.river || lava.lava[edge.index]) minLength = 1;
path0[edge.index] = buildNoisyLineSegments(random, edge.v0.point, t, edge.midpoint, q, minLength);
path1[edge.index] = buildNoisyLineSegments(random, edge.v1.point, s, edge.midpoint, r, minLength);
}
}
}
}
static public function buildNoisyLineSegments(random:PM_PRNG, A:Point, B:Point, C:Point, D:Point, minLength:Number):Vector.<Point> {
var points:Vector.<Point> = new Vector.<Point>();
function subdivide(A:Point, B:Point, C:Point, D:Point):void {
if (A.subtract(C).length < minLength || B.subtract(D).length < minLength) {
return;
}
var p:Number = random.nextDoubleRange(0.2, 0.8);
var q:Number = random.nextDoubleRange(0.2, 0.8);
var E:Point = Point.interpolate(A, D, p);
var F:Point = Point.interpolate(B, C, p);
var G:Point = Point.interpolate(A, B, q);
var I:Point = Point.interpolate(D, C, q);
var H:Point = Point.interpolate(E, F, q);
var s:Number = 1.0 - random.nextDoubleRange(-0.4, +0.4);
var t:Number = 1.0 - random.nextDoubleRange(-0.4, +0.4);
subdivide(A, Point.interpolate(G, B, s), H, Point.interpolate(E, D, t));
points.push(H);
subdivide(H, Point.interpolate(F, C, s), C, Point.interpolate(I, D, t));
}
points.push(A);
subdivide(A, B, C, D);
points.push(C);
return points;
}
}
//}
//package {
/*public*/ class Smoothing {
static public const functionsList:Array =[
{ data: Smoothing.linear, label:'<none> (linear)'},
{ data: Smoothing.smooth3, label:'smooth3'},
{ data: Smoothing.smooth5, label:'smooth5'},
{ data: Smoothing.quadIn, label:'quadIn'},
{ data: Smoothing.quadOut, label:'quadOut'},
{ data: Smoothing.quadInOut, label:'quadInOut'},
{ data: Smoothing.cubicIn, label:'cubicIn'},
{ data: Smoothing.cubicOut, label:'cubicOut'},
{ data: Smoothing.cubicInOut, label:'cubicInOut'},
{ data: Smoothing.quartIn, label:'quartIn'},
{ data: Smoothing.quartOut, label:'quartOut'},
{ data: Smoothing.quartInOut, label:'quartInOut'},
{ data: Smoothing.quintIn, label:'quintIn'},
{ data: Smoothing.quintOut, label:'quintOut'},
{ data: Smoothing.quintInOut, label:'quintInOut'},
{ data: Smoothing.expoIn, label:'expoIn'},
{ data: Smoothing.expoOut, label:'expoOut'},
{ data: Smoothing.expoInOut, label:'expoInOut'},
{ data: Smoothing.sinIn, label:'sinIn'},
{ data: Smoothing.sinOut, label:'sinOut'},
{ data: Smoothing.sinInOut, label:'sinInOut'},
{ data: Smoothing.bounceIn, label:'bounceIn'},
{ data: Smoothing.bounceOut, label:'bounceOut'},
{ data: Smoothing.bounceInOut, label:'bounceInOut'},
{ data: Smoothing.circIn, label:'circIn'},
{ data: Smoothing.circOut, label:'circOut'},
{ data: Smoothing.circInOut, label:'circInOut'},
];
static public function smooth5(t:Number):Number {
return t * t * t * (t * (t * 6 - 15) + 10);
}
static public function smooth3(t:Number):Number {
return t * t * (3 - 2 * t);
}
static public function linear(t:Number):Number {
return t;
}
static public function quadIn (t:Number):Number {
return t * t;
}
static public function quadOut (t:Number):Number {
return -t * (t-2);
}
static public function quadInOut (t:Number):Number {
if ((t *= 2) < 1) return 0.5 * t * t;
return -0.5 * ((--t)*(t-2) - 1);
}
static public function cubicIn(t:Number):Number {
return t*t*t;
}
static public function cubicOut(t:Number):Number {
return (--t)*t*t + 1;
}
static public function cubicInOut (t:Number):Number {
if ((t *= 2) < 1) return 0.5*t*t*t;
return 0.5*((t-=2)*t*t + 2);
}
static public function quartIn (t:Number):Number {
return t*t*t*t;
}
static public function quartOut (t:Number):Number {
return -((t=t/1-1)*t*t*t - 1);
}
static public function quartInOut (t:Number):Number {
if ((t *= 2) < 1) return 0.5*t*t*t*t;
return -0.5 * ((t-=2)*t*t*t - 2);
}
static public function quintIn(t:Number):Number {
return t*t*t*t*t;
}
static public function quintOut(t:Number):Number {
return ((t=t/1-1)*t*t*t*t + 1);
}
static public function quintInOut(t:Number):Number {
if ((t *= 2) < 1) return 0.5*t*t*t*t*t;
return 0.5*((t-=2)*t*t*t*t + 2);
}
static public function expoIn (t:Number):Number {
return (t==0) ? 0 : Math.pow(2, 10 * (t/1 - 1));
}
static public function expoOut (t:Number):Number {
return (t==1) ? 0+1 : (-Math.pow(2, -10 * t/1) + 1);
}
static public function expoInOut (t:Number):Number {
if (t==0 || t ==1) return t;
if ((t *= 2) < 1) return 0.5 * Math.pow(2, 10 * (t - 1));
return 0.5 * (-Math.pow(2, -10 * --t) + 2);
}
static public function sinIn (t:Number):Number {
return -Math.cos(t * (Math.PI/2)) + 1;
}
static public function sinOut (t:Number):Number {
return Math.sin(t * (Math.PI/2));
}
static public function sinInOut (t:Number):Number {
return -0.5 * (Math.cos(Math.PI*t) - 1);
}
static public function bounceOut (t:Number):Number {
if (t < (1/2.75)) {
return (7.5625*t*t);
} else if (t < (2/2.75)) {
return (7.5625*(t-=(1.5/2.75))*t + .75);
} else if (t < (2.5/2.75)) {
return (7.5625*(t-=(2.25/2.75))*t + .9375);
} else {
return (7.5625*(t-=(2.625/2.75))*t + .984375);
}
}
static public function bounceIn (t:Number):Number {
return 1 - bounceOut (1-t);
}
static public function bounceInOut (t:Number):Number {
if (t < 0.5) return bounceIn (t*2) * 0.5;
else return bounceOut (t*2-1) * 0.5 + 00.5;
}
static public function circIn (t:Number):Number {
return -(Math.sqrt(1 - t*t) - 1);
}
static public function circOut (t:Number):Number {
return Math.sqrt(1 - (t=t/1-1)*t);
}
static public function circInOut (t:Number):Number {
if ((t *= 2) < 1) return -0.5 * (Math.sqrt(1 - t*t) - 1);
return 0.5 * (Math.sqrt(1 - (t-=2)*t) + 1);
}
}
//}
//package {
/*public*/ class Perlin extends NoiseSuper {
static private var noiseBasis:Function = improved;
static private var interpolation:Function = smooth5;
static private var octaves:int = 4;
static private var lacunarity:Number = 2;
static private var H:Number = 0.5;
static private var offset:Number = 0.8;
static private var maxAmp:Number = 0;
static public function setParams(initObject:Object):void {
if(initObject.noiseBasis) noiseBasis = initObject.noiseBasis;
if(initObject.interpolation) interpolation = initObject.interpolation;
if(initObject.octaves) octaves = initObject.octaves;
if(initObject.lacunarity) lacunarity = initObject.lacunarity;
if(initObject.H) H = initObject.H;
if(initObject.offset) offset = initObject.offset;
calcMax();
}
static public function fractalNoise(x:Number, y:Number, z:Number):Number {
var amp:Number = 1;
var fscale:Number = 1;
var sum:Number = 0;
if (maxAmp == 0) calcMax();
for (var i:int = 0; i < octaves; i++, amp *= H, fscale *= lacunarity) {
sum += amp * noiseBasis(fscale*x, fscale*y, fscale*z);
}
return (sum * maxAmp + 1) * 0.5;
}
static public function turbulence(x:Number, y:Number, z:Number):Number {
var amp:Number = 1;
var fscale:Number = 1;
var sum:Number = 0;
if(maxAmp == 0) calcMax();
for (var i:int = 0; i < octaves; i++, amp *= H, fscale *= lacunarity) {
sum += amp * Math.abs( noiseBasis(fscale*x, fscale*y, fscale*z) );
}
return (sum * maxAmp + 1) * 0.5;
}
static public function turbulenceHard(x:Number, y:Number, z:Number):Number {
var amp:Number = 1;
var fscale:Number = 1;
var sum:Number = 0;
if(maxAmp == 0) calcMax();
for (var i:int = 0; i < octaves; i++, amp *= H, fscale *= lacunarity) {
sum += amp * Math.abs( 2 * noiseBasis(fscale*x, fscale*y, fscale*z) - 1 );
}
return (sum * maxAmp + 1) * 0.5;
}
static public function improved(x:Number, y:Number, z:Number):Number {
var X:int = Math.floor(x) & 255;
var Y:int = Math.floor(y) & 255;
var Z:int = Math.floor(z) & 255;
x -= Math.floor(x);
y -= Math.floor(y);
z -= Math.floor(z);
var u:Number = interpolation(x);
var v:Number = interpolation(y);
var w:Number = interpolation(z);
var A:int = hash[X]+Y;
var AA:int = hash[A]+Z;
var AB:int = hash[A+1]+Z;
var B:int = hash[X+1]+Y;
var BA:int = hash[B]+Z;
var BB:int = hash[B+1]+Z;
return lerp(w, lerp(v, lerp(u, grad(hash[AA ], x , y , z ),
grad(hash[BA ], x-1, y , z )),
lerp(u, grad(hash[AB ], x , y-1, z ),
grad(hash[BB ], x-1, y-1, z ))),
lerp(v, lerp(u, grad(hash[AA+1], x , y , z-1 ),
grad(hash[BA+1], x-1, y , z-1 )),
lerp(u, grad(hash[AB+1], x , y-1, z-1 ),
grad(hash[BB+1], x-1, y-1, z-1 ))));
}
static public function improvedU(x:Number, y:Number, z:Number):Number {
return 0.5 + 0.5 * improved(x, y, z);
}
static private function calcMax():void {
maxAmp = 0;
for (var i:int; i<octaves; i++) maxAmp += Math.pow(H, i);
maxAmp = 1/maxAmp;
}
}
//}
//package {
import flash.filters.BlurFilter;
import flash.ui.Keyboard;
import flash.utils.Dictionary;
import flash.geom.*;
import flash.display.*;
import flash.events.*;
import flash.text.*;
import flash.utils.ByteArray;
import flash.utils.getTimer;
import flash.utils.Timer;
import flash.net.FileReference;
import flash.system.System;
//import de.polygonal.math.PM_PRNG;
/*public*/ class mapgen2 extends Sprite {
static public var SIZE:int = 512;
static public var EXPORT_SIZE:int = 512;
static public var previewColors:Object = {
OCEAN: 0x0000CC,
COAST: 0x33335a,
LAKESHORE: 0x225588,
LAKE: 0x336699,
RIVER: 0x225588,
MARSH: 0x2f6666,
ICE: 0x99ffff,
BEACH: 0xa09077,
ROAD1: 0x442211,
ROAD2: 0x553322,
ROAD3: 0x664433,
BRIDGE: 0x686860,
LAVA: 0xcc3333,
SNOW: 0xffffff,
TUNDRA: 0xbbbbaa,
BARE: 0x888888,
SCORCHED: 0x555555,
TAIGA: 0x99aa77,
SHRUBLAND: 0x889977,
TEMPERATE_DESERT: 0xc9d29b,
TEMPERATE_RAIN_FOREST: 0x448855,
TEMPERATE_DECIDUOUS_FOREST: 0x679459,
GRASSLAND: 0x88aa55,
SUBTROPICAL_DESERT: 0xd2b98b,
TROPICAL_RAIN_FOREST: 0x337755,
TROPICAL_SEASONAL_FOREST: 0x559944
};
static public var displayColors:Object = {
OCEAN: 0x000000,
COAST: 0x000000,
LAKESHORE: 0x000000,
LAKE: 0x000000,
RIVER: 0x000000,
MARSH: 0x00FF00,
ICE: 0x0000FF,
BEACH: 0xFF0000,
ROAD1: 0x442211,
ROAD2: 0x553322,
ROAD3: 0x664433,
BRIDGE: 0x686860,
LAVA: 0x0000FF,
SNOW: 0x0000FF,
TUNDRA: 0x0000FF,
BARE: 0x0000FF,
SCORCHED: 0x0000FF,
TAIGA: 0x0000FF,
SHRUBLAND: 0xFF0000,
TEMPERATE_DESERT: 0xFF0000,
TEMPERATE_RAIN_FOREST: 0x00FF00,
TEMPERATE_DECIDUOUS_FOREST: 0x00FF00,
GRASSLAND: 0x00FF00,
SUBTROPICAL_DESERT: 0xFF0000,
TROPICAL_RAIN_FOREST: 0x00FF00,
TROPICAL_SEASONAL_FOREST: 0x00FF00
};
static public var exportDisplayColors:Object = {
OCEAN: 1,
COAST: 2,
LAKESHORE: 3,
LAKE: 4,
RIVER: 5,
MARSH: 6,
ICE: 7,
BEACH: 8,
ROAD1: 9,
ROAD2: 10,
ROAD3: 11,
BRIDGE: 12,
LAVA: 13,
SNOW: 14,
TUNDRA: 15,
BARE: 16,
SCORCHED: 17,
TAIGA: 18,
SHRUBLAND: 19,
TEMPERATE_DESERT: 20,
TEMPERATE_RAIN_FOREST: 21,
TEMPERATE_DECIDUOUS_FOREST: 22,
GRASSLAND: 23,
SUBTROPICAL_DESERT: 24,
TROPICAL_RAIN_FOREST: 25,
TROPICAL_SEASONAL_FOREST: 26
};
static public function getExportIndexLookup():Vector.<String> {
var i:String
var count:int = 0;
for (i in exportDisplayColors) {
count++;
}
var v:Vector.<String> = new Vector.<String>(count, true);
for (i in exportDisplayColors) {
v [ exportDisplayColors[i] - 1 ] = i;
}
return v;
}
static public var elevationGradientColors:Object = {
OCEAN: 0x000000,
GRADIENT_LOW: 0x000001,
GRADIENT_HIGH: 0xffffff
};
static public var lightGradientColors:Object = {
OCEAN: 0x000000,
GRADIENT_LOW: 0x000001,
GRADIENT_HIGH: 0xffffff
};
static public var moistureGradientColors:Object = {
OCEAN: 0x4466ff,
GRADIENT_LOW: 0xbbaa33,
GRADIENT_HIGH: 0x4466ff
};
public var islandType:String = 'Perlin';
static public var islandSeedInitial:String = "85882-1";
public var controls:Sprite = new Sprite();
public var islandSeedInput:TextField;
public var statusBar:TextField;
public var mapMode:String = 'smooth';
public var render3dTimer:Timer = new Timer(1000/20, 0);
public var noiseLayer:Bitmap = new Bitmap(new BitmapData(SIZE, SIZE));
private var rotationAnimation:Number = 0.0;
private var triangles3d:Array = [];
private var graphicsData:Vector.<IGraphicsData>;
public var map:Map;
public var roads:Roads;
public var lava:Lava;
public var watersheds:Watersheds;
public var noisyEdges:NoisyEdges;
[SWF(width="800", height="600", frameRate=60)]
public function mapgen2() {
addEventListener(Event.ADDED_TO_STAGE, onAddedToStage);
}
private function onAddedToStage(e:Event):void
{
removeEventListener(Event.ADDED_TO_STAGE, onAddedToStage);
stage.scaleMode = 'noScale';
stage.align = 'TL';
scaleX = SIZE > 512 ? .5 : 1;
scaleY = SIZE > 512 ? .5 : 1;
addChild(noiseLayer);
noiseLayer.bitmapData.noise(555, 128-10, 128+10, 7, true);
noiseLayer.blendMode = BlendMode.HARDLIGHT;
controls.x = SIZE;
addChild(controls);
addExportButtons();
addViewButtons();
addGenerateButtons();
addMiscLabels();
map = new Map(SIZE);
go(islandType);
render3dTimer.addEventListener(TimerEvent.TIMER, function (e:TimerEvent):void {
drawMap(mapMode);
});
}
public function newIsland(type:String):void {
var seed:int = 0, variant:int = 0;
var t:Number = getTimer();
if (islandSeedInput.text.length == 0) {
islandSeedInput.text = (Math.random()*100000).toFixed(0);
}
var match:Object = /\s*(\d+)(?:\-(\d+))\s*$/.exec(islandSeedInput.text);
if (match != null) {
seed = parseInt(match[1]);
variant = parseInt(match[2] || "0");
}
if (seed == 0) {
for (var i:int = 0; i < islandSeedInput.text.length; i++) {
seed = (seed << 4) | islandSeedInput.text.charCodeAt(i);
}
seed %= 100000;
variant = 1+Math.floor(9*Math.random());
}
islandType = type;
map.newIsland(type, seed, variant);
}
public function graphicsReset():void {
triangles3d = [];
graphics.clear();
graphics.beginFill(0xbbbbaa);
graphics.drawRect(0, 0, 2000, 2000);
graphics.endFill();
graphics.beginFill(displayColors.OCEAN);
graphics.drawRect(0, 0, SIZE, SIZE);
graphics.endFill();
}
public function go(type:String):void {
cancelCommands();
roads = new Roads();
lava = new Lava();
watersheds = new Watersheds();
noisyEdges = new NoisyEdges();
commandExecute("Shaping map...",
function():void {
newIsland(type);
});
commandExecute("Placing points...",
function():void {
map.go(0, 1);
drawMap('polygons');
});
commandExecute("Improving points...",
function():void {
map.go(1, 2);
drawMap('polygons');
});
commandExecute("Building graph...",
function():void {
map.go(2, 3);
map.assignBiomes();
drawMap('polygons');
});
commandExecute("Features...",
function():void {
map.go(3, 6);
map.assignBiomes();
drawMap('polygons');
});
commandExecute("Edges...",
function():void {
roads.createRoads(map);
watersheds.createWatersheds(map);
noisyEdges.buildNoisyEdges(map, lava, map.mapRandom);
drawMap(mapMode);
});
}
private var _guiQueue:Array = [];
private function _onEnterFrame(e:Event):void {
(_guiQueue.shift()[1])();
if (_guiQueue.length == 0) {
stage.removeEventListener(Event.ENTER_FRAME, _onEnterFrame);
statusBar.text = "";
dispatchEvent( new Event(COMPLETED));
} else {
statusBar.text = _guiQueue[0][0];
}
}
public function cancelCommands():void {
if (_guiQueue.length != 0) {
stage.removeEventListener(Event.ENTER_FRAME, _onEnterFrame);
statusBar.text = "";
_guiQueue = [];
}
}
public function commandExecute(status:String, command:Function):void {
if (_guiQueue.length == 0) {
statusBar.text = status;
stage.addEventListener(Event.ENTER_FRAME, _onEnterFrame);
}
_guiQueue.push([status, command]);
}
private static var _biomeMap:Array =
['BEACH', 'LAKE', 'ICE', 'MARSH', 'SNOW', 'TUNDRA', 'BARE', 'SCORCHED',
'TAIGA', 'SHRUBLAND', 'TEMPERATE_DESERT', 'TEMPERATE_RAIN_FOREST',
'TEMPERATE_DECIDUOUS_FOREST', 'GRASSLAND', 'SUBTROPICAL_DESERT',
'TROPICAL_RAIN_FOREST', 'TROPICAL_SEASONAL_FOREST'];
public function drawHistograms():void {
function landTypeBucket(p:Center):int {
if (p.ocean) return 1;
else if (p.coast) return 2;
else if (p.water) return 3;
else return 4;
}
function landTypeColor(bucket:int):uint {
if (bucket == 1) return displayColors.OCEAN;
else if (bucket == 2) return displayColors.BEACH;
else if (bucket == 3) return displayColors.LAKE;
else return displayColors.TEMPERATE_DECIDUOUS_FOREST;
}
function elevationBucket(p:Center):int {
if (p.ocean) return -1;
else return Math.floor(p.elevation*10);
}
function elevationColor(bucket:int):uint {
return interpolateColor(displayColors.TEMPERATE_DECIDUOUS_FOREST,
displayColors.GRASSLAND, bucket*0.1);
}
function moistureBucket(p:Center):int {
if (p.water) return -1;
else return Math.floor(p.moisture*10);
}
function moistureColor(bucket:int):uint {
return interpolateColor(displayColors.BEACH, displayColors.RIVER, bucket*0.1);
}
function biomeBucket(p:Center):int {
return _biomeMap.indexOf(p.biome);
}
function biomeColor(bucket:int):uint {
return displayColors[_biomeMap[bucket]];
}
function computeHistogram(bucketFn:Function):Array {
var p:Center, histogram:Array, bucket:int;
histogram = [];
for each (p in map.centers) {
bucket = bucketFn(p);
if (bucket >= 0) histogram[bucket] = (histogram[bucket] || 0) + 1;
}
return histogram;
}
function drawHistogram(x:Number, y:Number, bucketFn:Function, colorFn:Function,
width:Number, height:Number):void {
var scale:Number, i:int;
var histogram:Array = computeHistogram(bucketFn);
scale = 0.0;
for (i = 0; i < histogram.length; i++) {
scale = Math.max(scale, histogram[i] || 0);
}
for (i = 0; i < histogram.length; i++) {
if (histogram[i]) {
graphics.beginFill(colorFn(i));
graphics.drawRect(SIZE+x+i*width/histogram.length, y+height,
Math.max(0, width/histogram.length-1), -height*histogram[i]/scale);
graphics.endFill();
}
}
}
function drawDistribution(x:Number, y:Number, bucketFn:Function, colorFn:Function,
width:Number, height:Number):void {
var scale:Number, i:int, x:Number, w:Number;
var histogram:Array = computeHistogram(bucketFn);
scale = 0.0;
for (i = 0; i < histogram.length; i++) {
scale += histogram[i] || 0.0;
}
for (i = 0; i < histogram.length; i++) {
if (histogram[i]) {
graphics.beginFill(colorFn(i));
w = histogram[i]/scale*width;
graphics.drawRect(SIZE+x, y, Math.max(0, w-1), height);
x += w;
graphics.endFill();
}
}
}
var x:Number = 23, y:Number = 140, width:Number = 154;
drawDistribution(x, y, landTypeBucket, landTypeColor, width, 20);
drawDistribution(x, y+25, biomeBucket, biomeColor, width, 20);
drawHistogram(x, y+55, elevationBucket, elevationColor, width, 30);
drawHistogram(x, y+95, moistureBucket, moistureColor, width, 20);
}
private function drawPathForwards(graphics:Graphics, path:Vector.<Point>):void {
for (var i:int = 0; i < path.length; i++) {
graphics.lineTo(path[i].x, path[i].y);
}
}
private function drawPathBackwards(graphics:Graphics, path:Vector.<Point>):void {
for (var i:int = path.length-1; i >= 0; i--) {
graphics.lineTo(path[i].x, path[i].y);
}
}
private function interpolateColor(color0:uint, color1:uint, f:Number):uint {
var r:uint = uint((1-f)*(color0 >> 16) + f*(color1 >> 16));
var g:uint = uint((1-f)*((color0 >> 8) & 0xff) + f*((color1 >> 8) & 0xff));
var b:uint = uint((1-f)*(color0 & 0xff) + f*(color1 & 0xff));
if (r > 255) r = 255;
if (g > 255) g = 255;
if (b > 255) b = 255;
return (r << 16) | (g << 8) | b;
}
private function drawGradientTriangle(graphics:Graphics,
v1:Vector3D, v2:Vector3D, v3:Vector3D,
colors:Array, fillFunction:Function):void {
var m:Matrix = new Matrix();
var V:Vector3D = v1.add(v2).add(v3);
V.scaleBy(1/3.0);
var N:Vector3D = v2.subtract(v1).crossProduct(v3.subtract(v1));
N.normalize();
var G:Vector3D = new Vector3D(-N.x/N.z, -N.y/N.z, 0);
var C:Vector3D = new Vector3D(V.x - G.x*((V.z-0.5)/G.length/G.length), V.y - G.y*((V.z-0.5)/G.length/G.length));
if (G.length < 1e-6) {
var color:uint = colors[0];
if (colors.length == 2) {
color = interpolateColor(colors[0], colors[1], V.z);
} else if (colors.length == 3) {
if (V.z < 0.5) {
color = interpolateColor(colors[0], colors[1], V.z*2);
} else {
color = interpolateColor(colors[1], colors[2], V.z*2-1);
}
}
graphics.beginFill(color);
} else {
m.createGradientBox(1, 1, 0, 0, 0);
m.translate(-0.5, -0.5);
m.scale((1/G.length), (1/G.length));
m.rotate(Math.atan2(G.y, G.x));
m.translate(C.x, C.y);
var alphas:Array = colors.map(function (_:*, index:int, A:Array):Number { return 1.0; });
var spread:Array = colors.map(function (_:*, index:int, A:Array):int { return 255*index/(A.length-1); });
graphics.beginGradientFill(GradientType.LINEAR, colors, alphas, spread, m, SpreadMethod.PAD);
}
fillFunction();
graphics.endFill();
}
public function drawMap(mode:String):void {
graphicsReset();
noiseLayer.visible = true;
drawHistograms();
if (mode == '3d') {
if (!render3dTimer.running) render3dTimer.start();
noiseLayer.visible = false;
render3dPolygons(graphics, displayColors, colorWithSlope);
return;
} else if (mode == 'polygons') {
noiseLayer.visible = false;
renderDebugPolygons(graphics, displayColors);
} else if (mode == 'watersheds') {
noiseLayer.visible = false;
renderDebugPolygons(graphics, displayColors);
renderWatersheds(graphics);
return;
} else if (mode == 'biome') {
noiseLayer.visible = false;
renderPolygons(graphics, displayColors, null, null);
} else if (mode == 'slopes') {
noiseLayer.visible = false;
renderPolygons(graphics, {} , null, colorWithSlope, 0x808080);
} else if (mode == 'smooth') {
renderPolygons(graphics, displayColors, null, colorWithSmoothColors);
} else if (mode == 'elevation') {
noiseLayer.visible = false;
renderPolygons(graphics, elevationGradientColors, 'elevation', null);
} else if (mode == 'moisture') {
noiseLayer.visible = false;
renderPolygons(graphics, moistureGradientColors, 'moisture', null);
}
if (render3dTimer.running) render3dTimer.stop();
if (mode != 'slopes' && mode != 'moisture') {
}
if (mode != 'polygons') {
}
if (mode != 'slopes' && mode != 'moisture') {
}
}
public function render3dPolygons(graphics:Graphics, colors:Object, colorFunction:Function):void {
var p:Center, q:Corner, edge:Edge;
var zScale:Number = 0.15*SIZE;
graphics.beginFill(colors.OCEAN);
graphics.drawRect(0, 0, SIZE, SIZE);
graphics.endFill();
if (triangles3d.length == 0) {
graphicsData = new Vector.<IGraphicsData>();
for each (p in map.centers) {
if (p.ocean) continue;
for each (edge in p.borders) {
var color:int = colors[p.biome] || 0;
if (colorFunction != null) {
color = colorFunction(color, p, q, edge, colors, 0x808080);
}
var corner0:Corner = edge.v0;
var corner1:Corner = edge.v1;
if (corner0 == null || corner1 == null) {
continue;
}
var zp:Number = zScale*p.elevation;
var z0:Number = zScale*corner0.elevation;
var z1:Number = zScale*corner1.elevation;
triangles3d.push({
a:new Vector3D(p.point.x, p.point.y, zp),
b:new Vector3D(corner0.point.x, corner0.point.y, z0),
c:new Vector3D(corner1.point.x, corner1.point.y, z1),
rA:null,
rB:null,
rC:null,
z:0.0,
color:color
});
graphicsData.push(new GraphicsSolidFill());
graphicsData.push(new GraphicsPath(Vector.<int>([GraphicsPathCommand.MOVE_TO, GraphicsPathCommand.LINE_TO, GraphicsPathCommand.LINE_TO]),
Vector.<Number>([0, 0, 0, 0, 0, 0])));
graphicsData.push(new GraphicsEndFill());
}
}
}
var camera:Matrix3D = new Matrix3D();
camera.appendRotation(rotationAnimation, new Vector3D(0, 0, 1), new Vector3D(SIZE/2, SIZE/2));
camera.appendRotation(60, new Vector3D(1,0,0), new Vector3D(SIZE/2, SIZE/2));
rotationAnimation += 1;
for each (var tri:Object in triangles3d) {
tri.rA = camera.transformVector(tri.a);
tri.rB = camera.transformVector(tri.b);
tri.rC = camera.transformVector(tri.c);
tri.z = (tri.rA.z + tri.rB.z + tri.rC.z)/3;
}
triangles3d.sortOn('z', Array.NUMERIC);
for (var i:int = 0; i < triangles3d.length; i++) {
tri = triangles3d[i];
GraphicsSolidFill(graphicsData[i*3]).color = tri.color;
var data:Vector.<Number> = GraphicsPath(graphicsData[i*3+1]).data;
data[0] = tri.rA.x;
data[1] = tri.rA.y;
data[2] = tri.rB.x;
data[3] = tri.rB.y;
data[4] = tri.rC.x;
data[5] = tri.rC.y;
}
graphics.drawGraphicsData(graphicsData);
}
public function renderPolygons(graphics:Graphics, colors:Object, gradientFillProperty:String, colorOverrideFunction:Function, defaultColor:uint=0):void {
var p:Center, r:Center;
graphics.beginFill(defaultColor != 0 ? defaultColor : colors.OCEAN);
graphics.drawRect(0, 0, SIZE, SIZE);
graphics.endFill();
for each (p in map.centers) {
for each (r in p.neighbors) {
var edge:Edge = map.lookupEdgeFromCenter(p, r);
var color:int = colors[p.biome] || defaultColor;
if (colorOverrideFunction != null) {
color = colorOverrideFunction(color, p, r, edge, colors, defaultColor);
}
function drawPath0():void {
var path:Vector.<Point> = noisyEdges.path0[edge.index];
graphics.moveTo(p.point.x, p.point.y);
graphics.lineTo(path[0].x, path[0].y);
drawPathForwards(graphics, path);
graphics.lineTo(p.point.x, p.point.y);
}
function drawPath1():void {
var path:Vector.<Point> = noisyEdges.path1[edge.index];
graphics.moveTo(p.point.x, p.point.y);
graphics.lineTo(path[0].x, path[0].y);
drawPathForwards(graphics, path);
graphics.lineTo(p.point.x, p.point.y);
}
if (noisyEdges.path0[edge.index] == null
|| noisyEdges.path1[edge.index] == null) {
continue;
}
if (gradientFillProperty != null) {
var corner0:Corner = edge.v0;
var corner1:Corner = edge.v1;
var midpoint:Point = edge.midpoint;
var midpointAttr:Number = 0.5*(corner0[gradientFillProperty]+corner1[gradientFillProperty]);
drawGradientTriangle
(graphics,
new Vector3D(p.point.x, p.point.y, p[gradientFillProperty]),
new Vector3D(corner0.point.x, corner0.point.y, corner0[gradientFillProperty]),
new Vector3D(midpoint.x, midpoint.y, midpointAttr),
[colors.GRADIENT_LOW, colors.GRADIENT_HIGH], drawPath0);
drawGradientTriangle
(graphics,
new Vector3D(p.point.x, p.point.y, p[gradientFillProperty]),
new Vector3D(midpoint.x, midpoint.y, midpointAttr),
new Vector3D(corner1.point.x, corner1.point.y, corner1[gradientFillProperty]),
[colors.GRADIENT_LOW, colors.GRADIENT_HIGH], drawPath1);
} else {
graphics.beginFill(color);
drawPath0();
drawPath1();
graphics.endFill();
}
}
}
}
public function renderBridges(graphics:Graphics, colors:Object):void {
var edge:Edge;
for each (edge in map.edges) {
if (edge.river > 0 && edge.river < 4
&& !edge.d0.water && !edge.d1.water
&& (edge.d0.elevation > 0.05 || edge.d1.elevation > 0.05)) {
var n:Point = new Point(-(edge.v1.point.y - edge.v0.point.y), edge.v1.point.x - edge.v0.point.x);
n.normalize(0.25 + (roads.road[edge.index]? 0.5 : 0) + 0.75*Math.sqrt(edge.river));
graphics.lineStyle(1.1, colors.BRIDGE, 1.0, false, LineScaleMode.NORMAL, CapsStyle.SQUARE);
graphics.moveTo(edge.midpoint.x - n.x, edge.midpoint.y - n.y);
graphics.lineTo(edge.midpoint.x + n.x, edge.midpoint.y + n.y);
graphics.lineStyle();
}
}
}
public function renderRoads(graphics:Graphics, colors:Object):void {
var p:Center, A:Point, B:Point, C:Point;
var i:int, j:int, d:Number, edge1:Edge, edge2:Edge, edges:Vector.<Edge>;
function normalTowards(e:Edge, c:Point, len:Number):Point {
var n:Point = new Point(-(e.v1.point.y - e.v0.point.y), e.v1.point.x - e.v0.point.x);
var d:Point = c.subtract(e.midpoint);
if (n.x * d.x + n.y * d.y < 0) {
n.x = -n.x;
n.y = -n.y;
}
n.normalize(len);
return n;
}
for each (p in map.centers) {
if (roads.roadConnections[p.index]) {
if (roads.roadConnections[p.index].length == 2) {
edges = p.borders;
for (i = 0; i < edges.length; i++) {
edge1 = edges[i];
if (roads.road[edge1.index] > 0) {
for (j = i+1; j < edges.length; j++) {
edge2 = edges[j];
if (roads.road[edge2.index] > 0) {
d = 0.5*Math.min
(edge1.midpoint.subtract(p.point).length,
edge2.midpoint.subtract(p.point).length);
A = normalTowards(edge1, p.point, d).add(edge1.midpoint);
B = normalTowards(edge2, p.point, d).add(edge2.midpoint);
C = Point.interpolate(A, B, 0.5);
graphics.lineStyle(1.1, colors['ROAD'+roads.road[edge1.index]]);
graphics.moveTo(edge1.midpoint.x, edge1.midpoint.y);
graphics.curveTo(A.x, A.y, C.x, C.y);
graphics.lineStyle(1.1, colors['ROAD'+roads.road[edge2.index]]);
graphics.curveTo(B.x, B.y, edge2.midpoint.x, edge2.midpoint.y);
graphics.lineStyle();
}
}
}
}
} else {
for each (edge1 in p.borders) {
if (roads.road[edge1.index] > 0) {
d = 0.25*edge1.midpoint.subtract(p.point).length;
A = normalTowards(edge1, p.point, d).add(edge1.midpoint);
graphics.lineStyle(1.4, colors['ROAD'+roads.road[edge1.index]]);
graphics.moveTo(edge1.midpoint.x, edge1.midpoint.y);
graphics.curveTo(A.x, A.y, p.point.x, p.point.y);
graphics.lineStyle();
}
}
}
}
}
}
public function renderEdges(graphics:Graphics, colors:Object):void {
var p:Center, r:Center, edge:Edge;
for each (p in map.centers) {
for each (r in p.neighbors) {
edge = map.lookupEdgeFromCenter(p, r);
if (noisyEdges.path0[edge.index] == null
|| noisyEdges.path1[edge.index] == null) {
continue;
}
if (p.ocean != r.ocean) {
graphics.lineStyle(2, colors.COAST);
} else if ((p.water > 0) != (r.water > 0) && p.biome != 'ICE' && r.biome != 'ICE') {
graphics.lineStyle(1, colors.LAKESHORE);
} else if (p.water || r.water) {
continue;
} else if (lava.lava[edge.index]) {
graphics.lineStyle(1, colors.LAVA);
} else if (edge.river > 0) {
graphics.lineStyle(Math.sqrt(edge.river), colors.RIVER);
} else {
continue;
}
graphics.moveTo(noisyEdges.path0[edge.index][0].x,
noisyEdges.path0[edge.index][0].y);
drawPathForwards(graphics, noisyEdges.path0[edge.index]);
drawPathBackwards(graphics, noisyEdges.path1[edge.index]);
graphics.lineStyle();
}
}
}
public function renderDebugPolygons(graphics:Graphics, colors:Object):void {
var p:Center, q:Corner, edge:Edge, point:Point, color:int;
if (map.centers.length == 0) {
graphics.beginFill(0xdddddd);
graphics.drawRect(0, 0, SIZE, SIZE);
graphics.endFill();
for each (point in map.points) {
graphics.beginFill(0x000000);
graphics.drawCircle(point.x, point.y, 1.3);
graphics.endFill();
}
}
for each (p in map.centers) {
color = colors[p.biome] || (p.ocean? colors.OCEAN : p.water? colors.RIVER : 0xffffff);
graphics.beginFill(interpolateColor(color, 0xdddddd, 0.2));
for each (edge in p.borders) {
if (edge.v0 && edge.v1) {
graphics.moveTo(p.point.x, p.point.y);
graphics.lineTo(edge.v0.point.x, edge.v0.point.y);
if (edge.river > 0) {
graphics.lineStyle(2, displayColors.RIVER, 1.0);
} else {
graphics.lineStyle(0, 0x000000, 0.4);
}
graphics.lineTo(edge.v1.point.x, edge.v1.point.y);
graphics.lineStyle();
}
}
graphics.endFill();
graphics.beginFill(p.water > 0 ? 0x003333 : 0x000000, 0.7);
graphics.drawCircle(p.point.x, p.point.y, 1.3);
graphics.endFill();
for each (q in p.corners) {
graphics.beginFill(q.water? 0x0000ff : 0x009900);
graphics.drawRect(q.point.x-0.7, q.point.y-0.7, 1.5, 1.5);
graphics.endFill();
}
}
}
public function renderWatersheds(graphics:Graphics):void {
var edge:Edge, w0:int, w1:int;
for each (edge in map.edges) {
if (edge.d0 && edge.d1 && edge.v0 && edge.v1
&& !edge.d0.ocean && !edge.d1.ocean) {
w0 = watersheds.watersheds[edge.d0.index];
w1 = watersheds.watersheds[edge.d1.index];
if (w0 != w1) {
graphics.lineStyle(3.5, 0x000000, 0.1*Math.sqrt((map.corners[w0].watershed_size || 1) + (map.corners[w1].watershed.watershed_size || 1)));
graphics.moveTo(edge.v0.point.x, edge.v0.point.y);
graphics.lineTo(edge.v1.point.x, edge.v1.point.y);
graphics.lineStyle();
}
}
}
for each (edge in map.edges) {
if (edge.river) {
graphics.lineStyle(1.0, 0x6699ff);
graphics.moveTo(edge.v0.point.x, edge.v0.point.y);
graphics.lineTo(edge.v1.point.x, edge.v1.point.y);
graphics.lineStyle();
}
}
}
private var lightVector:Vector3D = new Vector3D(-1, -1, 0);
private var biomeApplicator:BiomeApplicator32;
private var _testSpr:Sprite;
public function calculateLighting(p:Center, r:Corner, s:Corner):Number {
var A:Vector3D = new Vector3D(p.point.x, p.point.y, p.elevation);
var B:Vector3D = new Vector3D(r.point.x, r.point.y, r.elevation);
var C:Vector3D = new Vector3D(s.point.x, s.point.y, s.elevation);
var normal:Vector3D = B.subtract(A).crossProduct(C.subtract(A));
if (normal.z < 0) { normal.scaleBy(-1); }
normal.normalize();
var light:Number = 0.5 + 35*normal.dotProduct(lightVector);
if (light < 0) light = 0;
if (light > 1) light = 1;
return light;
}
public function colorWithSlope(color:int, p:Center, q:Center, edge:Edge, displayColors:Object, defaultColor:uint):int {
var r:Corner = edge.v0;
var s:Corner = edge.v1;
if (!r || !s) {
return displayColors.OCEAN;
} else if (p.water) {
return color;
}
if (q != null && p.water == q.water) color = interpolateColor(color, displayColors[q.biome]!= null ? displayColors[q.biome] : defaultColor, 0.4);
var colorLow:int = interpolateColor(color, 0x333333, 0.7);
var colorHigh:int = interpolateColor(color, 0xffffff, 0.3);
var light:Number = calculateLighting(p, r, s);
if (light < 0.5) return interpolateColor(colorLow, color, light*2);
else return interpolateColor(color, colorHigh, light*2-1);
}
public function colorWithSmoothColors(color:int, p:Center, q:Center, edge:Edge, displayColors:Object, defaultColor:uint):int {
if (q != null && p.water == q.water) {
color = interpolateColor(displayColors[p.biome], displayColors[q.biome]!= null ? displayColors[q.biome] : defaultColor, 0.25);
}
return color;
}
static public var exportOverrideColors:Object = {
POLYGON_CENTER: 0x01,
POLYGON_CENTER_SAFE: 0x03,
OCEAN: 0x50,
COAST: 0x80,
LAKE: 0x60,
LAKESHORE: 0x70,
RIVER: 0x10,
MARSH: 0x10,
ICE: 0x40,
LAVA: 0x20,
SNOW: 0x30,
ROAD1: 0x90,
ROAD2: 0xa0,
ROAD3: 0xb0,
BRIDGE: 0xc0
};
static public var exportElevationColors:Object = {
OCEAN: 0x00,
GRADIENT_LOW: 0x00,
GRADIENT_HIGH: 0xff
};
static public const COMPLETED:String = "mapGenCompleted";
static public var PREVIEW_SIZE:int = 64;
static public var exportMoistureColors:Object = {
OCEAN: 0xff,
GRADIENT_LOW: 0x00,
GRADIENT_HIGH: 0xff
};
public function getPreviewBmp(exportSize:int = 0):Bitmap {
if (exportSize == 0) exportSize = PREVIEW_SIZE;
var exportBitmap:BitmapData = new BitmapData(exportSize, exportSize, false, 0);
var exportGraphics:Shape = new Shape();
renderPolygons(exportGraphics.graphics, previewColors, null, colorWithSmoothColors);
var m:Matrix = new Matrix();
m.scale(exportSize / SIZE, exportSize / SIZE);
exportBitmap.draw(exportGraphics, m, null,null,null,true);
return new Bitmap(exportBitmap, "auto", true);
}
public function makeExport(layer:String, exportSize:int = 0, compress:Boolean=true):ByteArray {
exportSize = exportSize != 0 ? exportSize : EXPORT_SIZE;
var exportBitmap:BitmapData = new BitmapData(exportSize, exportSize);
var exportGraphics:Shape = new Shape();
var exportData:ByteArray = new ByteArray();
var m:Matrix = new Matrix();
m.scale(exportSize / SIZE, exportSize / SIZE);
function saveBitmapToArray():void {
for (var y:int = 0; y < EXPORT_SIZE; y++) {
for (var x:int = 0; x < EXPORT_SIZE; x++) {
exportData.writeByte(exportBitmap.getPixel(x, y) & 0xff);
}
}
}
if (layer == 'overrides') {
renderPolygons(exportGraphics.graphics, exportOverrideColors, null, null);
renderEdges(exportGraphics.graphics, exportOverrideColors);
renderBridges(exportGraphics.graphics, exportOverrideColors);
stage.quality = 'low';
exportBitmap.draw(exportGraphics, m);
stage.quality = 'best';
for each (var p:Center in map.centers) {
if (!p.ocean) {
var r:Point = new Point(Math.floor(p.point.x * exportSize/SIZE),
Math.floor(p.point.y * exportSize/SIZE));
exportBitmap.setPixel(r.x, r.y,
exportBitmap.getPixel(r.x, r.y)
| (roads.roadConnections[p]?
exportOverrideColors.POLYGON_CENTER_SAFE
: exportOverrideColors.POLYGON_CENTER));
}
}
saveBitmapToArray();
} else if (layer == 'elevation') {
renderPolygons(exportGraphics.graphics, exportElevationColors, 'elevation', null);
exportBitmap.draw(exportGraphics, m);
saveBitmapToArray();
} else if (layer == 'moisture') {
renderPolygons(exportGraphics.graphics, exportMoistureColors, 'moisture', null);
exportBitmap.draw(exportGraphics, m);
saveBitmapToArray();
}
else if (layer == 'biometiles') {
renderPolygons(exportGraphics.graphics, exportDisplayColors, null, null);
stage.quality = 'low';
exportBitmap.draw(exportGraphics, m);
stage.quality = 'best';
saveBitmapToArray();
}
else if (layer === 'biomediffuse') {
renderPolygons(exportGraphics.graphics, displayColors, null, colorWithSmoothColors);
exportBitmap.draw(exportGraphics, m);
exportBitmap.applyFilter( exportBitmap, exportBitmap.rect, new Point(), new BlurFilter(12, 12, 4) );
addChild( new Bitmap(exportBitmap));
saveBitmapToArray();
}
else if (layer === 'slopes') {
renderPolygons(exportGraphics.graphics, {}, null, colorWithSlope, 0x808080);
exportBitmap.draw(exportGraphics, m);
exportBitmap.applyFilter( exportBitmap, exportBitmap.rect, new Point(), new BlurFilter(4, 4, 4) );
addChild( new Bitmap(exportBitmap));
saveBitmapToArray();
}
if (compress) exportData.compress();
return exportData;
}
public function makeButton(label:String, x:int, y:int, width:int, callback:Function):TextField {
var button:TextField = new TextField();
var format:TextFormat = new TextFormat();
format.font = "Arial";
format.align = 'center';
button.defaultTextFormat = format;
button.text = label;
button.selectable = false;
button.x = x;
button.y = y;
button.width = width;
button.height = 20;
if (callback != null) {
button.background = true;
button.backgroundColor = 0xffffcc;
button.addEventListener(MouseEvent.CLICK, callback);
}
return button;
}
public function addGenerateButtons():void {
var y:int = 4;
var islandShapeButton:TextField = makeButton("Island Shape:", 25, y, 150, null);
var seedLabel:TextField = makeButton("Shape #", 20, y+22, 50, null);
islandSeedInput = makeButton(islandSeedInitial, 70, y+22, 54, null);
islandSeedInput.background = true;
islandSeedInput.backgroundColor = 0xccddcc;
islandSeedInput.selectable = true;
islandSeedInput.type = TextFieldType.INPUT;
islandSeedInput.addEventListener(KeyboardEvent.KEY_UP, function (e:KeyboardEvent):void {
if (e.keyCode == 13) {
go(islandType);
}
});
function markActiveIslandShape(type:String):void {
mapTypes[islandType].backgroundColor = 0xffffcc;
mapTypes[type].backgroundColor = 0xffff00;
}
function switcher(type:String):Function {
return function(e:Event):void {
markActiveIslandShape(type);
go(type);
}
}
var mapTypes:Object = {
'Radial': makeButton("Radial", 23, y+44, 40, switcher('Radial')),
'Perlin': makeButton("Perlin", 65, y+44, 35, switcher('Perlin')),
'Square': makeButton("Square", 102, y+44, 44, switcher('Square')),
'Blob': makeButton("Blob", 148, y+44, 29, switcher('Blob'))
};
markActiveIslandShape(islandType);
controls.addChild(islandShapeButton);
controls.addChild(seedLabel);
controls.addChild(islandSeedInput);
controls.addChild(makeButton("Random", 125, y+22, 56,
function (e:Event):void {
islandSeedInput.text =
( (Math.random()*100000).toFixed(0)
+ "-"
+ (1 + Math.floor(9*Math.random())).toFixed(0) );
go(islandType);
}));
controls.addChild(mapTypes.Radial);
controls.addChild(mapTypes.Perlin);
controls.addChild(mapTypes.Square);
controls.addChild(mapTypes.Blob);
}
public function addViewButtons():void {
var y:int = 300;
function markViewButton(mode:String):void {
views[mapMode].backgroundColor = 0xffffcc;
views[mode].backgroundColor = 0xffff00;
}
function switcher(mode:String):Function {
return function(e:Event):void {
markViewButton(mode);
mapMode = mode;
drawMap(mapMode);
}
}
var views:Object = {
'biome': makeButton("Biomes", 25, y+22, 74, switcher('biome')),
'smooth': makeButton("Smooth", 101, y+22, 74, switcher('smooth')),
'slopes': makeButton("2D slopes", 25, y+44, 74, switcher('slopes')),
'3d': makeButton("3D slopes", 101, y+44, 74, switcher('3d')),
'elevation': makeButton("Elevation", 25, y+66, 74, switcher('elevation')),
'moisture': makeButton("Moisture", 101, y+66, 74, switcher('moisture')),
'polygons': makeButton("Polygons", 25, y+88, 74, switcher('polygons')),
'watersheds': makeButton("Watersheds", 101, y+88, 74, switcher('watersheds'))
};
markViewButton(mapMode);
controls.addChild(makeButton("View:", 50, y, 100, null));
controls.addChild(views.biome);
controls.addChild(views.smooth);
controls.addChild(views.slopes);
controls.addChild(views['3d']);
controls.addChild(views.elevation);
controls.addChild(views.moisture);
controls.addChild(views.polygons);
controls.addChild(views.watersheds);
}
public function addMiscLabels():void {
controls.addChild(makeButton("Distribution:", 50, 120, 100, null));
statusBar = makeButton("", SIZE/2-50, 10, 100, null);
addChild(statusBar);
}
public function addExportButtons():void {
var y:Number = 420;
controls.addChild(makeButton("Export Bitmaps:", 25, y, 150, null));
controls.addChild(makeButton("Elevation", 50, y+22, 100,
function (e:Event):void {
new FileReference().save(makeExport('elevation'), 'map_elevation.data');
}));
controls.addChild(makeButton("Moisture", 50, y+44, 100,
function (e:Event):void {
new FileReference().save(makeExport('moisture'), 'moisture.data');
}));
controls.addChild(makeButton("Overrides", 50, y+66, 100,
function (e:Event):void {
new FileReference().save(makeExport('overrides'), 'overrides.data');
}));
controls.addChild(makeButton("Biome Diffuse", 50, y+88, 100,
function (e:Event):void {
new FileReference().save(makeExport('biomediffuse'), 'map_biomediffuse.data');
}));
controls.addChild(makeButton("Biome Tiles", 50, y+88+22, 100,
function (e:Event):void {
createBiomeApplication( makeExport('biometiles') );
}));
controls.addChild(makeButton("2D Slope (lighting)", 50, y+88+44, 100,
function (e:Event):void {
new FileReference().save( makeExport('slopes'), 'map_slopelighting.data' );
}));
}
private function createBiomeApplication(bytes:ByteArray):void
{
biomeApplicator = new BiomeApplicator32();
biomeApplicator.addEventListener(Event.COMPLETE, onBiomeApplyComplete);
bytes.position = 0;
addChild( biomeApplicator.displayField);
bytes.uncompress();
biomeApplicator.processBiomes(bytes, Math.sqrt(bytes.length), this);
addChild( new Bitmap( biomeApplicator.testbitMap ) );
}
private function onBiomeApplyComplete(e:Event):void
{
biomeApplicator.removeEventListener(Event.COMPLETE, onBiomeApplyComplete);
var data:ByteArray = new ByteArray();
biomeApplicator.painter.writeBmpData(data, biomeApplicator.tileBitMap, biomeApplicator.tilesAcross);
data.compress();
new FileReference().save(data, "map_biometiles.data");
data.uncompress();
biomeApplicator.testbitMap.setVector(biomeApplicator.testbitMap.rect, biomeApplicator.tileBitMap);
if ( biomeApplicator.painter.getBmpData(data).compare(biomeApplicator.testbitMap) != 0) throw new Error("mismatch bitmapdata save!");
var spr:Sprite = new Sprite();
spr.addChild( new Bitmap(biomeApplicator.testbitMap) );
addChild( spr );
_testSpr = spr;
spr.addEventListener(MouseEvent.MOUSE_MOVE, traceBitmap);
addChild( biomeApplicator.displayField );
biomeApplicator.displayField.backgroundColor = 0xFFFFFF;
biomeApplicator.displayField.textColor = 0;
var resultField:TextField;
addChild( resultField= new TextField() );
resultField.text = biomeApplicator.displayField.text;
resultField.y = biomeApplicator.displayField.y + 20;
stage.addEventListener(KeyboardEvent.KEY_DOWN, onKeyboardEvent);
}
private function onKeyboardEvent(e:KeyboardEvent):void {
if (e.keyCode === Keyboard.TAB) {
_testSpr.mouseEnabled = !_testSpr.mouseEnabled;
}
}
private function traceBitmap(e:MouseEvent):void
{
var mx:int= e.localX;
var my:int = e.localY;
var color:uint = biomeApplicator.testbitMap.getPixel32(mx, my);
biomeApplicator.displayField.text = String( biomeApplicator.painter.getUint16bits(color) + ", "+color );
}
}
//}
// Make a map out of a voronoi graph
// Author: amitp@cs.stanford.edu
// License: MIT
//package terraingen.island {
import flash.geom.*;
import flash.utils.Dictionary;
import flash.utils.getTimer;
import flash.system.System;
// public
class Map {
static public var NUM_POINTS:int = 1000;
static public var LAKE_THRESHOLD:Number = 0.3; // 0 to 1, fraction of water corners for water polygon
static public var NUM_LLOYD_ITERATIONS:int = 2;
// Passed in by the caller:
public var SIZE:Number;
// Island shape is controlled by the islandRandom seed and the
// type of island, passed in when we set the island shape. The
// islandShape function uses both of them to determine whether any
// point should be water or land.
public var islandShape:Function;
// Island details are controlled by this random generator. The
// initial map upon loading is always deterministic, but
// subsequent maps reset this random number generator with a
// random seed.
public var mapRandom:PM_PRNG = new PM_PRNG();
// These store the graph data
public var points:Vector.<Point>; // Only useful during map construction
public var centers:Vector.<Center>;
public var corners:Vector.<Corner>;
public var edges:Vector.<Edge>;
public function Map(size:Number) {
SIZE = size;
reset();
}
// Random parameters governing the overall shape of the island
public function newIsland(type:String, seed:int, variant:int):void {
islandShape = IslandShape['make'+type](seed);
mapRandom.seed = variant;
}
public function reset():void {
var p:Center, q:Corner, edge:Edge;
// Break cycles so the garbage collector will release data.
if (points) {
points.splice(0, points.length);
}
if (edges) {
for each (edge in edges) {
edge.d0 = edge.d1 = null;
edge.v0 = edge.v1 = null;
}
edges.splice(0, edges.length);
}
if (centers) {
for each (p in centers) {
p.neighbors.splice(0, p.neighbors.length);
p.corners.splice(0, p.corners.length);
p.borders.splice(0, p.borders.length);
}
centers.splice(0, centers.length);
}
if (corners) {
for each (q in corners) {
q.adjacent.splice(0, q.adjacent.length);
q.touches.splice(0, q.touches.length);
q.protrudes.splice(0, q.protrudes.length);
q.downslope = null;
q.watershed = null;
}
corners.splice(0, corners.length);
}
// Clear the previous graph data.
if (!points) points = new Vector.<Point>();
if (!edges) edges = new Vector.<Edge>();
if (!centers) centers = new Vector.<Center>();
if (!corners) corners = new Vector.<Corner>();
System.gc();
}
public function go(first:int, last:int):void {
var stages:Array = [];
function timeIt(name:String, fn:Function):void {
var t:Number = getTimer();
fn();
}
// Generate the initial random set of points
stages.push
(["Place points...",
function():void {
reset();
points = generateRandomPoints();
}]);
stages.push
(["Improve points...",
function():void {
improveRandomPoints(points);
}]);
// Create a graph structure from the Voronoi edge list. The
// methods in the Voronoi object are somewhat inconvenient for
// my needs, so I transform that data into the data I actually
// need: edges connected to the Delaunay triangles and the
// Voronoi polygons, a reverse map from those four points back
// to the edge, a map from these four points to the points
// they connect to (both along the edge and crosswise).
stages.push
( ["Build graph...",
function():void {
var voronoi:Voronoi = new Voronoi(points, null, new Rectangle(0, 0, SIZE, SIZE));
buildGraph(points, voronoi);
improveCorners();
voronoi.dispose();
voronoi = null;
points = null;
}]);
stages.push
(["Assign elevations...",
function():void {
// Determine the elevations and water at Voronoi corners.
assignCornerElevations();
// Determine polygon and corner type: ocean, coast, land.
assignOceanCoastAndLand();
// Rescale elevations so that the highest is 1.0, and they're
// distributed well. We want lower elevations to be more common
// than higher elevations, in proportions approximately matching
// concentric rings. That is, the lowest elevation is the
// largest ring around the island, and therefore should more
// land area than the highest elevation, which is the very
// center of a perfectly circular island.
redistributeElevations(landCorners(corners));
// Assign elevations to non-land corners
for each (var q:Corner in corners) {
if (q.ocean || q.coast) {
q.elevation = 0.0;
}
}
// Polygon elevations are the average of their corners
assignPolygonElevations();
}]);
stages.push
(["Assign moisture...",
function():void {
// Determine downslope paths.
calculateDownslopes();
// Determine watersheds: for every corner, where does it flow
// out into the ocean?
calculateWatersheds();
// Create rivers.
createRivers();
// Determine moisture at corners, starting at rivers
// and lakes, but not oceans. Then redistribute
// moisture to cover the entire range evenly from 0.0
// to 1.0. Then assign polygon moisture as the average
// of the corner moisture.
assignCornerMoisture();
redistributeMoisture(landCorners(corners));
assignPolygonMoisture();
}]);
stages.push
(["Decorate map...",
function():void {
assignBiomes();
}]);
for (var i:int = first; i < last; i++) {
timeIt(stages[i][0], stages[i][1]);
}
}
// Generate random points and assign them to be on the island or
// in the water. Some water points are inland lakes; others are
// ocean. We'll determine ocean later by looking at what's
// connected to ocean.
public function generateRandomPoints():Vector.<Point> {
var p:Point, i:int, points:Vector.<Point> = new Vector.<Point>();
for (i = 0; i < NUM_POINTS; i++) {
p = new Point(mapRandom.nextDoubleRange(10, SIZE-10),
mapRandom.nextDoubleRange(10, SIZE-10));
points.push(p);
}
return points;
}
// Improve the random set of points with Lloyd Relaxation.
public function improveRandomPoints(points:Vector.<Point>):void {
// We'd really like to generate "blue noise". Algorithms:
// 1. Poisson dart throwing: check each new point against all
// existing points, and reject it if it's too close.
// 2. Start with a hexagonal grid and randomly perturb points.
// 3. Lloyd Relaxation: move each point to the centroid of the
// generated Voronoi polygon, then generate Voronoi again.
// 4. Use force-based layout algorithms to push points away.
// 5. More at http://www.cs.virginia.edu/~gfx/pubs/antimony/
// Option 3 is implemented here. If it's run for too many iterations,
// it will turn into a grid, but convergence is very slow, and we only
// run it a few times.
var i:int, p:Point, q:Point, voronoi:Voronoi, region:Vector.<Point>;
for (i = 0; i < NUM_LLOYD_ITERATIONS; i++) {
voronoi = new Voronoi(points, null, new Rectangle(0, 0, SIZE, SIZE));
for each (p in points) {
region = voronoi.region(p);
p.x = 0.0;
p.y = 0.0;
for each (q in region) {
p.x += q.x;
p.y += q.y;
}
p.x /= region.length;
p.y /= region.length;
region.splice(0, region.length);
}
voronoi.dispose();
}
}
// Although Lloyd relaxation improves the uniformity of polygon
// sizes, it doesn't help with the edge lengths. Short edges can
// be bad for some games, and lead to weird artifacts on
// rivers. We can easily lengthen short edges by moving the
// corners, but **we lose the Voronoi property**. The corners are
// moved to the average of the polygon centers around them. Short
// edges become longer. Long edges tend to become shorter. The
// polygons tend to be more uniform after this step.
public function improveCorners():void {
var newCorners:Vector.<Point> = new Vector.<Point>(corners.length);
var q:Corner, r:Center, point:Point, i:int, edge:Edge;
// First we compute the average of the centers next to each corner.
for each (q in corners) {
if (q.border) {
newCorners[q.index] = q.point;
} else {
point = new Point(0.0, 0.0);
for each (r in q.touches) {
point.x += r.point.x;
point.y += r.point.y;
}
point.x /= q.touches.length;
point.y /= q.touches.length;
newCorners[q.index] = point;
}
}
// Move the corners to the new locations.
for (i = 0; i < corners.length; i++) {
corners[i].point = newCorners[i];
}
// The edge midpoints were computed for the old corners and need
// to be recomputed.
for each (edge in edges) {
if (edge.v0 && edge.v1) {
edge.midpoint = Point.interpolate(edge.v0.point, edge.v1.point, 0.5);
}
}
}
// Create an array of corners that are on land only, for use by
// algorithms that work only on land. We return an array instead
// of a vector because the redistribution algorithms want to sort
// this array using Array.sortOn.
public function landCorners(corners:Vector.<Corner>):Array {
var q:Corner, locations:Array = [];
for each (q in corners) {
if (!q.ocean && !q.coast) {
locations.push(q);
}
}
return locations;
}
// Build graph data structure in 'edges', 'centers', 'corners',
// based on information in the Voronoi results: point.neighbors
// will be a list of neighboring points of the same type (corner
// or center); point.edges will be a list of edges that include
// that point. Each edge connects to four points: the Voronoi edge
// edge.{v0,v1} and its dual Delaunay triangle edge edge.{d0,d1}.
// For boundary polygons, the Delaunay edge will have one null
// point, and the Voronoi edge may be null.
public function buildGraph(points:Vector.<Point>, voronoi:Voronoi):void {
var p:Center, q:Corner, point:Point, other:Point;
var libedges:Vector.<DEdge> = voronoi.edges();
var centerLookup:Dictionary = new Dictionary();
// Build Center objects for each of the points, and a lookup map
// to find those Center objects again as we build the graph
for each (point in points) {
p = new Center();
p.index = centers.length;
p.point = point;
p.neighbors = new Vector.<Center>();
p.borders = new Vector.<Edge>();
p.corners = new Vector.<Corner>();
centers.push(p);
centerLookup[point] = p;
}
// Workaround for Voronoi lib bug: we need to call region()
// before Edges or neighboringSites are available
for each (p in centers) {
voronoi.region(p.point);
}
// The Voronoi library generates multiple Point objects for
// corners, and we need to canonicalize to one Corner object.
// To make lookup fast, we keep an array of Points, bucketed by
// x value, and then we only have to look at other Points in
// nearby buckets. When we fail to find one, we'll create a new
// Corner object.
var _cornerMap:Array = [];
function makeCorner(point:Point):Corner {
var q:Corner;
if (point == null) return null;
for (var bucket:int = int(point.x)-1; bucket <= int(point.x)+1; bucket++) {
for each (q in _cornerMap[bucket]) {
var dx:Number = point.x - q.point.x;
var dy:Number = point.y - q.point.y;
if (dx*dx + dy*dy < 1e-6) {
return q;
}
}
}
bucket = int(point.x);
if (!_cornerMap[bucket]) _cornerMap[bucket] = [];
q = new Corner();
q.index = corners.length;
corners.push(q);
q.point = point;
q.border = (point.x == 0 || point.x == SIZE
|| point.y == 0 || point.y == SIZE);
q.touches = new Vector.<Center>();
q.protrudes = new Vector.<Edge>();
q.adjacent = new Vector.<Corner>();
_cornerMap[bucket].push(q);
return q;
}
for each (var libedge:DEdge in libedges) {
var dedge:LineSegment = libedge.delaunayLine();
var vedge:LineSegment = libedge.voronoiEdge();
// Fill the graph data. Make an Edge object corresponding to
// the edge from the voronoi library.
var edge:Edge = new Edge();
edge.index = edges.length;
edge.river = 0;
edges.push(edge);
edge.midpoint = vedge.p0 && vedge.p1 && Point.interpolate(vedge.p0, vedge.p1, 0.5);
// Edges point to corners. Edges point to centers.
edge.v0 = makeCorner(vedge.p0);
edge.v1 = makeCorner(vedge.p1);
edge.d0 = centerLookup[dedge.p0];
edge.d1 = centerLookup[dedge.p1];
// Centers point to edges. Corners point to edges.
if (edge.d0 != null) { edge.d0.borders.push(edge); }
if (edge.d1 != null) { edge.d1.borders.push(edge); }
if (edge.v0 != null) { edge.v0.protrudes.push(edge); }
if (edge.v1 != null) { edge.v1.protrudes.push(edge); }
function addToCornerList(v:Vector.<Corner>, x:Corner):void {
if (x != null && v.indexOf(x) < 0) { v.push(x); }
}
function addToCenterList(v:Vector.<Center>, x:Center):void {
if (x != null && v.indexOf(x) < 0) { v.push(x); }
}
// Centers point to centers.
if (edge.d0 != null && edge.d1 != null) {
addToCenterList(edge.d0.neighbors, edge.d1);
addToCenterList(edge.d1.neighbors, edge.d0);
}
// Corners point to corners
if (edge.v0 != null && edge.v1 != null) {
addToCornerList(edge.v0.adjacent, edge.v1);
addToCornerList(edge.v1.adjacent, edge.v0);
}
// Centers point to corners
if (edge.d0 != null) {
addToCornerList(edge.d0.corners, edge.v0);
addToCornerList(edge.d0.corners, edge.v1);
}
if (edge.d1 != null) {
addToCornerList(edge.d1.corners, edge.v0);
addToCornerList(edge.d1.corners, edge.v1);
}
// Corners point to centers
if (edge.v0 != null) {
addToCenterList(edge.v0.touches, edge.d0);
addToCenterList(edge.v0.touches, edge.d1);
}
if (edge.v1 != null) {
addToCenterList(edge.v1.touches, edge.d0);
addToCenterList(edge.v1.touches, edge.d1);
}
}
}
// Determine elevations and water at Voronoi corners. By
// construction, we have no local minima. This is important for
// the downslope vectors later, which are used in the river
// construction algorithm. Also by construction, inlets/bays
// push low elevation areas inland, which means many rivers end
// up flowing out through them. Also by construction, lakes
// often end up on river paths because they don't raise the
// elevation as much as other terrain does.
public function assignCornerElevations():void {
var q:Corner, s:Corner;
var queue:Array = [];
for each (q in corners) {
q.water = !inside(q.point);
}
for each (q in corners) {
// The edges of the map are elevation 0
if (q.border) {
q.elevation = 0.0;
queue.push(q);
} else {
q.elevation = Infinity;
}
}
// Traverse the graph and assign elevations to each point. As we
// move away from the map border, increase the elevations. This
// guarantees that rivers always have a way down to the coast by
// going downhill (no local minima).
while (queue.length > 0) {
q = queue.shift();
for each (s in q.adjacent) {
// Every step up is epsilon over water or 1 over land. The
// number doesn't matter because we'll rescale the
// elevations later.
var newElevation:Number = 0.01 + q.elevation;
if (!q.water && !s.water) {
newElevation += 1;
}
// If this point changed, we'll add it to the queue so
// that we can process its neighbors too.
if (newElevation < s.elevation) {
s.elevation = newElevation;
queue.push(s);
}
}
}
}
// Change the overall distribution of elevations so that lower
// elevations are more common than higher
// elevations. Specifically, we want elevation X to have frequency
// (1-X). To do this we will sort the corners, then set each
// corner to its desired elevation.
public function redistributeElevations(locations:Array):void {
// SCALE_FACTOR increases the mountain area. At 1.0 the maximum
// elevation barely shows up on the map, so we set it to 1.1.
var SCALE_FACTOR:Number = 1.1;
var i:int, y:Number, x:Number;
locations.sortOn('elevation', Array.NUMERIC);
for (i = 0; i < locations.length; i++) {
// Let y(x) be the total area that we want at elevation <= x.
// We want the higher elevations to occur less than lower
// ones, and set the area to be y(x) = 1 - (1-x)^2.
y = i/(locations.length-1);
// Now we have to solve for x, given the known y.
// * y = 1 - (1-x)^2
// * y = 1 - (1 - 2x + x^2)
// * y = 2x - x^2
// * x^2 - 2x + y = 0
// From this we can use the quadratic equation to get:
x = Math.sqrt(SCALE_FACTOR) - Math.sqrt(SCALE_FACTOR*(1-y));
if (x > 1.0) x = 1.0; // TODO: does this break downslopes?
locations[i].elevation = x;
}
}
// Change the overall distribution of moisture to be evenly distributed.
public function redistributeMoisture(locations:Array):void {
var i:int;
locations.sortOn('moisture', Array.NUMERIC);
for (i = 0; i < locations.length; i++) {
locations[i].moisture = i/(locations.length-1);
}
}
// Determine polygon and corner types: ocean, coast, land.
public function assignOceanCoastAndLand():void {
// Compute polygon attributes 'ocean' and 'water' based on the
// corner attributes. Count the water corners per
// polygon. Oceans are all polygons connected to the edge of the
// map. In the first pass, mark the edges of the map as ocean;
// in the second pass, mark any water-containing polygon
// connected an ocean as ocean.
var queue:Array = [];
var p:Center, q:Corner, r:Center, numWater:int;
for each (p in centers) {
numWater = 0;
for each (q in p.corners) {
if (q.border) {
p.border = true;
p.ocean = true;
q.water = true;
queue.push(p);
}
if (q.water) {
numWater += 1;
}
}
p.water = (p.ocean || numWater >= p.corners.length * LAKE_THRESHOLD);
}
while (queue.length > 0) {
p = queue.shift();
for each (r in p.neighbors) {
if (r.water && !r.ocean) {
r.ocean = true;
queue.push(r);
}
}
}
// Set the polygon attribute 'coast' based on its neighbors. If
// it has at least one ocean and at least one land neighbor,
// then this is a coastal polygon.
for each (p in centers) {
var numOcean:int = 0;
var numLand:int = 0;
for each (r in p.neighbors) {
numOcean += int(r.ocean);
numLand += int(!r.water);
}
p.coast = (numOcean > 0) && (numLand > 0);
}
// Set the corner attributes based on the computed polygon
// attributes. If all polygons connected to this corner are
// ocean, then it's ocean; if all are land, then it's land;
// otherwise it's coast.
for each (q in corners) {
numOcean = 0;
numLand = 0;
for each (p in q.touches) {
numOcean += int(p.ocean);
numLand += int(!p.water);
}
q.ocean = (numOcean == q.touches.length);
q.coast = (numOcean > 0) && (numLand > 0);
q.water = q.border || ((numLand != q.touches.length) && !q.coast);
}
}
// Polygon elevations are the average of the elevations of their corners.
public function assignPolygonElevations():void {
var p:Center, q:Corner, sumElevation:Number;
for each (p in centers) {
sumElevation = 0.0;
for each (q in p.corners) {
sumElevation += q.elevation;
}
p.elevation = sumElevation / p.corners.length;
}
}
// Calculate downslope pointers. At every point, we point to the
// point downstream from it, or to itself. This is used for
// generating rivers and watersheds.
public function calculateDownslopes():void {
var q:Corner, s:Corner, r:Corner;
for each (q in corners) {
r = q;
for each (s in q.adjacent) {
if (s.elevation <= r.elevation) {
r = s;
}
}
q.downslope = r;
}
}
// Calculate the watershed of every land point. The watershed is
// the last downstream land point in the downslope graph. TODO:
// watersheds are currently calculated on corners, but it'd be
// more useful to compute them on polygon centers so that every
// polygon can be marked as being in one watershed.
public function calculateWatersheds():void {
var q:Corner, r:Corner, i:int, changed:Boolean;
// Initially the watershed pointer points downslope one step.
for each (q in corners) {
q.watershed = q;
if (!q.ocean && !q.coast) {
q.watershed = q.downslope;
}
}
// Follow the downslope pointers to the coast. Limit to 100
// iterations although most of the time with NUM_POINTS=2000 it
// only takes 20 iterations because most points are not far from
// a coast. TODO: can run faster by looking at
// p.watershed.watershed instead of p.downslope.watershed.
for (i = 0; i < 100; i++) {
changed = false;
for each (q in corners) {
if (!q.ocean && !q.coast && !q.watershed.coast) {
r = q.downslope.watershed;
if (!r.ocean) q.watershed = r;
changed = true;
}
}
if (!changed) break;
}
// How big is each watershed?
for each (q in corners) {
r = q.watershed;
r.watershed_size = 1 + (r.watershed_size || 0);
}
}
// Create rivers along edges. Pick a random corner point, then
// move downslope. Mark the edges and corners as rivers.
public function createRivers():void {
var i:int, q:Corner, edge:Edge;
for (i = 0; i < SIZE/2; i++) {
q = corners[mapRandom.nextIntRange(0, corners.length-1)];
if (q.ocean || q.elevation < 0.3 || q.elevation > 0.9) continue;
// Bias rivers to go west: if (q.downslope.x > q.x) continue;
while (!q.coast) {
if (q == q.downslope) {
break;
}
edge = lookupEdgeFromCorner(q, q.downslope);
edge.river = edge.river + 1;
q.river = (q.river || 0) + 1;
q.downslope.river = (q.downslope.river || 0) + 1; // TODO: fix double count
q = q.downslope;
}
}
}
// Calculate moisture. Freshwater sources spread moisture: rivers
// and lakes (not oceans). Saltwater sources have moisture but do
// not spread it (we set it at the end, after propagation).
public function assignCornerMoisture():void {
var q:Corner, r:Corner, newMoisture:Number;
var queue:Array = [];
// Fresh water
for each (q in corners) {
if ((q.water || q.river > 0) && !q.ocean) {
q.moisture = q.river > 0? Math.min(3.0, (0.2 * q.river)) : 1.0;
queue.push(q);
} else {
q.moisture = 0.0;
}
}
while (queue.length > 0) {
q = queue.shift();
for each (r in q.adjacent) {
newMoisture = q.moisture * 0.9;
if (newMoisture > r.moisture) {
r.moisture = newMoisture;
queue.push(r);
}
}
}
// Salt water
for each (q in corners) {
if (q.ocean || q.coast) {
q.moisture = 1.0;
}
}
}
// Polygon moisture is the average of the moisture at corners
public function assignPolygonMoisture():void {
var p:Center, q:Corner, sumMoisture:Number;
for each (p in centers) {
sumMoisture = 0.0;
for each (q in p.corners) {
if (q.moisture > 1.0) q.moisture = 1.0;
sumMoisture += q.moisture;
}
p.moisture = sumMoisture / p.corners.length;
}
}
// Assign a biome type to each polygon. If it has
// ocean/coast/water, then that's the biome; otherwise it depends
// on low/high elevation and low/medium/high moisture. This is
// roughly based on the Whittaker diagram but adapted to fit the
// needs of the island map generator.
static public function getBiome(p:Center):String {
if (p.ocean) {
return 'OCEAN';
} else if (p.water) {
if (p.elevation < 0.1) return 'MARSH';
if (p.elevation > 0.8) return 'ICE';
return 'LAKE';
} else if (p.coast) {
return 'BEACH';
} else if (p.elevation > 0.8) {
if (p.moisture > 0.50) return 'SNOW';
else if (p.moisture > 0.33) return 'TUNDRA';
else if (p.moisture > 0.16) return 'BARE';
else return 'SCORCHED';
} else if (p.elevation > 0.6) {
if (p.moisture > 0.66) return 'TAIGA';
else if (p.moisture > 0.33) return 'SHRUBLAND';
else return 'TEMPERATE_DESERT';
} else if (p.elevation > 0.3) {
if (p.moisture > 0.83) return 'TEMPERATE_RAIN_FOREST';
else if (p.moisture > 0.50) return 'TEMPERATE_DECIDUOUS_FOREST';
else if (p.moisture > 0.16) return 'GRASSLAND';
else return 'TEMPERATE_DESERT';
} else {
if (p.moisture > 0.66) return 'TROPICAL_RAIN_FOREST';
else if (p.moisture > 0.33) return 'TROPICAL_SEASONAL_FOREST';
else if (p.moisture > 0.16) return 'GRASSLAND';
else return 'SUBTROPICAL_DESERT';
}
}
public function assignBiomes():void {
var p:Center;
for each (p in centers) {
p.biome = getBiome(p);
}
}
// Look up a Voronoi Edge object given two adjacent Voronoi
// polygons, or two adjacent Voronoi corners
public function lookupEdgeFromCenter(p:Center, r:Center):Edge {
for each (var edge:Edge in p.borders) {
if (edge.d0 == r || edge.d1 == r) return edge;
}
return null;
}
public function lookupEdgeFromCorner(q:Corner, s:Corner):Edge {
for each (var edge:Edge in q.protrudes) {
if (edge.v0 == s || edge.v1 == s) return edge;
}
return null;
}
// Determine whether a given point should be on the island or in the water.
public function inside(p:Point):Boolean {
return islandShape(new Point(2*(p.x/SIZE - 0.5), 2*(p.y/SIZE - 0.5)));
}
}
//}
//package {
/*public*/ class MathUtils {
static public function clamp(n:Number):Number {
return n < 0 ? 0 : n > 1 ? 1 : n;
}
static public function contrast(n:Number, c:Number = 1):Number {
return ((n*2 - 1) * c * c + 1) * 0.5;
}
static public function brightness(n:Number, b:Number = 0):Number {
return (b<0) ? n * (1 + b) : 1 - (1 - n) * (1 - b);
}
}
//}
//package {
/*public*/ class PM_PRNG
{
public var seed:uint;
public static const MAX:uint = 0X7FFFFFFE;
public function PM_PRNG()
{
seed = 1;
}
public function nextInt():uint
{
return gen();
}
public function nextDouble():Number
{
return (gen() / 2147483647);
}
public function nextIntRange(min:Number, max:Number):uint
{
min -= .4999;
max += .4999;
return Math.round(min + ((max - min) * nextDouble()));
}
public function nextDoubleRange(min:Number, max:Number):Number
{
return min + ((max - min) * nextDouble());
}
public function setSeed(v:uint):void
{
if (v == 0) throw new Error("Seed value cannot be zero!");
if (v > MAX) throw new Error("Seed cannot exceed max:"+seed+" /" + MAX);
seed = v;
}
private function gen():uint
{
return seed = (seed * 16807) % 2147483647;
}
}
//}
