flash on 2013-1-23

/**
 * Copyright ohisama ( http://wonderfl.net/user/ohisama )
 * GNU General Public License, v3 ( http://www.gnu.org/licenses/quick-guide-gplv3.html )
 * Downloaded from: http://wonderfl.net/c/viKA
 */

package
{
    import flash.display.Sprite;
    import flash.events.Event;
    import org.papervision3d.materials.*;
    import org.papervision3d.view.*;
    public class Hemisphere0 extends BasicView
    {
        private var hemisphere: Hemisphere;
        public function Hemisphere0()
        {
            var material: WireframeMaterial = new WireframeMaterial(0x0000FF);
            material.doubleSided = true;
            hemisphere = new Hemisphere(material, 300, 10, 10);
            scene.addChild(hemisphere);
            startRendering();
            this.addEventListener(Event.ENTER_FRAME, loop);
        }
        private function loop(evt: Event): void
        {
            hemisphere.rotationX = viewport.mouseX;
            hemisphere.rotationY = viewport.mouseY;
        }
    }
}
import org.papervision3d.Papervision3D;
import org.papervision3d.core.geom.*;
import org.papervision3d.core.geom.renderables.Triangle3D;
import org.papervision3d.core.geom.renderables.Vertex3D;
import org.papervision3d.core.math.NumberUV;
import org.papervision3d.core.proto.*;
class Hemisphere extends TriangleMesh3D
{
    private var segmentsW: Number;
    private var segmentsH: Number;
    static public var DEFAULT_RADIUS: Number = 100;
    static public var DEFAULT_SCALE: Number = 1;
    static public var DEFAULT_SEGMENTSW: Number = 8;
    static public var DEFAULT_SEGMENTSH: Number = 6;
    static public var MIN_SEGMENTSW: Number = 3;
    static public var MIN_SEGMENTSH: Number = 2;
    public function Hemisphere(material: MaterialObject3D = null, radius: Number = 100, segmentsW: int = 8, segmentsH: int = 6)
    {
        super(material, new Array(), new Array(), null);
        this.segmentsW = Math.max(MIN_SEGMENTSW, segmentsW || DEFAULT_SEGMENTSW);
        this.segmentsH = Math.max(MIN_SEGMENTSH, segmentsH || DEFAULT_SEGMENTSH);
        if (radius == 0) radius = DEFAULT_RADIUS;
        var scale: Number = DEFAULT_SCALE;
        buildHemiphere(radius);
    }
    private function buildHemiphere(fRadius: Number): void
    {
        var i: Number, j: Number, k: Number;
        var iHor: Number = Math.max(3, this.segmentsW);
        var iVer: Number = Math.max(2, this.segmentsH);
        var aVertice: Array = this.geometry.vertices;
        var aFace: Array = this.geometry.faces;
        var aVtc: Array = new Array();
        for (j = 0; j < (iVer / 2 + 1); j++)
        {
            var fRad1: Number = Number(j / iVer);
            var fZ: Number = -fRadius * Math.cos(fRad1 * Math.PI);
            var fRds: Number = fRadius * Math.sin(fRad1 * Math.PI);
            var aRow: Array = new Array();
            var oVtx: Vertex3D;
            for (i = 0; i < iHor; i++)
            {
                var fRad2: Number = Number(2 * i / iHor);
                var fX: Number = fRds * Math.sin(fRad2 * Math.PI);
                var fY: Number = fRds * Math.cos(fRad2 * Math.PI);
                if (!((j == 0 || j == iVer) && i > 0))
                {
                    oVtx = new Vertex3D(fY, fZ, fX);
                    aVertice.push(oVtx);
                }
                aRow.push(oVtx);
            }
            aVtc.push(aRow);
        }
        var iVerNum: int = aVtc.length;
        for (j = 0; j < iVerNum; j++)
        {
            var iHorNum: int = aVtc[j].length;
            if (j > 0)
            {
                for (i = 0; i < iHorNum; i++)
                {
                    var bEnd: Boolean = i == (iHorNum - 1);
                    var aP1: Vertex3D = aVtc[j][bEnd ? 0 : i + 1];
                    var aP2: Vertex3D = aVtc[j][(bEnd ? iHorNum - 1 : i)];
                    var aP3: Vertex3D = aVtc[j-1][(bEnd ? iHorNum - 1 : i)];
                    var aP4: Vertex3D = aVtc[j-1][bEnd ? 0 : i + 1];
                    var fJ0: Number = j / (iVerNum - 1);
                    var fJ1: Number = (j - 1) / (iVerNum - 1);
                    var fI0: Number = (i + 1) / iHorNum;
                    var fI1: Number = i / iHorNum;
                    var aP4uv: NumberUV = new NumberUV(fI0, fJ1);
                    var aP1uv: NumberUV = new NumberUV(fI0, fJ0);
                    var aP2uv: NumberUV = new NumberUV(fI1, fJ0);
                    var aP3uv: NumberUV = new NumberUV(fI1, fJ1);
                    if (j < (aVtc.length - 1))  aFace.push(new Triangle3D(this, new Array(aP1, aP2, aP3), material, new Array(aP1uv, aP2uv, aP3uv)));
                    if (j > 1) aFace.push(new Triangle3D(this, new Array(aP1, aP3, aP4), material, new Array(aP1uv, aP3uv, aP4uv)));
                }
            }
        }
        for (i = 0; i < iHorNum; i++)
        {
            var bEnd_2: Boolean = i== (iHorNum - 1);
            var aP1_2: Vertex3D = aVtc[iVerNum - 1][bEnd_2 ? 0 : i + 1];
            var aP2_2: Vertex3D = aVtc[iVerNum - 1][bEnd_2 ? iHorNum - 1 : i];
            var aP3_2: Vertex3D = aVtc[iVerNum - 2][bEnd_2 ? iHorNum - 1 : i];
            var uvA: NumberUV = new NumberUV(0, 0);
            var uvC: NumberUV = new NumberUV(1, 0);
            var uvB: NumberUV = new NumberUV(0, 1);
            aFace.push(new Triangle3D(this, new Array(aP1_2, aP2_2, aP3_2), material, new Array(uvA, uvC, uvB)));
        }
        for each(var t: Triangle3D in aFace)
        {
            t.renderCommand.create = createRenderTriangle;
        }
        this.geometry.ready = true;
        if (Papervision3D.useRIGHTHANDED) this.geometry.flipFaces();
    }
}
