BitmapData Memory Allocation

by pigiuz

This test shows the bitmapdata memory allocation is not related to bitmapdata's area (it should be width*height*4).
The memory representation of a bitmapdata is 256bytes aligned for each row ( Math.max(height*(width/64),1) ). This means that bitmaps occupation is significantly different depending on their orientation: vertical bitmaps are much larger than horizontal ones (up to 256x !!!)

In the chart: red line is a vertical bitmapdata occupation and blue line is the occupation of a horizontal one of the same area.

see this bug report in adobe jira https://bugbase.adobe.com/index.cfm?event=bug&id=3094186

♥2 | Line 53 | Modified 2012-01-21 03:40:05 | MIT License

[Download] [Fullscreen] [Reload]

ActionScript3 source code

/**
 * Copyright pigiuz ( http://wonderfl.net/user/pigiuz )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/t6eA
 */

package {
    import flash.display.Bitmap;
    import flash.display.BitmapData;
    import flash.display.Sprite;
    import flash.events.Event;
    import flash.geom.Rectangle;
    import flash.system.System;

    [SWF(rameRate="60")]
    public class FlashTest extends Sprite {

        public const kb:Number = 1024;
        public const mb:Number = 1024*kb;
        public const maxMem:Number = 1*mb;
        public const maxSize:Number = 4096;
        public const minSize:Number = 1;

        private var _count:uint;
        private var _frameBuffer:BitmapData;
        private var _orientation:Boolean;

        public function FlashTest() {
            _frameBuffer = new BitmapData(stage.stageWidth,stage.stageHeight,true,0);
            addChild(new Bitmap(_frameBuffer));

            _count = minSize;
            _orientation = true;

            addEventListener(Event.ENTER_FRAME,loop);
        }

        public function loop(e:Event):void
        {

            if(_orientation){
                _frameBuffer.scroll(-1,0);
                _frameBuffer.fillRect(new Rectangle(_frameBuffer.width-1,0,1,_frameBuffer.height),0);
            }
            var prevMem:Number = System.totalMemoryNumber;
            var nextMem:Number;
            var bd:BitmapData;
            if(_orientation)
                bd = new BitmapData(_count,1,true,0);
            else
                bd = new BitmapData(1,_count,true,0);

            nextMem = System.totalMemoryNumber;

            var deltaMem:Number = nextMem-prevMem;
            var perc:Number = deltaMem/maxMem;

            trace(prevMem,nextMem,deltaMem,((perc*10000)>>0)/100);
            _frameBuffer.setPixel32(_frameBuffer.width-1,_frameBuffer.height-1-perc*_frameBuffer.height,_orientation?0xFF0000FF:0xFFFF0000);

            _count++;
            _count %= maxSize;
            if(_count<minSize){
                _count = minSize;
                _frameBuffer.scroll(-1,0);
                _frameBuffer.fillRect(new Rectangle(_frameBuffer.width-1,0,1,_frameBuffer.height),0xFF00FF00);
            }
            _orientation = !_orientation;
        }
    }
}
