* Copyright y_tti ( http://wonderfl.net/user/y_tti )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/qs4y
*/
package
{
import gs.TweenMax;
import gs.easing.Elastic;
import flash.display.Graphics;
import flash.display.Sprite;
import flash.events.Event;
import flash.events.MouseEvent;
import flash.geom.Point;
import flash.net.URLLoader;
import flash.net.URLRequest;
import flash.system.Security;
import flash.system.SecurityDomain;
import frocessing.core.F5Graphics;
import frocessing.shape.FShape;
import frocessing.shape.FShapeContainer;
import frocessing.shape.FShapeLine;
import frocessing.shape.FShapeRect;
import frocessing.shape.FShapeSVG;
import frocessing.shape.IFShape;
[SWF(width = "465", height = "465", frameRate = "30", backgroundColor = "0xFFFFFF")]
public class SVGTest extends Sprite
{
private var _loader:URLLoader;
private var _shapedata:FShapeSVG;
private var _commands:Vector.<int>;
private var _vertices:Vector.<Particle>;
private var _canvas:Sprite;
private var _fshapes:Array;
public static const MOVE_TO :int = 1;
public static const LINE_TO :int = 2;
public static const CURVE_TO :int = 3;
public static const BEZIER_TO :int = 10;
public static const CLOSE_PATH :int = 100;
public function SVGTest()
{
Wonderfl.capture_delay( 5 );
addEventListener(Event.ADDED_TO_STAGE , _init );
}
private function _init(e:Event):void {
var svgURL:String = "http://www.y-tti.com/lab/assets/henoheno.svg";
//お借りします。ありがとうございます。
//http://5ivestar.org/blog/2008/12/wonderfl-webproxy/
Security.loadPolicyFile("http://5ivestar.org/proxy/crossdomain.xml");
_loader = new URLLoader();
_loader.addEventListener(Event.COMPLETE , _loaderHandler);
_loader.load(new URLRequest("http://5ivestar.org/proxy/"+svgURL));
}
private function _loaderHandler(event:Event):void
{
//SVGパース
var svg:XML = XML(_loader.data);
_shapedata = new FShapeSVG(svg);
//真ん中寄せ
var shapeSP:Sprite = _shapedata.toSprite();
_canvas = new Sprite();
addChild(_canvas);
_canvas.x = (stage.stageWidth - shapeSP.width)>>1;
_canvas.y = (stage.stageHeight - shapeSP.height)>>1;
_commands = new Vector.<int>();
_vertices = new Vector.<Particle>();
_fshapes = [];
_getFshapes(_shapedata); //FShape型やその他の型を取り出す
_parse(); //MOVE_TOやその他のアクションと位置を保持
addEventListener(Event.ENTER_FRAME , _update);
_canvas.addEventListener(MouseEvent.ROLL_OVER , _rollOverHandler);
}
private function _getFshapes($fshapeContainer:FShapeContainer):void {
//中身がFShapeContainerだったときは再帰
for (var i:int = 0; i < $fshapeContainer.getChildCount(); i++) {
var shape:IFShape = $fshapeContainer.getChildAt(i);
if(shape is FShapeContainer) {
arguments.callee(shape);
} else {
_fshapes.push(shape);
}
}
}
private function _parse():void {
//_commandsに命令
//_verticesに位置をぶちこむ
for (var i:int = 0; i < _fshapes.length; i++) {
var shape:IFShape =_fshapes[i];
if(shape is FShapeLine){
var fline:FShapeLine = FShapeLine(shape);
_commands.push(MOVE_TO);
_vertices.push( new Particle(fline.x1,fline.y1) );
_commands.push(LINE_TO);
_vertices.push( new Particle(fline.x2,fline.y2) );
} else if(shape is FShape) {
var fshape:FShape = FShape(shape);
var xi:int = 0;
var yi:int = 1;
for (var j:int = 0; j < fshape.commands.length; j++) {
var cmd:int = fshape.commands[j];
if ( cmd == LINE_TO )
{
_commands.push(LINE_TO);
_vertices.push( new Particle(fshape.vertices[xi],fshape.vertices[yi]) );
xi += 2;
yi += 2;
}
else if ( cmd == BEZIER_TO )
{
_commands.push(BEZIER_TO);
_vertices.push(
new Particle(fshape.vertices[xi],fshape.vertices[yi]) ,
new Particle(fshape.vertices[xi+2],fshape.vertices[yi+2]),
new Particle(fshape.vertices[xi+4],fshape.vertices[yi+4]));
xi += 6;
yi += 6;
}
else if ( cmd == CURVE_TO )
{
_commands.push(CURVE_TO);
_vertices.push( new Particle(fshape.vertices[xi],fshape.vertices[yi]),
new Particle(fshape.vertices[xi+2],fshape.vertices[yi+2]));
xi += 4;
yi += 4;
}
else if ( cmd == MOVE_TO )
{
_commands.push(MOVE_TO);
_vertices.push( new Particle(fshape.vertices[xi],fshape.vertices[yi]) );
xi += 2;
yi += 2;
}
else if ( cmd == CLOSE_PATH )
{
_commands.push(CLOSE_PATH);
}
}
} else if(shape is FShapeRect){
var frect:FShapeRect = FShapeRect(shape);
_commands.push(MOVE_TO);
_vertices.push( new Particle(frect.x,frect.y) );
_commands.push(LINE_TO);
_vertices.push( new Particle(frect.x +frect.width,frect.y) );
_commands.push(LINE_TO);
_vertices.push( new Particle(frect.x +frect.width,frect.y+frect.height) );
_commands.push(LINE_TO);
_vertices.push( new Particle(frect.x,frect.y+frect.height) );
_commands.push(CLOSE_PATH);
}
}
}
//private var _t:TimelineMax;
private var _isOverMotion:Boolean = false;
private function _rollOverHandler(event:MouseEvent):void
{
//ロールオーバーでデフォルト位置へ戻してる。
//if(_t && _t.active) return;
if(_isOverMotion) return;
//_t = new TimelineMax();
for (var i:int = 0; i < _vertices.length; i++) {
var p:Particle = _vertices[i] as Particle;
// _t.insert(
TweenMax.to(p ,1 , {x:p.initX , y:p.initY , ease:Elastic.easeOut,easeParams:[5,1],delay:i*0.02,onComplete:function():void{_isOverMotion=false;}} );
// );
}
}
private function _update(e:Event):void {
//位置を更新してドロー
//if( !(_t && _t.active) ){
if(!_isOverMotion){
for (var i:int = 0; i < _vertices.length; i++) {
var p:Particle = _vertices[i] as Particle;
p.x += Math.random()*6-3;
p.y += Math.random()*6-3;
}
}
_draw();
}
private function _draw():void {
//線を書く
var sx:Number = 0;
var sy:Number = 0;
var px:Number = 0;
var py:Number = 0;
var xi:int = 0;
var yi:int = 1;
var pi:int = 0;
var gc:Graphics = _canvas.graphics;
gc.clear();
gc.lineStyle(2,0x0,1);
for (var i:int = 0; i < _commands.length; i++) {
var cmd:int = _commands[i];
if ( cmd == LINE_TO )
{
px = _vertices[pi].x;
py = _vertices[pi].y;
gc.lineTo( px, py );
pi += 1;
}
else if ( cmd == BEZIER_TO )
{
var bx:Number = _vertices[uint(pi+2)].x;
var by:Number = _vertices[uint(pi+2)].y;
_draw_bezier( gc, px, py, _vertices[pi].x, _vertices[pi].y, _vertices[uint(pi+1)].x, _vertices[uint(pi+1)].y, bx, by );
px = bx;
py = by;
pi += 3;
}
else if ( cmd == CURVE_TO )
{
px = _vertices[uint(pi+1)].x;
py = _vertices[uint(pi+1)].y;
gc.curveTo( _vertices[xi].x, _vertices[yi].y, px, py );
pi += 2;
}
else if ( cmd == MOVE_TO )
{
sx = px = _vertices[pi].x;
sy = py = _vertices[pi].y;
gc.moveTo( sx, sy );
pi += 1;
}
else if ( cmd == CLOSE_PATH )
{
gc.lineTo( sx, sy );
px = sx;
py = sy;
}
}
}
public var bezierDetail:uint = 20;
private function _draw_bezier( gc:Graphics, x0:Number, y0:Number, cx0:Number, cy0:Number, cx1:Number, cy1:Number, x:Number, y:Number ):void
{
var k:Number = 1.0/bezierDetail;
var t:Number = 0;
var tp:Number;
for ( var i:int = 1; i <= bezierDetail; i++ )
{
t += k;
tp = 1.0-t;
gc.lineTo( x0*tp*tp*tp + 3*cx0*t*tp*tp + 3*cx1*t*t*tp + x*t*t*t,
y0*tp*tp*tp + 3*cy0*t*tp*tp + 3*cy1*t*t*tp + y*t*t*t );
}
}
}
}
import flash.geom.Point;
class Particle{
public var x:Number = 0;
public var y:Number = 0;
public var initX:Number = 0;
public var initY:Number = 0;
public function Particle($x:Number=0,$y:Number=0){
x = initX = $x;
y = initY = $y;
}
}
