エッジ抽出できない
エッジ抽出をしようと思ったら、なんか変になったしソースも汚い
♥2 |
Line 107 |
Modified 2011-08-12 16:22:16 |
MIT License
archived:2017-03-20 14:57:12
ActionScript3 source code
/**
* Copyright 3f5 ( http://wonderfl.net/user/3f5 )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/q90Z
*/
package {
import flash.display.CapsStyle;
import flash.display.JointStyle;
import flash.display.AVM1Movie;
import flash.events.TimerEvent;
import flash.text.TextLineMetrics;
import flash.utils.Timer;
import flash.text.TextFormat;
import flash.display.BitmapData;
import flash.display.Bitmap;
import flash.text.TextField;
import flash.display.Sprite;
public class Edge extends Sprite {
public function Edge() {
var textFormat:TextFormat = new TextFormat();
textFormat.size = 60;
var text:TextField = new TextField();
text.text = 'あ';
text.autoSize = 'left';
text.setTextFormat(textFormat);
var bitmap:BitmapData = new BitmapData(text.width, text.height);
bitmap.draw(text);
var sprite:Sprite = new Sprite();
sprite.graphics.lineStyle(1, 0xFF0000);
var currentColor:uint = 0xFFFFFF, x:int = 0 , y:int = 0, _x:int, _y:int, hit:Boolean, i:int, map:Object = {}, c:Array, r:Array;
stage.addChild(text);
stage.addChild(sprite);
var p:Array = [
[1, 0],
[0, -1],
[-1, 0],
[1, 1],
[0, 1],
[-1, -1],
[-1, 1],
[1, -1]
];
for (_x = 0; _x < bitmap.width; _x++) {
map[_x] = {};
for (_y = 0; _y < bitmap.height; _y++) {
map[_x][_y] = true;
}
}
var f:Boolean = false;
(function ():void {
hit = false;
for (i = 0; i < p.length; i++) {
_x = x + p[i][0];
_y = y + p[i][1];
if (map.hasOwnProperty(_x) && map[_x].hasOwnProperty(_y) && map[_x][_y] == true) {
if (compColor(bitmap.getPixel(_x, _y), currentColor)) {
x = _x;
y = _y;
hit = true;
text.text = text.text + (i.toString());
break;
}
else {
map[_x][_y] = false;
}
}
}
if (!hit) {
f = true;
for (_x = 0; _x < bitmap.width; _x++) {
for (_y = 0; _y < bitmap.height; _y++) {
if (map[_x] && map[_x][_y] == true) {
x = _x;
y = _y;
hit = true;
break;
}
}
}
if (!hit) return;
}
map[x][y] = false;
if (f) {
sprite.graphics.moveTo(x, y);
f = false;
}
sprite.graphics.lineTo(x, y);
sleep(5, arguments.callee);
})();
}
private function sleep(delay:int, callback:Function):void {
var timer:Timer = new Timer(delay, 1);
timer.addEventListener(TimerEvent.TIMER_COMPLETE, callback);
timer.start();
}
private function compColor(col1:Number, col2:Number):Boolean {
if (col1 === 0 || col2 === 0) return false;
var r1:int = (col1 >> 16) & 0xFF;
var g1:int = (col1 >> 8) & 0xFF;
var b1:int = (col1 >> 0) & 0xFF;
var r2:int = (col2 >> 16) & 0xFF;
var g2:int = (col2 >> 8) & 0xFF;
var b2:int = (col2 >> 0) & 0xFF;
if (Math.abs(r1 - r2) <= 20 && Math.abs(g1 - g2) <= 20 && Math.abs(b1 - b2) <= 20) {
return true;
}
else {
return false;
}
}
}
}
