forked from: flash on 2010-5-8

/**
 * Copyright Karl94 ( http://wonderfl.net/user/Karl94 )
 * GNU General Public License, v3 ( http://www.gnu.org/licenses/quick-guide-gplv3.html )
 * Downloaded from: http://wonderfl.net/c/q1Zz
 */

// forked from Karl94's flash on 2010-5-8
// forked from Karl94's flash on 2010-5-8
//THIS AUGMENTED REALITY EXAMPLE DOESN'T NEED WEB-CAM
///////////////////////////////////////////////////////////
//                      INSTRUCTIONS                     //
//If you HAVE a web-cam: print and use this marker:      //
//http://saqoosha.net/lab/FLARToolKit/flarlogo-marker.pdf//
//                                                       //
//If you DON'T HAVE a web-cam: use your mouse to rotate  //
//  the maker, the mouse wheel to move it closer or      //
//  farther and the arrow keys to move it around         //
///////////////////////////////////////////////////////////

package{
    import flash.display.Bitmap;
    import flash.display.BitmapData;
    import flash.display.Sprite;
    import flash.display.GraphicsBitmapFill;
    import flash.display.GraphicsSolidFill;
    import flash.display.GraphicsStroke;
    import flash.display.GraphicsTrianglePath;
    import flash.display.IGraphicsData;
    //import flash.display.TriangleCulling;
    import flash.events.Event;
    import flash.events.IOErrorEvent;
    import flash.events.KeyboardEvent;
    import flash.events.MouseEvent;
    import flash.events.SecurityErrorEvent;
    import flash.events.StatusEvent;
    import flash.geom.Matrix3D;
    import flash.geom.Utils3D;
    import flash.geom.Vector3D;
    import flash.media.Camera;
    import flash.media.Video;
    import flash.system.Security;
    import flash.system.SecurityPanel;
    import flash.net.URLLoader;
    import flash.net.URLLoaderDataFormat;
    import flash.net.URLRequest;
    import flash.ui.Keyboard;


    import org.libspark.flartoolkit.core.param.FLARParam;
    import org.libspark.flartoolkit.core.raster.rgb.FLARRgbRaster_BitmapData;
    import org.libspark.flartoolkit.core.transmat.FLARTransMatResult;
    import org.libspark.flartoolkit.core.types.FLARIntSize;
    import org.libspark.flartoolkit.core.FLARCode;
    import org.libspark.flartoolkit.core.FLARMat;
    import org.libspark.flartoolkit.detector.FLARSingleMarkerDetector;

    [SWF(width=640, height=480, backgroundColor=0x808080, frameRate=30)]
    public class AR extends Sprite{
        private var _loader:URLLoader;
        private var _width:int = 640;
        private var _height:int = 480;
        private var _codeWidth:int = 80;

        private var _param:FLARParam;
        private var _code:FLARCode;
        private var _raster:FLARRgbRaster_BitmapData;
        private var _detector:FLARSingleMarkerDetector;

        private var _webcam:Camera;
        private var _video:Video;
        private var _marker:FLARCodeImage;
        private var _wrapper:Sprite = new Sprite();
        private var _container:Sprite = new Sprite();
        private var _capture:Bitmap;

        private var _resultMat:FLARTransMatResult = new FLARTransMatResult();
        private var _fr_mat:Matrix3D;

        private var mesh:Vector.<Number> = Vector.<Number>([
            -_width/2,-_height/2,0, -_width/2,_height/2,0, _width/2,_height/2,0, _width/2,-_height/2,0,
            -_width/2,-_height/2,500, -_width/2,_height/2,500, _width/2,_height/2,500, _width/2,-_height/2,500
        ]);
        private var data:Vector.<IGraphicsData> = Vector.<IGraphicsData>([
            new GraphicsStroke(4, false, "normal", "none", "round", 3.0, new GraphicsSolidFill(0xFF0000, 0.7)),
            new GraphicsTrianglePath(new Vector.<Number>(), Vector.<int>([4,5,7,5,6,7, 0,1,4,1,5,4, 1,2,5,2,6,5, 2,3,6,3,7,6, 3,0,7,0,4,7]), Vector.<Number>([0,0,0, 0,0,0, 0,0,0, 0,0,0]))
        ]);

        public function AR(){
            _container.x = _width/2;
            _container.y = _height/2;

            _loader = new URLLoader();
            _loader.dataFormat = URLLoaderDataFormat.BINARY;
            _loader.addEventListener(Event.COMPLETE, onLoadParam);
            _loader.load(new URLRequest("http://assets.wonderfl.net/static/flar/camera_para.dat"));
        }

        private function onLoadParam(e:Event):void {
            _loader.removeEventListener(Event.COMPLETE, onLoadParam);
            _param = new FLARParam();
            _param.loadARParam(_loader.data);
            _param.changeScreenSize(_width, _height);

            var size:FLARIntSize = _param.getScreenSize();
            var width:int  = size.w;
            var height:int = size.h;
            var tMat:FLARMat = new FLARMat (3, 4);
            var iMat:FLARMat = new FLARMat (3, 4);
            _param.getPerspectiveProjectionMatrix().decompMat(iMat, tMat);
            var icpara:Array = iMat.getArray();
            for (var i:int = 0; i < 4; i++) {
                icpara[1][i] = (height-1)*(icpara[2][i])-icpara[1][i];
            }
            var w:Number = icpara[0][0]/icpara[2][2];
            var h:Number = -icpara[1][1]/icpara[2][2];
            _fr_mat = new Matrix3D(Vector.<Number>([
                w, 0, 0, 0,
                0, h, 0, 0,
                0, 0, 1, 1,
                0, 0, 0, 0 ]
            ));

            _loader.dataFormat = URLLoaderDataFormat.TEXT;
            _loader.addEventListener(Event.COMPLETE, onLoadCode);
            _loader.load(new URLRequest("http://assets.wonderfl.net/static/flar/flarlogo.pat"));
        }

        private function onLoadCode(e:Event):void {
            _code = new FLARCode(16, 16);
            _code.loadARPatt(_loader.data);

            _loader.removeEventListener(Event.COMPLETE, onLoadCode);
            _loader = null;

            _capture = new Bitmap(new BitmapData(_width, _height, false));

            _raster = new FLARRgbRaster_BitmapData(_capture.bitmapData);
            _detector = new FLARSingleMarkerDetector(_param, _code, _codeWidth);
            _detector.setContinueMode(true);

            _capture.scaleX = 0.2;
            _capture.scaleY = 0.2;
            addChild(_capture);
            addChild(_container);

            _webcam = Camera.getCamera();
            if (!_webcam) {
                noCamera();
            }else{
                _video = new Video(_width, _height);
                _video.attachCamera(_webcam);
                if(_webcam.muted){
                    _webcam.addEventListener(StatusEvent.STATUS, onStatus);
                }else{
                    camera();
                }
            }
        }

        private function camera():void{
            _webcam.setMode(_width, _height, 30);
            _wrapper.addChild(_video);
            addEventListener(Event.ENTER_FRAME, onEnterFrame);
        }

        private function noCamera():void{
            _marker = new FLARCodeImage(_code);
            _marker.x = _width/2;
            _marker.y = _height/2;
            _marker.z = 0;
            _marker.scaleX = _marker.scaleY = 2;
            _wrapper.addChild(_marker);
            stage.addEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
            stage.addEventListener(MouseEvent.MOUSE_WHEEL, onMouseWheel);
            stage.addEventListener(KeyboardEvent.KEY_DOWN, onKeyDown);
            onEnterFrame();
        }

        private function onStatus(e:StatusEvent):void{
            _webcam.removeEventListener(StatusEvent.STATUS, onStatus);
            if(e.code == "Camera.Muted"){
                noCamera();
            }else if(e.code == "Camera.Unmuted"){
                camera();
            }
        }

        private function onMouseMove(e:MouseEvent):void{
            _marker.transform.matrix3D.pointAt(new Vector3D(e.stageX, e.stageY, -300), new Vector3D(0, 0, -1), new Vector3D(0, -1, 0));
            onEnterFrame();
        }

        private function onMouseWheel(e:MouseEvent):void{
            _marker.transform.matrix3D.appendTranslation(0, 0, e.delta*5);
            onEnterFrame();
        }

        private function onKeyDown(e:KeyboardEvent):void{
            switch(e.keyCode){
                case Keyboard.UP: _marker.transform.matrix3D.appendTranslation(0, -10, 0);
                    break;
                case Keyboard.DOWN: _marker.transform.matrix3D.appendTranslation(0, 10, 0);
                    break;
                case Keyboard.RIGHT: _marker.transform.matrix3D.appendTranslation(10, 0, 0);
                    break;
                case Keyboard.LEFT: _marker.transform.matrix3D.appendTranslation(-10, 0, 0);
                    break;
            }
            onEnterFrame();
        }

        private function onEnterFrame(e:Event = null):void{
            if(_marker){
                _capture.bitmapData.fillRect(_capture.bitmapData.rect, 0xFFFFFF);
            }
            _capture.bitmapData.draw(_wrapper);

            if (_detector.detectMarkerLite(_raster, 80) && _detector.getConfidence() > 0.3){
                _detector.getTransformMatrix(_resultMat);
                var m:Matrix3D = new Matrix3D(Vector.<Number>([
                    _resultMat.m23,0,0,0,
                    0,_resultMat.m23,0,0,
                    0,0,1,1,
                    _resultMat.m23*_resultMat.m03,-_resultMat.m23*_resultMat.m13,_resultMat.m23,_resultMat.m23
                ]));
                /*Vector.<Number>([
                    /*_resultMat.m01, _resultMat.m11, _resultMat.m21, 0,
                    _resultMat.m00, _resultMat.m10, _resultMat.m20, 0,
                    _resultMat.m02, _resultMat.m12, _resultMat.m22, 0,* /
                    1,0,0,0,
                    0,1,0,0,
                    0,0,1,0,
                    _resultMat.m03, _resultMat.m13, _resultMat.m23, 1]
                ));*/
                //m.invert();
                //m.append(_fr_mat);

                Utils3D.projectVectors(m, mesh, GraphicsTrianglePath(data[1]).vertices, GraphicsTrianglePath(data[1]).uvtData);
                _container.x = stage.stageWidth/2-_resultMat.m03;
                _container.y = stage.stageHeight/2+_resultMat.m13;
                _container.graphics.clear();
                _container.graphics.drawGraphicsData(data);
                _container.alpha = 1;
            }else{
                _container.alpha = 0.3;
            }
        }
    }
}


import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.display.Shape;
import flash.display.Sprite;
import org.libspark.flartoolkit.core.FLARCode;

class FLARCodeImage extends Sprite{
    public function FLARCodeImage(code:FLARCode){
        var patBW:Array = code.getPatBW()[1];
        var pWidth:int = code.getWidth();
        var pHeight:int = code.getHeight();

        var bmp:BitmapData = new BitmapData(pWidth, pHeight);
        var bw:uint;
        for(var x:uint = 0; x < pWidth; x++){
            for(var y:uint = 0; y < pHeight; y++){
                bw = (255-((patBW[y][x] & 0xFF)+code.averageOfPattern)) & 0xFF;
                bmp.setPixel(x, y, (bw << 16) | (bw << 8) | bw);
            }
        }

        var shape:Shape = new Shape();
        var image:Bitmap = new Bitmap(bmp);
        image.width *= 3;
        image.height *= 3;
        image.x = -image.width/2;
        image.y = -image.height/2;

        shape.graphics.beginFill(0x000000);
        shape.graphics.drawRect(-image.width, -image.height, 2*image.width, 2*image.height);
        this.addChild(shape);
        this.addChild(image);
    }
}
