forked from: forked from: Trajectory Path formula on slope. (Single parabolic raycast))

/**
 * Copyright Glidias ( http://wonderfl.net/user/Glidias )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/pSmp
 */

// forked from Glidias's forked from: forked from: Trajectory Path formula
// forked from Glidias's forked from: Trajectory Path formula
package
{
    import flash.display.Sprite;
    import flash.events.Event;
    import flash.events.KeyboardEvent;
    import flash.events.MouseEvent;
    import flash.geom.Point;
    import flash.geom.Vector3D;
    import flash.ui.Keyboard;

    /**

     * @author Glenn Ko
     */
    [SWF(frameRate="60", backgroundColor="#FFFFFF")]
    public class LobTrajectory extends Sprite
    {
        private var SPEED:Number = 244;
        private var DRAW_SEGMENTS:int  = 16;
        private var startPosition:Point = new Point();
        private var GRAVITY:Number = 266;

        private var velocity:Point = new Point();
        private var _displace:Point = new Point();

        private var curPosition:Point = new Point();
        private var curSprite:Sprite = new Sprite();

        private var totalFlightTime:Number;

        private var _tRise:Number;
        private var _h:Number;

        private var slopeHeight:Number;
        private var mSlope:Number;

        public function LobTrajectory()
        {


            y= -130;
            startPosition.x = 100;
            startPosition.y = 100;// stage.stageHeight -100;

            slopeHeight = 100;


            mSlope = slopeHeight/stage.stageWidth;


            curPosition = startPosition.clone();




            drawPath();

            stage.addEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
            addEventListener(Event.ENTER_FRAME, onEnterFrame);

            curSprite.graphics.beginFill(0xFF0000);
            curSprite.graphics.drawCircle(0, 0, 4);
            addChild(curSprite);

            stage.addEventListener(KeyboardEvent.KEY_DOWN, onKeyDOwn);

        }

        private function onKeyDOwn(e:KeyboardEvent):void
        {
            var keyCode:uint = e.keyCode;
            if (keyCode === Keyboard.NUMPAD_DIVIDE) {
                onMouseMove(null);
            }
            else if (keyCode === Keyboard.NUMPAD_ADD) {

                onMouseMove(null);
            }
            else if (keyCode === Keyboard.LEFT) {
                    startPosition.x--;
                      onMouseMove(null);
            }
            else if (keyCode === Keyboard.RIGHT) {
                startPosition.x++;
                  onMouseMove(null);
            }
            else if (keyCode === Keyboard.UP) {
                startPosition.y++;
                  onMouseMove(null);
            }
            else if (keyCode === Keyboard.DOWN) {
                startPosition.y--;
                  onMouseMove(null);
            }
        }

        private function onEnterFrame(e:Event):void
        {
            var timeElapsed:Number =  (1 / 60);
                velocity.y -= GRAVITY * timeElapsed;


            curPosition.x += velocity.x * timeElapsed;
            curPosition.y += velocity.y * timeElapsed;

            curSprite.x = curPosition.x;
            curSprite.y = (stage.stageHeight - curPosition.y);


        }



    private function getTrajectoryTimeOfFlight2(yo:Number , vyo:Number, g:Number):Number {


        //y(t) = yo + (vyo)*t - (g/2)t2
        //x(t) = vxo*t,

    //    vyo = -vyo;
        //g = -g;


        var t1:Number = vyo/g;
        var t2:Number = Math.sqrt( vyo * vyo + g * 2 * yo) / g;
        _tRise = t1;
        _h =  yo + vyo*vyo/(2*g);
    //    return t1 + t2;
        //y = yo +  (vyo * t - g / 2 * t * t);
        //x = vxo * t;

        var slope:Number      =  mSlope;// 0.0; // For line.
        var yIntercept:Number  = -startPosition.x * mSlope;

        //y = Ax2 + Bx + C
        var A:Number  = g / 2; // For parabolla, quadratic function coefficients.
        var B:Number  = -vyo;
        var C:Number  = -yo;

        var a:Number = 0.0; // For solving quadratic formula.
        var b:Number  = 0.0;
        var c:Number  = 0.0;

        var x1:Number  = 0.0; // Point(s) of intersection.
        var y1:Number  = 0.0;
        var x2:Number  = 0.0;
        var y2:Number  = 0.0;

        a = A;
        b = B + slope*velocity.x;
        c = C - yIntercept;



        var discriminant:Number = b * b - 4 * a * c;

        if(discriminant > 0.0)
        {
            x1 = (-b + Math.sqrt(discriminant)) / (2.0 * a);
            x2 = (-b - Math.sqrt(discriminant)) / (2.0 * a);

            y1 = slope * x1 + yIntercept;
            y2 = slope * x2 + yIntercept;


            return  x1 > x2 ? x1 : x2;

        }
        else if(discriminant == 0.0)
        {
            x1 = (-b) / (2.0 * a);

            y1 = slope * x1 + yIntercept;
            return x1;
        }


        return -1;

    }




        private function onMouseMove(e:MouseEvent):void
        {

            //  startPosition.x  = mouseX;
          //  startPosition.y = mouseY;

            _displace.x = mouseX - startPosition.x;
            _displace.y = (  (stage.stageHeight-mouseY) - (startPosition.y)    );
            _displace.normalize(SPEED);


            velocity.x = _displace.x;
            velocity.y = _displace.y;

            curPosition.x = startPosition.x;
            curPosition.y = startPosition.y;


          totalFlightTime =   getTrajectoryTimeOfFlight2( startPosition.y, velocity.y, GRAVITY);


            drawPath();
        }


        private function drawPath():void
        {
            graphics.clear();
            graphics.beginFill(0x000000, 1);
            graphics.lineStyle(0, 0, 1);

            var totalTimeToUse:Number = totalFlightTime;// (totalTime > MAX_TIME) ? totalTime : totalTime / MAX_TIME * MAX_TIME;

            for (var i:int = 0; i <= DRAW_SEGMENTS; i++) {  // draw in between segments

                var t:Number = (i / DRAW_SEGMENTS) * totalTimeToUse;
               //(stage.stageHeight - startPosition.y) - .5 * GRAVITY * t * t + velocity.y * t
                var px:Number;
                var py:Number;
                graphics.drawCircle(
                px= startPosition.x + velocity.x * t,
                py = stage.stageHeight - (startPosition.y - .5 * GRAVITY * t * t + velocity.y * t)
                ,4);

                 // get forward vector
                var vx:Number = velocity.x;
                var vy:Number = velocity.y - GRAVITY*t;
                var d:Number = 1 / Math.sqrt(vx * vx + vy * vy); // normalize
                vx *= d;
                vy *= d;
                graphics.moveTo(px, py);
                graphics.lineTo(px + vx * 11, py - vy * 11);
            }



           // if (_tRise <0) _tRise = 0;

            graphics.moveTo(startPosition.x + _tRise*velocity.x, startPosition.y);
            graphics.lineTo(startPosition.x + _tRise*velocity.x, startPosition.y - 320)

             graphics.moveTo(startPosition.x + totalFlightTime*velocity.x, startPosition.y);
            graphics.lineTo(startPosition.x + totalFlightTime*velocity.x, startPosition.y - 320);

            graphics.beginFill(0xFFFF00,1);
              graphics.drawCircle(
                px= startPosition.x + _tRise*velocity.x,
               py = stage.stageHeight - (startPosition.y -  .5 * GRAVITY * _tRise * _tRise + velocity.y * _tRise
                ,4), 4);

                graphics.moveTo(0,stage.stageHeight-1);
                graphics.lineTo(stage.stageWidth, stage.stageHeight - 1 - slopeHeight);

                   graphics.moveTo(0,stage.stageHeight-1);
                graphics.lineTo(stage.stageWidth, stage.stageHeight-1 );

        }



    }

}
