forked from: PV3D 2.0 / 勉強2日目(カメラのtargetとLines3D)

/**
 * Copyright smallflowergame ( http://wonderfl.net/user/smallflowergame )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/oDwQ
 */

// forked from ninehundred's PV3D 2.0 / 勉強2日目(カメラのtargetとLines3D)
//////////////////////////////////////////////////////////////////////////////////////////
//
//  [ PV3D 2.0 / 勉強2日目(カメラのtargetとLines3D) ]
//
//  今回のテーマ
//  - カメラのtargetを"DisplayObject3D.ZERO"から
//  - 対象物に変えたケースとLines3Dを使用
//
//////////////////////////////////////////////////////////////////////////////////////////

package
{
    // # imports
    import flash.display.*;
    import flash.events.*;
    import flash.text.*;
    /*//
    import flash.errors.*;
    import flash.external.*;
    import flash.filters.*;
    import flash.geom.*;
    import flash.media.*;
    import flash.net.*;
    import flash.system.*;
    import flash.ui.*;
    import flash.utils.*;
    //*/

    import com.flashdynamix.motion.*;
    import com.flashdynamix.utils.*;
    import fl.motion.easing.*;
    //import net.hires.debug.Stats;

    import org.papervision3d.scenes.Scene3D;
    import org.papervision3d.objects.DisplayObject3D;
    import org.papervision3d.objects.primitives.*;
    import org.papervision3d.cameras.*;
    import org.papervision3d.view.Viewport3D;
    import org.papervision3d.render.BasicRenderEngine;
    import org.papervision3d.materials.*;
    import org.papervision3d.materials.utils.MaterialsList;
    import org.papervision3d.core.geom.Lines3D;
    import org.papervision3d.materials.special.LineMaterial;

    [SWF(width="465", height="465", backgroundColor="0x0", frameRate="60")]


    public class App extends Sprite
    {

        // ================================================== //
        // STEP00 - Constructor & Parameters
        // ================================================== //
        private var _scene        :Scene3D;
        private var _camera        :Camera3D;
        private var _viewport    :Viewport3D;
        private var _renderer    :BasicRenderEngine;
        private var _cube        :Cube;

        private const EarthSize :int = 3000;
        private var _infoText    :TextField;


        public function App()
        {
            if(stage) init();
            else addEventListener(Event.ADDED_TO_STAGE, init);
        }

        private function init(e:Event=null):void
        {
            removeEventListener(Event.ADDED_TO_STAGE, init);
            initStage();        // ステージの初期化
            initPV3D();            // PV3D各種パーツの初期化
                        Wonderfl.capture_delay( 15 );
        }





        // ================================================== //
        // STEP01 - PV3Dの初期化
        // ================================================== //

        private function initPV3D():void
        {
            // 必須アイテムの初期化
            _renderer = new BasicRenderEngine();
            _scene    = new Scene3D();
            _viewport = new Viewport3D(0, 0, true, true);
            addChild(_viewport);

            // カメラの初期化
            _camera        = new Camera3D();
            _camera.x      = -2000;
            _camera.y      = 2000;
            _camera.z      = 4000;
            _camera.zoom   = 30;
            _camera.focus  = 30;
            //_camera.target = DisplayObject3D.ZERO;

            initEarth();    // 地上配置
            initMaterial();    // マテリアルの設置
            initLines();    // マテリアルのXYZ軸をラインで設置

            stage.addEventListener(Event.ENTER_FRAME, update);
        }

        // 地上配置
        // -----------------------------------------------------
        private function initEarth():void
        {
            var wire:WireframeMaterial = new WireframeMaterial(0x666666);
            wire.oneSide    = false;
            var earth:Plane = new Plane(wire, EarthSize, EarthSize, 8, 8);
            earth.rotationX = 90;
            _scene.addChild(earth);
        }

        // マテリアルの設置
        // -----------------------------------------------------
        private function initMaterial():void
        {
            var materilaList:MaterialsList = new MaterialsList({
                front:     new ColorMaterial(0xFFFFFF*Math.random(), 1.0),
                back:     new ColorMaterial(0xFFFFFF*Math.random(), 1.0),
                right:     new ColorMaterial(0xFFFFFF*Math.random(), 1.0),
                left:     new ColorMaterial(0xFFFFFF*Math.random(), 1.0),
                top:     new ColorMaterial(0xFFFFFF*Math.random(), 1.0),
                bottom: new ColorMaterial(0xFFFFFF*Math.random(), 1.0)
            });

            _cube   = new Cube(materilaList, 200, 200, 200, 6, 6, 6);
            _cube.x = 500;
            _cube.y = 250;
            _cube.z = 0;

            _scene.addChild(_cube);
            _camera.target = _cube;// _cameraのターゲットがZEROじゃないのがPOINT
        }

        // マテリアルの設置
        // -----------------------------------------------------
        private function initLines():void
        {
            var lineX:Lines3D = new Lines3D(new LineMaterial(0xFF0000));
            var lineY:Lines3D = new Lines3D(new LineMaterial(0x00FF00));
            var lineZ:Lines3D = new Lines3D(new LineMaterial(0x0000FF));
            _cube.addChild(lineX);    lineX.addNewLine(2, 100, 0, 0, 200, 0, 0);
            _cube.addChild(lineY);    lineY.addNewLine(2, 0, 100, 0, 0, 200, 0);
            _cube.addChild(lineZ);    lineZ.addNewLine(2, 0, 0, 100, 0, 0, 200);
        }










        // ================================================== //
        // STEP02 - Event
        // ================================================== //
        private function update(e:Event=null):void
        {
            _renderer.renderScene(_scene, _camera, _viewport);
            updateMaterial();
            updateInfo();
        }

        // material animation
        // -----------------------------------------------------
        private var vecX:int = 1;
        private var vecY:int = -1;
        private var vecZ:int = 1;
        private var spdX:int = Math.random() * 10 + 10;
        private var spdY:int = Math.random() * 10 + 10;
        private var spdZ:int = Math.random() * 10 + 10;

        private function updateMaterial():void
        {
            _cube.rotationX += 5;
            _cube.rotationZ += 5;
            _cube.x += spdX * vecX;
            _cube.y += spdY * vecY;
            _cube.z += spdZ * vecZ;
            if(_cube.x < -EarthSize/2 || _cube.x > EarthSize/2) vecX = vecX * -1;
            if(_cube.y < 100          || _cube.y > EarthSize/2) vecY = vecY * -1;
            if(_cube.z < -EarthSize/2 || _cube.z > EarthSize/2) vecZ = vecZ * -1;
        }

        // info text
        // -----------------------------------------------------
        private function updateInfo():void
        {

            if(!_infoText)
            {
                _infoText = addChild(new TextField()) as TextField;
                _infoText.defaultTextFormat = new TextFormat('_等幅', 10, 0xFFFFFF);
                _infoText.selectable = false;
                _infoText.autoSize   = TextFieldAutoSize.LEFT;
                _infoText.x = _infoText.y = 5;
            }
            _infoText.text = '';
            _infoText.appendText('#_camera properties'             +'\n');
            _infoText.appendText('-------------------------------' +'\n');
            _infoText.appendText('x         : '+ _camera.x           +'\n');
            _infoText.appendText('y         : '+ _camera.y           +'\n');
            _infoText.appendText('z         : '+ _camera.z           +'\n');
            _infoText.appendText('zoom      : '+ _camera.zoom      +'\n');
            _infoText.appendText('focus     : '+ _camera.focus     +'\n');
            _infoText.appendText('rotationX : '+ _camera.rotationX +'\n');
            _infoText.appendText('rotationY : '+ _camera.rotationY +'\n');
            _infoText.appendText('rotationZ : '+ _camera.rotationZ +'\n');
            _infoText.appendText(''                                +'\n');
            _infoText.appendText('#_cube properties'               +'\n');
            _infoText.appendText('-------------------------------' +'\n');
            _infoText.appendText('x         : '+ _cube.x           +'\n');
            _infoText.appendText('y         : '+ _cube.y           +'\n');
            _infoText.appendText('z         : '+ _cube.z           +'\n');
            _infoText.appendText('rotationX : '+ _cube.rotationX   +'\n');
            _infoText.appendText('rotationY : '+ _cube.rotationY   +'\n');
            _infoText.appendText('rotationZ : '+ _cube.rotationZ   +'\n');
        }



        // ================================================== //
        // STEP99 - Commons & Settings
        // ================================================== //
        private function initStage():void
        {
            stage.align                  = StageAlign.TOP_LEFT;
            stage.scaleMode              = StageScaleMode.NO_SCALE;
            stage.quality                = StageQuality.MEDIUM;
            stage.displayState           = StageDisplayState.NORMAL;
            stage.frameRate              = 60;
            stage.showDefaultContextMenu = false;
        }
    }
}
