forked from: Marching Squares Algorithm

/**
 * Copyright omari ( http://wonderfl.net/user/omari )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/mbQH
 */

// forked from st33d's Marching Squares Algorithm
package {
    import flash.display.Bitmap;
    import flash.display.BitmapData;
    import flash.display.Graphics;
    import flash.display.Shape;
    import flash.display.Sprite;
    import flash.events.Event;
    import flash.events.MouseEvent;
    import flash.geom.Point;
    import flash.geom.Rectangle;

    /**
     * Marching Squares algorithm - could be optimised, I guess
     * (By that I don't mean slapping Vectors all over the shop)
     *
     * Click to sample an area for outline mapping
     *
     * based on:
     * http://en.wikipedia.org/wiki/Marching_squares
     *
     *
     * @author Aaron Steed, nitrome.com
     */

    [SWF(frameRate="30", backgroundColor = "#CCCCCC")]

    public class FlashTest extends Sprite {

        public var result:Shape;
        public var check_image:BitmapData;
        public var check_image_holder:Bitmap;
        public var map_image:BitmapData;
        public var map_image_holder:Bitmap;

        public var mouse_pressed:Boolean;
        public var mouse_count:int;
        public var frame_count:int;

        public static const WIDTH:Number = 465;
        public static const HEIGHT:Number = 465;

        public function FlashTest(){
            init();
        }

        private function init():void {

            initImages();
            frame_count = 0;
            mouse_count = -1;
            mouse_pressed = false;

            stage.addEventListener(MouseEvent.MOUSE_DOWN, mousePressed);
            stage.addEventListener(MouseEvent.MOUSE_UP, mouseReleased);
            addEventListener(Event.ENTER_FRAME, loop);
        }

        private function loop(e:Event = null):void {
            if(mouse_pressed){
                capture();
                march();
            }
            frame_count++;
        }

        private function mousePressed(e:MouseEvent = null):void{
            mouse_count = frame_count;
            mouse_pressed = true;
        }

        private function mouseReleased(e:MouseEvent = null):void{
            mouse_pressed = false;
        }

        private function capture():void{
            check_image.fillRect(check_image.rect, 0xff0000ff);
            check_image.copyPixels(map_image, new Rectangle( -1 + (mouseX / 4), -1 + (mouseY / 4), 14, 14), new Point(1,1));
        }



        public static const SCAN_POINTS:Array = [new Point(0, 0), new Point(1, 0), new Point(0, 1), new Point(1, 1)];

        public static const UP:Point = new Point(0, -1);
        public static const RIGHT:Point = new Point(1, 0);
        public static const DOWN:Point = new Point(0, 1);
        public static const LEFT:Point = new Point(-1, 0);

        public static const MARCH:Array = [
            RIGHT,//new Point(1, 0), // 0: 0000
            DOWN,//    new Point(0, 1), // 1: 0001
            LEFT,//    new Point(-1, 0), // 2: 0010
            LEFT,//    new Point(-1, 0), // 3: 0011
            RIGHT,//    new Point(1, 0), // 4: 0100
            DOWN,//    new Point(0, 1), // 5: 0101
            LEFT,//    new Point(-1, 0), // 6: 0110
            LEFT,//    new Point(-1, 0), // 7: 0111
            UP,//    new Point(0, -1), // 8: 1000
            UP,//    new Point(0, -1), // 9: 1001
            UP,//    new Point(0, -1), // 10: 1010
            UP,//    new Point(0, -1), // 11: 1011
            RIGHT,//    new Point(1, 0), // 12: 1100
            DOWN,//    new Point(0, 1), // 13: 1101
            RIGHT//    new Point(1, 0), // 14: 1110
        ];

        private function march():void{
            // get bounding box
            var bounds:Rectangle = check_image.getColorBoundsRect(0xFFFFFFFF, 0xFFFF0000);

            var gfx:Graphics = result.graphics;
            gfx.clear();
            gfx.lineStyle(5, 0);

            var scale:Number = check_image_holder.scaleX;

            var buffer:BitmapData = check_image.clone();

            var j:int;
            while(bounds.width + bounds.height > 0){

                var pos:Point = new Point(bounds.x - 1, bounds.y - 1);
                var loop:Point = null;
                var index:int = getMarchVectorIndex(bounds.x - 1, bounds.y - 1);
                var march_vector:Point = MARCH[index];

                // fail safe
                var i:int;
                while(++i < 1000){

                    if((index) && !loop){
                        loop = pos.clone();
                        buffer.setPixel(loop.x + 1, loop.y + 1, 0xFFFF00);
                        gfx.moveTo((pos.x + 1) * scale, (pos.y + 1) * scale);
                    }

                    pos.x += march_vector.x;
                    pos.y += march_vector.y;

                    if(loop) gfx.lineTo((pos.x + 1) * scale, (pos.y + 1) * scale);
                    if(loop && pos.x == loop.x && pos.y == loop.y) break;

                    index = getMarchVectorIndex(pos.x, pos.y);

                    march_vector = MARCH[index];
                }

                check_image.floodFill(loop.x+1, loop.y+1, 0xFF0000FF);
                bounds = check_image.getColorBoundsRect(0xFFFFFFFF, 0xFFFF0000);

                // fail safe
                if(++j > 100) break;
            }
            check_image.copyPixels(buffer, buffer.rect, new Point());

        }

        public function getMarchVectorIndex(x:int, y:int, col:uint = 0xFFFF0000):int{
            var index:int = 0;
            if(check_image.getPixel32(x+1, y+1) == col) index++;
            if(check_image.getPixel32(x, y + 1) == col) index += 1 << 1;
            if(check_image.getPixel32(x + 1, y) == col) index += 1 << 2;
            if(check_image.getPixel32(x, y) == col) index += 1 << 3;

            return index;
        }


        private function initImages():void{
            map_image = new BitmapData(WIDTH >> 3, HEIGHT >> 2, true, 0xff0000ff);
            map_image_holder = new Bitmap(map_image);
            map_image_holder.scaleX = map_image_holder.scaleY = 4;
            addChild(map_image_holder);

            var rect:Rectangle = new Rectangle();
            for(var i:int = 0; i < 100; i++) {
                rect.x = Math.random() * map_image.width;
                rect.y = Math.random() * map_image.height;
                rect.width = Math.random() * 20;
                rect.height = Math.random() * 20;
                map_image.fillRect(rect, 0xffff0000);
            }

            check_image = new BitmapData(16, 16, true, 0xff00ff00);
            check_image_holder = new Bitmap(check_image);
            addChild(check_image_holder);
            check_image_holder.scaleX = check_image_holder.scaleY = 14;
            check_image_holder.x = WIDTH * 0.5;


            result = new Shape();
            addChild(result);
            result.x = WIDTH * 0.5;
        }

    }

}
