Pseudo 3D Push Button Decorator

by FlashBum
author Jesse Freeman aka @theFlashBum | http://jessefreeman.com

This is a simple demo of how to create a "3d Push Button" similar
to the new UI on wp7 phones. Noting fancy here but I do add the
notion of force so depending on where you press the button it will
rotate farther.

Since this is a decorator (see internal class) it can be applied
to any button (as long as you are compiling for FP 10.0).

It is important to note that the rotation will be "off" based on
the center position of the box.
♥0 | Line 61 | Modified 2010-03-07 14:02:29 | MIT License
play

ActionScript3 source code

/**
 * Copyright FlashBum ( http://wonderfl.net/user/FlashBum )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/kF4I
 */

package {

import flash.display.Sprite;
    import flash.display.StageAlign;
    import flash.display.StageScaleMode;
    import flash.events.MouseEvent;
    import flash.text.TextField;

    /**
      * author Jesse Freeman aka @theFlashBum | http://jessefreeman.com
      *
      * This is a simple demo of how to create a "3d Push Button" similar
      * to the new UI on wp7 phones. Noting fancy here but I do add the
      * notion of force so depending on where you press the button it will
      * rotate farther.
      *
 	  * Since this is a decorator (see internal class) it can be applied
 	  * to any button (as long as you are compiling for FP 10.0).
      *
      * It is important to note that the rotation will be "off" based on
      * the center position of the box.
      *
      */

public class ButtonTest extends Sprite {

    private var decorator:PushButtonDecorator;
    private var testButton:Sprite;

    public function ButtonTest() {

            configureStage();
            init();
        }

        protected function configureStage():void {
            stage.align = StageAlign.TOP_LEFT;
            stage.scaleMode = StageScaleMode.NO_SCALE;
        }

    protected function init():void
    {
        testButton = addChild(createButton()) as Sprite;
        testButton.x = stage.stageWidth * .5 - testButton.width *.5;
        testButton.y = stage.stageHeight * .5 - testButton.height *.5;

        testButton.addEventListener(MouseEvent.CLICK, onClick)
        decorator = new PushButtonDecorator(testButton);

    }

    private function onClick(event:MouseEvent):void {

        decorator.push(event.localX/testButton.width);
    }

    private function createButton():Sprite {

        var button:Sprite = new Sprite();
        button.graphics.beginFill( Math.random() * 0xFFFFFF);
        button.graphics.drawRect(0,0,100,100);
        button.graphics.endFill();

        button.buttonMode = true;
        button.useHandCursor = true;

        return button;
    }
}
}

	import caurina.transitions.*;

    import flash.display.DisplayObject;

    internal class PushButtonDecorator {

        private var _target:DisplayObject;

        public function PushButtonDecorator(target:DisplayObject = null) {
            if(target)_target = target;
        }

        public function get target():DisplayObject {
            return _target;
        }

        public function set target(value:DisplayObject):void {
            _target = value;
        }

        public function push(force:Number = 1):void {

            var rotY:Number = -30 * force;

            Tweener.addTween(_target, {time:.2, rotationY: rotY, overwrite: 0, onComplete:reset});

        }

        public function reset(delay:Number = 0):void
        {
            Tweener.addTween(_target, {time:.2, rotationY: 0, overwrite: 0, delay:delay});
        }


    }
