* Copyright mutantleg ( http://wonderfl.net/user/mutantleg )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/iuIt
*/
package {
import flash.display.StageQuality;
import flash.events.Event;
import flash.display.Sprite;
public class FlashTest extends Sprite {
public function FlashTest() {
stage.quality = StageQuality.LOW;
stage.addEventListener(Event.ENTER_FRAME, onEnter);
}//ctor
public var myDraw:xVertDraw = new xVertDraw();
public var gt:int = 0;
public function onEnter(e:Event):void
{
graphics.clear();
graphics.lineStyle(2, 0);
var ang:Number;
ang = Math.sin(gt*0.05)*256;
/*
myDraw.drawLine(graphics, -100, 0, -200, 100, 0, -200);
myDraw.drawLine(graphics, -100, 0, -200, -100, 0, 200);
myDraw.drawLine(graphics, 100, 0, -200, 100, 0, 200);
myDraw.drawLine(graphics, 0,50, 0, 0, 0, -1000);
*/
//myDraw.drawBox(graphics, -50,-50,-150+ang, 50,50,-100+ang);
var i:int; var k:int;
for (k = -8; k < 8; k++)
{
for (i = -8; i < 8; i++)
{
myDraw.drawBox(graphics, k*64-16, -16+ang ,-150+i*64-16,
k*64+16,16+ang,-150+i*64+16);
}//nexti
}//nextk
//myDraw.addVert(0,0,-50,8);
// myDraw.renderVert(graphics);
gt += 1;
}//onenter
}//classend
}
import flash.display.Graphics;
internal class xVert
{
public var sx:Number = 0; public var sy:Number = 0;
public var sr:Number = 0;
public var sw:Number = 1;
public var sortCode:int = 0;
}//xvert
internal class xVertDraw
{
public var vecVert:Vector.<xVert>;
public var it:int = 0;
public var projMat:Vector.<Number> = Vector.<Number>([1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1]);
public var rendw:Number = 465 * 0.5;
public var rendh:Number = 465 * 0.5;
public function xVertDraw()
{
init(1024);
setProjMat(projMat, 90, 1, 1, 1000);
}//ctor
public function init(num:int):void
{
vecVert = new Vector.<xVert>(num, false);
var i:int; for (i = 0; i < num; i++) { vecVert[i] = new xVert(); }
}//init
public function drawBox(g:Graphics, minx:Number, miny:Number, minz:Number,
maxx:Number, maxy:Number, maxz:Number):void
{
drawLine(g,minx, miny, minz, maxx, miny, minz);
drawLine(g,minx, maxy, minz, maxx, maxy, minz);
drawLine(g,minx, miny, maxz, maxx, miny, maxz);
drawLine(g,minx, maxy, maxz, maxx, maxy, maxz);
drawLine(g,minx, miny, minz, minx, maxy, minz);
drawLine(g,maxx, miny, minz, maxx, maxy, minz);
drawLine(g,minx, miny, maxz, minx, maxy, maxz);
drawLine(g,maxx, miny, maxz, maxx, maxy, maxz);
drawLine(g,minx, miny, minz, minx, miny, maxz);
drawLine(g,maxx, miny, minz, maxx, miny, maxz);
drawLine(g,minx, maxy, minz, minx, maxy, maxz);
drawLine(g,maxx, maxy, minz, maxx, maxy, maxz);
}//drawbox
public function drawLine(g:Graphics, ax:Number, ay:Number, az:Number,
bx:Number, by:Number, bz:Number):void
{
var mat:Vector.<Number>;
var sx0:Number, sy0:Number, sz0:Number, w0:Number;
var sx1:Number, sy1:Number, sz1:Number, w1:Number;
mat = projMat;
w0 = ax * mat[3] + ay * mat[7] + az * mat[11] + mat[15];
w1 = bx * mat[3] + by * mat[7] + bz * mat[11] + mat[15];
if (w0 <= 0 && w1 <= 0) { return; }
sx0 = ax * mat[0] + ay * mat[4] + az * mat[8] + mat[12];
sy0 = ax * mat[1] + ay * mat[5] + az * mat[9] + mat[13];
//sz0 = ax * mat[2] + ay * mat[6] + az * mat[10] + mat[14];
sx1 = bx * mat[0] + by * mat[4] + bz * mat[8] + mat[12];
sy1 = bx * mat[1] + by * mat[5] + bz * mat[9] + mat[13];
//sz1 = bx * mat[2] + by * mat[6] + bz * mat[10] + mat[14];
sx0 /= w0; sy0 /= w0;
//projection fix
if (w0 < 0.0)
{ if (sx0 > 0) { sx0 = -1.0 - sx0; } else { sx0 = 1.0 - sx0; }
if (sy0 > 0) { sy0 = -1.0 - sy0; } else { sy0 = 1.0 - sy0; }
}//endif
sx0 *= rendw; sy0 *= -rendh; sx0 += rendw; sy0 += rendh;
sx1 /= w1; sy1 /= w1;
//projection fix
if (w1 < 0.0)
{ if (sx1 > 0) { sx1 = -1.0 - sx1; } else { sx1 = 1.0 - sx1; }
if (sy1 > 0) { sy1 = -1.0 - sy1; } else { sy1 = 1.0 - sy1; }
}//endif
sx1 *= rendw; sy1 *= -rendh; sx1 += rendw; sy1 += rendh;
g.moveTo(sx0, sy0); g.lineTo(sx1, sy1);
}//drawline
public function addVert(ax:Number, ay:Number, az:Number, rad:Number):void
{
var a:xVert; var mat:Vector.<Number>; var m:Number;
var sx:Number; var sy:Number; var sz:Number;
var w:Number;
mat = projMat;
w = ax * mat[3] + ay * mat[7] + az * mat[11] + mat[15];
if (w <= 0) { return; }
sx = ax * mat[0] + ay * mat[4] + az * mat[8] + mat[12];
sy = ax * mat[1] + ay * mat[5] + az * mat[9] + mat[13];
sz = ax * mat[2] + ay * mat[6] + az * mat[10] + mat[14];
sx /= w; sy /= w;
sx *= rendw; sy *= -rendh;
sx += rendw; sy += rendh;
m = (1 / w) * rendh * rad;
a = vecVert[it]; it += 1; if (it >= vecVert.length) { it = vecVert.length - 1; }
a.sx = sx; a.sy = sy; a.sw = w; a.sr = m;
a.sortCode = 0x0FffFFff - int(sz);
}//addvert
public function renderVert(g:Graphics):void
{
//g.lineStyle(2, 0);
var i:int; var num:int; var a:xVert;
num = it; sortVert(vecVert, num);
for (i = 0; i < num; i++)
{ a = vecVert[i];
g.beginFill(0x808080, 1);
g.drawCircle(a.sx, a.sy, a.sr);
g.endFill();
}//nexti
it = 0;
}//rendervert
public function sortVert(vec:Vector.<xVert>, num:int):void
{ radixSortVert(vec, num); }//sortvert
public var tempVec:Vector.<xVert> = new Vector.<xVert>(8192, false);
public var tempBuck:Vector.<int> = new Vector.<int>(256, false);
public function radixSortVert(vec:Vector.<xVert>, num:int):void
{
var a:xVert; var temp:Vector.<xVert>; var buck:Vector.<int>;
var i:int; var k:uint; var shift:int; var g:int;
if (vec.length < num) { num = vec.length; }
temp = tempVec; if (temp.length < num) { return; }
buck = tempBuck; shift = 0;
while (shift < 32) {
for (k = 0; k < 256; k++) { buck[k] = 0; } //reset bucket
for (i = 0; i < num; i++) { g = (vec[i].sortCode >> shift) &0xFF; buck[g]++; }
for (i = 1; i < 256; i++) { buck[i] += buck[i - 1]; }
for (i = num - 1; i >= 0; i--) { g = (vec[i].sortCode >> shift) &0xFF; temp[--buck[g] ] = vec[i]; }
for (i = 0; i < num; i++) { vec[i] = temp[i]; }
shift += 8;
}//wend
}//radixsort
public static function setProjMat(vec:Vector.<Number>,
fovdeg:Number = 60.0, aspect:Number=1.0, nearp:Number = 1.0, farp:Number=1000.0):void
{ var f:Number; var i:int;
for (i = 0; i < 16; i++) { vec[i] = 0.0; }
f = 1.0 / Math.tan( (fovdeg * (3.1415 / 180.0)) * 0.5 );
if (nearp == 0) { nearp = 0.0001; }
if (farp == 0) { farp = 0.0001; }
vec[0] = f / aspect; vec[5] = f;
vec[10] = (farp + nearp) / (nearp - farp);
vec[14] = (2.0 * farp * nearp) / (nearp - farp);
vec[11] = -1.0; vec[15] = 0.0;
}//projmatrix
}//vertdraw
