flash on 2010-1-8
♥0 |
Line 95 |
Modified 2010-01-09 11:52:14 |
MIT License
archived:2017-03-20 16:28:21
ActionScript3 source code
/**
* Copyright cpu_t ( http://wonderfl.net/user/cpu_t )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/iPrr
*/
package {
import flash.display.BitmapData;
import flash.display.Shape;
import flash.display.Sprite;
import flash.display.TriangleCulling;
import flash.events.Event;
import flash.events.MouseEvent;
import flash.geom.Matrix3D;
import flash.geom.PerspectiveProjection;
import flash.geom.Point;
import flash.geom.Utils3D;
import flash.geom.Vector3D;
import net.hires.debug.Stats;
[SWF (width = 465, height = 465, frameRate = 60, backgroundColor = 0x000000)]
public class test10 extends Sprite {
private var _viewport:Shape;
private var _vertices:Vector.<Number>;
private var _uvtData:Vector.<Number>;
private var _worldMatrix:Matrix3D;
private var _viewMatrix:Matrix3D;
private var _projection:PerspectiveProjection;
public function test10() {
stage.addChild(new Stats());
_viewport = new Shape();
_viewport.x = stage.stageWidth * 0.5;
_viewport.x = stage.stageHeight * 0.5;
addChild(_viewport);
createMesh();
_worldMatrix = new Matrix3D();
_viewMatrix = new Matrix3D();
_viewMatrix.appendTranslation(0, 0, 150);
_projection = new PerspectiveProjection();
_projection.fieldOfView = 60;
addEventListener(Event.ENTER_FRAME, enterFrameHandler);
stage.addEventListener(MouseEvent.MOUSE_DOWN, function(e:Event):void {
_oldMousePos = new Point(mouseX, mouseY);
});
stage.addEventListener(MouseEvent.MOUSE_MOVE, function(e:Event):void {
if (_oldMousePos != null) {
_viewMatrix.appendTranslation(mouseX - _oldMousePos.x, mouseY - _oldMousePos.y, 0);
_oldMousePos.x = mouseX;
_oldMousePos.y = mouseY;
}
});
stage.addEventListener(MouseEvent.MOUSE_UP, function(e:Event):void {
_oldMousePos = null;
});
}
private var _oldMousePos:Point;
private function createMesh():void
{
_vertices = new Vector.<Number>;
_uvtData = new Vector.<Number>;
for (var i:int = 0; i < 100; i++) {
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_vertices.push(Math.random() * 100 - 50);
_uvtData.push(0, 0, 0);
_uvtData.push(0, 1, 0);
_uvtData.push(1, 0, 0);
}
}
private function enterFrameHandler(e:Event):void
{
update();
render();
}
private function render():void
{
var m:Matrix3D = new Matrix3D();
m.append(_worldMatrix);
m.append(_viewMatrix);
m.append(_projection.toMatrix3D());
var projected:Vector.<Number> = new Vector.<Number>;
Utils3D.projectVectors(m, _vertices, projected, _uvtData);
var texture:BitmapData = new BitmapData(100, 100, false, 0x00FF00);
texture.perlinNoise(5, 5, 3, 0, true, true);
_viewport.graphics.clear();
_viewport.graphics.lineStyle( -1, 0xFFFFFF);
//_viewport.graphics.beginFill(0x8080ff, 0.2);
_viewport.graphics.beginBitmapFill(texture, null, false, true);
_viewport.graphics.drawTriangles(projected, null, _uvtData, TriangleCulling.POSITIVE);
_viewport.graphics.endFill();
}
private function update():void
{
_worldMatrix.appendRotation(1, Vector3D.Y_AXIS);
}
}
}
