* Copyright phi16 ( http://wonderfl.net/user/phi16 )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/h7n1
*/
package {
import flash.events.KeyboardEvent;
import flash.events.Event;
import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.display.Sprite;
public class Render extends Sprite {
private var bmp:BitmapData;
private var ps:Vector.<uint>;
private const fail:Sample = new Sample(false);
private const white:Vec = new Vec(0.740063,0.742313,0.733934);
private const green:Vec = new Vec(0.162928,0.4080903,0.0833759);
private const red:Vec = new Vec(0.366046,0.0371827,0.0416385);
private const pls:Array = [
[new Vec(1,0,0),new Vec(-1,0,0),white],
[new Vec(-1,0,0),new Vec(1,0,0),white],
[new Vec(0,-1,0),new Vec(0,1,0),red],
[new Vec(0,1,0),new Vec(0,-1,0),green],
[new Vec(0,0,1),new Vec(0,0,-1),white],
];
private const cam:Vec = new Vec(0,0,-3);
private const camD:Vec = new Vec(0,0,1);
private const lgh:Vec = new Vec(-0.99,0,0);
private var sR:Array = [], sG:Array = [], sB:Array = [];
private var sC:Array = [], sS:Array = [];
private var path:Array = [], befL:Array = [];
private var id:int = 0;
public function Render() {
bmp = new BitmapData(465,465,false,0);
var bm:Bitmap = new Bitmap(bmp);
addChild(bm);
id=0;
for(var i:int=0;i<465;i++){
for(var j:int=0;j<465;j++){
id++;
sR[id]=sG[id]=sB[id]=sC[id]=0;
sS[id]=getSample(i,j);
path[id]=new Array();
befL[id]=new Vec(lumi(sS[id],0,0),lumi(sS[id],0,1),lumi(sS[id],0,2));
}
}
addEventListener(Event.ENTER_FRAME,draw);
}
public function draw(e:Event):void{
var c:int = 2000;
ps = bmp.getVector(bmp.rect);
while(c --> 0){
var i:int = Math.floor(Math.random()*465);
var j:int = Math.floor(Math.random()*465);
id=i*465+j;
ps[id] = getColor(id);
}
bmp.setVector(bmp.rect,ps);
}
public function plane(n:Vec,s:Vec,p:Vec,v:Vec,emi:Number,col:Vec):Sample{
var b:Vec = s.sub(p);
var c:Number = b.dot(n);
var e:Number = v.dot(n);
if(c*e <= 0)return fail;
return (new Sample(true)).on(p.add(v.mul(c/e)),n.mul(e<0?1:-1),col,emi,c/e);
}
public function collide(p:Vec,v:Vec):Sample{
var a:Sample = new Sample(false);
for(var i:int=0;i<pls.length;i++){
a.or(plane(pls[i][1],pls[i][0],p,v,0,pls[i][2]));
}
return a;
}
public function lumi(a:Sample,idx:int,x:int):Number{//The integrated color with emission
var v:Vec;
var ne:Number = 0;
var g:Number = 0;
if(path[id].length == idx){
v = lgh.sub(a.p);
var l2:Number = v.lengthSq();
if(l2<1)l2=1;
v.normalize();
ne = 1.0;
g = a.n.dot(v)*1/l2;
}else{
v = path[id][idx];
v.normalize();
var s:Sample = collide(a.p,v);
if(s.b){
ne = lumi(s,idx+1,x);
}
g = -v.dot(a.n)*v.dot(s.n);
}
var brdf:Number = a.c.e(x)/Math.PI;
var prob:Number = 1/Math.PI/2;
return a.e + ne*brdf*g/prob;
}
public function G(p1:Vec,n1:Vec,p2:Vec,n2:Vec):Number{
var v:Vec = p1.sub(p2);
var r2:Number = v.lengthSq();
return -v.dot(n1)*v.dot(n2)/r2;
}
public function hemiRandom(n:Vec):Vec{
var u1:Number = Math.random()*2-1;
var u2:Number = Math.random();
var r:Number = Math.sqrt(1-u1*u1);
var phi:Number = 2*Math.PI*u2;
var v:Vec = new Vec(Math.cos(phi)*r, Math.sin(phi)*r, u1);
if(v.dot(n)<0)v.mul(-1);
v.normalize();
return v;
}
public function getSample(x:int,y:int):Sample{
var p:Vec = cam;
var v:Vec = new Vec(x/465*2-1,y/465*2-1,2);
v.normalize();
return collide(p,v);
}
public function reSample(q:Sample,i:int):Vec{
var p:Array = path[i];
/*path[i] = [];
var m:Sample = q;
while(Math.random() < 0){
var r:Vec = hemiRandom(m.n);
path[i].push(r);
m = collide(m.p,r);
if(!m.b)break;
}*/
var d:Number = 0;//0.5;//1/Math.PI/2;
if(Math.random() < d){
path[i] = [];
}else{
path[i] = [hemiRandom(q.n)];
d = 1-d;
}
var e:Vec = new Vec(lumi(q,0,0),lumi(q,0,1),lumi(q,0,2));
/*if(e.val() / befL[i].val() <= Math.random()){ //Dispose
e = befL[i];
path[i] = p;
}
befL[i] = e;*/
return e.mul(d);
}
public function getColor(i:int):uint{
var q:Sample = sS[i];
var u:Vec = reSample(q,i);
sR[i]+=Math.max(u.x,0);
sG[i]+=Math.max(u.y,0);
sB[i]+=Math.max(u.z,0);
sC[i]++;
return cons(sR[i]/sC[i],sG[i]/sC[i],sB[i]/sC[i]);
}
public function cons(r:Number,g:Number,b:Number):uint{
var rr:Number = Math.pow(Math.min(r,1),1/2.2)*255;
var gg:Number = Math.pow(Math.min(g,1),1/2.2)*255;
var bb:Number = Math.pow(Math.min(b,1),1/2.2)*255;
return (Math.floor(rr)*256+Math.floor(gg))*256+Math.floor(bb);
}
}
}
var eps : Number = 0.00001;
class Sample{
public var b:Boolean;
public var p:Vec, n:Vec;
public var c:Vec, e:Number, d:Number;
public function Sample(b_:Boolean){
b=b_;
}
public function on(p_:Vec,n_:Vec,c_:Vec,e_:Number,d_:Number):Sample{
p=p_,n=n_,c=c_,e=e_,d=d_;
return this;
}
public function or(m:Sample):void{
if(m.b==false)return;
if(b==false){
b=true,p=m.p,n=m.n,c=m.c,e=m.e,d=m.d;
}else{
if(d<m.d){
return;
}else{
p=m.p,n=m.n,c=m.c,e=m.e,d=m.d;
}
}
}
}
class Vec{
public var x:Number,y:Number,z:Number;
public function Vec(x_:Number,y_:Number,z_:Number){
x=x_,y=y_,z=z_;
}
public function normalize():void{
var e:Number = length();
if(Math.abs(e)<eps)return;
x/=e;
y/=e;
z/=e;
}
public function length():Number{
return Math.sqrt(lengthSq());
}
public function lengthSq():Number{
return x*x+y*y+z*z;
}
public function zero():Boolean{
return lengthSq() < eps;
}
public function dot(p:Vec):Number{
return x*p.x+y*p.y+z*p.z;
}
public function sub(p:Vec):Vec{
return new Vec(x-p.x,y-p.y,z-p.z);
}
public function add(p:Vec):Vec{
return new Vec(x+p.x,y+p.y,z+p.z);
}
public function mul(d:Number):Vec{
return new Vec(d*x,d*y,d*z);
}
public function e(p:int):Number{
if(p==0)return x;
if(p==1)return y;
if(p==2)return z;
return 0;
}
public function val():Number{
return 0.299*x + 0.587*y + 0.114*z;
}
}
