forked from: vpath

/**
 * Copyright zaacch ( http://wonderfl.net/user/zaacch )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/glBx
 */

// forked from lizhi's vpath
package
{
    import adobe.utils.CustomActions;
    import com.bit101.components.HUISlider;
    import com.bit101.components.InputText;
    import com.bit101.components.PushButton;
    import com.bit101.components.Slider;
    import flash.display.Sprite;
    import flash.events.Event;
    import flash.events.MouseEvent;
    import flash.geom.Point;
    import flash.text.TextField;
    import net.hires.debug.Stats;
    /**
     * ...
     * @author lizhi http://game-develop.net/
     */
    [SWF(frameRate=60)]
    public class TestPath extends Sprite
    {
        private var ballss:Vector.<Vector.<Sprite>> =new Vector.<Vector.<Sprite>>();
        public var startBall:Sprite;
        public var endBall:Sprite;
        public var start:VPoint = new VPoint;
        public var end:VPoint = new VPoint;
        public var lines:Vector.<VLine> = new Vector.<VLine>;
        public var lps:Vector.<VPoint> = new Vector.<VPoint>;
        private var nowVersion:int = 1;
        private var open:BinaryHeap;
        private var path:Vector.<VPoint>;
        private var silder:HUISlider;
        public function TestPath()
        {
            ballss.push(new Vector.<Sprite>);
            for (var i:int = 0; i < 7;i++ ) {
                ballss[0].push(createBall(i));
            }
            startBall = createBall(i);
            endBall = createBall(i);
            stage.addEventListener(MouseEvent.MOUSE_UP, stage_mouseUp);
            addEventListener(Event.ENTER_FRAME, enterFrame);

            addChild(new Stats);
            new PushButton(this, 0, 100, "add lines", createLines);
            silder = new HUISlider(this, 0, 120, "num");
            silder.tick = 1;
            silder.setSliderParams(3, 10, 5);
        }

        private function createLines(e:Event):void {
            ballss.push(new Vector.<Sprite>);
            for (var i:int = 0; i < silder.value; i++ ) {
                var s:Sprite = createBall(i);
                s.x = i * 100 + 100;
                s.y = 100+50*Math.random();
                ballss[ballss.length-1].push(s);
            }
        }

        private function enterFrame(e:Event):void
        {
            graphics.clear();
            graphics.lineStyle(0);

            lines.length = 0;
            lps.length = 0;
            for each(var balls:Vector.<Sprite> in ballss){
                for (var i:int = 0; i < balls.length-1; i++ ) {
                    var line:VLine = new VLine;
                    var p0:VPoint = new VPoint;
                    p0.x = balls[i].x;
                    p0.y = balls[i].y;
                    var p1:VPoint = new VPoint;
                    p1.x = balls[i+1].x;
                    p1.y = balls[i + 1].y;

                    var d:Point = p1.subtract(p0);
                    d.normalize(1);
                    p1.x += d.x;
                    p1.y += d.y;
                    p0.x -= d.x;
                    p0.y -= d.y;

                    line.p0 = p0;
                    line.p1 = p1;
                    lines.push(line);
                    lps.push(p0,p1);
                }
            }

            start = new VPoint;
            start.x = startBall.x;
            start.y = startBall.y;
            end.x = endBall.x;
            end.y = endBall.y;
            for each(line in lines) {
                dline(line.p0, line.p1);
            }

            /*for each(line in lines) {
                for (i = 0; i < line.ps.length; i++ ) {
                    graphics.lineStyle(0, passable(start,line.ps[i])?0xff00:0xff0000);
                    dline(start, line.ps[i]);
                }
            }*/

            nowVersion++;
            open = new BinaryHeap(justMin);
            start.g = 0;
            var node:VPoint = start;
            node.version = nowVersion;
            var flag:Boolean = true;
            while (!passable(node,end)) {
                for each(var test:VPoint in lps) {
                    if (test == node||!passable(node,test)) {
                        continue;
                    }
                    var cost:Number = Point.distance(node, test);
                    var g:Number = node.g + cost;
                    var h:Number = Point.distance(end, test);
                    var f:Number = g + h;
                    if (test.version==nowVersion) {
                        if (test.f>f) {
                            test.f = f;
                            test.g = g;
                            test.h = h;
                            test.parent = node;
                        }
                    }else {
                        test.f = f;
                        test.g = g;
                        test.h = h;
                        test.parent = node;
                        open.ins(test);
                        test.version = nowVersion;
                    }
                }
                if (open.a.length==1) {
                    flag = false;
                    break;
                }
                node = open.pop() as VPoint;
            }
            path = new Vector.<VPoint>;
            if(flag){
                end.parent = node;
                node = end;
                path.push(node);
                while (node != start){
                    node = node.parent;
                    path.unshift(node);
                }
            }

            graphics.lineStyle(3, 0xffff, .5);
            for (i = 0; i < path.length-1;i++ ) {
                dline(path[i], path[i+1]);
            }
        }

        private function passable(p0:VPoint, p1:VPoint):Boolean {
            for each(var line:VLine in lines) {
                if (intersect(p0,p1,line.p0,line.p1)) {
                    return false;
                }
            }
            return true;
        }

        private function dline(b1:VPoint, b2:VPoint):void {
            graphics.moveTo(b1.x, b1.y);
            graphics.lineTo(b2.x, b2.y);
        }

        private function stage_mouseUp(e:MouseEvent):void
        {
            stopDrag();
        }

        private function createBall(i:int):Sprite {
            var b:Sprite = new Sprite;
            var tf:TextField = new TextField;
            tf.mouseEnabled = tf.mouseWheelEnabled = false;
            b.addChild(tf);
            tf.autoSize = "left";
            tf.text = "" + i;
            tf.x = -tf.width / 2;
            tf.y = -tf.height / 2;
            b.graphics.beginFill(0xffffff * Math.random(), .7);
            b.graphics.drawCircle(0, 0, 10);
            b.x = Math.random() * stage.stageWidth;
            b.y = Math.random() * stage.stageHeight;
            b.addEventListener(MouseEvent.MOUSE_DOWN, onMD);
            addChild(b);
            return b;
        }

        private function onMD(e:Event):void {
            (e.currentTarget as Sprite).startDrag();
        }

        public static function intersect(p1:Point,p2:Point,p3:Point,p4:Point):Boolean {
            return((Math.max(p1.x,p2.x)>=Math.min(p3.x,p4.x))&&
                    (Math.max(p3.x,p4.x)>=Math.min(p1.x,p2.x))&&
                    (Math.max(p1.y,p2.y)>=Math.min(p3.y,p4.y))&&
                    (Math.max(p3.y,p4.y)>=Math.min(p1.y,p2.y))&&
                    (multiply(p3,p2,p1)*multiply(p2,p4,p1)>0)&&
                    (multiply(p1,p4,p3)*multiply(p4,p2,p3)>0));
        }

        public static function multiply(sp:Point,ep:Point,op:Point):int {
            return((sp.x-op.x)*(ep.y-op.y)-(ep.x-op.x)*(sp.y-op.y));
        }
        private function justMin(x:Object, y:Object):Boolean {
            return x.f < y.f;
        }

    }

}
import flash.geom.Point;

class VLine
    {
        public var p0:VPoint;
        public var p1:VPoint;
        public function VLine()
        {

        }

    }
class VPoint extends Point
    {
        public var line:VLine;
        public var g:Number;
        public var h:Number;
        public var f:Number;
        public var version:int = -1;
        public var parent:VPoint;
        public function VPoint()
        {

        }

    }

class BinaryHeap {
    public var a:Array = [];
    public var justMinFun:Function = function(x:Object, y:Object):Boolean {
        return x < y;
    };

    public function BinaryHeap(justMinFun:Function = null){
        a.push(-1);
        if (justMinFun != null)
            this.justMinFun = justMinFun;
    }

    public function ins(value:Object):void {
        var p:int = a.length;
        a[p] = value;
        var pp:int = p >> 1;
        while (p > 1 && justMinFun(a[p], a[pp])){
            var temp:Object = a[p];
            a[p] = a[pp];
            a[pp] = temp;
            p = pp;
            pp = p >> 1;
        }
    }

    public function pop():Object {
        var min:Object = a[1];
        a[1] = a[a.length - 1];
        a.pop();
        var p:int = 1;
        var l:int = a.length;
        var sp1:int = p << 1;
        var sp2:int = sp1 + 1;
        while (sp1 < l){
            if (sp2 < l){
                var minp:int = justMinFun(a[sp2], a[sp1]) ? sp2 : sp1;
            } else {
                minp = sp1;
            }
            if (justMinFun(a[minp], a[p])){
                var temp:Object = a[p];
                a[p] = a[minp];
                a[minp] = temp;
                p = minp;
                sp1 = p << 1;
                sp2 = sp1 + 1;
            } else {
                break;
            }
        }
        return min;
    }
}
