Interactive Cube Dragon

/**
 * Copyright mfc314159 ( http://wonderfl.net/user/mfc314159 )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/fo3M
 */

package  {
	// Credit to Wonderfl for all the inspiration, and who ever made the demo I used cause
	// I can't find the original.
	// I hope someone who is where I was yeserday finds this useful today.
	//
	// @Author Dave M.  mfc314159@yahoo.com
	// I basically took a papervision box demo and incorperated a simple 3D path system
	// that I was aleady working on to create the basis for what I would like to become
	// a Dragon.  The path is created by constantly changeing the angle of each axis to
	// create an arcing 3D path.  If it runs away from you just click and a centered
	// postion will begin.
	//
	// Any help is greatly appreciated
	// ---Questions yet to be answered---
	// Can I set the camera position to the leading postion? cause that would be cool.
	// How do I properly change the yaw, roll, and pitch to reflect the position of the segment?
	// many .. many .. more ...
	//
	// ---Things To Do---
	// make use of number3D
	// better control input
	// make sin & cos tables
	// object to hit
	//
	//
	import flash.display.Sprite;
	import flash.display.StageAlign;
	import flash.events.Event;
	import flash.events.MouseEvent;
	import org.papervision3d.cameras.Camera3D;
        import org.papervision3d.materials.BitmapFileMaterial;
        import org.papervision3d.materials.ColorMaterial;
        import org.papervision3d.materials.utils.MaterialsList;
        import org.papervision3d.objects.primitives.Cube;
        import org.papervision3d.render.BasicRenderEngine;
        import org.papervision3d.scenes.Scene3D;
        import org.papervision3d.view.Viewport3D;


	public class dragon extends Sprite {
	private var viewport:Viewport3D;
	private var scene:Scene3D;
	private var renderer:BasicRenderEngine;
	private var camera:Camera3D;
	private var materialsList:MaterialsList;
   	private var cube:Cube;

	private var plane1:ColorMaterial; //front
	private var plane2:ColorMaterial; //back
	private var plane3:ColorMaterial; //left
	private var plane4:ColorMaterial; //right
	private var plane5:ColorMaterial; //top
	private var plane6:ColorMaterial; //bottom

	//--Everyone loves Pie
	private const piE:Number = Math.PI / 180;

	//--Reusuable id# to use with While loops
	private var id:int = 0;

	//--Number of segments
	private var max:int = 50;

	//--Spread of segements
	private var spread:int = 10;

	private var origin:Array = []; //origin position
	private var path:Array = [];   //traveled path
	private var _dragon:Array = []; //segment objects
	private var pathID:Array = []; //segment path ID


	//--Direction Angles
	private var xAng:Number = Math.random() * 180.00;
	private var yAng:Number = Math.random() * 180.00;
	private var zAng:Number = Math.random() * 180.00;

	//--Turing Speeds
	private var turnSpeed:Number = 1;
	private var turnSpeedX:Number = turnSpeed / 1;
	private var turnSpeedY:Number = turnSpeed / 2;
	private var turnSpeedZ:Number = turnSpeed / 3;

	//--Leading Path vars
	private var speed:Number = 5;
	private var pathX:Number = speed *  Math.sin(piE * xAng);
	private var pathY:Number = speed *  Math.cos(piE * yAng);
	private var pathZ:Number = speed *  Math.sin(piE * zAng);

	public function dragon() {

		//--PAPERVISION INIT
		stage.frameRate = 60;
		stage.quality = "BEST";
		stage.scaleMode = "noScale";
		stage.align = StageAlign.TOP_LEFT;
		viewport = new Viewport3D();
		viewport.viewportWidth = 1000;
		viewport.viewportHeight = 700;
		viewport.x = ( this.stage.stageWidth - viewport.viewportWidth ) / 2;
		viewport.y = ( this.stage.stageHeight - viewport.viewportHeight ) / 2;
		addChild(viewport);
		scene = new Scene3D();
		camera = new Camera3D();
		renderer = new BasicRenderEngine();

		//--Planes for Cube:  Green Sides, Red Bottom, Grey Top, 50% alpha overall
		plane1 = new ColorMaterial(0x00ff00, .5); //front
		plane2 = new ColorMaterial(0x00ff00, .5); //back
		plane3 = new ColorMaterial(0x00ff00, .5); //left
		plane4 = new ColorMaterial(0x00ff00, .5); //right
		plane5 = new ColorMaterial(0xf0f0f0, .5); //top
		plane6 = new ColorMaterial(0xff0000, .5); //bottom

		//--Add planes to material list
		materialsList = new MaterialsList();
		materialsList.addMaterial(plane1 , "front");
		materialsList.addMaterial(plane2 , "back");
		materialsList.addMaterial(plane3 , "left");
		materialsList.addMaterial(plane4 , "right");
		materialsList.addMaterial(plane5 , "top");
		materialsList.addMaterial(plane6 , "bottom");



		//--origin position array
		origin["x"] = Number(500.00);  //  x position
		origin["y"] = Number(1000.00); //  y position
		origin["z"] = Number(250.00);  //  z position

		//--path positions array
		path["X"] = new Array(); //  x position
		path["Y"] = new Array(); //  y position
		path["Z"] = new Array(); //  z position
		path["p"] = new Array(); //  pitch
		path["r"] = new Array(); //  roll
		path["y"] = new Array(); //  yaw
		while(id < (max * spread)) {
			path.X[id] = Number(origin.x);
			path.Y[id] = Number(origin.y);
			path.Z[id] = Number(origin.z);
			path.p[id] = Number(0.00);
			path.r[id] = Number(0.00);
			path.y[id] = Number(0.00);
			id++;
		}
		id = 0; //reset

		//base Size & ratio for each portion Begin/Mid/End
		var sizeBegin:int = 37;
		var numBegin:int = max * .2;
		var sizeMid:int = 50;
		var numMid:int = numBegin + (max *.2);
		var sizeEnd:int = 25;
		var numEnd:int = numMid + (max * .6);
		var segSize:int = 0;

                //add segments to the _dragon array
		//set pathIDs of segments in _dragon
		while(id < max) {

                        if((id < numBegin) && (id >= 0))      { segSize = sizeBegin; }
			if((id < numMid) && (id >= numBegin)) { segSize = sizeMid;   }
			if((id < numEnd) && (id >= numMid))   { segSize = sizeEnd;   }

		        if(id != 0) {
			//Add Cube for segment
			_dragon[id] = new Cube(materialsList, segSize, segSize, segSize, 1, 1, 1);
			} else {
			//Head Cube segment
			_dragon[id] = new Cube(materialsList, (segSize * 2), segSize, (segSize * 1.5), 1, 1, 1);
			}
			pathID[id] = int(id * spread); //find segment id# on path
			scene.addChild(_dragon[id]);   //add segment to scene
			id++;
		}


		//Fill the path array with init values
		setup();

		//--Reset origin
		stage.addEventListener(MouseEvent.CLICK, newPath);
		//--Generate path from mouse input
		stage.addEventListener(MouseEvent.MOUSE_MOVE, mousePath);
		//--Change Speed
		stage.addEventListener(MouseEvent.MOUSE_WHEEL, changeSpeed);
                //--start Main Loop
		stage.addEventListener(Event.ENTER_FRAME, mainLoop);

	}

	//------------------------------------------MOUSE INPUT HANDLERS
	private function newPath(evt:MouseEvent) {

		origin.x = evt.stageX;
		origin.y = evt.stageY;
		origin.z = 250;

		turnSpeed = -2 + (Math.random() * 4);
		turnSpeedX = turnSpeed / 1;
		turnSpeedY = turnSpeed / 2;
		turnSpeedZ = turnSpeed / 3;
	}
	private function mousePath(evt:MouseEvent) {

		turnSpeedX = (evt.stageX - 500) * .006;
		turnSpeedY = (evt.stageY - 350) * .006;
		turnSpeedZ = Math.sqrt((turnSpeedX * turnSpeedX) + (turnSpeedY * turnSpeedY));
	}

	private function changeSpeed(evt:MouseEvent) {
		if(evt.delta > 0) { speed += .1;
		} else {	    speed -= .1; }
		trace(speed);
	}
	//-----------------------------------------------------MAIN LOOP
	private function mainLoop(evt:Event) {

		//--STAGE 1
		//find next position

		xAng += turnSpeedX;  //change angles
		yAng += turnSpeedY;
		zAng += turnSpeedZ;

		if(xAng > 360) { xAng = xAng - 360; } // limit angles
		if(yAng > 360) { yAng = yAng - 360; }
		if(zAng > 360) { zAng = zAng - 360; }

		pathX = speed * Math.sin(piE * xAng); // angles to coordindates
		pathY = speed * Math.cos(piE * yAng);
		pathZ = speed * Math.sin(piE * zAng);

		origin.x += pathX; //add path coordinates to current positions
		origin.y += pathY;
		origin.z += pathZ;

		//--STAGE 2:--Shift and Add positions to path array
		//shift path positions down
		path.X.pop();
		path.Y.pop();
		path.Z.pop();
		path.p.pop();
		path.r.pop();
		path.y.pop();
		//add new position to path
		path.X.unshift(origin.x);
		path.Y.unshift(origin.y);
		path.Z.unshift(origin.z);
		//path.p.unshift(turnSpeedX);
		path.r.unshift(turnSpeedZ);
		//path.y.unshift(turnSpeedZ);

		//--STAGE 3:--Set Positions
		id = 0; //reset
		while(id < max) {
			_dragon[id].x = path.X[pathID[id]];
			_dragon[id].y = path.Y[pathID[id]];
			_dragon[id].z = path.Z[pathID[id]];
			//dragon[id].pitch(path.p[pathID[id]]);
			_dragon[id].roll(path.r[pathID[id]]);
			//dragon[id].yaw(path.y[pathID[id]]);
			id++;
		}

		//--STAGE 4:--Render The Scene
		renderer.renderScene(scene, camera, viewport);
	}

	private function setup() {
		//fills the path array with values to cut down on inital drawing time
		id = 0;
		while(id < (max * spread)){
			//--STAGE 1
			//find next position
			xAng += turnSpeedX;
			yAng += turnSpeedY;
			zAng += turnSpeedZ;

			if(xAng > 360) { xAng = xAng - 360; }
			if(yAng > 360) { yAng = yAng - 360; }
			if(zAng > 360) { zAng = zAng - 360; }

			pathX = speed * Math.sin(piE * xAng);
			pathY = speed * Math.cos(piE * yAng);
			pathZ = speed * Math.sin(piE * zAng);

			origin.x += pathX;
			origin.y += pathY;
			origin.z += pathZ;

			//--STAGE 2
			//shift positions down
			path.X.pop();
			path.Y.pop();
			path.Z.pop();
			path.p.pop();
			path.r.pop();
			path.y.pop();
			//add new position to path
			path.X.unshift(origin.x);
			path.Y.unshift(origin.y);
			path.Z.unshift(origin.z);
			path.p.unshift(turnSpeedX);
			path.r.unshift(turnSpeedZ);
			path.y.unshift(turnSpeedZ);

			id++;

		}


	}
	}

}
