* Copyright mutantleg ( http://wonderfl.net/user/mutantleg )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/fSlm
*/
package {
import flash.events.Event;
import flash.display.Sprite;
public class FlashTest extends Sprite {
public var a:ColTest;
public function FlashTest() {
graphics.clear();
graphics.lineStyle(2,0);
//graphics.drawRect(0,0,32,32);
a = new ColTest();
addChild(a);
stage.addEventListener(Event.ENTER_FRAME, onEnter);
}
public function onEnter(e:Event):void
{
a.onEnter(e);
}//onenter
}
}
import flash.display.Sprite;
import flash.display.Graphics;
import flash.events.Event;
import flash.geom.Point;
internal class ColTest extends Sprite
{
public var ray:RayTest;
public var ob:ColOb;
public function ColTest()
{
ray = new RayTest();
ob = new ColOb();
addChild(ob.debSpr);
var w:Number = 64;
var h:Number = 16;
ob.addLine(new Line(-w,-h,w,-h));
ob.addLine(new Line(-w,h,w,h));
ob.addLine(new Line(-w,-h,-w,h));
ob.addLine(new Line( w,-h,w,h));
graphics.clear();
graphics.lineStyle(2,0);
graphics.drawRect(0,0,400,400);
//stage.addEventListener(Event.ENTER_FRAME,onEnter);
}//coltest
public function onEnter(e:Event):void
{
graphics.clear();
graphics.lineStyle(2,0);
//graphics.drawRect(0,0,400,400);
ray.start.x = 30;
ray.start.y = 30;
ray.end.x = mouseX;
ray.end.y = mouseY;
ob.cx = 200;
ob.cy = 200;
ob.ori += 0.02;
ray.test(ob);
ray.draw(graphics);
ob.draw(ob.debSpr);
ob.debDraw(graphics);
}//onenter
};//coltest
internal class RayTest
{
public var start:Point = new Point();
public var end:Point = new Point();
public var col:Point = new Point();
public var t:Number = 0;
public var bColl:Boolean = false;
public function RayTest()
{
}
public function test(ob:ColOb):Boolean
{
t = ob.lineTest(start, end);
bColl = t >= 0 && t <= 1.0;
if (bColl)
{
col.x = start.x + (end.x - start.x) * t;
col.y = start.y + (end.y - start.y) * t;
}
else
{
col.x = end.x;
col.y = end.y;
}
return bColl;
}//test
public function draw(g:Graphics):void
{
g.moveTo(start.x, start.y);
g.lineTo(col.x, col.y);
g.drawCircle(col.x, col.y, 4);
}//draw
};//test
internal class Line
{
public var v0:Point = new Point();
public var v1:Point = new Point();
public function Line(sx:Number,sy:Number, ex:Number, ey:Number)
{
v0.x = sx;
v0.y = sy;
v1.x = ex;
v1.y = ey;
}//ctor
};//line
internal class ColOb
{
public var cx:Number = 0;
public var cy:Number = 0;
public var ori:Number = 0;
public var debSpr:Sprite = new Sprite();
public var vecLine:Vector.<Line> = new Vector.<Line>;
public function addLine(a:Line):void
{
vecLine.push(a);
calcMinMax();
}//addline
public var minx:Number = 0;
public var maxx:Number = 0;
public var miny:Number = 0;
public var maxy:Number = 0;
public var rad:Number = 0;
public function calcMinMax():void
{
var i:int;
var num:int;
var m:Line;
num = vecLine.length;
minx = 9999999;
miny = 9999999;
maxy = -9999999;
maxx = -9999999;
for (i =0; i < num; i++)
{
m = vecLine[i];
if (minx > m.v0.x) { minx = m.v0.x; }
if (minx > m.v1.x) { minx = m.v1.x; }
if (maxx < m.v0.x) { maxx = m.v0.x; }
if (maxx < m.v1.x) { maxx = m.v1.x; }
if (miny > m.v0.y) { miny = m.v0.y; }
if (miny > m.v1.y) { miny = m.v1.y; }
if (maxy < m.v0.y) { maxy = m.v0.y; }
if (maxy < m.v1.y) { maxy = m.v1.y; }
}//nexti
var mag:Number;
var dx:Number;
var dy:Number;
dx = maxx - minx;
dy = maxy - miny;
mag = Math.sqrt(dx*dx+dy*dy);
rad = mag /2;
}//calcminmax
public function debDraw(g:Graphics):void
{
g.lineStyle(1, 0x0000FF);
g.drawRect(cx+minx,cy+miny, maxx-minx, maxy-miny);
g.lineStyle(1,0xFF0000);
g.drawCircle(cx,cy, rad);
var r2:Number;
r2 = rad + 16;
g.lineStyle(1,0x00FF00);
g.drawRect(cx-r2,cy-r2,r2+r2,r2+r2);
}//deb
public function draw(s:Sprite):void
{
var i:int;
var num:int;
var m:Line;
var g:Graphics;
g = s.graphics;
num = vecLine.length;
g.clear();
g.lineStyle(2,0);
g.drawCircle(0,0, 4);
for (i = 0; i < num; i++)
{
m = vecLine[i];
g.moveTo(m.v0.x, m.v0.y);
g.lineTo(m.v1.x, m.v1.y);
}//nexti
s.x = cx;
s.y = cy;
s.rotation = ori * (180 / 3.1415);
}//draw
public static var vs:Point = new Point();
public static var ve:Point = new Point();
public function lineTest(s:Point, e:Point):Number
{
var ang:Number;
var rx:Number;
var ry:Number;
//transform line into the colob coordinate system
ang = -ori;
rx = s.x - cx;
ry = s.y - cy;
vs.x = Math.cos(ang) * rx - Math.sin(ang) * ry;
vs.y = Math.sin(ang) * rx + Math.cos(ang) * ry;
rx = e.x - cx;
ry = e.y - cy;
ve.x = Math.cos(ang) * rx - Math.sin(ang) * ry;
ve.y = Math.sin(ang) * rx + Math.cos(ang) * ry;
//go through all lines
var i:int;
var num:int;
var smallt:Number;
var dist:Number;
var m:Line;
smallt = 999;
num = vecLine.length;
for (i = 0; i < num; i++)
{
m = vecLine[i];
dist = lineLineInter(vs, ve, m.v0, m.v1);
if (dist < smallt)
{
smallt = dist;
}
}//nexti
return smallt;
}//linetest
public function lineLineInter(v0:Point, v1:Point, v2:Point, v3:Point):Number
{
var ua:Number;
var ub:Number;
var bot:Number;
bot = ((v3.y-v2.y)*(v1.x-v0.x))-((v3.x-v2.x)*(v1.y-v0.y));
if (bot == 0) { return 999;}
ua = (((v3.x-v2.x)*(v0.y-v2.y))-((v3.y-v2.y)*(v0.x-v2.x))) / bot;
ub = (((v1.x-v0.x)*(v0.y-v2.y))-((v1.y-v0.y)*(v0.x-v2.x))) / bot;
if (ua > 1 || ua < 0 || ub > 1 || ub < 0) { return 999; }
return ua;
}//lineline
};//classend
