forked from: 線分の交差判定
forked from 線分の交差判定 (diff: 3)
http://hakuhin.hp.infoseek.co.jp/main/as/collision.html 参考にしました てか、まんまです
ActionScript3 source code
/**
* Copyright hemingway ( http://wonderfl.net/user/hemingway )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/bq31
*/
// forked from Mae_ITR's 線分の交差判定
package
{
//http://hakuhin.hp.infoseek.co.jp/main/as/collision.html
//参考にしました てか、まんまです
import flash.display.Sprite;
import flash.geom.Point;
import flash.events.Event;
import flash.events.MouseEvent;
import flash.display.StageAlign;
import flash.display.StageScaleMode;
import com.bit101.components.*;
public class LineCrossTest extends Sprite
{
private var a:Point;
private var b:Point;
private var c:Point;
private var d:Point;
private var OldMouse:Point;
private var ballA:Ball;
private var ballB:Ball;
private var ballC:Ball;
private var txt:Label;
public function LineCrossTest()
{
this.stage.align = StageAlign.TOP_LEFT;
this.stage.scaleMode = StageScaleMode.NO_SCALE;
init();
}
private function init():void
{
a = new Point(stage.stageWidth*Math.random(),stage.stageHeight*Math.random());
b = new Point(stage.stageWidth*Math.random(),stage.stageHeight*Math.random());
c = new Point();
d = new Point(mouseX,mouseY);
OldMouse = d.clone();
ballA = new Ball(5, 0x999999);
ballA.x = a.x;
ballA.y = a.y;
ballA.addEventListener(MouseEvent.MOUSE_DOWN, onPress);
ballA.addEventListener(MouseEvent.MOUSE_UP, onRelease);
ballB = new Ball(5, 0x999999);
ballB.x = b.x;
ballB.y = b.y;
ballB.addEventListener(MouseEvent.MOUSE_DOWN, onPress);
ballB.addEventListener(MouseEvent.MOUSE_UP, onRelease);
ballC = new Ball(3, 0x00FF99);
ballC.x = c.x;
ballC.y = c.y;
txt = new Label(this, 6, 6);
addChild(ballC);
addChild(ballB);
addChild(ballA);
draw();
addEventListener(Event.ENTER_FRAME, onEnterFrame);
}
private function onEnterFrame(e:Event):void
{
d.x = mouseX - OldMouse.x;
d.y = mouseY - OldMouse.y;
draw();
calculation();
OldMouse.x = mouseX;
OldMouse.y = mouseY;
}
private function calculation():void {
var ab:Point = new Point(b.x - a.x, b.y - a.y);
var n:Point = new Point( -ab.y, ab.x);
n.normalize(1);
var dd:Number = -(a.x * n.x + a.y * n.y);
if (d.x != 0 || d.y != 0) {
var t:Number = -(n.x * OldMouse.x + n.y * OldMouse.y + dd) / (n.x * d.x + n.y * d.y);
if (t > 0 && t <= 1) {
c.x = OldMouse.x + d.x * t;
c.y = OldMouse.y + d.y * t;
var ac:Point = new Point(c.x - a.x, c.y - a.y);
var bc:Point = new Point(c.x - b.x, c.y - b.y);
var doc:Number = (ac.x * bc.x) + (ac.y * bc.y);
if (doc < 0) {
ballC.x = c.x;
ballC.y = c.y;
txt.text = "x : " + c.x + "\n" + "y : " + c.y + "\n";
}
}
}
}
private function onPress(e:MouseEvent):void
{
e.target.startDrag();
stage.addEventListener(MouseEvent.MOUSE_MOVE, onMove);
}
private function onMove(e:MouseEvent):void
{
a.x = ballA.x;
a.y = ballA.y;
b.x = ballB.x;
b.y = ballB.y;
}
private function onRelease(e:MouseEvent):void
{
e.target.stopDrag();
stage.removeEventListener(MouseEvent.MOUSE_MOVE, onMove);
}
private function draw():void
{
this.graphics.clear();
this.graphics.lineStyle(1, 0xCCCCCC);
this.graphics.moveTo(a.x, a.y);
this.graphics.lineTo(b.x, b.y);
this.graphics.lineStyle(1, 0x00FF99, 0.5);
this.graphics.moveTo(OldMouse.x, OldMouse.y);
this.graphics.lineTo(mouseX, mouseY);
}
}
}
import flash.display.Sprite
class Ball extends Sprite {
private var radius:Number;
private var color:uint;
public function Ball(radius:Number = 40, color:uint = 0xff0000) {
this.radius = radius;
this.color = color;
init();
}
public function init():void {
graphics.beginFill(color);
graphics.drawCircle(0, 0, radius);
graphics.endFill();
}
}
