* Copyright mutantleg ( http://wonderfl.net/user/mutantleg )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/arii
*/
package {
import flash.display.Shape;
import flash.events.MouseEvent;
import flash.ui.Keyboard;
import flash.display.BitmapData;
import flash.events.KeyboardEvent;
import flash.text.TextField;
import flash.events.Event;
import flash.display.Sprite;
public class FlashTest extends Sprite {
public function FlashTest() {
Wonderfl.disable_capture();
deb = new TextField();
deb.width=320;deb.height=240; deb.mouseEnabled=false;
addChild(deb);
myRend = new xMiniRender();
addChild(myRend);
myRend.init();
stage.addEventListener(Event.ENTER_FRAME, initLoop);
}//ctor
public var myRend:xMiniRender;
public var deb:TextField;
public function initLoop(e:Event):void
{
if (myRend.cerr) { deb.text = myRend.cerr_msg; return; }
if (myRend.cready == false) { return; }
stage.removeEventListener(Event.ENTER_FRAME, initLoop);
stage.addEventListener(Event.ENTER_FRAME, onEnter);
deb.text = "ready";
deb.text = myRend.context.driverInfo;
}//init
public var gt:int = 0;
public function onEnter(e:Event):void
{
deb.text = ""+gt;
myRend.context.clear();
myRend.use2DMode(465,465);
myRend.setColor(1,0,0); myRend.drawRect(0,0, 465,465);
myRend.setColor(0,0,1); myRend.drawRect(64,64, 64,64);
myRend.setColor(0,0,0,0.5);
myRend.drawSprite(330, 330, 640,640, gt*-0.03);
myRend.setColor(0,0,1);
myRend.drawSprite(230, 230, 64,64, gt*0.1);
var i:int;
var n:Number;
for (i =0; i < 256; i++)
{
myRend.setColor(((gt+i)%256)/256,0.3,i*0.02,0.2);
n = (gt+i) *0.02;
myRend.drawSprite(230+Math.sin(n)*256, 230+Math.cos(n)*256, 64+i,64, i);
}
myRend.context.present();
gt += 1;
}//onenter
}//classend
}
import flash.display.BitmapData;
import flash.display.Sprite;
import flash.events.ErrorEvent;
import flash.events.Event;
import flash.geom.Matrix;
import flash.geom.Matrix3D;
import flash.geom.Vector3D;
import flash.utils.ByteArray;
import com.adobe.utils.AGALMiniAssembler;
import flash.display3D.*;
import flash.display3D.textures.Texture;
internal class xMiniRender extends Sprite
{
public var cready:Boolean = false;
public var cerr:Boolean = false;
public var cerr_msg:String = "noerror";
public var context:Context3D = null;
public var scrWidth:int = 400;
public var scrHeight:int = 400;
public var prog:Program3D;
public var projmat:Matrix3D = new Matrix3D();
public var cammat:Matrix3D = new Matrix3D();
public var mat:Matrix3D = new Matrix3D();
public var texMat:Matrix3D = new Matrix3D();
public var blankSkin:xTex;
public function init():void
{
stage.stage3Ds[0].addEventListener(Event.CONTEXT3D_CREATE, contReady);
stage.stage3Ds[0].addEventListener(ErrorEvent.ERROR, onError);
stage.stage3Ds[0].requestContext3D(Context3DRenderMode.AUTO);
}//init
public function onError(e:ErrorEvent):void { trace("context error: ", e.text); cerr_msg = e.text; cerr = true; }
public function contReady(e:Event):void
{
context = stage.stage3Ds[0].context3D;
context.addEventListener(ErrorEvent.ERROR, onError);
context.configureBackBuffer(scrWidth, scrHeight, 0, true);
context.enableErrorChecking = true; // false; //set true for debug false for speed
initProgram(context);
context.setProgram(prog);
cready = true;
rectGeo = new xGeo();
rectGeo.initPlane(1); rectGeo.upload(context);
blankSkin = new xTex();
var temp:BitmapData;
temp = new BitmapData(64,64,true,0xFFffFFff);
temp.perlinNoise(12,5,2,4,true,true,7, true);
blankSkin.genTex(temp, context);
}//contready
public function initProgram(c:Context3D):void
{
prog = c.createProgram();
var code:String;
var vert:ByteArray;
var frag:ByteArray;
var assembler:AGALMiniAssembler = new AGALMiniAssembler();
code = "";
code += "m44 vt0, va0, vc4\n"; //pos * objmatrix
code += "m44 op, vt0, vc0\n"; // * cammatrix
code += "m44 v0, va1, vc8\n" // uv*texture matrix to fragment
code += "mov v1, va2\n" // vertex color to fragment
vert = assembler.assemble(Context3DProgramType.VERTEX, code);
code = "";
code += "tex ft0 v0, fs0 <2d, linear, miplinear, wrap>\n";
code += "mul ft1, fc0, v1\n"; //color*vertex color
code += "mul oc, ft1, ft0\n"; //texture * color
frag = assembler.assemble(Context3DProgramType.FRAGMENT, code);
prog.upload(vert, frag);
}//initprogram
public static function setOrthoMatrix(m:Matrix3D,
left:Number, right:Number, bottom:Number, top:Number, near:Number, far:Number):void
{
var vec:Vector.<Number>; var i:int;
vec = m.rawData; for (i = 0; i < 16; i++) { vec[i] = 0.0; }
vec[0] = 2.0 / (right - left); vec[5] = 2.0 / (top - bottom);
vec[10] = -2 / (far - near); vec[12] = (right + left) / (left - right);
vec[13] = (top + bottom) / (bottom - top); vec[14] = (far + near) / (near - far);
vec[15] = 1.0; m.rawData = vec;
}//setortho
public var rectGeo:xGeo;
public var rectColor:Vector.<Number> = Vector.<Number>([1.0, 1.0, 1.0, 1.0]);
public var rectUv:Matrix3D = new Matrix3D();
public var rectTrans:Matrix3D = new Matrix3D();
public function setCurTex(skin:xTex):void
{ context.setTextureAt(0, skin.tex); }
public function setColor(r:Number=1.0, g:Number=1.0, b:Number=1.0, a:Number = 1.0):void
{
rectColor[0] = r; rectColor[1] = g; rectColor[2] = b; rectColor[3] = a;
context.setProgramConstantsFromVector(Context3DProgramType.FRAGMENT, 0, rectColor);
}//set2dcolor
public function setUv(u0:Number = 0.0, v0:Number = 0.0, uw:Number = 1.0, vh:Number = 1.0):void
{
rectUv.identity();
rectUv.appendScale(uw, vh, 1);
rectUv.appendTranslation(u0, v0, 0);
context.setProgramConstantsFromMatrix(Context3DProgramType.VERTEX, 8, rectUv, true);
}//set2duv
public function drawRect(ax:Number, ay:Number, aw:Number, ah:Number):void
{ drawSprite(ax + aw * 0.5, ay + ah * 0.5, aw, ah, 0); }
public function getMag(ax:Number, ay:Number):Number { return Math.sqrt(ax * ax + ay * ay); }
public function drawLine(ax:Number, ay:Number, bx:Number, by:Number, w:Number):void
{
var a:Number; var d:Number;
a = Math.atan2(ay - by, ax - bx);
d = getMag(bx - ax, by - ay);
drawSprite(ax + Math.cos(a) * d * -0.5, ay + Math.sin(a) * d * -0.5, w, d, a+1.57);
}//draw2dline
public function drawSprite(ax:Number, ay:Number, aw:Number, ah:Number, ang:Number=0):void
{
var g:xGeo; g = rectGeo;
var c:Context3D; c = context;
rectTrans.identity();
rectTrans.appendScale(aw, -ah, 1); //note the negative Y trick here
if (ang!=0){rectTrans.appendRotation(ang * 57.29, Vector3D.Z_AXIS);}
rectTrans.appendTranslation(ax, ay, 0);
c.setProgramConstantsFromMatrix(Context3DProgramType.VERTEX, 4, rectTrans, true);
c.drawTriangles(g.bufFace, 0, g.numFace);
}//draw2dsprite
public function use2DMode(w:Number=640, h:Number=480):void
{
var g:xGeo; var c:Context3D;
g = rectGeo; c = context;
context.setProgram(prog);
setOrthoMatrix(projmat, 0, w, h, 0, 1000, -1000);
mat.identity(); mat.append(projmat);
c.setProgramConstantsFromMatrix(Context3DProgramType.VERTEX, 0, mat, true);
c.setCulling(Context3DTriangleFace.NONE);
c.setDepthTest(false, Context3DCompareMode.ALWAYS);
c.setBlendFactors(Context3DBlendFactor.SOURCE_ALPHA, Context3DBlendFactor.ONE_MINUS_SOURCE_ALPHA);
setCurTex(blankSkin);
setColor(1, 1, 1, 1);
setUv(0, 0, 1, 1);
//all rectangles use same buffer (uv set with texture matrix)
c.setVertexBufferAt(0, g.bufVert, 0, Context3DVertexBufferFormat.FLOAT_3);
c.setVertexBufferAt(1, g.bufUv, 0, Context3DVertexBufferFormat.FLOAT_2);
c.setVertexBufferAt(2, g.bufColor, 0, Context3DVertexBufferFormat.FLOAT_4);
}//set2dmode
}//xminirender
internal class xGeo
{
public var vecVert:Vector.<Number> ; public var vecUv:Vector.<Number> ; public var vecFace:Vector.<uint> ;
public var vecColor:Vector.<Number>;
public var bufVert:VertexBuffer3D; public var bufUv:VertexBuffer3D;
public var bufColor:VertexBuffer3D; public var bufFace:IndexBuffer3D;
public var numVert:int=0; public var numFace:int=0;
public function upload(c:Context3D):void
{
if (bufVert != null) { bufVert.dispose(); } if (bufUv != null) { bufUv.dispose(); }
if (bufFace != null) { bufFace.dispose(); } if (bufColor != null) { bufColor.dispose(); }
numVert = Math.floor( vecVert.length / 3); numFace = Math.floor( vecFace.length / 3);
bufVert = c.createVertexBuffer(numVert, 3); bufUv = c.createVertexBuffer(numVert, 2);
bufColor = c.createVertexBuffer(numVert, 4); bufFace = c.createIndexBuffer(numFace * 3);
bufVert.uploadFromVector(vecVert, 0, numVert);
bufUv.uploadFromVector(vecUv, 0, numVert);
bufColor.uploadFromVector(vecColor, 0, numVert);
bufFace.uploadFromVector(vecFace, 0, numFace * 3);
}//upload
public function initPlane(s:Number = 1.0):void
{
var n:Number; var pa:Number;
n = -0.5 * s; pa = 0.5 * s;
numFace = 6; numVert = 4;
vecFace = Vector.<uint>([0, 1, 2, 2, 1, 3]);
vecVert = Vector.<Number>([ n, n, 0, pa, n, 0, n, pa, 0, pa, pa, 0]);
vecUv = Vector.<Number>([0.0, 1.0, 1.0, 1.0, 0.0, 0.0, 1.0, 0.0]);
var i:int; var num:int;
num = numVert * 4;
vecColor = new Vector.<Number>(num, false);
for (i = 0; i < num; i++) { vecColor[i] = 1.0; }
}//iniplane
}//xgeo
internal class xTex
{
public var tex:Texture = null;
public static function getXor(w:int, h:int, red:Boolean=true,green:Boolean=true,blue:Boolean=true):BitmapData
{
var bm:BitmapData; var k:int; var i:int;
bm = new BitmapData(w,h,false,0);
for (i = 0; i < h; i++) { for (k = 0; k < w; k++) {
bm.setPixel(k,i, (red ? ((i^k)<<16):0) | (green ? ((i ^ k) << 8):0) | (blue ? (i^k):0)); }}
return bm;
}//getxor
private var tempMat:Matrix = new Matrix();
public function genTex(bm:BitmapData, c:Context3D):void
{
var s:int; var m:int; var tmp:BitmapData;
tex = c.createTexture(bm.width, bm.height, Context3DTextureFormat.BGRA, false);
tex.uploadFromBitmapData( bm , 0);
tempMat.identity();
m = 1; s = bm.width * 0.5;
while (s > 0)
{
tempMat.a = s / bm.width;
tempMat.d = s / bm.height;
tmp = new BitmapData(s, s, bm.transparent, 0);
tmp.draw(bm, tempMat, null, null, null, true);
tex.uploadFromBitmapData(tmp, m); m += 1; s *= 0.5;
}//wend
}//gentex
};//classend xtex
