forked from: パーリンノイズ勉強 曲線

/**
 * Copyright Maksim.Prohorchik ( http://wonderfl.net/user/Maksim.Prohorchik )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/gr9p
 */

package {

    import flash.display.Sprite;
    import flash.display.BitmapData;
    import flash.display.GraphicsPathCommand;

    public class PerlinWaves extends Sprite {
        public var n:int =32;     //     dimensions width
        public var m:int =8;    //    dimensions 'distance'
        public var depthLevel:Number = 360.0; // dimensions: y-level of the bottom floor

        //     two bitmaps: bitmapData (set,get - zdata) holds the info for the height,
        //    textureMap is the texture that is drawn ...
        private var zData:BitmapData;
        public var textureMap:BitmapData = new BitmapData(1,1,true,0xFFFFFFFF);

        private var vertices:Vector.<Number>;
        private    var indices:Vector.<int>;
        private    var uvtData:Vector.<Number>;
        private var i:int;
        private var j:int;

        public function PerlinWaves(bmp:BitmapData) {

            zData = bmp;
            n = zData.width;
            init();

            upDate();

        }

        public function set bitmapData(bmp:BitmapData):void {
            this.zData=bmp;
            upDate();
        }
        public function get bitmapData():BitmapData {
            return this.zData;
        }

        private function init():void {

            vertices = new Vector.<Number>();
            indices = new Vector.<int>();
            uvtData = new Vector.<Number>();


            for (j=0; j!=m; j++) {
                for (i=0 ; i!=n; i++) {
                    // x,y coordinates, initialize vector size
                    vertices.push(0.0, 0.0);

                    // texture mapping coordinates between 0,0 and 1,1
                    uvtData.push(i/(n-1.0),j/(m-1.0));
                }
            }

            //
            // indices for two triangles, CCW
            //
            //        ii-----ii+1
            //         |\    |
            //         | \   |
            //         |   \ |
            //         |    \|
            //        ii+n---ii+n+1

            var ii:int =0;
            for (j=0 ; j!=m-1; j++) {
                for (i=0 ; i!=n-1; i++) {
                    indices.push(ii,ii+n+1,ii+1);
                    indices.push(ii+n,ii+n+1,ii++);
                }
                ii++;
            }

        }


        private function upDate():void {

            // when the maps updated, the mesh info, e.g uvtData and indices
            // remain the same, only vertices will be updated

            var ii:int =0;
            for (j=0; j!=m;j++) {
                for (i=0 ; i!=n; i++) {

                    // x-coordinate
                    vertices[ii++]= i/(n-1); // *100.0;

                    if (j==m-1) { // y-coordinate, bottom level
                        vertices[ii++]= depthLevel;

                    } else { // y-coordinate, sampled from image's blue channel
                        vertices[ii++]= Number(zData.getPixel(i,j) & 0xFF);
                    }
                }
            }

            // draw the new graphics
            with (this.graphics) {
                clear();
                beginBitmapFill(this.textureMap);
                drawTriangles(vertices,indices,uvtData);
                endFill();
            }

        }
    }
}
