* Copyright Nowloading_ ( http://wonderfl.net/user/Nowloading_ )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/Uzrm
*/
package {
import flash.display.DisplayObject;
import org.papervision3d.materials.*;
import org.papervision3d.materials.utils.*;
import org.papervision3d.materials.special.*;
import org.papervision3d.objects.primitives.*;
import org.papervision3d.objects.*;
import org.papervision3d.view.*;
import flash.events.*;
[SWF(backgroundColor = 0x000000)]
public class mf extends BasicView {
//
//
//cube格納用オブジェクト
private var field:DisplayObject3D;
//表面用と下部用のcube
private var ucube:Cube;
private var dcube:Cube;
//cubeの縦横幅とcube間の長さ;
private var wide:int = 50;
private var dx:int = 5;
//cubeの色指定配列:color[x軸][z軸]
//数値は0=green,1=brown, 2=blueに対応
//色の指定(uColor=上部の色;dColor = 下部の色)
private var uColor:Array = [[0,0,0,1,1],
[0,0,1,2,2],
[0,1,2,2,2],
[0,1,1,2,2],
[0,0,1,2,2],
];
private var dColor:Array = [[1,1,1,1,1],
[1,1,1,1,2],
[1,1,1,2,2],
[1,1,1,1,2],
[1,1,1,2,2],
];
//各cubeの高さ
private var hCube:Array = [[6,4,2,2,3],
[4,2,1,0,0],
[2,1,0,0,0],
[3,2,2,0,0],
[4,3,3,0,0],
];
//上下cubeの高さ管理変数
private var high:int =20;
//cube用colormaterial;実際に使うのはcubeMat配列のみ
private var gr:ColorMaterial = new ColorMaterial(0x60ff60);
private var br:ColorMaterial = new ColorMaterial(0xd0a080);
private var bl:ColorMaterial = new ColorMaterial(0xd0ddff);
private var g:MaterialsList = new MaterialsList( { all:gr } );
private var l:MaterialsList = new MaterialsList( { all:br } );
private var b:MaterialsList = new MaterialsList( { all:bl } );
private var cubeMat:Array = [g,l,b];
//
//
//plane格納用オブジェクト
private var chara:DisplayObject3D;
//charaの管理配列と通し番号用変数
private var c:Array = new Array();
private var charaNo:int = 0;
private var plane:Plane;
//Plane用material;実際に使うのはplaneMat配列のみ
private var aka:WireframeMaterial = new WireframeMaterial(0xcc0000,3);
private var ao:WireframeMaterial = new WireframeMaterial(0x0000cc,3);
private var midori:WireframeMaterial = new WireframeMaterial(0x00cc00,3);
private var planeMat:Array = [aka,ao,midori];
//planeの配置;1=akaPlane,2=aoPlane,3=midoriPlane;
private var haiti:Array = [[1,0,0,0,2],
[0,1,0,0,0],
[1,0,0,0,0],
[0,0,0,0,3],
[2,2,0,0,0],
];
//
//
//radiun
private var rad:int = 0;
//
//
//土台baseと軸表示plane
private var baseColor:ColorMaterial = new ColorMaterial(0x8a5040);
private var baseMat:MaterialsList = new MaterialsList({all:baseColor});
private var base:Cube;
private var planeColor:ColorMaterial = new ColorMaterial(0xdddddd,0.2);
private var planeX:Plane;
private var planeY:Plane;
private var planeZ:Plane;
//constructer
public function mf() {
init();
}
private function init():void{
/*for(var m:int = 0;m<planeMat.length; m++){
planeMat[m].doubleSided = true;
}*/
field = new DisplayObject3D;
chara = new DisplayObject3D;
scene.addChild(field);
scene.addChild(chara);
for(var i:int = 0; i<uColor.length; i++){
for(var j:int = 0; j<uColor[0].length; j++){
//Fieldの作成
ucube = new Cube(cubeMat[uColor[i][j]],wide,wide,high/2);
dcube = new Cube(cubeMat[dColor[i][j]],wide,wide,(hCube[i][j]+1)*high);
ucube.x = dcube.x = -((wide+dx)*Math.floor(uColor.length/2)) + ((wide+dx)*i);
ucube.z = dcube.z = -((wide+dx)*Math.floor(uColor[0].length/2)) + ((wide+dx)*j);
dcube.y = ((hCube[i][j]+1)*high)/2;
ucube.y = dcube.y*2 + high/4;
field.addChild(ucube,"UC_x"+i+"z"+j);
field.addChild(dcube,"DC_x"+i+"z"+j);
//charaの追加
//ここまだ代数にしてない
if(haiti[i][j] != 0){
plane = new Plane(planeMat[haiti[i][j]-1],40,60,4,8);
plane.x = -((wide+dx)*Math.floor(uColor.length/2)) + ((wide+dx)*i);
plane.z = -((wide+dx)*Math.floor(uColor[0].length/2)) + ((wide+dx)*j);
plane.y = ucube.y + 55;
c[charaNo] = plane;
chara.addChild(c[charaNo], "CHARA_"+charaNo);
charaNo +=1;
}
}
}
//baseと軸planeの追加
base = new Cube(baseMat,(wide+dx)*uColor.length-dx,(wide+dx)*uColor[0].length-dx,10);
base.y = -high/2;
scene.addChild(base);
planeColor.doubleSided = true;
planeX = new Plane(planeColor,500,500);
planeX.rotationY = 90;
scene.addChild(planeX);
planeY = new Plane(planeColor,500,500);
planeY.rotationX = 90;
scene.addChild(planeY);
planeZ = new Plane(planeColor,500,500);
scene.addChild(planeZ);
//camera.x = 400;
camera.y = 250;
camera.z = -400;
startRendering();
addEventListener(Event.ENTER_FRAME,oEF);
}
private function oEF(e:Event):void{
camera.x = 400*Math.sin(rad*Math.PI/180);
camera.z = -400*Math.cos(rad*Math.PI/180);
for(var n:int=0;n<charaNo; n++){
c[n].rotationY = -rad;
}
rad += 2;
if ( rad>=360){
rad =0;
}
}
}
}
