forked from: 3dmap

/**
 * Copyright jmbyh521 ( http://wonderfl.net/user/jmbyh521 )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/K5Mh
 */

// forked from lizhi's 3dmap
package {
    import flash.display.Bitmap;
    import flash.display.BitmapData;
    import flash.display.GradientType;
    import flash.display.Shape;
    import flash.display.Sprite;
    import flash.display.TriangleCulling;
    import flash.events.Event;
    import flash.events.MouseEvent;
    import flash.geom.Matrix;
    import flash.geom.Matrix3D;
    import flash.geom.PerspectiveProjection;
    import flash.geom.Point;
    import flash.geom.Utils3D;
    import flash.geom.Vector3D;
    import sliz.miniui.Checkbox;
    import sliz.miniui.Silder;

    /**
     * ...
     * @author sliz http://game-develop.net/blog/
     */
    public class Test2 extends Sprite {
        private var cm:Matrix3D = new Matrix3D();
        private var cvm:Matrix3D = new Matrix3D();
        private var m:Matrix3D = new Matrix3D();
        private var vm:Matrix3D = new Matrix3D();
        private var p:PerspectiveProjection = new PerspectiveProjection();
        private var pm:Matrix3D = p.toMatrix3D();
        private var vins:Vector.<Number>;
        private var vouts:Vector.<Number> = new Vector.<Number>();
        private var uvts:Vector.<Number>;
        private var indexs:Vector.<int>;
        private var v2ds:Vector.<Number> = new Vector.<Number>();

        private var view:Shape = new Shape();
        private var bmd:BitmapData;
        private var offset:Point = new Point;

        private var uvbmd:BitmapData = new BitmapData(256, 90, false);
        private var fractal:Checkbox;
        private var base:Silder;
        private var numoctaves:Silder;
        private var hscale:Silder;
        private var wave:Checkbox;

        public function Test2(){
            bmd = new BitmapData(50, 50, false);
            indexs = new Vector.<int>();
            for (var j:int = 0; j < bmd.height - 1; j++){
                for (var i:int = 0; i < bmd.width - 1; i++){
                    var a:int = j * bmd.width + i;
                    indexs.push(a, a + 1, a + bmd.width, a + bmd.width + 1, a + bmd.width, a + 1);
                }
            }

            addEventListener(Event.ENTER_FRAME, render);
            addChild(view);
            view.x = 228;
            view.y = 228;
            addChild(new Bitmap(bmd));
            var uvimage:Bitmap = new Bitmap(uvbmd);
            addChild(uvimage);
            uvimage.x = bmd.width;
            reset();
            stage.addEventListener(MouseEvent.CLICK, reset);

            fractal = new Checkbox("fractal", 310, 0, this);
            fractal.setToggle(true);
            wave = new Checkbox("wave", 310, 20, this);
            base = new Silder(310, 40, this, "base");
            base.value = 0.3;
            numoctaves = new Silder(310, 60, this, "octaves");
            numoctaves.value = 0.5;
            hscale = new Silder(310, 80, this, "hscale");
            hscale.value = 0.5;
        }

        private function reset(e:MouseEvent = null):void {
            var pen:Shape = new Shape();
            var matr:Matrix = new Matrix();
            matr.createGradientBox(uvbmd.width, uvbmd.height);
            var c:int = 7 * Math.random();
            var colors:Array = [];
            var ratios:Array = [];
            var d:int = 0xff / c + 0.5;
            for (var i:int = 0; i < c; i++){
                var rc:uint = 0xffffff * Math.random();
                colors.push(rc, rc);
                ratios.push(d * i, Math.min(d * (i + 0.8), 0xff));
            }
            pen.graphics.beginGradientFill(GradientType.LINEAR, colors, null, ratios, matr);
            pen.graphics.drawRect(0, 0, uvbmd.width, uvbmd.height);
            uvbmd.draw(pen);
            for (i = 0; i < uvbmd.width; i++){
                var color:uint = uvbmd.getPixel(i, 0);
                for (var j:int = 1; j < uvbmd.height; j++){
                    var a:Number = (uvbmd.height - j) / uvbmd.height;
                    var r:int = (color << 8 >>> 24) * a;
                    var g:int = (color << 16 >>> 24) * a;
                    var b:int = (color << 24 >>> 24) * a;
                    uvbmd.setPixel(i, j, (r << 16) | (g << 8) | b);
                }
            }
        }

        private function render(e:Event):void {
            cm.identity();
            cm.appendTranslation(0, 0, -300);
            cm.appendRotation(70 + view.mouseY / 20, Vector3D.X_AXIS);
            cm.appendRotation(view.mouseX / 20, Vector3D.Y_AXIS);
            offset.x += view.mouseX / 400;
            offset.y += view.mouseY / 400;
            var basev:Number = base.value * 50;
            var numoctavesV:int = numoctaves.value * 5 + 1;
            var offsets:Array = [];
            var c:int = numoctavesV;
            if(wave.getToggle()){
                while (c-- > 0) {
                    if(c%2==0){
                        offsets.push(new Point(offset.x,0));
                    }else {
                        offsets.push(new Point(0,offset.y));
                    }
                }
            }else {
                while (c-- > 0){
                    offsets.push(offset);
                }
            }
            bmd.perlinNoise(basev, basev, numoctavesV, 1, false, fractal.getToggle(), 7, false, offsets);
            vins = new Vector.<Number>();
            uvts = new Vector.<Number>();
            var hscalev:Number = hscale.value;
            for (var j:int = 0; j < bmd.height; j++){
                for (var i:int = 0; i < bmd.width; i++){
                    var v:uint = bmd.getPixel(i, j) << 24 >>> 24;
                    var v2:uint = bmd.getPixel(i, j + 1) << 24 >>> 24;
                    uvts.push(v / 256, (v - v2 + 64) / 100, 0);
                    vins.push((i - bmd.width / 2) * 10, (j - bmd.height / 2) * 10, (v - 128) * hscalev);
                }
            }

            cvm.rawData = cm.rawData;
            cvm.invert();
            vm.rawData = m.rawData;
            vm.append(cvm);
            vm.transformVectors(vins, vouts);
            Utils3D.projectVectors(pm, vouts, v2ds, uvts);
            view.graphics.clear();
            view.graphics.beginBitmapFill(uvbmd);
            //view.graphics.lineStyle(0);
            view.graphics.drawTriangles(v2ds, indexs, uvts, TriangleCulling.NEGATIVE);
        }
    }
}
