forked from: HelloWorld3D 2

/**
 * Copyright hemingway ( http://wonderfl.net/user/hemingway )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/BlhL
 */

// forked from nitoyon's HelloWorld3D 2
// forked from nitoyon's HelloWorld3D
// BitmapData に描画した TextField から座標をとって
// FP10 の 3D 機能で変換して描画してみた
//-----------------------------------------------------
// 見所
// - PerspectiveProjection を初めて使ってみた
// - あとはいつも通り transformVectors やら projectVectors で。
package {
    import flash.display.*;
    import flash.events.Event;
    import flash.geom.*;
    import flash.text.*;

    [SWF(backgroundColor=0x000000)]
    public class StringParticle3 extends Sprite{
        private static const WIDTH:Number = 475;
        private static const HEIGHT:Number = 475;
        private static const F:Number = 100;
        private var points:Vector.<Number> = new Vector.<Number>();
        private var colors:Vector.<uint> = new Vector.<uint>();

        public function StringParticle3()
        {
            stage.scaleMode = "noScale";
            stage.align = "TL";

            // BitmapData にテキストを描画して座標を points に格納する
            var bmd:BitmapData = createBitmapData("HELLO WORLD");
            initParticles(bmd);

            // キャンバスを準備
            var canvas:BitmapData = new BitmapData(WIDTH, HEIGHT, false, 0x000000);
            addChild(new Bitmap(canvas));

            // FP10 用 座標変換の準備
            var xys:Vector.<Number> = new Vector.<Number>();
            var uvts:Vector.<Number> = new Vector.<Number>();
            var points2:Vector.<Number> = new Vector.<Number>();
            var mtx3d:Matrix3D = new Matrix3D();

            // 透視投影用の変換行列作成
            var proj:PerspectiveProjection = new PerspectiveProjection();
            proj.fieldOfView = 180;
            var projMat:Matrix3D = proj.toMatrix3D();

            var counter:int = 0;
            var rotX:Number = 0, rotY:Number = 0;
            addEventListener("enterFrame", function(event:Event):void{
                var targetRotateX:Number = -(mouseX - WIDTH / 2) / WIDTH * 270;
                var targetRotateY:Number = (mouseY - HEIGHT / 2) / HEIGHT * 120;
                rotX += (targetRotateX - rotX) * .1;
                rotY += (targetRotateY - rotY) * .1;

                // 角度を設定して変換する (points → points2)
                mtx3d.identity();
                mtx3d.appendScale(1, 1, Math.sin(counter / 180 * Math.PI) * 10 + 12);
                mtx3d.appendRotation(rotX, Vector3D.Y_AXIS);
                mtx3d.appendRotation(rotY, Vector3D.X_AXIS);
                mtx3d.transformVectors(points, points2);

                // BitmapData に描画する
                canvas.lock();
                canvas.fillRect(canvas.rect, 0x000000);
                for (var i:int = 0; i < points.length / 3; i++){
                    var z:Number = points2[i * 3 + 2];
                    var f:Number = F / (z + F);
                    canvas.setPixel32(points2[i * 3    ] * f + WIDTH  / 2,
                                      points2[i * 3 + 1] * f + HEIGHT / 2,
                                      colors[i]);
                }
                canvas.unlock();

                counter+=3;
            });
        }

        private static function createBitmapData(letters:String):BitmapData{
            var fmt:TextFormat = new TextFormat();
            fmt.size = 50;

            var tf:TextField = new TextField();
            tf.defaultTextFormat = fmt;
            tf.autoSize = "left";
            tf.textColor = 0xffffff;
            tf.text = letters;

            var bmd:BitmapData = new BitmapData(tf.textWidth, tf.textHeight, false, 0x000000);
            var mtx:Matrix = new Matrix();
            bmd.draw(tf, mtx);

            return bmd;
        }

        private function initParticles(bmd:BitmapData):void{
            for (var yy:int = 0; yy < bmd.height; yy++){
                for (var xx:int = 0; xx < bmd.width; xx++){
                    var c:uint = bmd.getPixel(xx, yy);
                    if (c != 0){
                        for (var zz:int = -5; zz <= 5; zz++){
                            points.push(xx - bmd.width / 2, yy - bmd.height / 2, zz);
                            colors.push(c);
                        }
                    }
                }
            }
        }
    }
}
