drawTrianglesを使ったScale9Bitmap
でもなんか微妙にズレてる
*/
package
{
import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.display.Graphics;
import flash.display.Shape;
import flash.display.Sprite;
import flash.geom.Point;
public class Scale9Bitmap_Triangles extends Sprite
{
private var g:Graphics;
private var s:Shape;
private var s9b:Scale9Bitmap;
public function Scale9Bitmap_Triangles()
{
addChild( s = new Shape() );
g = s.graphics;
s9b = new Scale9Bitmap( createBitmap(), 16,16,16,16 );
s9b.width = 96;
s9b.height = 96;
draw();
}
private function draw():void
{
g.clear();
s9b.draw( g );
/*
g.lineStyle( 0, 0xFFFF00 );
g.moveTo(16,0);
g.lineTo(16,96);
g.lineStyle( 0, 0x00FFFF );
g.moveTo(80,0);
g.lineTo(80,96);
g.moveTo(96,0);
g.lineTo(96,96);
g.lineStyle( 0, 0xFF0000 );
g.moveTo(0,80);
g.lineTo(96,80);
g.moveTo(0, 96);
g.lineTo(96,96);
//*/
}
private function createBitmap():BitmapData
{
var bd:BitmapData = new BitmapData(48,48,false,0);
var f:BitmapData = new BitmapData(16,16, false, 0xFFFFFF);
var p:Point = new Point();
bd.copyPixels( f, f.rect, p );
p.x = 16;
f.fillRect(f.rect, 0xFF0000);
bd.copyPixels( f, f.rect, p );
p.x = 32;
f.fillRect(f.rect, 0xFFFF00);
bd.copyPixels( f, f.rect, p );
p.y = 16;
p.x = 0;
f.fillRect(f.rect, 0xFF00);
bd.copyPixels( f, f.rect, p );
p.x = 16;
f.fillRect(f.rect, 0x0);
bd.copyPixels( f, f.rect, p );
p.x = 32;
f.fillRect(f.rect, 0xFF);
bd.copyPixels( f, f.rect, p );
p.y = 32;
p.x = 0;
f.fillRect(f.rect, 0xFF00FF);
bd.copyPixels( f, f.rect, p );
p.x = 16;
f.fillRect(f.rect, 0xFFFF);
bd.copyPixels( f, f.rect, p );
p.x = 32;
f.fillRect(f.rect, 0xFFFFFF);
bd.copyPixels( f, f.rect, p );
return bd;
}
}
}
import flash.display.BitmapData;
import flash.display.Graphics;
import flash.display.GraphicsBitmapFill;
import flash.display.GraphicsEndFill;
import flash.display.GraphicsTrianglePath;
import flash.display.IGraphicsData;
class Scale9Bitmap
{
private static const LT:int = 0;
private static const T:int = 12;
private static const RT:int = 24;
private static const L:int = 36;
private static const R:int = 48;
private static const LB:int = 60;
private static const B:int = 72;
private static const RB:int = 84;
private static const C:int = 96;
protected var data:Vector.<IGraphicsData>;
protected var v:Vector.<Number>;
protected var uv:Vector.<Number>;
protected var index:Vector.<int>;
protected var culculated:Boolean = false;
private var _bitmapData:BitmapData;
private var _l:Number = 0;
private var _t:Number = 0;
private var _r:Number = 0;
private var _b:Number = 0;
private var _w:int;
private var _h:int;
public function Scale9Bitmap( bitmapData:BitmapData, left:Number = 0, top:Number = 0, right:Number = 0, bottom:Number = 0)
{
_bitmapData = bitmapData;
_w = bitmapData.width;
_h = bitmapData.height;
v = new Vector.<Number>( 108, false); // ( ( 2 * 3 ) * 2 ) * 9 = 108
uv = new Vector.<Number>( 108, false );
index = new Vector.<int>( 54 , false );
for(var i:int = 0; i<54; i++) index[i] = i;
data = new Vector.<IGraphicsData>( 3, false );
data[0] = new GraphicsBitmapFill( bitmapData );
data[1] = new GraphicsTrianglePath( v, index, uv);
data[2] = new GraphicsEndFill();
setGrid( left, top, right, bottom );
}
protected function culc():void
{
culculated = true;
var iw:Number = bitmapData.width - ( left + right);
var ih:Number= bitmapData.height - ( top + bottom );
var r:Number = width - right;
var b:Number = height - bottom;
setRect( LT, 0,0, left, top);
setRect( T, left, 0, innerWidth, top);
setRect( RT, r,0, right, top);
setRect( L, 0,top, left, innerHeight );
setRect( C, left,top, innerWidth, innerHeight );
setRect( R, r,top, right, innerHeight );
setRect( LB, 0, b, left, bottom );
setRect( B, left, b, innerWidth, bottom );
setRect( RB, r,b, right, bottom );
setUV( LT, 0,0, left, top);
setUV( T, left, 0, iw, top);
setUV( RT, r,0, right, top);
setUV( L, 0,top, left, ih );
setUV( C, left,top, iw, ih );
setUV( R, r,top, right, ih );
b = bitmapData.height - bottom;
setUV( LB, 0, b, left, bottom );
setUV( B, left,b, iw, bottom );
setUV( RB, r,b, right, bottom );
}
protected function setRect( offset:int, x:Number, y:Number, width:Number, height:Number ):void
{
v[offset] = v[offset + 6] = v[offset+10] = x;
v[offset + 1] = v[offset + 3] = v[offset + 7] = y;
v[offset + 2] = v[offset + 4] = v[offset + 8] = x + width;
v[offset + 5] = v[offset + 9] = v[offset + 11] = y + height;
}
protected function setUV( offset:int, x:Number, y:Number, width:Number, height:Number ):void
{
var w:int = bitmapData.width;
var h:int = bitmapData.height;
uv[offset] = uv[offset + 6] = uv[offset+10] = x / w;
uv[offset + 1] = uv[offset + 3] = uv[offset + 7] = y / h;
uv[offset + 2] = uv[offset + 4] = uv[offset + 8] = (x + width) / w;
uv[offset + 5] = uv[offset + 9] = uv[offset + 11] = (y + height) / h;
}
public function setGrid( left:Number = 0, top:Number = 0, right:Number = 0, bottom:Number = 0 ):void
{
this.left = left;
this.top = top;
this.right = right;
this.bottom = bottom;
}
public function get bitmapData():BitmapData
{
return _bitmapData;
}
public function set bitmapData( value:BitmapData ):void
{
_bitmapData = value;
(data[0] as GraphicsBitmapFill).bitmapData = value;
}
public function get left():Number
{
return _l;
}
public function set left( value:Number ):void
{
_l = value < 0 ? 0 : value;
culculated = false;
}
public function get right():Number
{
return _r;
}
public function set right( value:Number ):void
{
_r = value < 0 ? 0 : value;
culculated = false;
}
public function get top():Number
{
return _t;
}
public function set top( value:Number ):void
{
_t = value < 0 ? 0 : value;
culculated = false;
}
public function get bottom():Number
{
return _b;
}
public function set bottom( value:Number ):void
{
_b = value < 0 ? 0 : value;
culculated = false;
}
public function get innerWidth():Number
{
return width - ( left + right );
}
public function get innerHeight():Number
{
return height - ( top + bottom );
}
public function get width():int
{
return _w;
}
public function set width( value:int ):void
{
_w = value < (left + right) ? (left+right) : value;
culculated = false;
}
public function get height():int
{
return _h;
}
public function set height( value:int ):void
{
_h = value < (left + right) ? (left+right) : value;
culculated = false;
}
public function draw( graphics:Graphics ):void
{
if( culculated == false ) culc();
graphics.drawGraphicsData( data );
}
}
