01_15_RenderingTriangles

/**
 * Copyright amashio ( http://wonderfl.net/user/amashio )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/8BGc
 */

package{

    import flash.display.Sprite;
    import flash.display.Bitmap;
    import flash.display.BitmapData;
    import flash.display.Loader;
    import flash.display.LoaderInfo;
    import flash.events.Event;
    import flash.events.MouseEvent;
    import flash.net.URLRequest;
    import flash.text.TextField;
    import flash.system.Security;

    public class Main extends Sprite{

        private var _anchors:Vector.<Sprite>;
        private var _anchor:Sprite;
        private var _anchorIndex:uint;
        private var _vertices:Vector.<Number>;
        private var _indices:Vector.<int>;
        private var _uvtData:Vector.<Number>;
        private var _image:BitmapData;

        public function Main(){
            loadImage();
        }

        private function loadImage():void{
            //Security.loadPolicyFile("http://5ivestar.org/proxy/crossdomain.xml");
            var loader:Loader = new Loader();
            loader.contentLoaderInfo.addEventListener(Event.COMPLETE, onImageLoaded);
            //loader.load(new URLRequest("http://5ivestar.org/proxy/http://amashio.com/wonderfl/15_RenderingTriangles/footprints.jpg"));
            loader.load(new URLRequest("http://assets.wonderfl.net/images/related_images/e/e0/e0cf/e0cf8ee7ba2ec3781d2a28710adf1e7d94ccfbfe"));
        }

        private function defineTriangles():void{
            var border:Number = 50;
            var width:Number = stage.stageWidth;
            var height:Number = stage.stageHeight;

            _anchors = new Vector.<Sprite>();
            addAnchor(border, border);
            addAnchor(width-border, border);
            addAnchor(width/2, height/2);
            addAnchor(border, height-border);
            addAnchor(width-border, height-border);

            _vertices = new Vector.<Number>();
            for each(var anchor:Sprite in _anchors){
                _vertices.push(anchor.x, anchor.y);
            }

            _indices = new Vector.<int>();
            _indices.push(1, 0, 2);
            _indices.push(0, 2, 3);
            _indices.push(1, 2, 4);
            _indices.push(2, 3, 4);

            _uvtData = new Vector.<Number>();
            _uvtData.push(0, 0);
            _uvtData.push(1, 0);
            _uvtData.push(0.5, 0,5);
            _uvtData.push(0, 1);
            _uvtData.push(1, 1);
        }

        private function addAnchor(x:Number, y:Number):void{
            var anchor:Sprite = new Sprite();
            anchor.graphics.lineStyle(20);
            anchor.graphics.lineTo(1, 0);
            anchor.addEventListener(MouseEvent.MOUSE_DOWN, onAnchorDown);
            anchor.addEventListener(MouseEvent.MOUSE_UP, onAnchorUp);
            anchor.x = x;
            anchor.y = y;
            var label:TextField = new TextField();
            label.x = -4;
            label.y = -9;
            label.mouseEnabled = false;
            label.textColor = 0xFFFFFF;
            label.text = String(_anchors.length);
            anchor.addChild(label);
            addChild(anchor);
            _anchors.push(anchor);
        }

        private function draw():void{
            graphics.clear();
            graphics.beginBitmapFill(_image);
            graphics.drawTriangles(_vertices, _indices, _uvtData);
            graphics.endFill();
        }

        private function onAnchorDown(event:MouseEvent):void{
            _anchor = event.target as Sprite;
            _anchor.startDrag();
            _anchorIndex = _anchors.indexOf(_anchor);
            stage.addEventListener(MouseEvent.MOUSE_MOVE, onAnchorMove);
        }

        private function onAnchorMove(event:MouseEvent):void{
            _vertices[_anchorIndex*2] = _anchor.x;
            _vertices[_anchorIndex*2+1] = _anchor.y;
            draw();
            event.updateAfterEvent();
        }

        private function onAnchorUp(event:MouseEvent):void{
            if(_anchor){
                _anchor.stopDrag();
                stage.removeEventListener(MouseEvent.MOUSE_MOVE, onAnchorMove);
            }
        }

        private function onImageLoaded(event:Event):void{
            var loaderInfo:LoaderInfo = event.target as LoaderInfo;
            var bitmap:Bitmap = loaderInfo.content as Bitmap;
            _image = bitmap.bitmapData;
            defineTriangles();
            draw();
        }
    }
}
