forked from: Smooth Moving with Catmull-Rom splines

/**
 * Copyright aobyrne ( http://wonderfl.net/user/aobyrne )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/7Hjq
 */

package {
    import flash.text.engine.TextBlock;
    import flash.display.Sprite;
    import flash.geom.Point;
    import flash.text.*
    import flash.events.MouseEvent;
    import flash.events.Event;


    public class CatmulTest extends Sprite {
            private var titleText:TextField;
            private var spot:Vector.<Point>;

            private var moveBall:Sprite;
            private var currentSpot:int = 0;
            private var time:int = 0;
            private var reserBtn:Sprite;
            private var yy:Number;
        public function CatmulTest() {
            // write as3 code here..
            createTextTitle();
            stage.addEventListener(MouseEvent.CLICK , putPoint );
            resetPoints();
            makeBall();
            addEventListener(Event.ENTER_FRAME, animation);
            makeResetBtn();
        }
        private function putPoint(e:MouseEvent):void{
                if ( !reserBtn.hitTestPoint(e.stageX , e.stageY)  )
                {
                    setPoint(e.stageX,e.stageY);

                    if(spot.length == 3){
                        makeBall();
                        this.addEventListener(Event.ENTER_FRAME , animation );
                    }
                }
        }
        private function makeBall():void{
                moveBall = new Sprite();
                addChild(moveBall);
                moveBall.graphics.beginFill(0xFFCC00 , 0.5 );
                moveBall.graphics.drawCircle(0,0,20);
                moveBall.x = spot[0].x;
                moveBall.y = spot[0].y;
        }
        private function animation(e:Event):void{
                    var p0:Point = spot [(currentSpot-1 + spot.length) % spot.length];
                var p1:Point = spot[currentSpot ];
                var p2:Point = spot [(currentSpot  +1 + spot.length) % spot.length];
                var p3:Point = spot[(currentSpot  +2 + spot.length) % spot.length];


                var pointSpot:Point = spline (p0, p1, p2, p3, 0.01 * time);
                moveBall.x = pointSpot.x;
                moveBall.y = pointSpot.y;
                time+=2;
                if(time == 100){
                    time=0;
                    currentSpot++;
                    if(currentSpot > spot.length-1){
                        currentSpot = 0;
                    }
                }
        }
        private function createTextTitle():void{
                titleText = new TextField();
               addChild(titleText);
               titleText.text = "Click to add more points";
               titleText.selectable = false;
               titleText.autoSize = TextFieldAutoSize.LEFT;
               var tf:TextFormat = new TextFormat();
               tf.size = 20;
               tf.font = "Verdana";
               tf.color = 0x555555;
               titleText.setTextFormat(tf);
               titleText.x = (stage.stageWidth/2)-(titleText.width/2);
               titleText.y = (stage.stageHeight/2)-(titleText.height/2);
            }
        private function spline (p0:Point, p1:Point, p2:Point, p3:Point, t:Number):Point
        {
            return new Point (
                0.5 * ((          2*p1.x) +
                    t * (( -p0.x           +p2.x) +
                    t * ((2*p0.x -5*p1.x +4*p2.x -p3.x) +
                    t * (  -p0.x +3*p1.x -3*p2.x +p3.x)))),
                0.5 * ((          2*p1.y) +
                    t * (( -p0.y           +p2.y) +
                    t * ((2*p0.y -5*p1.y +4*p2.y -p3.y) +
                    t * (  -p0.y +3*p1.y -3*p2.y +p3.y))))
            );
        }
        private function makeResetBtn():void{
                reserBtn = new Sprite();
                var labelTxt:TextField  = new TextField();
                addChild(reserBtn);
                reserBtn.addChild(labelTxt);
                labelTxt.text ="Click Here To Reset";
                labelTxt.autoSize = TextFieldAutoSize.LEFT;
                reserBtn.graphics.beginFill(0x00CCFF , 0.5 );
                reserBtn.graphics.drawRect( 0 , 0, labelTxt.width , labelTxt.height );
                labelTxt.selectable = false;
                reserBtn.addEventListener(MouseEvent.CLICK , reset );
                reserBtn.buttonMode = true;
        }
        private function reset(e:MouseEvent):void{
            this.removeEventListener(Event.ENTER_FRAME , animation );
            removeChild(moveBall);
            moveBall = null;
            spot = new Vector.<Point>();
            this.graphics.clear();
            resetPoints();
            makeBall();
            addEventListener(Event.ENTER_FRAME, animation);
        }

        private function setPoint(xx:Number,yy:Number):void
        {
            spot.push(new Point(xx , yy));
            this.graphics.clear();
                for (var i:int = 0; i < spot.length; i++) {
                    this.graphics.beginFill(0xFF0000 , 1 );
                    this.graphics.drawCircle(spot[i].x , spot[i].y ,3);
                     this.graphics.endFill();

                var p0:Point = spot [(i -1 + spot.length) % spot.length];
                var p1:Point = spot[i];
                var p2:Point = spot [(i +1 + spot.length) % spot.length];
                var p3:Point = spot[(i +2 + spot.length) % spot.length];

                this.graphics.lineStyle(1,0x00FF00 , 0.3 );
                     this.graphics.moveTo(p2.x , p2.y );
                     this.graphics.lineTo(p3.x , p3.y);

                this.graphics.lineStyle (0, 0x7FFF);
                this.graphics.moveTo (p1.x, p1.y);
                for (var j:int = 1; j < 101; j++) {
                    var q:Point = spline (p0, p1, p2, p3, 0.01 * j);
                    this.graphics.lineTo (q.x, q.y);
                }
                this.graphics.lineStyle ();
                this.graphics.endFill ();
            }
        }

        private function resetPoints():void
        {
            spot = new Vector.<Point>();
            for (var i:int = 0; i < 10; i++)
            {
                setPoint(20+Math.random()*400,20+Math.random()*400)
            }
        }
    }
}
