FakeCurve

/**
 * Copyright faseer ( http://wonderfl.net/user/faseer )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/6w0N
 */

package
{
    import flash.display.Sprite;
    import flash.events.MouseEvent;
    import flash.geom.Point;

    public class FakeCurve extends Sprite
    {
        private const numVertices:int = 10;
        private const segWidth:Number = 5.0;
        private const minWidth:Number = 5 * segWidth;
        private const maxWidth:Number = 20 * segWidth;
        private const vHeight:Number = 120;
        private const startX:Number = 2;
        private const startY:Number = 200;

        private const bgc:int = 0x000000;
        private const lineClr:int = 0x6666ff;
        private const curveClr:int = 0xffaaaa;

        private var vertices:Vector.<Point> = new Vector.<Point>( numVertices, true );
        private var segments:Vector.<Point> = new Vector.<Point>;
        private var canvas:Sprite = new Sprite();

        public function FakeCurve()
        {
            init();
            refresh();
        }

        private function init():void
        {
            graphics.beginFill( bgc );
            graphics.drawRect( 0,0, stage.stageWidth, stage.stageHeight );
            graphics.endFill();

            addChild( canvas );

            stage.addEventListener( MouseEvent.CLICK, refresh );
        }

        private function refresh( e:MouseEvent = null ):void
        {
            createVertices();
            segmentVertices();
            drawLines();
        }

        private function createVertices():void
        {
            var x:Number = startX,
                y:Number,
                i:int;

            for( i = 0; i < numVertices; ++i )
            {
                x = x + minWidth + Math.random() * ( maxWidth - minWidth );
                y = startY + Math.random() * vHeight * (i&1 ? 1 : -1);
                vertices[i] = new Point( x, y );
            }
        }

        private function segmentVertices():void
        {
            var i:int, j:int,
                w:Number,  h:Number,
                sx:Number, sy:Number,
                seg:int,
                dx:Number,
                da:Number,
                x:Number,  y:Number;

            segments.length = 0;

            for( i = 1; i < numVertices; ++i )
            {
                sx = vertices[ i-1 ].x;
                sy = vertices[ i-1 ].y;
                w  = vertices[  i  ].x - sx;
                h  = vertices[  i  ].y - sy;

                seg = w / segWidth;
                dx  = w / seg;
                da  = Math.PI / seg;

                // skip the lastest vertex which lapped the first vertex of next segment
                for( j = 0; j < seg - 1; ++j )
                {
                    x = sx + dx * j;
                    y = sy + h * ( 1 - Math.cos(da * j) ) * .5;

                    segments.push( new Point( x, y ) );
                }
            }

            // add the lastest vertex
            segments.push( new Point( vertices[ i-1 ].x, vertices[ i-1 ].y ) );
        }

        private function drawLines():void
        {
            var i:int;

            canvas.graphics.clear();

            // draw origin vertices
            canvas.graphics.lineStyle( 1, lineClr );
            canvas.graphics.moveTo( vertices[0].x, vertices[0].y );
            for( i = 1; i < numVertices; ++i )
            {
                canvas.graphics.lineTo( vertices[i].x, vertices[i].y );
            }
            // draw segments to fake curve
            canvas.graphics.lineStyle( 1.5, curveClr );
            canvas.graphics.moveTo( segments[0].x, segments[0].y );
            for( i = 1; i < segments.length; ++i )
            {
                canvas.graphics.lineTo( segments[i].x, segments[i].y );
            }
        }
    }
}
