forked from: RoundPolygon

/**
 * Copyright aobyrne ( http://wonderfl.net/user/aobyrne )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/6rp9
 */

// forked from 178ep3's RoundPolygon
//        drawRoundPolygon( Graphics , 丸みレベル(0～10) , 直径 , 角数);
//        7角形が何か変だ。。　>>>凡ミスでした。 uwiさんのナイスな指摘で解決。
//        丸みレベルは、　0で丸み無し、　10で完全に丸(10だと何か変)
//        普通の多角形なら drawPolygon( Graphics , 直径 , 角数);
package
{
    import flash.display.*;

    public class TejidoHexagonal extends Sprite
    {
        static private const HEXAGON:int = 6;

        public function TejidoHexagonal()
        {
            var i:uint=0;
            var q:uint=0;
            for(i=0; i<3; i++)
            {
                for(q=0; q<3; q++)
                {
//                    塗りや線を設定して
                    graphics.beginFill(Math.random()*0xffffff);
//                    PolygonクラスのdrawRoundPolygonに設定を渡す
                    Polygon.drawRoundPolygon(graphics,5,60,i*3+q+3,75 + q*150,75 + i*150);
                }
            }
            var pRadius:Number = 100;
            var roundnessRadius:Number = 5;
            var sprite:Sprite = addChild(new Sprite) as Sprite;
            sprite.graphics.beginFill(0xff77);
            Polygon.drawRoundPolygon(sprite.graphics, roundnessRadius, pRadius, HEXAGON);
            sprite.x = pRadius;
            sprite.y = pRadius;
            var sopas:Sprite = addChild(new Sprite) as Sprite;
            var g:Graphics = sopas.graphics;
            g.lineStyle(2);
            g.drawRect(0, 0, 2 * pRadius, 2 * pRadius);
            var shape:Shape = addChild(new Shape) as Shape;
            shape.graphics.lineStyle(0);
            Polygon.drawPolygon(shape.graphics, pRadius, HEXAGON);
            shape.x = pRadius;
            shape.y = pRadius;

        }

    }

}
import flash.display.*;
import flash.geom.*;



class Polygon
{
    public function Polygon(){}

    public static function drawPolygon(target:Graphics, radius:Number, polygon:uint, cx:Number=0, cy:Number=0):void
    {
        var list:Array = getPoints(radius,polygon,cx,cy);
        var i:uint=0;
        var len:uint = list.length;

        target.moveTo(list[0].x,list[0].y);
        for(i=1; i<len; i++)
        {
            target.lineTo(list[i].x,list[i].y);
        }
        target.lineTo(list[0].x,list[0].y);
        target.endFill();
    }

    public static function drawRoundPolygon(target:Graphics,round:uint,radius:Number,polygon:uint,cx:Number=0, cy:Number=0):void
    {
        var con:Array = getPoints(radius,polygon,cx,cy);
        var anc:Array = [];
        var i:uint=0;
        if(round>10)round=10;
        var n:Number = round/20;
        var cLen:uint = con.length;

        for(i=0; i<cLen; i++)
        {
            var p:Point = new Point(0,0);
            var q:Point = new Point(0,0);
            if(i==0)
            {
                p = Point.interpolate(con[cLen-1],con[0],n);
                q = Point.interpolate(con[1],con[0],n);
            }
            else if(i==cLen-1)
            {
                p = Point.interpolate(con[i-1],con[i],n);
                q = Point.interpolate(con[0],con[i],n);
            }
            else
            {
                p = Point.interpolate(con[i-1],con[i],n);
                q = Point.interpolate(con[i+1],con[i],n);
            }
            anc.push(p);
            anc.push(q);
        }

        var len:uint = anc.length;
        target.moveTo(anc[0].x,anc[0].y);
        for(i=1; i<len-2; i+=2)
        {
            target.curveTo(con[(i-1)/2].x,con[(i-1)/2].y,anc[i].x,anc[i].y);
            target.lineTo(anc[i+1].x,anc[i+1].y);
        }
        target.curveTo(con[cLen-1].x,con[cLen-1].y,anc[len-1].x,anc[len-1].y);
        target.lineTo(anc[0].x,anc[0].y);
        target.endFill();
    }

    private static function getPoints(radius:Number, polygon:uint, cx:Number=0, cy:Number=0):Array
    {
        var list:Array = [];
        var angle:Number = 360/polygon;
        var i:Number=0;
        for(i=0; i<360; i+=angle)
        {
            var p:Point = Point.polar(radius, i * Math.PI / 180);
            p=p.add(new Point(cx, cy));
            list.push(p);
        }
        return list
    }
}
