forked from: Random Grid Cell Sizing

/**
 * Copyright hacker_rs10vazy ( http://wonderfl.net/user/hacker_rs10vazy )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/6CbF
 */

// forked from FTMSuperfly's Random Grid Cell Sizing
package
{
    import com.greensock.TweenMax;
    import flash.display.MovieClip;
    import flash.display.Sprite;
    import flash.display.StageAlign;
    import flash.display.StageScaleMode;
    import flash.events.Event;

    /**
     * ...
     * @author J
     */
    public class DaGrid extends Sprite
    {
        public var stageWidth:int;
        public var stageHeight:int;
        public var gridWidth:Number;//All the dimensions of your pictures must be factors of gridWidth
        public var gridColumns:int;
        public var gridRows:int;
        public var numVariants:int; // How many different sizes of square?

        public var container:Sprite;
        public var pictureGrid:Array;//keeps track of what grid cells are taken by previous placement of pictures

        public var arrayOfPictures:Array; // this just creates some random pictures and adds them to the array. In reality you would create your own array of pictures.


        public function DaGrid()
        {
            /*This picture placement is an original work and protected under creative commons license
            *All use of this work including forks, edits, changes or derivitives must be credited to:
            *
            *    www.shaedo.com
            *
            */
            stage.align = StageAlign.TOP_LEFT;
            stage.scaleMode = StageScaleMode.NO_SCALE;

            stageWidth = stage.stageWidth;
            stageHeight = stage.stageHeight;
            gridWidth = 20;//All the dimensions of your pictures must be factors of gridWidth
            gridColumns = stageWidth / gridWidth;
            gridRows = stageHeight / gridWidth;
            numVariants = 10; // How many different sizes of square?

            container = new Sprite();
            addChild(container);

            pictureGrid = createGrid();//keeps track of what grid cells are taken by previous placement of pictures

            //draw a grid to demonstrate how the pictures will be layed down.
            //each grid square is gridWidth * gridWidth
            //The grid of course is just so you can see visually as it happens.

            drawGrid(false);

            // Matt: Made the number of pictures created a function of the grid size - approx!
            // this just creates some random pictures and adds them to the array. In reality you would create your own array of pictures.
            arrayOfPictures = createPictures(gridColumns * gridRows);

            addPictures(arrayOfPictures);

            var m:MovieClip;
            var i:int;

            for (i = 0; i < arrayOfPictures.length; i++)
            {
                m = arrayOfPictures[i];
                m.x = m.targetX;
                m.y = m.targetY;
            }

            stage.addEventListener(Event.RESIZE, onResizeHandler, false, 0, true);
            stage.dispatchEvent(new Event(Event.RESIZE));

            for (i = 0; i < arrayOfPictures.length; i++)
            {
                TweenMax.from( arrayOfPictures[i], 1, { alpha:0, delay:Math.random() } );
            }
        }

        private function onResizeHandler(e:Event):void
        {
            container.x = (stage.stageWidth * 0.5) - (container.width * 0.5);
            container.y = (stage.stageHeight * 0.5) - (container.height * 0.5);
        }



        public function createGrid():Array // this creates a grid that keeps track of what cells have been already occupied by previous pictures
        {
            var a:Array = new Array();
            var b:Array;
            for (var i:int = 0; i < gridColumns; i++)
            {
                b = new Array();
                for (var j:int = 0; j < gridRows; j++)
                {
                    b.push(false);//false indicates that the grid square is not yet taken
                }
                b.push(true);// This creates a cap at the end of the COLUMN to prevent pictures being placed off the edge
                a.push(b);
            }

            b = new Array();// This creates a cap at the end of the ROW to prevent pictures being placed off the edge
            for (var k:int = 0; k < gridRows; k++)
            {
                b.push(true);//false indicates that the grid square is not yet taken
            }
            a.push(b);

            return(a);
        }

        // iterate through the grid, check for an empty grid square, check if adjacent grid squares for size of picture are unoccupied, set the pictures target coordinates
        public function addPictures(picArray:Array):void
        {
            for(var i:int=0;i<picArray.length;i++)
            //run through each picture
            {
                var m:MovieClip = picArray[i];

                searchLoop: for (var r:int = 0; r < gridRows; r++)
                //run through each row
                {
                    for (var c:int = 0; c < gridColumns; c++)
                    //run through each column
                    {
                        if (pictureGrid[c][r] == false)
                        //if the current square is unoccupied
                        {
                            // Matt: iterate through adjacent grid squares and check if available
                            var safe:Boolean = true;
                            for (var x:int = 0; x < m.gridSquares * 3; x++)
                            {
                                for (var y:int = 0; y < m.gridSquares * 2; y++)
                                {
                                    if (pictureGrid[c + x][r + y] == true)
                                    {
                                        safe = false;
                                        break; // from the "for y" loop
                                    }
                                }
                                if (safe==false) {break} // from the "for x" loop
                            }

                            if (safe==true) // Matt: Probably a better way to pass the exit status of the for loops than this, but since I don't know AS...
                            {
                                m.targetX = c * gridWidth;
                                m.targetY = r * gridWidth;
                                container.addChild(m);

                                for (x = 0; x < m.gridSquares * 3; x++)
                                {
                                    for (y = 0; y < m.gridSquares * 2; y++)
                                    {
                                        pictureGrid[c + x][r + y] = true; //Mark grid squares as occupied.
                                    }
                                }

                                break searchLoop;//from the switch statement
                            }
                        }
                    }
                }
            }
        }

        public function createPictures(n:int=30):Array
        {
            var a:Array = new Array();
            for (var i:int = 0; i < n; i++)
            {
                var r:int = Math.random() * numVariants + 1; // random
                var c:int = Math.random() * numVariants + 1; // control
                var d:int = Math.random() * 1 + 1; // horizonal or vertical
                if (r <= c)
                // make less squares the bigger they are.
                {
                    var rectX:int = gridWidth * r * 3 - 1;
                    var rectY:int = gridWidth * r * 2 - 1;
                    var m:MovieClip = new MovieClip();
                    m.graphics.beginFill(Math.random() * 0xFFFFFF);
                    m.graphics.drawRect(0, 0, rectX, rectY);
                    m.gridSquares = r;
                    a.push(m);
                }
            }
            return(a);
        }

        public function drawGrid(value:Boolean = true):void
        {
        // Matt: Removed: var columns:int = 11; var rows:int = 8; var sizeParam:Number = 50;
        // Matt: Using gridColumns; gridRows; gridWidth; instead.

            if (value)
            {
                var i:int;
                var _grid:Sprite = new Sprite();
                container.addChild(_grid);
                _grid.graphics.lineStyle(2,0xDDDDDD);//what ever colour you want

                for (i = 0; i < gridColumns+1; i ++)//draws columns
                {
                    _grid.graphics.moveTo(i * gridWidth, 0);
                    _grid.graphics.lineTo(i * gridWidth, gridRows * gridWidth);
                }
                for (i= 0; i < gridRows +1; i ++)//draws rows
                {
                    _grid.graphics.moveTo(0, i * gridWidth);
                    _grid.graphics.lineTo(gridColumns * gridWidth, i * gridWidth);
                }

            }
        }





    }

}
