* Copyright greentec ( http://wonderfl.net/user/greentec )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/6BLt
*/
package {
import com.bit101.components.Label;
import com.bit101.components.NumericStepper;
import com.bit101.components.PushButton;
import com.bit101.components.Window;
import flash.display.Sprite;
import flash.events.Event;
import flash.events.MouseEvent;
import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.geom.ColorTransform;
import flash.geom.Matrix;
import com.bit101.charts.LineChart;
public class FlashTest extends Sprite {
public var problemN:int = 12;
public var fitnessMax:int = problemN * problemN;
public var prevBestFitness:int = 0;
public var bestFitness:int = 0;
public var fitnessLineChart:LineChart;
public var fitnessLineChartLabel:Label;
public var chartRefreshCycle:int = 50;
public var bestFitnessLineChart:LineChart;
public var bestFitnessLineChartLabel:Label;
public var bestData:Array = [];
public var tile_width:int = 30;
public var tile_height:int = 30;
public var board_width:int = tile_width * problemN;
public var queenSize:int = 30;
public var tileBitmapData:BitmapData;
public var tileBitmap:Bitmap;
public var gridSprite:Sprite;
public var queenBitmapData:BitmapData;
public var queenBitmap:Bitmap;
public var queenSprite:Sprite;
public var generationNo:int = 0;
public var endGenerationNo:int = 10000;
public var populationNum:int = 50;
public var population:Vector.<Vector.<int>>=new Vector.<Vector.<int>>(populationNum);
public var populationScore:Vector.<int> = new Vector.<int>(populationNum);
public var selectionExpect:Vector.<int>;
public var queenGraphic:Sprite;
public var eliteRate:Number = 0.05;
public var parentRate:Number = 0.4;
public var mutationRate:Number = 0.03;
public var redQueenColt:ColorTransform;
public var uiWindow:Window;
public var startButton:PushButton;
public var stopButton:PushButton;
public var resetButton:PushButton;
public var titleLabel:Label;
public var generationLabel:Label;
public var fitnessLabel:Label;
public var nLabel:Label;
public var nNumericStepper:NumericStepper;
public var populationLabel:Label;
public var populationNumericStepper:NumericStepper;
public var parentLabel:Label;
public var parentNumericStepper:NumericStepper;
public var mutationLabel:Label;
public var mutationNumericStepper:NumericStepper;
public var boardMaxWidthLabel:Label;
public var boardMaxWidthNumericStepper:NumericStepper;
public var graphWindow:Window;
public function FlashTest() {
// write as3 code here..
if (stage) init();
else addEventListener(Event.ADDED_TO_STAGE, init);
}
private function init(e:Event = null):void
{
removeEventListener(Event.ADDED_TO_STAGE, init);
// entry point
stage.scaleMode = "noScale";
tileBitmapData = new BitmapData(465, 465, true, 0x00ffffff);
gridSprite = new Sprite();
tileBitmap = new Bitmap(tileBitmapData);
addChild(tileBitmap);
initTileGrid(problemN, problemN);
initPopulation(populationNum, problemN);
queenBitmapData = new BitmapData(465, 465, true, 0x00ffffff);
queenBitmap = new Bitmap(queenBitmapData);
addChild(queenBitmap);
queenGraphic = new Sprite();
with (queenGraphic.graphics)
{
lineStyle(0, 0x000000);
beginFill(0x000000);
drawCircle(0, -12, 2);
drawCircle(5, -10, 2);
drawCircle(10, -8, 2);
drawCircle(-5, -10, 2);
drawCircle(-10, -8, 2);
moveTo( -8, 0);
lineTo( -10, -8);
lineTo( -5, 0);
lineTo( -5, -10);
lineTo( -2, 0);
lineTo( 0, -12);
lineTo( 2, 0);
lineTo( 5, -10);
lineTo( 5, 0);
lineTo( 10, -8);
lineTo( 8, 0);
lineTo( 6, 2);
lineTo( 5, 5);
lineTo( 8, 10);
lineTo( -8, 10);
lineTo( -5, 5);
lineTo( -6, 2);
lineTo( -8, 0);
endFill();
lineStyle(1, 0xffffff);
moveTo(-4, 5);
lineTo(4, 5);
moveTo( -5, 2);
lineTo(5, 2);
}
redQueenColt = new ColorTransform(0.5, 0.5, 0.5, 1, 255, 0, 0, 0);
uiWindow = new Window(this, 300, 10, "Control");
uiWindow.width = 150;
uiWindow.height = 250;
uiWindow.hasMinimizeButton = true;
uiWindow.alpha = 0.7;
startButton = new PushButton(uiWindow, 10, 30, "Start", onStart);
startButton.width = 43;
startButton.height = 40;
stopButton = new PushButton(uiWindow, startButton.x + startButton.width, startButton.y, "Stop", onStop);
stopButton.width = 43;
stopButton.height = 40;
resetButton = new PushButton(uiWindow, stopButton.x + stopButton.width, stopButton.y, "Reset", onReset);
resetButton.width = 43;
resetButton.height = 40;
titleLabel = new Label(uiWindow, 10, startButton.y + startButton.height, "N-Queen Solver - with GA");
generationLabel = new Label(uiWindow, 10, titleLabel.y + titleLabel.height, "Generation : " + String(generationNo) + " / " + String(endGenerationNo));
fitnessLabel = new Label(uiWindow, 10, generationLabel.y + generationLabel.height, "Best Fit. : " + String(bestFitness));
nLabel = new Label(uiWindow, 10, fitnessLabel.y + fitnessLabel.height, "N");
nNumericStepper = new NumericStepper(uiWindow, uiWindow.width - 90, nLabel.y);
nNumericStepper.step = 1;
nNumericStepper.width = 80;
nNumericStepper.minimum = 2;
nNumericStepper.maximum = 50;
nNumericStepper.value = problemN;
//nNumericStepper.enabled = false;
populationLabel = new Label(uiWindow, 10, nLabel.y + nLabel.height, "Population");
populationNumericStepper = new NumericStepper(uiWindow, uiWindow.width - 90, populationLabel.y);
populationNumericStepper.width = 80;
populationNumericStepper.value = populationNum;
populationNumericStepper.step = 50;
populationNumericStepper.minimum = 50;
parentLabel = new Label(uiWindow, 10, populationLabel.y + populationLabel.height, "Parent %");
parentNumericStepper = new NumericStepper(uiWindow, uiWindow.width - 90, parentLabel.y);
parentNumericStepper.width = 80;
parentNumericStepper.value = parentRate * 100;
parentNumericStepper.step = 5;
parentNumericStepper.minimum = 10;
mutationLabel = new Label(uiWindow, 10, parentLabel.y + parentLabel.height, "Mutation %");
mutationNumericStepper = new NumericStepper(uiWindow, uiWindow.width - 90, mutationLabel.y, onChangeValue);
mutationNumericStepper.name = "mu";
mutationNumericStepper.width = 80;
mutationNumericStepper.value = mutationRate * 100;
mutationNumericStepper.step = 0.5;
mutationNumericStepper.minimum = 0;
boardMaxWidthLabel = new Label(uiWindow, 10, mutationLabel.y + mutationLabel.height, "Board Max");
boardMaxWidthNumericStepper = new NumericStepper(uiWindow, uiWindow.width - 90, boardMaxWidthLabel.y);
boardMaxWidthNumericStepper.width = 80;
boardMaxWidthNumericStepper.value = problemN * tile_width;
boardMaxWidthNumericStepper.step = 20;
boardMaxWidthNumericStepper.minimum = 200;
boardMaxWidthNumericStepper.maximum = 460;
graphWindow = new Window(this, 5, 300, "Graph");
graphWindow.width = 455;
graphWindow.height = 150;
graphWindow.hasMinimizeButton = true;
graphWindow.alpha = 0.7;
fitnessLineChart = new LineChart(graphWindow, 40, 40, null);
fitnessLineChart.showGrid = true;
fitnessLineChart.showScaleLabels = true;
fitnessLineChart.lineColor = 0xff0080;
fitnessLineChart.width = 170;
fitnessLineChartLabel = new Label(graphWindow, 10, fitnessLineChart.y - 20, "All Population Fitness");
fitnessLineChartLabel.x = fitnessLineChart.x;
fitnessLineChart.autoScale = false;
fitnessLineChart.maximum = fitnessMax;
fitnessLineChart.minimum = -1 * fitnessMax;
bestFitnessLineChart = new LineChart(graphWindow, fitnessLineChart.x + fitnessLineChart.width + 50 + 5, fitnessLineChart.y, null);
bestFitnessLineChart.showGrid = true;
bestFitnessLineChart.showScaleLabels = true;
bestFitnessLineChart.lineColor = 0x00ff00;
bestFitnessLineChart.width = 170;
bestFitnessLineChartLabel = new Label(graphWindow, 10, bestFitnessLineChart.y - 20, "Best Population Fitness");
bestFitnessLineChartLabel.x = bestFitnessLineChart.x;
bestFitnessLineChart.autoScale = false;
bestFitnessLineChart.maximum = fitnessMax;
bestFitnessLineChart.minimum = 0;
}
private function onChangeValue(e:Event):void
{
switch(e.target.name)
{
case "mu": //mutation
mutationRate = e.target.value / 100;
break;
}
}
private function onStart(e:Event):void
{
addEventListener(Event.ENTER_FRAME, onLoop);
startButton.enabled = false;
stopButton.enabled = true;
resetButton.enabled = false;
nNumericStepper.enabled = false;
populationNumericStepper.enabled = false;
parentNumericStepper.enabled = false;
}
private function onStop(e:Event):void
{
removeEventListener(Event.ENTER_FRAME, onLoop);
stopButton.enabled = false;
startButton.enabled = true;
resetButton.enabled = true;
nNumericStepper.enabled = true;
populationNumericStepper.enabled = true;
parentNumericStepper.enabled = true;
}
private function onReset(e:Event):void
{
problemN = nNumericStepper.value;
fitnessMax = problemN * problemN;
board_width = boardMaxWidthNumericStepper.value;
tile_width = board_width / problemN;
tile_height = tile_width;
initTileGrid(problemN, problemN);
generationNo = 0;
populationNum = populationNumericStepper.value;
initPopulation(populationNum, problemN);
drawBestPosition(population[0]);
bestFitness = evalPopulation(population[0]);
drawUI();
fitnessLineChart.maximum = fitnessMax;
fitnessLineChart.minimum = -1 * fitnessMax;
bestFitnessLineChart.maximum = fitnessMax;
bestFitnessLineChart.minimum = 0;
bestData = [];
}
private function onLoop(e:Event):void
{
var i:int;
var j:int;
var temp:int;
//select
sortDescending();
var selectionSum:int = 0;
selectionExpect = new Vector.<int>(populationNum * parentRate);
for (i = 0; i < populationNum * parentRate ; i += 1)
{
selectionExpect[i] = Math.max(1, populationScore[i]);
selectionSum += selectionExpect[i];
//trace(selectionExpect[i]);
}
//crossover
for (i = populationNum * eliteRate; i < populationNum; i += 1) //i = pop * elite => elite preserve; not elite => new pop
{
var firstParent:int = Math.random() * selectionSum;
var secondParent:int = Math.random() * selectionSum;
for (j = 0; j < selectionExpect.length; j += 1)
{
if (firstParent < selectionExpect[j])
{
firstParent = j;
break;
}
firstParent -= selectionExpect[j];
}
for (j = 0; j < selectionExpect.length; j += 1)
{
if (secondParent < selectionExpect[j])
{
secondParent = j;
break;
}
secondParent -= selectionExpect[j];
}
if (firstParent == secondParent) //same parent - reSelect
{
i -= 1;
continue;
//trace("HI");
}
else //find crossover point
{
for (var k:int = 0; k < problemN; k += 1)
{
population[i][k] = population[firstParent][k];
}
var crossOverPoint1:int = Math.random() * (problemN - 1);
var crossOverPoint2:int = int( Math.random() * (problemN - crossOverPoint1) ) + crossOverPoint1;
//trace(crossOverPoint1, crossOverPoint2);
for (k = crossOverPoint1; k < crossOverPoint2; k += 1)
{
if (population[i][k] != population[secondParent][k])
{
for (var l:int = 0; l < problemN; l += 1)
{
if (population[i][l] == population[secondParent][k] && l != k)
{
temp = population[i][l];
population[i][l] = population[i][k];
population[i][k] = temp;
break;
}
}
}
else
{
population[i][k] = population[secondParent][k];
}
}
}
}
//mutate
for (i = populationNum * eliteRate; i < populationNum; i += 1) //not elite => mutation
{
for (j = 0; j < problemN; j += 1)
{
if (Math.random() < mutationRate)
{
var second:int = Math.random() * problemN;
while (second == j)
{
second = Math.random() * problemN; //trace("HI" + j);
}
temp = population[i][j];
population[i][j] = population[i][second];
population[i][second] = temp;
}
}
}
prevBestFitness = bestFitness;
var bestPopulationIndex:int = 0;
for (i = 0; i < populationNum; i += 1)
{
populationScore[i] = evalPopulation(population[i]);
if (Math.max(bestFitness, populationScore[i]) != bestFitness)
{
bestFitness = Math.max(bestFitness, populationScore[i]);
bestPopulationIndex = i;
}
}
generationNo += 1;
//draw Route & bestChart
bestData.push(bestFitness);
if(prevBestFitness != bestFitness)
{
drawBestPosition(population[bestPopulationIndex]);
drawBestChart();
}
drawUI();
if (generationNo >= endGenerationNo || evalPopulation(population[bestPopulationIndex]) == fitnessMax)
{
sortDescending();
drawChart(true);
onStop(new Event(MouseEvent.CLICK));
//removeEventListener(Event.ENTER_FRAME, onLoop);
}
}
private function drawBestChart():void
{
bestFitnessLineChart.data = bestData;
bestFitnessLineChart.draw();
}
private function drawChart(sw:Boolean):void
{
if (generationNo % chartRefreshCycle == 2 || sw == true)
{
var dataArray:Array = [];
for (var i:int = 0; i < populationScore.length; i += 1)
{
dataArray.push(populationScore[i]);
}
fitnessLineChart.data = dataArray;
fitnessLineChart.minimum = 0;
fitnessLineChart.draw();
//trace(dataArray);
}
}
private function drawUI():void
{
generationLabel.text = "Generation : " + String(generationNo) + " / " + String(endGenerationNo);
fitnessLabel.text = "Best Fit. : " + String(bestFitness);
}
private function drawBestPosition(pop:Vector.<int>):void
{
queenBitmapData.fillRect(queenBitmapData.rect, 0x00ffffff);
var mat:Matrix;
var redArray:Array = [];
for (var j:int = 0; j < pop.length; j += 1)
{
redArray.push(0);
}
for (var i:int = 0; i < pop.length - 1; i += 1) //diagonal check - left down, right down
{
for (j = i + 1; j < pop.length; j += 1)
{
if (Math.abs(pop[i] - pop[j]) == Math.abs(i - j))
{
redArray[i] = 1;
redArray[j] = 1;
}
}
}
for (i = 0; i < pop.length; i += 1)
{
mat = new Matrix();
if (tile_width < queenSize)
{
mat.scale(tile_width / queenSize, tile_width / queenSize);
}
mat.translate((pop[i]+1) * tile_width, (i+1) * tile_height);
mat.translate( -1 * tile_width / 2, -1 * tile_height / 2);
if (redArray[i] == 0)
{
queenBitmapData.draw(queenGraphic, mat);
}
else //draw Red Queen
{
queenBitmapData.draw(queenGraphic, mat, redQueenColt);
}
}
}
private function sortDescending():void
{
var temp:Array = [];
var obj:Object;
for (var i:int = 0; i < population.length; i += 1)
{
obj = new Object();
obj.population = population[i];
obj.score = populationScore[i];
temp.push(obj);
}
temp.sortOn("score", Array.NUMERIC | Array.DESCENDING);
for (i = 0; i < population.length; i += 1)
{
population[i] = temp[i].population;
populationScore[i] = temp[i].score;
}
drawChart(false);
}
private function initTileGrid(tileNum_X:int, tileNum_Y:int):void
{
tileBitmapData.fillRect(tileBitmapData.rect, 0x00ffffff);
//print Tile Grid
gridSprite.graphics.clear();
gridSprite.graphics.lineStyle(1, 0xffffff, 1);
gridSprite.graphics.beginFill(0xc0c0c0, 1);
gridSprite.graphics.drawRect(0, 0, tileNum_X * tile_width, tileNum_Y * tile_height);
gridSprite.graphics.endFill();
for (var i:int = 0; i < tileNum_X; i += 1)
{
gridSprite.graphics.moveTo(i * tile_width, 0);
gridSprite.graphics.lineTo(i * tile_width, tileNum_Y * tile_height);
}
for (i = 0; i < tileNum_Y; i += 1)
{
gridSprite.graphics.moveTo(0, i * tile_height);
gridSprite.graphics.lineTo(tileNum_X * tile_width, i * tile_height);
}
tileBitmapData.draw(gridSprite);
}
private function initPopulation(populationNum:int, randomNum:int):void
{
for (var i:int = 0; i < populationNum; i += 1)
{
var onePopulation:Array = printRandomNumber(randomNum, randomNum);
population[i] = new Vector.<int>(randomNum);
for (var j:int = 0; j < randomNum; j += 1)
{
population[i][j] = onePopulation[j];
}
//trace(population[i]);
//init Score
populationScore[i] = evalPopulation(population[i]);
//trace("population: ", population[i], "score: ", populationScore[i]);
}
generationNo += 1;
}
private function evalPopulation(pop:Vector.<int>):int
{
var score:int = problemN * problemN;
for (var i:int = 0; i < pop.length - 1; i += 1) //diagonal check - left down, right down
{
for (var j:int = i + 1; j < pop.length; j += 1)
{
if (Math.abs(pop[i] - pop[j]) == Math.abs(i - j))
{
score -= problemN;
}
}
}
return score;
}
private function printRandomNumber(n:int, k:int) : Array
{
var original:Array=[];
var result:Array=[];
var i:int;
var randInt:int;
var temp:Object;
for(i=0;i<n;i+=1)
{
original.push(i);
}
for(i=0;i<k;i+=1)
{
randInt = Math.random()*(n-i) + i;
temp = original[i];
original[i] = original[randInt];
original[randInt] = temp;
result.push(original[i]);
}
return result;
}
}
}
