forked from: ぷよっとしたスライム。png画像から作る版。

/**
 * Copyright Akiyah ( http://wonderfl.net/user/Akiyah )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/5V6o
 */

package {
    import flash.display.*;
    import flash.events.*;
    import flash.geom.*;
    import flash.net.*;
    import flash.system.*;

    public class PuyoDot3 extends Sprite {
        //private var _rect:Rectangle = new Rectangle(0, 0, PuyoDot.STAGE_W, PuyoDot.STAGE_H);
        //private var _point:Point = new Point();

        private var _displayLayer:Bitmap;

        // ビットマップ
        private var _clearBitmap:BitmapData = new BitmapData(PuyoDot.STAGE_W, PuyoDot.STAGE_H, true, 0x00000000);
        private var _displayBitmap:BitmapData = new BitmapData(PuyoDot.STAGE_W, PuyoDot.STAGE_H);


        private var bmd:BitmapData;
        private var loader:Loader = new Loader();
        Security.loadPolicyFile("http://assets.wonderfl.net/crossdomain.xml");

        private var puyoDot:PuyoDot = new PuyoDot();

        public function PuyoDot3() {
            loader.contentLoaderInfo.addEventListener(Event.COMPLETE, loadDone);
            loader.load(new URLRequest("http://assets.wonderfl.net/images/related_images/e/e1/e1b1/e1b1a2d1ea3db94a33f5eb77daaf9125081062b7"));
        }
        private function loadDone(e:Event):void {
            bmd = new BitmapData(loader.width,loader.height,true,0x000000);
            bmd.draw(loader);
            init();
        }
        private function init():void {
            _displayLayer = new Bitmap(_displayBitmap);
            addChild(_displayLayer);
            puyoDot.init(new MapSlime(), drawParticles);

            // フレームの処理を登録
            addEventListener(
                Event.ENTER_FRAME,
                function (event:Event):void{
                    puyoDot.frame(mouseX, mouseY)
                });
            // マウスドラッグ
            this.stage.addEventListener(MouseEvent.MOUSE_DOWN,
                                        function(e:Event):void {
                                            puyoDot.startBornDrag(mouseX, mouseY);
                                        });
            this.stage.addEventListener(MouseEvent.MOUSE_UP,
                                        function(e:Event):void {
                                            puyoDot.endBornDrag();
                                        });
        }

        private var _drawShape:Shape = new Shape();
        public function drawParticles(particleList:Array, dotMap:DotMap, _h:int, _w:int):void{
            var g:Graphics = _drawShape.graphics;
            g.clear();
            var x:int, y:int;
            var n:int = 17;
            //g.lineStyle(1, 0x000000, 0.1);
            for (y = 0; y < _h-1; y++){
                for (x = 0; x < _w-1; x++){
                    if(!dotMap.isDot(x, y)) continue;    // ドットが無いなら描画省略
                    drawSquare(g, bmd, new Point(x*n,y*n), n,
                               particleList[x][y].getPoint(),
                               particleList[x+1][y].getPoint(),
                               particleList[x][y+1].getPoint(),
                               particleList[x+1][y+1].getPoint());
                }
            }
            _displayBitmap.copyPixels(_clearBitmap,
                                      new Rectangle(0, 0, PuyoDot.STAGE_W, PuyoDot.STAGE_H),
                                      new Point(0, 0));
            _displayBitmap.draw(_drawShape);
        }
        private function drawSquare(g:Graphics, bmd:BitmapData, start:Point, len:Number,
                                    p0:Point, p1:Point, p2:Point, p3:Point):void{
            var a:Triangle;
            var b:Triangle;
            a = new Triangle(start,
                             start.add(new Point(len, 0)),
                             start.add(new Point(0, len)));
            b = new Triangle(p0, p1, p2);
            drawTriangle(g, bmd, Triangle.transformMatrix(a, b), b);

            a = new Triangle(start.add(new Point(len, 0)),
                             start.add(new Point(len, len)),
                             start.add(new Point(0, len)));
            b = new Triangle(p1, p3, p2);
            drawTriangle(g, bmd, Triangle.transformMatrix(a, b), b);
        }
        private function drawTriangle(g:Graphics, bmd:BitmapData,
                                      m:Matrix, b:Triangle):void{
            g.beginBitmapFill(bmd, m);
            g.moveTo(b.p0.x, b.p0.y);
            g.lineTo(b.p1.x, b.p1.y);
            g.lineTo(b.p2.x, b.p2.y);
            g.lineTo(b.p0.x, b.p0.y);
            g.endFill();
        }
    }
}

import flash.geom.Point;
import flash.geom.Matrix;

class PuyoDot {
    public static const STAGE_W:uint = 465;
    public static const STAGE_H:uint = 465;

    // パーティクル
    private var _particleList:Array = [];    //:Array :Particle
    private var _particleDistance:int;
    private var _w:int;
    private var _h:int;

    // ドラッグ
    private var _dragIdX:int = -1;
    private var _dragIdY:int = -1;

    private static const _WALL_LEFT:Number = 0;
    private static const _WALL_RIGHT:Number = 465;
    private static const _GROUND_LINE:Number = 350;

    private static const _DOT_CONNECT_MAX:int = 4;
    private static const _DERIVATION:int = 3;    // 計算の分割数。
    private static const _MAP_SIZE:Number = 200;

    private static const _PI:Number = Math.PI;
    private static const _PI2:Number = 2.0 * _PI;
    private static const _RADIAN90:Number    = _PI * 0.5;
    private static const _RADIAN180:Number    = _PI * 1.0;
    private static const _RADIAN270:Number    = _PI * -0.5;
    private static const _TO_DEGREE:Number    = 180 / _PI;

    private static const _GRAVITY:Number = 0.2 / _DERIVATION;
    private static const _ROTATION_RATE:Number = 0.05 / _DERIVATION;    // 自身バネ（根元）
    private static const _VERTICAL_RATE:Number = 0.2 / _DERIVATION;    // ターゲットバネ（さきっぽ）
    private static const _MOUSE_PULL_RATE:Number = 2.0 / _DERIVATION;

    private static const _FRICTION:Number = 0.1 / _DERIVATION;
    private static const _ROTATE_FRICTION:Number = 1 - 0.2 / _DERIVATION;
    private static const _MOUSE_ROTATE_FRICTION:Number = 1 - 0.8 / _DERIVATION;
    private static const _MOUSE_MOVE_FRICTION:Number = 1 - 0.5 / _DERIVATION;
    private static const _GROUND_FRICTION:Number = 1 - 0.2 / _DERIVATION;

    private var _dotMap:DotMap;
    private var drawFunction:Function;

    public function init(dotMap:DotMap, drawFunction:Function):void {    // ここから開始
        this._dotMap = dotMap;
        this.drawFunction = drawFunction;

        _w = _dotMap.w+1;
        _h = _dotMap.h+1;
        _particleDistance = _MAP_SIZE / _w;
        var tmpBaceX:Number = (STAGE_W - _MAP_SIZE) / 2;
        var tmpBaceY:Number = 20;
        var x:int, y:int;
        var particle:Particle;
        // 生成
        for (x = 0; x < _w; x++) {
            _particleList[x] = [];
            for (y = 0; y < _h; y++) {
                particle = new Particle();
                var tmpNearDotList:Array = [_dotMap.isDot(x, y), _dotMap.isDot(x-1, y),
                                            _dotMap.isDot(x-1, y-1), _dotMap.isDot(x, y-1)];
                particle.connect[0] = (tmpNearDotList[0] || tmpNearDotList[3]) && x < _w-1;    // 右
                particle.connect[1] = (tmpNearDotList[1] || tmpNearDotList[0]) && y < _h-1;    // 下
                particle.connect[2] = (tmpNearDotList[2] || tmpNearDotList[1]) && 0 < x;    // 左
                particle.connect[3] = (tmpNearDotList[3] || tmpNearDotList[2]) && 0 < y;    // 上

                if (!particle.connect[0] && !particle.connect[1] && !particle.connect[2] && !particle.connect[3]){
                    _particleList[x][y] = null;
                    continue;
                }
                particle.color = _dotMap.getColor(x, y);
                particle.x = tmpBaceX + _particleDistance * x + Math.random()*3;
                particle.y = tmpBaceY + _particleDistance * y;
                _particleList[x][y] = particle;
            }
        }
        for (x = 0; x < _w; x++){
            for (y = 0; y < _h; y++){
                particle = _particleList[x][y];
                if (particle == null) continue;
                particle.connect[4] = particle.connect[0] && Particle(_particleList[x+1][y]).connect[0];    // 右右
                particle.connect[5] = particle.connect[1] && Particle(_particleList[x][y+1]).connect[1];    // 下下
                particle.connect[6] = particle.connect[2] && Particle(_particleList[x-1][y]).connect[2];    // 左左
                particle.connect[7] = particle.connect[3] && Particle(_particleList[x][y-1]).connect[3];    // 上上
            }
        }
    }

    // ドラッグ
    public function startBornDrag(mouseX:int, mouseY:int):void{
        var x:int, y:int;
        for (x = 0; x < _w; x++){
            for (y = 0; y < _h; y++){
                var particle:Particle = _particleList[x][y];
                if (particle == null) continue;
                if (Math.pow(particle.x - mouseX, 2) + Math.pow(particle.y - mouseY, 2) < Math.pow(_particleDistance*0.8, 2)) {
                    _dragIdX = x;
                    _dragIdY = y;
                    return;
                }
            }
        }
    }
    public function endBornDrag():void{
        _dragIdX = -1;
        _dragIdY = -1;
    }

    // フレーム挙動
    public function frame(mouseX:Number, mouseY:Number):void{
        for (var i:int=0; i<_DERIVATION; i++){
            rotate();
            force(mouseX, mouseY);
            move();
        }
        drawFunction(_particleList, _dotMap, _h, _w);
        //main.drawPparticles(_particleList, _dotMap, _h, _w);    // 描画処理
    }

    // ボーンの向きを決定する
    public function rotate():void{
        var x:int, y:int;
        for (x = 0; x < _w; x++){
            for (y = 0; y < _h; y++){
                var particle:Particle = _particleList[x][y];
                if (particle == null) continue;
                var subParticle:Particle;
                if (particle.connect[0]){    // 右パーティクルに対する処理
                    subParticle = _particleList[x+1][y];
                    calcConnectRForce(particle, subParticle, 0);
                    calcConnectRForce(subParticle, particle, _RADIAN180);
                }
                if (particle.connect[1]){    // 下パーティクルに対する処理
                    subParticle = _particleList[x][y+1];
                    calcConnectRForce(particle, subParticle, _RADIAN90);
                    calcConnectRForce(subParticle, particle, _RADIAN270);
                }
                if (particle.connect[4]){    // 右右パーティクルに対する処理
                    subParticle = _particleList[x+2][y];
                    calcConnectRForce(particle, subParticle, 0);
                    calcConnectRForce(subParticle, particle, _RADIAN180);
                }
                if (particle.connect[5]){    // 下下パーティクルに対する処理
                    subParticle = _particleList[x][y+2];
                    calcConnectRForce(particle, subParticle, _RADIAN90);
                    calcConnectRForce(subParticle, particle, _RADIAN270);
                }
                if (x == _dragIdX && y == _dragIdY) particle.vr *= _MOUSE_ROTATE_FRICTION;
                else particle.vr *= _ROTATE_FRICTION;    // 摩擦

                particle.radian += particle.vr;
            }
        }
    }
    // 接続されたパーツの回転方向を計算する
    private function calcConnectRForce(particle:Particle, targetParticle:Particle, connectAngle:Number):void{
        var angle:Number = Math.atan2(targetParticle.y - particle.y, targetParticle.x - particle.x);
        particle.vr += ajustRadian(angle - (connectAngle + particle.radian)) * _ROTATION_RATE;
    }

    public function force(mouseX:Number, mouseY:Number):void{
        var x:int, y:int;
        for (x = 0; x < _w; x++){
            for (y = 0; y < _h; y++){
                var particle:Particle = _particleList[x][y];
                if (particle == null) continue;
                var subParticle:Particle;
                if (particle.connect[0]){    // 右パーティクルに対する処理
                    subParticle = _particleList[x+1][y];
                    calcConnectFoce(particle, subParticle, 0, _particleDistance);
                    calcConnectFoce(subParticle, particle, _RADIAN180, _particleDistance);
                }
                if (particle.connect[1]){    // 下パーティクルに対する処理
                    subParticle = _particleList[x][y+1];
                    calcConnectFoce(particle, subParticle, _RADIAN90, _particleDistance);
                    calcConnectFoce(subParticle, particle, _RADIAN270, _particleDistance);
                }
                if (particle.connect[4]){    // 右右パーティクルに対する処理
                    subParticle = _particleList[x+2][y];
                    calcConnectFoce(particle, subParticle, 0, _particleDistance*2);
                    calcConnectFoce(subParticle, particle, _RADIAN180, _particleDistance*2);
                }
                if (particle.connect[5]){    // 下下パーティクルに対する処理
                    subParticle = _particleList[x][y+2];
                    calcConnectFoce(particle, subParticle, _RADIAN90, _particleDistance*2);
                    calcConnectFoce(subParticle, particle, _RADIAN270, _particleDistance*2);
                }
                particle.ay += _GRAVITY;
                if (_dragIdX == x && _dragIdY == y){    // マウスで引っ張る
                    var point:Point = pullForce(particle.x, particle.y, mouseX, mouseY, _MOUSE_PULL_RATE);
                    particle.ax += point.x;
                    particle.ay += point.y;
                    particle.vx *= _MOUSE_MOVE_FRICTION;
                    particle.vy *= _MOUSE_MOVE_FRICTION;
                }
            }
        }
    }
    // 接続された２パーツの力を計算する
    private function calcConnectFoce(particle:Particle, targetParticle:Particle, connectAngle:Number, distance:Number):void{
        var toAngle:Number = ajustRadian(connectAngle + particle.radian);
        var toX:Number = particle.x + Math.cos(toAngle) * distance;
        var toY:Number = particle.y + Math.sin(toAngle) * distance;
        var ax:Number = (targetParticle.x - toX) * _VERTICAL_RATE;
        var ay:Number = (targetParticle.y - toY) * _VERTICAL_RATE;
        particle.ax += ax;
        particle.ay += ay;
        targetParticle.ax -= ax;
        targetParticle.ay -= ay;
    }
    // ポイントx1 y1を、ポイントx2 y2へ、係数rateだけ移動させる場合の、XYの力を返す
    private function pullForce(x1:Number, y1:Number, x2:Number, y2:Number, rate:Number):Point{
        var point:Point = new Point();
        var distance:Number = calcDistance(x1, y1, x2, y2);

        var angle:Number = Math.atan2(y2 - y1, x2 - x1);
        point.x = Math.cos(angle) * distance * rate;
        point.y = Math.sin(angle) * distance * rate;
        return point;
    }
    // ポイントx1 y1から、ポイントx2 y2までの距離
    private function calcDistance(x1:Number, y1:Number, x2:Number, y2:Number):Number{
        return Math.sqrt(Math.pow(x2-x1, 2) + Math.pow(y2-y1, 2));
    }
    // radian角度を、-π～πの範囲に修正する
    private function ajustRadian(radian:Number):Number{
        return radian - _PI2 * Math.floor( 0.5 + radian / _PI2);
    }

    public function move():void{
        var x:int, y:int;
        for (x = 0; x < _w; x++){
            for (y = 0; y < _h; y++){
                var particle:Particle = _particleList[x][y];
                if (particle == null) continue;

                // 空気抵抗 TODO:速度に対しての処理で良いはず。
                particle.ax += -_FRICTION * particle.vx;
                particle.ay += -_FRICTION * particle.vy;

                // 速度、位置への反映
                particle.vx += particle.ax;
                particle.vy += particle.ay;
                particle.x += particle.vx;
                particle.y += particle.vy;
                particle.ax = 0;
                particle.ay = 0;    // 力をクリア

                // 壁チェック
                if (0 < particle.vy && _GROUND_LINE < particle.y){
                    particle.y = _GROUND_LINE;
                    particle.vy *= -0.8;
                    if (particle.vy < -50) particle.vy = -50;
                    particle.vx *= _GROUND_FRICTION;
                }
                if (particle.vx < 0 && particle.x < _WALL_LEFT){
                    particle.x = _WALL_LEFT;
                    particle.vx = 0;
                    particle.vy *= _GROUND_FRICTION;
                }else if (0 < particle.vx && _WALL_RIGHT < particle.x){
                    particle.x = _WALL_RIGHT;
                    particle.vx = 0;
                    particle.vy *= _GROUND_FRICTION;
                }
            }
        }
    }
}

class Particle {
    public var x:Number = 0;    // 位置
    public var y:Number = 0;
    public var vx:Number = 0;    // 速度
    public var vy:Number = 0;
    public var ax:Number = 0;    // 加速度=力    TOTO:最後まで意味無かったら消す
    public var ay:Number = 0;

    public var radian:Number = 0;    // 向き
    public var vr:Number = 0;    // 向き速度

    public var color:uint = 0x000000;    // パーティクルの色。右下の枠の色
    public var connect:Array = [true, true, true, true];    // パーティクルの接続状態を毎回チェックしなくていいように、保持しておく

    public function getPoint():Point {
        return new Point(x, y);
    }
}
class DotMap {
    public var w:uint = 16;
    public var h:uint = 16;

    public var pallet:Array = [];    // カラーパレット。ゼロ番は透過色予定:uint
    public var strPallet:Array = [];    // :String
    public var strMap:String = "";
    public var map:Array = [];    // ピクセルマップ:int

    function DotMap() {
        init();
        readMap();
    }
    protected function init():void {
        w = 16;    // 16くらいが妥当。あんまり多すぎると自重で潰れるし、重い
        h = 16;
        pallet = [0x000000, 0xDC2900, 0xFFA53B, 0x8B7300];    // 一応何色でも可能
        strPallet = ["＿", "○", "□", "■"];

        strMap =
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■"+
                "■■■■■■■■■■■■■■■■";

    }
    private function readMap():void{
        for (var i:int; i<w*h; i++){
            map.push(strPallet.indexOf(strMap.substr(i, 1)));
        }
    }

    public function isDot(x:int, y:int):Boolean{
        if (x < 0 || y < 0 || w <= x || h <= y) return false;
        if (map[x + y*w] == 0) return false;
        return true;
    }
    public function getColor(x:int, y:int):uint{
        if (x < 0 || y < 0 || w <= x || h <= y) return 0;
        return pallet[map[x + y*w]];
    }
}
class MapSlime extends DotMap {
    override protected function init():void{
        w = 16;
        h = 16;
        pallet = [0x000000, 0xffffff];
        strPallet = ["_", "w"];
        strMap =
            "________________"+
            "_______ww_______"+
            "_______ww_______"+
            "______wwww______"+
            "______wwww______"+
            "____wwwwwwww____"+
            "__wwwwwwwwwwww__"+
            "_wwwwwwwwwwwwww_"+
            "wwwwwwwwwwwwwwww"+
            "wwwwwwwwwwwwwwww"+
            "wwwwwwwwwwwwwwww"+
            "wwwwwwwwwwwwwwww"+
            "wwwwwwwwwwwwwwww"+
            "_wwwwwwwwwwwwww_"+
            "__wwwwwwwwwwww__"+
            "____wwwwwwww____"+
            "";
    }
}

class Triangle {
    public var p0:Point;
    public var p1:Point;
    public var p2:Point;
    function Triangle(p0:Point, p1:Point, p2:Point) {
        this.p0 = p0;
        this.p1 = p1;
        this.p2 = p2;
    }
    public function matrix():Matrix {
        return new Matrix(
            p1.x - p0.x, p1.y - p0.y,
            p2.x - p0.x, p2.y - p0.y);
    }
    public static function transformMatrix(a:Triangle, b:Triangle):Matrix {
        var ma : Matrix = a.matrix();
        ma.invert();
        var mb : Matrix = b.matrix();
        var m : Matrix = new Matrix();
        m.translate(-a.p0.x, -a.p0.y);
        m.concat(ma);
        m.concat(mb);
        m.translate(b.p0.x, b.p0.y);
        return m;
    }
}
