* Copyright tepe ( http://wonderfl.net/user/tepe )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/4PKD
*/
package {
import flash.display.*;
import flash.events.*;
import flash.net.*
import flash.text.*;
public class Main extends Sprite {
private var txt1:TextField = new TextField();
private var ar:Array;
private var logar:Array;
private var gs:GroupSpecifier;//接続グループ機能制限
private var nc:NetConnection;
private var group:NetGroup;
private var reqflg:Boolean;
private var groupName:String;
private var NETCANVAS_CMD_1LINE:String = "1line";//通信コマンド
private var btn:Btn;
private var map1:ozmap = new ozmap();
private var s:Sprite = new Sprite();
public function Main() {
btn = new Btn();
btn.init({type:1,width:60});
btn.text = "scrool";
btn.x = 125;
btn.y = 400;
map1.addChild(btn);
btn.addEventListener(MouseEvent.CLICK,function():void{
if(btn.text == "scrool"){
btn.text = "write";
map1.Enabled = true;
//マウスイベント
map1.field.removeEventListener(MouseEvent.MOUSE_DOWN, onMouseDown);
map1.field.removeEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
map1.field.removeEventListener(MouseEvent.MOUSE_UP, onMouseUp);
}
else{
btn.text = "scrool";
map1.Enabled = false;
//マウスイベント
map1.field.addEventListener(MouseEvent.MOUSE_DOWN, onMouseDown);
map1.field.addEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
map1.field.addEventListener(MouseEvent.MOUSE_UP, onMouseUp);
}
});
var btn2:Btn = new Btn();
btn2.init({typw:1,width:80});
btn2.text = "full screen";
btn2.x = 50;
btn2.y = 400;
map1.addChild(btn2);
btn2.addEventListener(MouseEvent.CLICK,function():void{
if(btn2.text == "full screen"){
btn2.text = "normal";
stage.displayState = StageDisplayState.FULL_SCREEN;
}
else{
btn2.text = "full screen";
stage.displayState = StageDisplayState.NORMAL;
}
});
txt1.text = "aaa!;";
// グループ機能制限
groupName = new String();
groupName = "net.wonderfl.ozmap.test"
gs = new GroupSpecifier(groupName);//接続グループ名
gs.postingEnabled = true;//ポスティング許可
gs.ipMulticastMemberUpdatesEnabled = true;//IP情報のマルチキャスト許可
gs.multicastEnabled = true;//NetStreamによるストリーミング許可
gs.objectReplicationEnabled = true;//オブジェクトの複製許可
gs.routingEnabled = true;//NetGroupでの転送メソッド許可
gs.serverChannelEnabled = true;//メンバーへサーバーチャンネルを開く権限を付与
// RTMFPコネクション
nc = new NetConnection();
//イベント NET_STATUS
nc.addEventListener(NetStatusEvent.NET_STATUS, procNetStatus);
//接続
nc.connect("rtmfp://p2p.rtmfp.net/3ea2ccfc17227d122a776d41-31e9e4d71a17/");
logar = new Array();
reqflg = false;
}
private function initCanvas():void {
addChild(map1);
map1.field.addChild(s);
addChild(txt1);
txt1.text = group.estimatedMemberCount.toString();
txt1.width = 400;
//txt1.text = nc.nearID.toString();
//txt1.appendText("\n"+nc.nearNonce.toString());
map1.field.addEventListener(MouseEvent.MOUSE_DOWN, onMouseDown);
map1.field.addEventListener(MouseEvent.MOUSE_MOVE, onMouseMove);
map1.field.addEventListener(MouseEvent.MOUSE_UP, onMouseUp);
map1.Enabled = false;
}
//マウスダウン 描画開始
private function onMouseDown(e:MouseEvent):void {
ar = new Array();
//ar.push(e.stageX);
//ar.push(e.stageY);
ar.push(map1.field.mouseX);
ar.push(map1.field.mouseY);
s.graphics.lineStyle(2,0x000000);
//s.graphics.moveTo(e.stageX, e.stageY);
s.graphics.moveTo(map1.field.mouseX,map1.field.mouseY);
}
//マウス移動 描画
private function onMouseMove(e:MouseEvent):void {
if (e.buttonDown) {
//ar.push(e.stageX);
//ar.push(e.stageY);
ar.push(map1.field.mouseX);
ar.push(map1.field.mouseY);
s.graphics.lineStyle(2,0x000000);
//s.graphics.moveTo(e.stageX, e.stageY);
s.graphics.lineTo(map1.field.mouseX,map1.field.mouseY);
}
}
//マウスアップ 描画終了
private function onMouseUp(e:MouseEvent):void {
group.post({cmd: NETCANVAS_CMD_1LINE, msg: ar});//メッセージ送信
logar.push(ar);//ログ追加
ar = null;//クリア
if (!reqflg) {
group.addHaveObjects(0, 0);
}
}
//通信イベント
private function procNetStatus(e:NetStatusEvent):void {
var i:int;
var j:int;
switch (e.info.code) {
case "NetConnection.Connect.Success"://接続確立
group = new NetGroup(nc, gs.groupspecWithAuthorizations());
group.addEventListener(NetStatusEvent.NET_STATUS, procNetStatus);
break;
case "NetGroup.Connect.Success"://グループ接続確立
initCanvas();//開始
break;
case "NetGroup.Neighbor.Connect"://メンバー接続
if (logar.length == 0) {
reqflg = true;
group.addWantObjects(0, 0);//同期
}
break;
case "NetGroup.Posting.Notify"://メンバーからのポスト受信
var obj:Object = e.info.message;//メッセージオブジェクト
var ar1:Array = obj.msg;//メッセージ
var cmd:String = obj.cmd;//コマンド
logar.push(ar1);//メッセージをログに追記
group.addHaveObjects(0, 0);//同期
if (cmd == NETCANVAS_CMD_1LINE) {
var shape:Shape = new Shape();
shape.graphics.lineStyle(2, 0x000000);
shape.graphics.moveTo(ar1[0], ar1[1]);//ライン開始点
for (j = 2; j < ar1.length; j += 2) {
shape.graphics.lineTo(ar1[j], ar1[j+1]);
}
map1.field.addChild(shape);
}
break;
case "NetGroup.Replication.Request"://隣接ノードからの要求
if (e.info.index == 0) {
group.writeRequestedObject(e.info.requestID, {log: logar});
}
break;
case "NetGroup.Replication.Fetch.Result"://隣接ノードが要求を満たした
if (e.info.index == 0) {
reqflg = false;
logar = e.info.object.log;
group.addHaveObjects(0, 0);
var shape0:Shape = new Shape();
shape0.graphics.lineStyle(2, 0x000000);
for (i = 0; i < logar.length; ++i) {
var ar:Array = logar[i];
shape0.graphics.moveTo(ar[0], ar[1]);
for (j = 2; j < ar.length; j += 2) {
shape0.graphics.lineTo(ar[j], ar[j+1]);
}
}
map1.field.addChild(shape0);
}
break;
}
}
}
}
import flash.geom.Point;
import flash.display.*;
import flash.events.*;
import flash.utils.*;
import flash.filters.*;
class ozmap extends Sprite{
public var scale:Number = 1;
public var zoom:int;//ホイール回転量反映
private var scale_A:Number = 1.0;//拡大率
public var field:Sprite;//フィールド
private var mapFocusX:Number=0;
private var mapFocusY:Number=0;
private var scrFocusX:int=0;
private var scrFocusY:int=0;
private var mX:int=0;
private var mY:int=0;
private var scalingPanel:Sprite;
private var base:Sprite;
private var mapscale:int=0;
private var dragPanel:Shape = new Shape();
private var onMouseBtn:Boolean;
private var msk:Sprite = new Sprite();
private var mapMode:Boolean;//マップモード true:マップ操作ON false:マップ操作OFF
public function get Enabled():Boolean{
return mapMode;
}
public function set Enabled(sw:Boolean):void{
if(mapMode == sw)return;
mapMode = sw;
if(mapMode == true){
field.addEventListener(MouseEvent.MOUSE_DOWN,down1);
field.addEventListener(MouseEvent.MOUSE_UP,up1);
}
else{
field.removeEventListener(MouseEvent.MOUSE_DOWN,down1);
field.removeEventListener(MouseEvent.MOUSE_UP,up1);
}
}
//コンストラクタ
public function ozmap():void {
//カーソル位置描画
scalingPanel = new Sprite();//ズーム中心
addChild(scalingPanel);
//マップ基準座標
base = new Sprite();
scalingPanel.addChild(base);
//マップ上への配置
field = new Sprite();
field.addEventListener(MouseEvent.MOUSE_DOWN,down1);
field.addEventListener(MouseEvent.MOUSE_UP,up1);
mapMode = true;
addEventListener(MouseEvent.MOUSE_WHEEL,on_wheel);//ホイール操作
field.addEventListener(MouseEvent.MOUSE_DOWN,stopZoom);//ズーム停止
addEventListener(Event.ENTER_FRAME, onFrame);//メインループ
base.addChildAt(field,0);
field.addChild(dragPanel);
aaaa();
}
public function get fieldScale():int {
return mapscale;
}
public function setAreaRect(x:Number,y:Number,width:Number,height:Number):void{
this.addChild(msk);
this.x = x;
this.y = y;
msk.graphics.beginFill(0xff0000);
msk.graphics.drawRect(0,0,width,height);
msk.graphics.endFill();
this.mask = msk;
}
//ズーム停止
private function stopZoom(e:MouseEvent):void{
zoom = 0;
}
//マップドラッグ
private var scrOn:Boolean;
private function down1(e:MouseEvent):void{
scrOn=false;
onMouseBtn=true;
e.currentTarget.startDrag();
addEventListener(MouseEvent.MOUSE_MOVE, onMove);
e.stopPropagation();//イベントの伝播を止める
}
private function up1(e:MouseEvent):void{
onMouseBtn=false;
e.currentTarget.stopDrag();
removeEventListener(MouseEvent.MOUSE_MOVE,onMove);
// e.stopPropagation();//イベントの伝播を止める
}
private function onMove(e:MouseEvent):void{
aaaa();
}
//ホイール操作
private function on_wheel(e:MouseEvent):void {
zoom += e.delta;
e.stopPropagation();
}
//メインループ
private function onFrame(e:Event):void {
on_zoom();
//フルスクリーンでのスクロールモード
if(stage.displayState == StageDisplayState.FULL_SCREEN){
var size:Number = 50;
if(scrOn==true && onMouseBtn==false){
if(stage.mouseY < size)field.y -= (stage.mouseY-size)/scale_A/5;
else if(this.root.loaderInfo.height-size < stage.mouseY){
field.y -= (size+stage.mouseY-this.root.loaderInfo.height)/scale_A/5;
}
if(stage.mouseX < 10)field.x -= (stage.mouseX-10)/scale_A/10;
else if(this.root.loaderInfo.width-10 < stage.mouseX){
field.x -= (10+stage.mouseX-this.root.loaderInfo.width)/scale_A/10;
}
}
else{
if(stage.mouseY < size)scrOn=false;
else if(this.root.loaderInfo.height-size < stage.mouseY)scrOn=false;
else if(stage.mouseX < 10)scrOn=false;
else if(this.root.loaderInfo.width-10 < stage.mouseX)scrOn=false;
else scrOn=true;
}
}
}
//マップスクロール基準点の更新
private function aaaa():void{
if (0 <= zoom) {
mX = mouseX; mY = mouseY;//カーソル位置
//ズーム中心
scalingPanel.x = mouseX; scalingPanel.y = mouseY;
//マップ位置
base.x -= (mX-scrFocusX)/scale_A; base.y -= (mY-scrFocusY)/scale_A;
//フォーカス位置
scrFocusX = mX; scrFocusY = mY;
}
else{
mX = this.root.loaderInfo.width/2; mY = this.root.loaderInfo.height/2;//カーソル位置
//ズーム中心
scalingPanel.x =this.root.loaderInfo.width/2; scalingPanel.y = this.root.loaderInfo.height/2;
//マップ位置
base.x -= (mX-scrFocusX)/scale_A; base.y -= (mY-scrFocusY)/scale_A;
//フォーカス位置
scrFocusX = mX; scrFocusY = mY;
}
//フィールドドラッグ用
dragPanel.graphics.clear();
dragPanel.graphics.beginFill(0xff0000,0);
dragPanel.graphics.drawCircle(-(field.x+field.parent.x)/field.scaleX,-(field.y+field.parent.y)/field.scaleY,600/field.scaleX);
dragPanel.graphics.endFill();
}
private function on_zoom():void{
if (zoom != 0) {
aaaa();//基準点更新
if (zoom < 0) {
scale_A *= 1 + (0.005 * zoom);
}
else if (0 < zoom) {
scale_A *= 1 + (0.005 * zoom);
}
if(2 < scale_A){
field.scaleX *= 2;
field.scaleY *= 2;
scale_A /= 2;
field.x += field.x+base.x;
field.y += field.y+base.y;
mapscale--;
}
else if(scale_A < 1.0){
field.x -= (field.x+base.x)/2;
field.y -= (field.y+base.y)/2;
scale_A *= 2;
field.scaleX /= 2;
field.scaleY /= 2;
mapscale++;
}
scale = field.scaleX * scale_A;
scalingPanel.scaleX = scale_A;
scalingPanel.scaleY = scale_A;
}
}
}
//////////////////////////////////////////////////
// Btnクラス
//////////////////////////////////////////////////
import flash.display.*;
import flash.text.*;
import flash.filters.GlowFilter;
import flash.events.MouseEvent;
class Btn extends Sprite {
public var id:uint;
private var shade:Shape;
private var bottom:Shape;
private var light:Shape;
private var base:Shape;
private var txt:TextField;
private var label:String = "";
private static var fontType:String = "_ゴシック";
private var _width:uint = 60;
private static var _height:uint = 20;
private static var corner:uint = 5;
private var type:uint = 1;
private static var bColor:uint = 0xFFFFFF;
private static var sColor:uint = 0x000000;
private static var upColor:uint = 0x666666;
private static var overColor:uint = 0x333333;
private static var offColor:uint = 0x999999;
private static var gColor:uint = 0x00ff00;
private var blueGlow:GlowFilter;
private var shadeGlow:GlowFilter;
private var _clicked:Boolean = false;
private var _enabled:Boolean = true;
public function Btn() {
}
public function init(option:Object):void {
if (option.id != undefined) id = option.id;
if (option.label != undefined) label = option.label;
if (option.width != undefined) _width = option.width;
if (option.type != undefined) type = option.type;
draw();
}
private function draw():void {
switch (type) {//カラーパターン
case 1 :// White
bColor = 0xFFFFFF;
sColor = 0x000000;
upColor = 0x666666;
overColor = 0x333333;
offColor = 0x999999;
break;
case 2 :// Black
bColor = 0x000000;
sColor = 0xFFFFFF;
upColor = 0x666666;
overColor = 0x999999;
offColor = 0x333333;
break;
}
blueGlow = new GlowFilter(gColor, 0.6, 5, 5, 2, 3, false, true);
shadeGlow = new GlowFilter(sColor, 0.3, 4, 4, 2, 3, false, true);
shade = new Shape();
bottom = new Shape();
light = new Shape();
base = new Shape();
txt = new TextField();
addChild(shade);
addChild(bottom);
addChild(light);
addChild(base);
addChild(txt);
createBase(shade, _width, _height, corner, sColor);
shade.filters = [shadeGlow];
createBase(bottom, _width, _height, corner, sColor, 0.3);
createBase(light, _width, _height, corner, gColor);
light.filters = [blueGlow];
createBase(base, _width, _height, corner, bColor);
txt.x = -_width*0.5;
txt.y = -_height*0.5;
txt.width = _width;
txt.height = _height - 1;
txt.type = TextFieldType.DYNAMIC;
txt.selectable = false;
//txt.embedFonts = true;
//txt.antiAliasType = AntiAliasType.ADVANCED;
var tf:TextFormat = new TextFormat();
tf.font = fontType;
tf.size = 12;
tf.align = TextFormatAlign.CENTER;
txt.defaultTextFormat = tf;
txt.text = label;
enabled = true;
mouseChildren = false;
}
public function get text():String{
return txt.text;
}
public function set text(str:String):void{
txt.text = str;
}
private function rollOver(evt:MouseEvent):void {
_over();
}
private function rollOut(evt:MouseEvent):void {
_up();
}
private function press(evt:MouseEvent):void {
_down();
}
private function release(evt:MouseEvent):void {
_up();
}
private function click(evt:MouseEvent):void {
}
private function _up():void {
txt.y = -_height*0.5;
txt.textColor = upColor;
base.y = -1;
light.visible = false;
light.y = -1;
}
private function _over():void {
txt.y = -_height*0.5;
txt.textColor = overColor;
base.y = -1;
light.visible = true;
light.y = -1;
}
private function _down():void {
txt.y = -_height*0.5 + 1;
txt.textColor = overColor;
base.y = 0;
light.visible = true;
light.y = 0;
}
private function _off():void {
txt.y = -_height*0.5 + 1;
txt.textColor = offColor;
base.y = 0;
light.visible = false;
light.y = 0;
}
public function get clicked():Boolean {
return _clicked;
}
public function set clicked(param:Boolean):void {
_clicked = param;
enabled = !_clicked;
if (_clicked) {
_down();
} else {
_up();
}
}
public function get enabled():Boolean {
return _enabled;
}
public function set enabled(param:Boolean):void {
_enabled = param;
buttonMode = _enabled;
mouseEnabled = _enabled;
useHandCursor = _enabled;
if (_enabled) {
_up();
addEventListener(MouseEvent.MOUSE_OVER, rollOver, false, 0, true);
addEventListener(MouseEvent.MOUSE_OUT, rollOut, false, 0, true);
addEventListener(MouseEvent.MOUSE_DOWN, press, false, 0, true);
addEventListener(MouseEvent.MOUSE_UP, release, false, 0, true);
addEventListener(MouseEvent.CLICK, click, false, 0, true);
} else {
_off();
removeEventListener(MouseEvent.MOUSE_OVER, rollOver);
removeEventListener(MouseEvent.MOUSE_OUT, rollOut);
removeEventListener(MouseEvent.MOUSE_DOWN, press);
removeEventListener(MouseEvent.MOUSE_UP, release);
removeEventListener(MouseEvent.CLICK, click);
}
}
private function createBase(target:Shape, w:uint, h:uint, c:uint, color:uint, alpha:Number = 1):void {
target.graphics.beginFill(color, alpha);
target.graphics.drawRoundRect(-w*0.5, -h*0.5, w, h, c*2);
target.graphics.endFill();
}
}
