* Copyright mutantleg ( http://wonderfl.net/user/mutantleg )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/3nUH
*/
package {
import flash.ui.Keyboard;
import flash.events.KeyboardEvent;
import flash.events.MouseEvent;
import flash.text.TextField;
import flash.events.Event;
import flash.display.Sprite;
public class FlashTest extends Sprite {
public function FlashTest() {
deb = new TextField();
deb.mouseEnabled = false;
deb.width = 320;
deb.height = 240;
addChild(deb);
myShape = new xShape();
myShape.cx = 200;
myShape.cy = 200;
stage.addEventListener(KeyboardEvent.KEY_DOWN, kdown);
stage.addEventListener(KeyboardEvent.KEY_UP, kup);
stage.addEventListener(MouseEvent.MOUSE_DOWN, mdown);
stage.addEventListener(Event.ENTER_FRAME, onEnter);
}//ctor
public var vecKey:Vector.<Boolean> = new Vector.<Boolean>(512,false);
public function kdown(e:KeyboardEvent):void { if (e.keyCode > 511) { return;}vecKey[e.keyCode]=true; }
public function kup(e:KeyboardEvent):void { if (e.keyCode > 511) { return;}vecKey[e.keyCode]=false; }
public function isKeyDown(k:int):Boolean { return vecKey[k]; }
public function mdown(e:MouseEvent):void
{
myShape.genShape();
cx = 200;
cy = 50;
vx =0; vy =0;
}//mdown
public var myShape:xShape;
public var deb:TextField;
public var dir:int = 0;
public function onEnter(e:Event):void
{
movePlat();
myShape.ma = myShape.roll;
myShape.mx = myShape.cx;
myShape.my = myShape.cy;
if (dir == 0)
{ myShape.cx += 1; }
else { myShape.cx -= 1;}
if (myShape.cx > 300) { dir = 1;}
else if (myShape.cx < 100) { dir = 0;}
myShape.roll += 0.01;
myShape.ma = angDiff(myShape.roll, myShape.ma);
myShape.mx = myShape.cx - myShape.mx;
myShape.my = myShape.cy - myShape.my;
deb.text = " " + myShape.ma + " " + myShape.mx + " " + myShape.my;
//when travelling on the shape ->
// transform us by the change in the shapes position/rotation
var bnear:Boolean;
bnear = nearLeft || nearRight || nearUp;
if (bStartGround || bnear)
{
cx += myShape.mx;
cy += myShape.my;
var kx:Number;
var ky:Number;
var rx:Number;
var ry:Number;
var ma:Number;
var ca:Number;
var sa:Number;
ma = myShape.ma;
kx = cx - myShape.cx;
ky = cy - myShape.cy;
ca = Math.cos(ma);
sa = Math.sin(ma);
rx = kx * ca - ky * sa;
ry = kx * sa + ky * ca;
rx += myShape.cx;
ry += myShape.cy;
cx = rx;
cy = ry;
//graphics.drawCircle(rx,ry, xrad);
}
graphics.clear();
graphics.lineStyle(2, 0);
myShape.drawShape(graphics, 0);
graphics.beginFill(0xFF,0.5);
//graphics.drawCircle(cx,cy, xrad);
graphics.drawEllipse(cx-xrad,cy-yrad,xrad+xrad,yrad+yrad);
graphics.endFill();
}//onenter
public function isWall(wx:Number, wy:Number):Boolean
{
return myShape.isPointInside(wx,wy);
}//iswall
public static function angDiff(a:Number, b:Number):Number
{
a -= b;
if (a > 3.14) { a -= 6.28; }
if (a < -3.14) { a += 6.28;}
return a;
}//angdiff
public var keyLeft:Boolean = false;
public var keyRight:Boolean = false;
public var keyDown:Boolean = false;
public var keyUp:Boolean = false;
public var bStartGround:Boolean = false;
public var cx:Number = 200;
public var cy:Number = 50;
public var vx:Number = 0;
public var vy:Number = 0;
public var xrad:Number = 8;
public var yrad:Number = 16;
public var nearUp:Boolean = false;
public var nearLeft:Boolean = false;
public var nearRight:Boolean = false;
public function movePlat():void
{
keyLeft = (isKeyDown(Keyboard.A) || isKeyDown(Keyboard.LEFT));
keyRight = (isKeyDown(Keyboard.D) || isKeyDown(Keyboard.RIGHT));
keyUp = (isKeyDown(Keyboard.W) || isKeyDown(Keyboard.UP));
keyDown = (isKeyDown(Keyboard.S) || isKeyDown(Keyboard.DOWN));
bStartGround = isWall(cx,cy+yrad+1) || isWall(cx,cy+yrad);
var s:Number;
var maxs:Number;
s = 1;
maxs = 4;
vy += 0.4;
if (keyDown) { vy += s; }
if (keyUp) { vy -= s; }
if (keyLeft) { if (vx > -maxs) { vx -= s; } }
if (keyRight) { if (vx < maxs) { vx += s; } }
if (vx < 0 && isWall(cx - xrad, cy)) { vx = 0; }
else if (vx > 0 && isWall(cx + xrad, cy)) { vx = 0; }
if (vy < 0 && isWall(cx, cy - yrad)) { vy = 0; }
else if (vy > 0 && isWall(cx, cy + yrad)) { vy = 0; }
vx *= 0.9;
vy *= 0.98;
cx += vx;
cy += vy;
if (cy > 250 && vy >= 0) { vy = 0; cy = 250; }
if (bStartGround && vy >= 0) { checkSlope(12); }
if (isWall(cx-xrad+1, cy)) { cx+= 1; }
if (isWall(cx+xrad-1, cy)) { cx-= 1; }
nearLeft = isWall(cx-xrad, cy);
nearRight = isWall(cx+xrad, cy);
nearUp = isWall(cx, cy-yrad);
}//moveplat
public function checkSlope(pow:int = 8):void
{
var i:int;
if (isWall(cx,cy+yrad+pow)==true)
for (i = 0; i < pow; i++)
{
if (isWall(cx, cy + yrad + 1) == true) { break; }
cy += 1;
}
if (isWall(cx,cy+yrad-pow)==false)
for (i = 0; i < pow; i++)
{
if (isWall(cx, cy + yrad - 1) == false) { break; }
cy -= 1;
}
}//checkslop
}//classend
}
import flash.display.Graphics;
internal class xShape
{
public var vecLine:Vector.<xLine>;
public var cx:Number = 0;
public var cy:Number = 0;
public var roll:Number = 0;
public var mx:Number = 0;
public var my:Number = 0;
public var ma:Number = 0;
public function xShape()
{
genShape();
}//ctor
//see http://wonderfl.net/c/n5Ja
//for readable version
public function isPointInside(kx:Number, ky:Number):Boolean
{
var a:xLine; var i:int; var num:int;
var w:int; var wz:Number; var ax:Number;
var ay:Number; var bx:Number; var by:Number;
var kx:Number; var ky:Number;
var c:uint;
var ca:Number; var sa:Number;
var px:Number; var py:Number;
//transform point to the shape's space
kx -= cx;
ky -= cy;
ca = Math.cos(-roll);
sa = Math.sin(-roll);
px = ca*kx - sa*ky;
py = sa*kx + ca*ky;
w = 0;
num = vecLine.length;
for (i = 0; i < num; i++)
{
a = vecLine[i];
if (a.y0 <= py && a.y1 <= py) { continue; }
if (a.y0 > py && a.y1 > py) { continue; }
//which side of the line we are on?
//(using cross product)
ax = px - a.x0; ay = py - a.y0;
bx = a.x1 - a.x0; by = a.y1 - a.y0;
wz = (ax*by)-(ay*bx);
if (wz > 0) { c = 0x0000FF; w+= 1;}
else if (wz < 0) { c = 0xFF0000; w -= 1;}
}//nexti
return (w != 0);
}//ispointin
public function drawShape(g:Graphics, c:uint=0):void
{
var i:int; var num:int; var a:xLine;
var rx:Number;
var ry:Number;
var ca:Number;
var sa:Number;
ca = Math.cos(roll);
sa = Math.sin(roll);
g.beginFill(c,0.5);
//g.lineStyle();
num = vecLine.length;
for (i = 0; i < num; i++)
{
a = vecLine[i];
if (i == 0)
{
rx = a.x0*ca - a.y0*sa+cx;
ry = a.x0*sa + a.y0*ca+cy;
g.moveTo(rx, ry);
rx = a.x1*ca - a.y1*sa+cx;
ry = a.x1*sa + a.y1*ca+cy;
g.lineTo(rx, ry);
}
else
{
rx = a.x1*ca - a.y1*sa+cx;
ry = a.x1*sa + a.y1*ca+cy;
g.lineTo(rx, ry);
//g.lineTo(a.x1+cx, a.y1+cy);
}//endif
}//nexti
/*a = vecLine[0];
rx = a.x0*ca - a.y0*sa+cx;
ry = a.x0*sa + a.y0*ca+cy;
g.lineTo(a.x0+cx, a.y0+cy);
*/
g.endFill();
}//drawshape
public function genShape():void
{
vecLine = new Vector.<xLine>(0,false);
var ang:Number;
var kx:Number; var ky:Number;
var px:Number; var py:Number;
var d:Number;
var nx:Number; var ny:Number;
var mag:Number;
px = 0; py = 0;
for (ang = 0; ang < 6.28; ang+=0.5)
{
d = (Math.random()*60 + 30);
kx = Math.cos(ang) * d;
ky = Math.sin(ang) * d;
if (ang == 0) { px =kx; py= ky; continue; }
vecLine.push(new xLine(px,py,kx,ky) );
nx = -(py - ky);
ny = px - kx;
mag = Math.sqrt(nx*nx+ny*ny);
if (mag == 0) { mag =0.00001;}
nx /= mag; ny /= mag;
px = kx; py = ky;
}//nextang
vecLine.push(new xLine(kx,ky,vecLine[0].x0,vecLine[0].y0));
}//genshape
}//xshape
internal class xLine
{
public var x0:Number = 0;
public var y0:Number = 0;
public var x1:Number = 0;
public var y1:Number = 0;
public function xLine(ax:Number,ay:Number, bx:Number, by:Number):void
{
x0 = ax; y0 = ay; x1 = bx; y1 = by;
//calc normal (and midpoint) only needed for debugging
var mag:Number;
nx = -(y0 - y1);
ny = (x0 - x1);
mag = Math.sqrt(nx*nx+ny*ny);
if (mag == 0) { mag = 0.00001;}
nx /= mag;
ny /= mag;
cx = x0 +(x1-x0)*0.5;
cy = y0 +(y1-y0)*0.5;
}//xline
public var cx:Number = 0;
public var cy:Number = 0;
public var nx:Number = 0;
public var ny:Number = 0;
}//xline
