* Copyright jules ( http://wonderfl.net/user/jules )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/3Rd8
*/
package {
import flash.display.Sprite;
import flash.display.MovieClip;
import flash.display.Loader;
import flash.events.*;
import flash.net.URLRequest;
import flash.display.BitmapData;
import flash.display.Bitmap;
import flash.utils.ByteArray;
import flash.geom.Rectangle;
import flash.events.MouseEvent;
public class FlashTest extends Sprite {
public var bitmapdata:BitmapData = new BitmapData(800,600, false, 0x000000);
public var bitmap:Bitmap = new Bitmap(bitmapdata);
public var canvas:BitmapData = Bitmap(addChild(bitmap)).bitmapData;
public var mySpray:Spray = new Spray(canvas,0);
public function FlashTest() {
// write as3 code here..
stage.addEventListener(MouseEvent.MOUSE_DOWN, startSpray);
stage.addEventListener(MouseEvent.MOUSE_MOVE, moveSpray);
stage.addEventListener(MouseEvent.MOUSE_UP, stopSpray);
//addEventListener(MouseEvent.MOUSE_MOVE, test());
//addEventListener(MouseEvent.CLICK, test());
//canvas.addEventListener(MouseEvent.MOUSE_OVER, mouseOverHandler);
}
public function startSpray(event:MouseEvent):void{
//test();
mySpray.spray(mouseX,mouseY);
}
public function stopSpray(event:MouseEvent):void{
//test();
}
public function moveSpray(event:MouseEvent):void{
//test();
mySpray.spray(mouseX,mouseY);
}
public function test() {
for (var i:int = 0;i<50;i++) {
mySpray.spray(50* i,40*i);
}
}
}
}
import flash.display.BitmapData;
import flash.utils.ByteArray;
import flash.geom.Rectangle;
class Spray {
//constructor
public function Spray(canvas:BitmapData,type:int) {
class_canvas = canvas;
if (type == 0) { //dither
sprayType = 0;
trace("constructing dithering");
myRandom = new Random();
} else if (type == 1) { //gaussian
sprayType = 1;
trace("constructing gaussian");
generateKernel();
brush = 1;
}
}
//PROPERTIES***************************************************************/
public var class_canvas:BitmapData;
public var sprayType: int;
//private var r_seed:int = 12345678;
private var maxRadius:int = 25;
private var density:int = 9;
private var ditherColour:uint = 0x99f00000;//red colour.0x55f00000
private var brush:int = 2;
private var myRandom:Random;
//-------------------Gaussian Properties-------------------//
private var stDev:Number = 7;
private var kernelSize:int = 51;
private var kernelStart:int = 3;
private var kernelFinish:int = -3;
public var kernel:Array;
//Colour stuff
private var a:uint = 0;
private var r:uint = 0;
private var g:uint = 0;
private var b:uint = 0;
private var a2:uint = 0;
private var r2:uint = 0;
private var g2:uint = 0;
private var b2:uint = 0;
private var currVal:uint;
private var test:uint;
private var kernelVal:Number;
//END OF PROPERTIES***************************************************************/
//METHODS
public function setBrush(size:int):void {
brush = size;
trace("brush is now: " + brush);
}
public function spray(x:int,y:int):void {
if (sprayType == 0) {
ditherSpray(x,y);
} else if (sprayType == 1) {
gaussianSpray(x,y);
}
}//end spray funcrion
public function ditherSpray(x:Number,y:Number):void {
//taken from flash example on net, cant remember where
for (var i:int = 0; i < density; i++) {
var angle:Number = myRandom.uniform() * Math.PI * 2;
var radius:Number = myRandom.uniform() * maxRadius;
var x1:int = x + Math.cos(angle) * radius;
var y1:int = y + Math.sin(angle) * radius;
/*end flash ex*/
paint(x1,y1,ditherColour);
}//end for
}
public function paint(x,y,colour):void {
//colour = colour+20; uncomment this for changing colours
for (var i:int = 0; i<brush; i++) {
for (var j:int = 0; j<brush; j++) {
class_canvas.setPixel32(x+i,y+j,colour);
}
}
}
//*****************************GAUSSIAN SPRAY METHODS******************************//
public function gaussian(x:int,y:int):Number {
var i:Number = (1 / (2 * Math.PI * Math.pow(stDev,2)));
//=(1/(2*PI()*POWER(stdev,2)))
var j:Number = Math.exp(- ((Math.pow(x,2) + Math.pow(y,2)) / (2 * Math.pow(stDev,2))));
//=EXP(-((POWER(I20,2)+POWER(J20,2))/(2*POWER(stdev,2))))
return i * j;
}
public function generateKernel():void {
//generate a blank kernel
trace("generating kernel");
var i:Number;
var j:Number;
kernel = new Array(kernelSize);
kernelStart = Math.floor(kernelSize/2);
kernelFinish = - Math.floor(kernelSize/2);
for (i=kernelStart; i >= kernelFinish; i--) {
kernel[i] = new Array(kernelSize);
for (j=kernelStart; j >= kernelFinish; j--) {
kernel[i][j] = gaussian(Math.abs(i),Math.abs(j));
}
}
var oldMax:Number = kernel[0][0];//centre of the kernel will be the max value
var oldMin:Number = kernel[kernelStart][kernelStart];//top left of the kernel should always be the min value
scaleKernel(oldMin,oldMax,0,255);
}//end generateKernel function
private function scaleKernel(oldMin:int,oldMax:int,newMin:int,newMax:int):void {
var i:int;
var j:int;
trace("scaling kernel");
//trace("kerne " + kernel[1][1]);
for (i=kernelStart; i >= kernelFinish; i--) {
for (j=kernelStart; j >= kernelFinish; j--) {
kernel[i][j] = Math.round(((kernel[i][j] - oldMin) / oldMax)*50);
//trace(kernel[i][j]);
}
}
}
public function gaussianSpray(x:int,y:int):void {
//currVal = 0x60FF00DD;
//trace("stdev: " + stDev);
for (var i:int=kernelStart; i >= kernelFinish; i--) {
for (var j:int=kernelStart; j >= kernelFinish; j--) {
currVal = class_canvas.getPixel32(x+i,y+j);
//trace(currVal);
var argb:Array = HexToARGB(currVal);
kernelVal = kernel[i][j];
r2 = addColour(argb[1],kernelVal);
a2 = addAlpha(argb[0],kernelVal);
//trace(r2);
//test = ARGBToHex(argb[0],r2,argb[2],argb[3]);
test = ARGBToHex(a2,r2,argb[2],argb[3]);
paint(x+i,y+j,test);
}
}
}//End gaussian spray method
private function RGBToHex(r:uint, g:uint, b:uint):uint {
var hex:uint = (r << 16 | g << 8 | b);
return hex;
}
private function ARGBToHex(a:uint, r:uint, g:uint, b:uint):uint {
var hex:uint = (a << 24 | r << 16 | g << 8 | b);
return hex;
}
private function HexToRGB(hex:uint):Array {
var rgb:Array = [];
var r:uint = hex >> 16 & 0xFF;
var g:uint = hex >> 8 & 0xFF;
var b:uint = hex & 0xFF;
rgb.push(r, g, b);
return rgb;
}
//probably needs reference
private function HexToARGB(hex:uint):Array {
var argb:Array = [];
var a:uint = hex >> 24 & 0xFF;
var r:uint = hex >> 16 & 0xFF;
var g:uint = hex >> 8 & 0xFF;
var b:uint = hex & 0xFF;
argb.push(a,r, g, b);
return argb;
}
private function addAlpha(oldC:Number,newC:Number):Number {
var temp:Number = oldC+newC;
if (temp > 200) {
return 200;
} else {
return temp;
}
}
private function addColour(oldC:Number,newC:Number):Number {
var temp:Number = oldC+newC;
if (temp > 255) {
return 255;
} else {
return temp;
}
}
private function subtractColour(oldC:Number,newC:Number):Number {
var temp:Number = oldC-newC;
if (temp < 0) {
return 0;
} else {
return temp;
}
}
public function setstDev(newstDev:Number):void {
stDev = newstDev;
trace("stdev: "+ stDev);
}
public function setSize(newSize:int):void {
kernelSize = newSize;
trace("kernelSize: "+kernelSize);
}
}//end class
class Random {
//constructor
//constructor takes a seed value or defaults to use 12345678 if constructor parameter is empty
public function Random(seed:int = 12345678) {
r_seed = seed;
}
//properties***************************************************************/
public var r_seed:int;
// Basic Lehmer generator - constants
private var m:int = 2147483647;
private var a:int = 48271;
private var q:int = 44488;
private var r:int = 3399;
// private var r_seed:int = 12345678;
//METHODS*******************************************/
// Basic Lehmer generator - uniform[0,1]
// For more information see Knuth, Vol. II.
public function uniform():Number {
var hi:int = r_seed / q;
var lo:int = r_seed - q * hi;
var t:int = a * lo - r * hi;
if (t > 0) {
r_seed = t;
} else {
r_seed = t + m;
}
var returnValue:Number = r_seed / m;
//trace("r_seed=" + r_seed + " m=" + m + " returnValue=" + returnValue);
return returnValue;
}
public function test():void {
trace("testing method in random class");
}
}//end class
