forked from: Sea of Clouds

/**
 * Copyright bradsedito ( http://wonderfl.net/user/bradsedito )
 * MIT License ( http://www.opensource.org/licenses/mit-license.php )
 * Downloaded from: http://wonderfl.net/c/2eup
 */

// forked from tencho's Sea of Clouds
/**
 * 雲海のテスト
 * クリックでカメラを切り替えられます（操作はできません）
 * BitmapData.draw()を毎フレーム何十回もやってるので結構重いです
 * 雲の数を200～300にするといい感じに雲海になるんですが重すぎて断念
 *
 * （追加修正）
 * ・カメラを少し調整しました
 * ・初期化時の雲画像生成が重いのでプログレスバーをつけました
 * ・ごく稀に穴だらけの雲が出来るバグを修正
 * ・低画質で遠景画像を傾けた時のぶれを修正
 * ・穴だらけのバグが直ってなかったのでさらに修正（検証→http://wonderfl.net/c/d01w）
 * ・恥ずかしい間違いを修正＞＜
 */
package  {
    import flash.display.Bitmap;
    import flash.display.BitmapData;
    import flash.display.Sprite;
    import flash.events.Event;
    import flash.events.MouseEvent;
    import flash.filters.GlowFilter;
    import flash.geom.ColorTransform;
    import flash.geom.Matrix;
    import flash.geom.Point;
    import flash.utils.getTimer;
    import net.hires.debug.Stats;
    import org.papervision3d.core.geom.renderables.Vertex3D;
    import org.papervision3d.core.math.Number3D;
    import org.papervision3d.materials.ColorMaterial;
    import org.papervision3d.materials.utils.MaterialsList;
    import org.papervision3d.objects.DisplayObject3D;
    import org.papervision3d.objects.primitives.Cube;
    import org.papervision3d.objects.primitives.Plane;
    import org.papervision3d.Papervision3D;
    import org.papervision3d.view.BasicView;
    [SWF(width = "465", height = "465", frameRate = "30", backgroundColor = "#000000")]
    public class Cloud extends Sprite {
        private var PI:Number;
        private var time:int = 0;
        //雲の数
        private var cloudNum:int = 100;
        private var loading:LoadingScene;
        private var loadCount:int = 0;
        private var bv:BasicView;
        private var cameraTarget:DisplayObject3D;
        private var horizonTarget:DisplayObject3D;
        private var plane:DisplayObject3D;
        private var smokes:Vector.<Smoke>;
        private var cameraRotation:Number = 0;
        private var cameraAngle:Number = 100;
        private var cameraRoll:Number = 0;
        private var cameraDist:Number = 500;
        private var canvas1:BitmapData;
        private var canvas2:BitmapData;
        private var farCloud:Sprite;
        private var bg:BackGround;
        private var sea:Sprite;
        private var cameraMode:int = 0;
        private var planeMaterial:ColorMaterial;
        private var wingMaterial:ColorMaterial;
        private var startTime:int;
        //コンストラクタ
        public function Cloud() {
            Wonderfl.capture_delay(7);
            Param.init();
            PI = Math.PI / 180;
            stage.frameRate = 60;
            stage.quality = "low";
            Papervision3D.PAPERLOGGER.unregisterLogger(Papervision3D.PAPERLOGGER.traceLogger);
            bv = new BasicView(Param.display.width, Param.display.height, false, false, "Free");
            planeMaterial = new ColorMaterial(Param.planeColor, 1);
            wingMaterial = new ColorMaterial(Param.planeColor, 1);
            wingMaterial.doubleSided = true;
            cameraTarget = bv.scene.addChild(new DisplayObject3D());
            horizonTarget = bv.scene.addChild(new DisplayObject3D());
            horizonTarget.autoCalcScreenCoords = true;
            addChild(Painter.createGradientRect(Param.display.width, Param.display.height, [Param.skyColor1], [1]));
            sea = addChild(Painter.createGradientRect(Param.display.width, Param.display.height, [Param.seaColor], [1])) as Sprite;
            bg = addChild(new BackGround()) as BackGround;
            bg.x = Param.display.width / 2;
            bg.mask = addChild(Painter.createGradientRect(Param.display.width, Param.display.height, [0x000000], [1]));
            canvas1 = new BitmapData(Param.display.width, Param.display.height, true, 0x00FFFFFF);
            canvas2 = new BitmapData(Param.display.width, Param.display.height, true, 0x00FFFFFF);
            addChild(new Bitmap(canvas1));
            addChild(bv.viewport);
            addChild(new Bitmap(canvas2));
            addChild(new Stats());
            //雲生成
            smokes = new Vector.<Smoke>();
            for (var i:int = 0; i < cloudNum; i++) {
                var smoke:Smoke = new Smoke(bv.scene);
                smokes.push(smoke);
                smoke.setPosition(Math.random() * 3500 - 1750, Math.random() * -300 + 10000, Math.random() * 4000 - 2000);
            }
            plane = bv.scene.addChild(createAirPlain());
            plane.rotationY = -90;
            plane.y = 10000;
            plane.scale = 0.5;
            plane.autoCalcScreenCoords = true;
            bv.viewport.filters = [new GlowFilter(Param.outlineColor, 1, 3, 3, 6, 1)];
            //
            loading = addChild(new LoadingScene()) as LoadingScene;
            addEventListener(Event.ENTER_FRAME, onLoading);
        }
        private function onClick(e:MouseEvent):void {
            cameraMode = (cameraMode + 1) % 5;
        }
        //画像生成中
        private function onLoading(...arg):void {
            for (var i:int = 0; i < 3; i++) {
                if(loadCount >= smokes.length){
                    removeEventListener(Event.ENTER_FRAME, onLoading);
                    start()
                    break;
                }
                var smoke:Smoke = smokes[loadCount];
                smoke.changeImage();
                loadCount++;
                loading.setPercentage(loadCount / smokes.length);
            }
        }
        //レンダリング開始
        private function start():void {
            stage.addEventListener(MouseEvent.CLICK, onClick);
            startTime = getTimer();
            removeChild(loading);
            addEventListener(Event.ENTER_FRAME, onEnter);
            onEnter();
        }
        //毎フレーム処理
        private function onEnter(...arg):void {
            time = getTimer() - startTime + 7000;
            plane.rotationZ = Math.sin(PI * time / 150) * 30;
            var area:int = 2000;
            //雲を動かす
            for each(var sm:Smoke in smokes) {
                sm.do3d.z = ((sm.startPosition.z + time * 0.42) + area) % (area * 2) - area;
                var loop:int = int(((sm.startPosition.z + time * 0.42) + area) / (area * 2));
                if (sm.loop != loop) {
                    sm.loop = loop;
                    sm.do3d.x = Math.random() * 3500 - 1750;
                    sm.do3d.y = Math.random() * -300 + 10000;
                }
            }
            //カメラ移動
            switch(cameraMode) {
                case 0:
                    cameraDist = Math.sin(PI * time / 80) * 200 + 600;
                    cameraRotation = time / 1000 * 60 * 0.2;
                    cameraRoll = Math.sin(PI * time / 50) * 20;
                    cameraAngle = Math.sin(PI * time / 100) * 100 + 50;
                    cameraTarget.position = new Number3D(0, 10000, 0);
                    break;
                case 1:
                    cameraDist = 280;
                    cameraRotation = Math.sin(PI * time / 110) * 20 + 90;
                    cameraRoll = -plane.rotationZ;
                    cameraAngle = Math.sin(PI * time / 90) * 50 + 30;
                    cameraTarget.position = new Number3D(0, 10000, -10000);
                    break;
                case 2:
                    cameraDist = 500;
                    cameraRotation = Math.sin(PI * time / 110) * 10;
                    cameraRoll = 0;
                    cameraAngle = Math.sin(PI * -time / 70) * 200;
                    cameraTarget.position = new Number3D(0, 10000, 0);
                    break;
                case 3:
                    cameraDist = 800;
                    cameraRotation = -time / 200;
                    cameraRoll = 0;
                    cameraAngle = -400;
                    cameraTarget.position = new Number3D(0, 10000, 0);
                    break;
                case 4:
                    cameraDist = 50;
                    cameraRotation = 90;
                    cameraRoll = -plane.rotationZ/2;
                    cameraAngle = 30 + plane.rotationZ;
                    cameraTarget.position = new Number3D(1000, 10000, -700);
                    break;
            }
            bv.camera.position = new Number3D(Math.cos(PI*cameraRotation)*cameraDist, cameraAngle+10000, Math.sin(PI*cameraRotation)*cameraDist);
            bv.camera.lookAt(cameraTarget);
            bv.camera.roll(cameraRoll);
            var crot:Number = Math.atan2(cameraTarget.z - bv.camera.z, cameraTarget.x - bv.camera.x);
            //地平線用ダミーモデルをカメラの前方に配置
            horizonTarget.position = new Number3D(Math.cos(crot) * 500000, 0, Math.sin(crot) * 500000);
            //PV3Dレンダリング
            bv.renderer.renderScene(bv.scene, bv.camera, bv.viewport);
            //背景画像を地平線の高さに移動
            bg.y = int(horizonTarget.screen.y + Param.center.y);
            bg.rotation = cameraRoll;
            bg.setPositionPer(crot / PI / 360);
            sea.visible = horizonTarget.screen.y + Param.center.y < Param.display.height;
            //雲画像処理
            canvas1.fillRect(Param.display, 0x00FFFFFF);
            canvas2.fillRect(Param.display, 0x00FFFFFF);
            smokes.sort(function(a:Smoke, b:Smoke):Number { return int(a.scale > b.scale) - int(a.scale < b.scale); } );
            for each(var smoke:Smoke in smokes) {
                smoke.refresh();
                if (smoke.do3d.screen.z > 10 && smoke.alpha) {
                    var target:BitmapData = (plane.screen.z < smoke.do3d.screen.z)? canvas1 : canvas2;
                    var ct:ColorTransform = new ColorTransform(1, 1, 1, smoke.alpha, 0, 0, 0, 0);
                    var mat:Matrix = new Matrix();
                    mat.scale(smoke.scale, smoke.scale);
                    mat.rotate(PI * bv.camera.localRotationZ);
                    var offsetX:Number = smoke.scale * smoke.imageSize.width / 2;
                    var offsetY:Number = smoke.scale * smoke.imageSize.height / 2;
                    var xp:Number = smoke.do3d.screen.x + Param.center.x - (Math.cos(PI * cameraRoll) * offsetX - Math.sin(PI * cameraRoll) * offsetY);
                    var yp:Number = smoke.do3d.screen.y + Param.center.y - (Math.sin(PI * cameraRoll) * offsetX + Math.cos(PI * cameraRoll) * offsetY);
                    mat.translate(xp, yp);
                    target.draw(smoke.image, mat, ct);
                }
            }
        }
        //航空機モデルを生成
        private function createAirPlain():DisplayObject3D {
            var i:int;
            var plane:DisplayObject3D = new DisplayObject3D();
            var d:DisplayObject3D = plane.addChild(new DisplayObject3D());
            var body:Plane = new Plane(planeMaterial, 446, 46, 3, 2);//23
            for (i = 0; i <= 2; i++) body.geometry.vertices[i].y = [-12, -6, 0][i];
            for (i = 3; i <= 5; i++) body.geometry.vertices[i].x = -178;
            for (i = 6; i <= 8; i++) body.geometry.vertices[i].x = 77;
            for (i = 9; i <= 11; i++) body.geometry.vertices[i].y = [7, 15, 23][i-9];
            for (i = 4; i <= 7; i += 3) body.geometry.vertices[i].z = -22;
            var wing:Plane = new Plane(wingMaterial, 190, 96, 2, 1);
            for (i = 0; i <= 5; i++) wing.geometry.vertices[i].x = [0, 64, 190][int(i / 2)];
            for (i = 0; i <= 5; i++) wing.geometry.vertices[i].y = [0, 96, 53, 117, 165, 190][i];
            for (i = 2; i <= 5; i++) wing.geometry.vertices[i].z = [ -5, -12][int((i - 2) / 2)];
            wing.position = new Number3D( -86, -10, -10);
            wing.rotationZ = -90;
            wing.rotationY = 90;
            var wing2:Plane = new Plane(wingMaterial, 66, 72, 1, 1);
            for (i = 0; i <= 3; i++) {
                wing2.geometry.vertices[i].x = [0, 0, 72, 72][i];
                wing2.geometry.vertices[i].y = [0, 66, 72, 100][i];
            }
            wing2.rotationZ = -90;
            wing2.rotationY = 90;
            wing2.position = new Number3D(148,10,0);
            var wing3:Plane = new Plane(wingMaterial, 82, 64, 1, 1);
            for (i = 0; i <= 3; i++) {
                wing3.geometry.vertices[i].x = [0, 82, 82, 110][i];
                wing3.geometry.vertices[i].y = [0, 0, 64, 64][i];
            }
            wing3.position = new Number3D(130, 21, 0);
            d.addChild(body);
            d.addChild(wing);
            d.addChild(wing2);
            var engine1:Cube = d.addChild(new Cube(new MaterialsList( { all:planeMaterial } ), 48, 16, 16, 1, 1, 1)) as Cube;
            var engine2:Cube = d.addChild(new Cube(new MaterialsList( { all:planeMaterial } ), 48, 16, 16, 1, 1, 1)) as Cube;
            engine1.position = new Number3D(-20, -15, 64);
            engine2.position = new Number3D(40, -15, 137);
            engine1.rotationX = engine2.rotationX = 45;
            plane.addChild(wing3);
            var frip:DisplayObject3D = plane.addChild(d.clone());
            frip.scaleZ *= -1;
            for each(var model:DisplayObject3D in frip.children) model.geometry.flipFaces();
            return plane.alpha = 0;
        }
    }
}
import flash.display.Bitmap;
import flash.display.BitmapData;
import flash.display.Sprite;
import flash.display.Stage;
import flash.events.Event;
import flash.filters.BevelFilter;
import flash.filters.BlurFilter;
import flash.filters.ColorMatrixFilter;
import flash.filters.GlowFilter;
import flash.geom.Matrix;
import flash.geom.Point;
import flash.geom.Rectangle;
import org.papervision3d.core.math.Number3D;
import org.papervision3d.objects.DisplayObject3D;
import org.papervision3d.scenes.Scene3D;
//各種パラメータ
class Param {


    static public var center:Point;
    static public var display:Rectangle;
    //航空機の色
    static public var planeColor:uint = 0xFFFFFF;
    //航空機のアウトライン
    static public var outlineColor:uint = 0x40699E;
    //雲の色
    static public var cloudColor:uint = 0xFFD7DDE5;
    //雲のハイライト色
    static public var lightColor:uint = 0xFFFFFF;
    //雲の影の色
    static public var shadowColor:uint = 0x294A59;
    //空の色（上）
    static public var skyColor1:uint = 0x1F437F;
    //空の色（下）
    static public var skyColor2:uint = 0x6290C1;
    //地平線付近の色
    static public var horizonColor:uint = 0xA0BCD1;
    //地上の色
    static public var seaColor:uint = 0x7D8C98;
    public function Param() { }
    static public function init():void {
            display = new Rectangle(0, 0, 465, 465);
            center = new Point(display.width / 2, display.height / 2);
    }
}
class Painter {
    public function Painter() { }
    static private var errorSeed:Array = [346, 514, 1155, 1519, 1690, 1977, 2327, 2337, 2399, 2860, 2999, 3099, 4777, 4952, 5673, 6265, 7185, 7259, 7371, 7383, 7717, 7847, 8032, 8350, 8676, 8963, 8997, 9080, 9403, 9615, 9685];
    //雲画像生成
    static public function createCloud(width:int, height:int, type:Boolean = true):BitmapData {
        var gradiation:Sprite = new Sprite();
        var drawMatrix:Matrix = new Matrix();
        drawMatrix.createGradientBox(width, height);
        gradiation.graphics.beginGradientFill("radial", [0x000000, 0x000000], [0, 1], [0, 255], drawMatrix);
        gradiation.graphics.drawRect(0, 0, width, height);
        gradiation.graphics.endFill();
        var alphaBmp:BitmapData = new BitmapData(width, height);
        var seed:int = int(Math.random() * 10000);
        //perlinNoise画像の1つのチャンネルにブロック状の穴が発生するランダムシード値があるので危ない値は避ける
        if (errorSeed.indexOf(seed) != -1) seed++;
        alphaBmp.perlinNoise(width / 3, height / 2.5, 5, seed, false, true, 1|2|4, false);
        var zoom:Number = (type)? 1.8 : 1.1;
        var ct:Number = (type)? 1.6 : 0.2;
        var ctMatrix:Array = [ct + 1, 0, 0, 0, -(128 * ct), 0, ct + 1, 0, 0, -(128 * ct), 0, 0, ct + 1, 0, -(128 * ct), 0, 0, 0, 1, 0];
        alphaBmp.draw(gradiation, new Matrix(zoom, 0, 0, zoom, -(zoom - 1) / 2 * width, -(zoom - 1) / 2 * height));
        alphaBmp.applyFilter(alphaBmp, alphaBmp.rect, new Point(), new ColorMatrixFilter(ctMatrix));
        var image:BitmapData = new BitmapData(width, height, true, Param.cloudColor);
        image.copyChannel(alphaBmp, alphaBmp.rect, new Point(), 4, 8);
        image.applyFilter(image, image.rect, new Point(), new GlowFilter(Param.lightColor, 1, 4, 4, 1, 3, true));
        var bsize:Number = Math.min(width, height) / 30;
        image.applyFilter(image, image.rect, new Point(), new BevelFilter(bsize, 45, Param.lightColor, 1, Param.shadowColor, 1, bsize/5, bsize/5, 1, 3));
        alphaBmp.dispose();
        return image;
    }
    //グラデーションスプライト生成
    static public function createGradientRect(w:Number, h:Number, colors:Array, alphas:Array, ratios:Array = null, r:Number = 0):Sprite {
        var rts:Array = new Array();
        if(ratios == null){
            for (var n:int = 0; n < colors.length; n++) rts.push(int(255 * n / (colors.length - 1)));
        } else {
            for (var m:int = 0; m < ratios.length; m++) rts[m] = Math.round(ratios[m] * 255);
        }
        var sp:Sprite = new Sprite();
        var mat:Matrix = new Matrix();
        mat.createGradientBox(w, h, Math.PI / 180 * r, 0, 0);
        if (colors.length == 1 && alphas.length == 1) sp.graphics.beginFill(colors[0], alphas[0]);
        else sp.graphics.beginGradientFill("linear", colors, alphas, rts, mat);
        sp.graphics.drawRect(0, 0, w, h);
        sp.graphics.endFill();
        return sp;
    }
}
//遠景画像
class BackGround extends Sprite {
    private var farWidth:int = 2000;
    private var farHeight:int = 20;
    private var viewWidth:int = 600;
    private var viewImage:BitmapData;
    private var farImage:BitmapData;
    public function BackGround() {
        var sky:Sprite = addChild(Painter.createGradientRect(Param.display.width*2, Param.display.height, [Param.skyColor1, Param.skyColor2, Param.horizonColor], [1, 1, 1], [0, 0.9, 1], 90)) as Sprite;
        sky.x = -Param.display.width;
        sky.y = -Param.display.height;
        var ground:Sprite = addChild(Painter.createGradientRect(Param.display.width*2, Param.display.height, [Param.horizonColor, Param.seaColor], [1, 1], null, 90)) as Sprite;
        ground.y = -1;
        ground.x = -Param.display.width;
        //遠景画像作成
        farImage = new BitmapData(farWidth + viewWidth, farHeight, true, 0x00FFFFFF);
        for (var n:int = 0; n < 40; n++) {
            var cloud:BitmapData = Painter.createCloud(80, 20, true);
            farImage.copyPixels(cloud, cloud.rect, new Point(Math.random() * 1960, farHeight - 20), null, null, true);
        }
        farImage.applyFilter(farImage, farImage.rect, new Point(), new BlurFilter(2, 2, 1));
        farImage.copyPixels(farImage, new Rectangle(0, 0, viewWidth, farHeight), new Point(farWidth, 0));
        viewImage = new BitmapData(viewWidth, farHeight, true, 0x88FFFFFF);
        var img:Bitmap = addChild(new Bitmap(viewImage)) as Bitmap;
        img.x = -viewWidth / 2;
        img.y = -farHeight;
    }
    public function setPositionPer(per:Number):void {
        per = ((per % 1) +1) % 1;
        var px:int = int(farWidth * (1 - per));
        viewImage.copyPixels(farImage, new Rectangle(px, 0, viewWidth, farHeight), new Point(0, 0));
    }
}
//画像生成中画面
class LoadingScene extends Sprite {
    private var lineWidth:Number = 200;
    private var loadedLine:Sprite;
    public function LoadingScene() {
        var bg:Sprite = addChild(Painter.createGradientRect(Param.display.width, Param.display.height, [0x000000], [1])) as Sprite;
        var baseLine:Sprite = addChild(Painter.createGradientRect(lineWidth, 2, [0x444444], [1])) as Sprite;
        loadedLine = addChild(Painter.createGradientRect(lineWidth, 2, [0x7DA3C8], [1])) as Sprite;
        baseLine.x = loadedLine.x = int((Param.display.width - lineWidth) / 2);
        baseLine.y = loadedLine.y = int((Param.display.height - baseLine.height) / 2);
        setPercentage(0);
    }
    public function setPercentage(per:Number):void {
        loadedLine.width = lineWidth * per;
    }
}
//雲
class Smoke {
    public var do3d:DisplayObject3D;
    public var image:BitmapData;
    public var imageSize:Rectangle;
    public var alpha:Number;
    public var scale:Number;
    public var loop:int;
    public var startPosition:Number3D;
    public function Smoke(scene:Scene3D) {
        do3d = scene.addChild(new DisplayObject3D());
        do3d.autoCalcScreenCoords = true;
        do3d.position = new Number3D();
        imageSize  = new Rectangle(0, 0, 400, 200);
    }
    public function changeImage():void {
        image = Painter.createCloud(imageSize.width, imageSize.height, Math.random() > 0.3);
    }
    //雲の初期位置を設定
    public function setPosition(x:Number, y:Number, z:Number):void {
        startPosition = new Number3D(x, y, z);
        do3d.position = startPosition.clone();
    }
    //スケールと透明度を更新
    public function refresh():void {
        scale = 700 / do3d.screen.z;
        var per1:Number = Math.max(0, Math.min(1, do3d.screen.z / 100));
        var per2:Number = Math.max(0, Math.min(1, 1 - (do3d.screen.z - 1500) / 800));
        alpha = per1 * per2 * 2;
    }
}
