* Copyright greentec ( http://wonderfl.net/user/greentec )
* MIT License ( http://www.opensource.org/licenses/mit-license.php )
* Downloaded from: http://wonderfl.net/c/2RjF
*/
package {
import away3d.cameras.Camera3D;
import away3d.containers.Scene3D;
import away3d.containers.View3D;
import away3d.controllers.HoverController;
import away3d.debug.AwayStats;
import away3d.entities.Mesh;
import away3d.lights.PointLight;
import away3d.materials.ColorMaterial;
import away3d.primitives.CubeGeometry;
import away3d.lights.DirectionalLight;
import away3d.materials.lightpickers.StaticLightPicker;
import com.bit101.components.PushButton;
import com.bit101.components.Label;
import flash.display.*;
import flash.events.*;
import flash.geom.*;
public class FlashTest extends Sprite {
private var view:View3D;
private var scene:Scene3D;
private var camera:Camera3D;
private var awayStats:AwayStats;
private var cameraController:HoverController;
private var light:DirectionalLight;
private var lightPicker:StaticLightPicker;
private var pointLight:PointLight;
private var pointLight2:PointLight;
private var colorMaterial:ColorMaterial;
//navigation variables
private var move:Boolean = false;
private var lastPanAngle:Number;
private var lastTiltAngle:Number;
private var lastMouseX:Number;
private var lastMouseY:Number;
public var maxStem:int = 600;
public var stemCount:int = 0;
public var stemLength:int = 150;
public var stemRadius:int = 60;
public var stemThick:int = 20;
public var angleDiff:int = 90;
public var depthMax:int = 9;
public var stemPool:Array = [];
public var _label:Label;
public function FlashTest() {
// write as3 code here..
Wonderfl.disable_capture();
stage.scaleMode = StageScaleMode.NO_SCALE;
stage.align = StageAlign.TOP_LEFT;
initEngine();
initLight();
initMaterial();
initObject();
initListener();
var button:PushButton = new PushButton(this, 465 - 110, 10, "Reset", onReset);
_label = new Label(this, button.x, 30, "");
}
private function onReset(e:Event):void
{
stemCount = 0;
var colorArray:Array;
colorArray = hsv(Math.random() * 360, 1, 1);
pointLight.color = colorArray[0] << 16 | colorArray[1] << 8 | colorArray[2];
colorArray = hsv(Math.random() * 360, 1, 1);
pointLight2.color = colorArray[0] << 16 | colorArray[1] << 8 | colorArray[2];
var i:int;
var stem:Mesh;
for (i = 0; i < maxStem; i += 1)
{
stem = stemPool[i];
stem.visible = false;
}
initStem();
}
private function initEngine():void
{
view = new View3D();
view.antiAlias = 4;
scene = view.scene;
camera = view.camera;
camera.lens.far = 5000;
cameraController = new HoverController(camera);
cameraController.distance = 800;
cameraController.panAngle = 45;
cameraController.tiltAngle = 20;
awayStats = new AwayStats(view);
}
private function initLight():void
{
light = new DirectionalLight( 0.5, -1, 1);
light.color = 0xffffff;
light.ambient = 0.4;
//scene.addChild(light);
pointLight = new PointLight();
var colorArray:Array;
colorArray = hsv(Math.random() * 360, 1, 1);
pointLight.color = colorArray[0] << 16 | colorArray[1] << 8 | colorArray[2];
pointLight.specular = 1;
pointLight.diffuse = 0.8;
pointLight.x = Math.random() * 200 - 100;
pointLight.z = Math.random() * 200 - 100;
pointLight.y = -100;
pointLight2 = new PointLight();
colorArray = hsv(Math.random() * 360, 1, 1);
pointLight2.color = colorArray[0] << 16 | colorArray[1] << 8 | colorArray[2];
pointLight2.specular = 1;
pointLight2.diffuse = 0.8;
pointLight2.x = -pointLight.x;
pointLight2.z = -pointLight.z;
pointLight.y = -100;
lightPicker = new StaticLightPicker([light, pointLight, pointLight2]);
}
private function initMaterial():void
{
colorMaterial = new ColorMaterial(0x292929);
colorMaterial.lightPicker = lightPicker;
colorMaterial.specular = 0.3;
}
private function initObject():void
{
stemPool = [];
var i:int;
for (i = 0; i < maxStem; i += 1)
{
var stem:Mesh = new Mesh(new CubeGeometry());
stemPool.push(stem);
scene.addChild(stem);
stem.visible = false;
}
initStem();
}
private function initStem():void
{
var stem:Mesh;
var startX:Number = 0;
var startY:Number = -200;
var startZ:Number = 0;
var angle:Number = 0;
stem = stemPool[stemCount];
stem.geometry = new CubeGeometry(stemThick, stemLength, stemThick, 1, 1, 1, false);
stem.material = colorMaterial;
stem.y = startY;
stem.visible = true;
//scene.addChild(stem);
stemCount += 1;
makeStem(startX, startY, startZ, 60, 1);
makeStem(startX, startY, startZ, 180, 1);
makeStem(startX, startY, startZ, 300, 1);
//trace(stemCount);
}
private function makeStem(startX:Number, startY:Number, startZ:Number, angle:Number, depth:int):void
{
if (stemCount >= maxStem || depth >= depthMax)
{
return;
}
var scale:Number = (depthMax - depth + 3) / depthMax;
var newHeight:Number = stemLength * scale;
var dx:Number = Math.cos(angle * Math.PI / 180) * stemRadius * scale;
var dy:Number = newHeight;
var dz:Number = Math.sin(angle * Math.PI / 180) * stemRadius * scale;
var newLength:Number = Math.sqrt(dx * dx + dy * dy + dz * dz);
var stem:Mesh = stemPool[stemCount];
stem.geometry = new CubeGeometry(stemThick * scale,
newLength,
stemThick * scale,
1,
1,
1,
false);
stem.material = colorMaterial;
stem.x = startX + dx;
stem.y = startY;
stem.z = startZ + dz;
var theta:Number = Math.acos(dy / newLength) * 180 / Math.PI;
var phi:Number = Math.atan2(dz, dx) * 180 / Math.PI;
stem.y += Math.sin(theta / 180 * Math.PI) * newLength;
stem.rotationX = 0;
stem.rotationY = 0;
stem.rotationZ = 0;
/*
var m:Matrix3D = new Matrix3D();
m.prependRotation( -theta - 90, new Vector3D(1, 0, 0));
m.prependRotation( -phi + 90, Vector3D.Y_AXIS);
var vec:Vector3D = m.decompose()[1];
stem.rotationX = vec.x;
stem.rotationY = vec.y;
stem.rotationZ = vec.z;
*/
//stem.rotate(Vector3D.X_AXIS, -theta - 90);
//stem.rotate(Vector3D.Y_AXIS, -phi + 90);
//stem.rotate(new Vector3D(1, 0, 0), -theta - 90);
//stem.rotate(Vector3D.Y_AXIS, -phi + 90);
stem.transform.prependRotation( -theta - 90, Vector3D.X_AXIS);
stem.transform.prependRotation( -phi + 90, Vector3D.Y_AXIS);
//scene.addChild(stem);
stem.visible = true;
stemCount += 1;
if (Math.random() < 0.85)
{
makeStem(stem.x + dx, stem.y, stem.z + dz, angle + angleDiff * Math.random(), depth + 1);
}
if (Math.random() < 0.85)
{
makeStem(stem.x + dx, stem.y, stem.z + dz, angle - angleDiff * Math.random(), depth + 1);
}
}
private function initListener():void
{
stage.addEventListener(MouseEvent.MOUSE_DOWN, onMouseDown);
stage.addEventListener(MouseEvent.MOUSE_UP, onMouseUp);
stage.addEventListener(Event.RESIZE, resizeHandler);
addEventListener(Event.ENTER_FRAME, render);
addChild(view);
addChild(awayStats);
}
private function render(e:Event):void
{
if (move)
{
cameraController.panAngle = 0.3 * (stage.mouseX - lastMouseX) + lastPanAngle;
cameraController.tiltAngle = 0.3 * (stage.mouseY - lastMouseY) + lastTiltAngle;
}
view.render();
//view.renderer.queueSnapshot(source);
}
private function onMouseDown(e:MouseEvent):void
{
lastPanAngle = cameraController.panAngle;
lastTiltAngle = cameraController.tiltAngle;
lastMouseX = stage.mouseX;
lastMouseY = stage.mouseY;
move = true;
}
private function onMouseUp(e:MouseEvent):void
{
move = false;
}
private function resizeHandler(e:Event):void
{
view.width = stage.stageWidth;
view.height = stage.stageHeight;
}
private function hsv(h:Number, s:Number, v:Number):Array{
var r:Number, g:Number, b:Number;
var i:int;
var f:Number, p:Number, q:Number, t:Number;
if (s == 0){
r = g = b = v;
return [Math.round(r * 255), Math.round(g * 255), Math.round(b * 255)];
}
h /= 60;
i = Math.floor(h);
f = h - i;
p = v * (1 - s);
q = v * (1 - s * f);
t = v * (1 - s * (1 - f));
switch( i ) {
case 0:
r = v;
g = t;
b = p;
break;
case 1:
r = q;
g = v;
b = p;
break;
case 2:
r = p;
g = v;
b = t;
break;
case 3:
r = p;
g = q;
b = v;
break;
case 4:
r = t;
g = p;
b = v;
break;
default: // case 5:
r = v;
g = p;
b = q;
break;
}
return [Math.round(r * 255), Math.round(g * 255), Math.round(b * 255)];
}
}
}
